As cable deployment continues to bring broadband to
the masses, it is now becoming easier to safeguard both
personal data and computing resources. The buildout of
cable access networks is encouraging cable subscribers to
connect multiple computers to share broadband connections.
Cable subscribers can connect multiple PCs using
combinations of wired and wireless Local Area Network
(LAN) technologies, allowing each of these PCs to share
a single broadband connection. Both home users and
companies need to protect against hacker attacks and
remove the risk of unauthorized users gaining entry
into the LAN.
Residential subscribers need the ability to safeguard
their home computing resources and personal information,
and Small Office Home Office (SOHO) users and Small
to Medium Enterprise (SME) users must protect the value
of their business information. Telecommuters and people
working from home after hours need to similarly protect
the integrity of company information.
The United States Federal Government recommends that
Internet users add firewall protection — a system designed
to prevent unauthorized access to or from a private network
and also warns that PCs without firewalls can be accessed
through their Internet connection. Without firewall
protection, users can lose valuable personal or corporate
information and they risk permanent damage to PCs and
peripherals. Multi-PC households, small businesses
and corporate telecommuters can all benefit from
easy-to-use firewalls that allow them to enjoy the
advantages of broadband Internet connections —
while avoiding the risk of intrusion.
Always-on broadband connections present particular
risks that must be addressed. It is critical that each LAN
is protected by a firewall. Without a firewall, anyone
on the Internet could theoretically access computing
resources and private data. Everyone operating a LAN
connected to the Internet should deploy a firewall that
secures the LAN and protects it against outside attack.
All traffic entering or leaving the LAN pass through
the firewall, which examines each traffic flow and
blocks flows that do not meet the specified security
criteria. There are different configurations for firewalls,
and cable subscribers need to ensure that they provide
the appropriate security levels.
Protecting Local Area Networks
with Easy-To-Use Firewalls
Wireless Cable Modem Gateway Family White Paper

Firewalls
2
Wireless Cable Modem Gateway Family
Security
Firewalls — An Overview
The primary purpose of a firewall is to provide a single
point of entry where defense can be implemented.
Firewalls allow access to resources on the Internet, and
public and private networks from devices on the LAN,
while preventing unauthorized access from the Internet
to the LAN.
The firewall must provide a method for system
administrators to configure access control lists to establish
the rules for access according to local policies. All access
should be logged to ensure adequate information for
a detailed security audit. But deployment should not be
a daunting task because most home or small business
networks do not have Information Technology
(IT) departments.
When selecting cable access equipment, subscribers should
make sure that access equipment offers pre-configured
firewall capabilities that are sufficient to meet their
needs. Set-it-and-forget-it is the right approach for
residential subscribers, but many gamers and small
business subscribers will want the flexibility and power
to customize the firewall for added levels of security
and flexibility.
LAN Security with the otorola Wireless Cable odem
Gateway Family
The Motorola Wireless Cable Modem Gateway Family
allows cable subscribers to easily secure LAN resources.
The SBG1000 includes a robust, flexible and easy-to-use
integrated firewall. This Data Over Cable Service
Interface Specification (DOCSIS) cable modem provides
unprecedented functionality in a single platform.
Subscribers can deploy this space-saving solution to
connect to the cable network and safely allow both wired
and wireless clients to share the broadband connection.
The Motorola SBG1000 Wireless Cable Modem Gateway
even includes a print server so that residential users, SOHO
subscribers and small businesses can reduce printing
costs by connecting a single printer as a shared resource
for Windows, Macintosh and Linux computers. Cable
subscribers can easily deploy wireless LANs, wired LANs
or hybrid wireless/wired LANs to share resources such as
hard-drives, printers and peripherals while protecting each
computer from outside intrusion. Only Motorola offers
such a compact, secure and full-featured solution that
allows cable subscribers to quickly and easily establish
secure LANs connected to broadband cable networks.
It includes an 802.11b wireless access point that allows
PCs to connect securely to the Internet without the
need for expensive home cabling.

The Motorola SBG1000 includes a router with a five-port
10/100Base-T Ethernet switch that allows wired PCs to
access the Internet and shared resources on the network.
Future versions of the Motorola Wireless Cable Modem
Gateway Family will include all of the features of the
SBG1000, and will also provide an enterprise-grade Virtual
Private Network (VPN) endpoint so users can create secure,
tunneled connections to corporate resources. For more
information, please download the VPN whitepaper available
at http://www.motorola.com/broadband/whitepapers.html.
3
White Paper
SURFboard ®
HIGH SPEED CABLE MODEM
Wireless
ACCESS POINT
Firewall
ADVANCED SECURITY
Print Server
WINDOWS | MAC | LINUX
Router
5-PORT 10/100 SWITCH
Printer
Laptops
PDAs
Desktop Computers
Firewall
High Speed
Internet
Access via
Cable
• 10/100 Ethernet
• USB
• NAT/NAPT
• IPSec VPN
802.11b
Wireless Networking
Internet
Wireless Cable Modem Gateway
Wireless Cable odem Gateway:
Typical network configuration

Fea tures
4
Advance Firewall Features on the otorola Wireless Cable
odem Gateway Family
A Web-based graphical user interface simplifies
configuration so the authorized administrator can create
customized levels of security. The full-featured firewall
capabilities of the Motorola SBG1000 come pre-configured
so users do not have to be security experts to effectively
protect their LAN. However, for those LAN connections
that require increased security or flexibility, the Motorola
SBG1000 can be easily customized to secure LAN
resources to desired levels. It contains the following
robust firewall features:
Network Address Translation
The Motorola SBG1000 Wireless Cable Modem Gateway
is an ethernet router and it also supports Network Address
Translation (NAT) so private Internet Protocol (IP)
addresses within the LAN can be automatically mapped
to the public IP address on the Gateway.
The cable operator issues an IP address to the SBG1000,
which includes an integrated Dynamic Host Control
Protocol (DHCP) server that issues dynamic IP addresses to
computers on the LAN. Smaller LANs can add PCs simply,
or in larger LANs network administrators can create a NAT
table that does the global-to-local and local-to-global IP
address mapping. The use of NAT allows increased
security since different levels of security can be defined for
each IP address on the LAN. Private IP addresses within
the LAN are hidden from the public Internet because
external users only see the IP address of the SBG1000.
The Motorola SBG1000 Wireless Cable Modem Gateway’s
implementation of NAT supports multi-session IPSec
VPN passthrough as well as H.323 video conferencing
standards. Authorized users can take advantage of the
built-in IPSec support to establish secure VPN tunnels to
enterprise resources. Multiple tunnels can be established
at a single time and multiple users can each establish a
tunnel. For example, a husband and wife on separate PCs
can tunnel into their respective employers’ VPNs at the
same time using the SBG1000.
As broadband connections deliver increased bandwidth
to the home, video conferencing is becoming more widely
deployed. Intelligence within the Motorola SBG1000
Wireless Cable Modem Gateway will identify video
conferencing sessions using the H.323 standard and allow
them to be established through the firewall so authorized
users can establish secure video conferencing over the
Internet. Firewall features within the SBG1000 will create
an opening to allow the H.323 sessions to be securely
established so video conferencing tunnels can be
easily established.
Wireless Cable Modem Gateway Family

5
Stateful Packet Inspection
The Wireless Cable Modem Gateway Family maintains
stateful information for every TCP/IP session at both the
network and transport layers. It monitors all incoming and
outgoing packets, applying policies to each one while
screening for improper packets and intrusion attempts. The
Motorola SBG1000 inspects and analyzes the state of each
traffic flow and offers programmable filters so authorized
users have the flexibility to optionally enforce specific rules
for port usage, blocking specific domains or implementing
customized security levels. The firewall within the SBG1000
Wireless Cable Modem Gateway analyzes the relationships
of the newly created session so new protocols can be
added to the firewall configuration. This allows maximum
flexibility for supporting additional protocols and new
services while maintaining a secure LAN connected to
the Internet.
The Motorola SBG1000 Wireless Cable Modem
Gateway comes pre-configured but users can also
customize stateful packet inspection to address the
following parameters:
• IP address and port numbers
• Packet count and byte count
• Sequence and acknowledgement number
• Time stamps
• Payload modification history
• Dynamic association
• Other identifying information requested
by the LAN administrator
Intrusion Detection
Attempts to infiltrate the LAN are monitored and repelled
by the Motorola SBG1000, which includes extensive
intrusion detection features to prevent unauthorized access.
If the system suspects that an external party has attempted
to crash through the firewall, it will attempt to identify the
IP address of the potential culprit, prevent access, log the
event and automatically generate an e-mail to the LAN
administrator with information about the intrusion event.
This information can even be shared with the cable
operator to help identify hackers and filter them off
the cable access network.
White Paper
The firewall within the SBG1000 Wireless Cable Modem Gateway
analyzes the relationships of the newly created session
so new protocols can be added to the firewall confi uration.

6
Denial of Service Attack Prevention
With the expansion of the Internet we often hear about
Denial of Service (DoS) attacks harming major Web
sites. Yahoo, Amazon and even the White House
Web sites have all been shut down by DoS attacks as
publicly reported in 2000. A DoS attack is an incident in
which users or organizations are deprived of the services
they would normally expect to have operational. In the
worst cases, LAN services may be temporarily forced to
cease operations or an intruder may gain access onto the
LAN to corrupt processing resources to support other
malicious attacks.
Although DoS attacks are usually intentional and malicious,
they can happen accidentally and they can cause
major damage to LAN computers and require a great
deal of downtime. These attacks can range from buffer
overflow attacks, in which more traffic is sent to the
LAN than it can handle, to Smurf attacks, in which the
perpetrator sends an IP ping to computers on the LAN
specifying that they broadcast to a number of hosts so
there will be innumerable ping replies that flood the
LAN so it can no longer receive or distinguish valid
Internet traffic.
The Motorola Wireless Cable Modem Gateway Family
comes pre-configured with extensive features for
preventing DoS attacks. Stateful packet inspection
features monitor traffic flows in real time for both
LAN sessions and Internet access sessions. The
SBG1000 Wireless Cable Modem Gateway detects
misuse of LAN resources and flags anomalies that may,
in fact, be suspicious traffic. It can be customized so future
DoS attacks can be catalogued and added so the LAN
can be protected for the long term. It also offers blockers
for the following DoS attack types, as well as over
20 additional attack types.
• SYN flooding • BackOrifice
• TCP hijacking • Net Bus
• LAN attack • Smurf
• WinNuke • ICMP flooding
• Christmas tree • Trojan Horse
• SYN/FIN
D Z Hosting
A Demilitarized Zone (DMZ) is a neutral zone between
the private LAN and the public Internet. It opens up a
computer for clear, non-secure connections to the outside,
and the machine becomes vulnerable to security threats.
Wireless Cable Modem Gateway Family
The SBG1000 monitors all incomin and out oin packets,
applyin policies to each one while screenin for intrusion attempts.

Resources
7
Because there are no security prevention safeguards in
place, there are also no potential link impediments either.
The use of a DMZ may therefore be desirable for
specialized applications, such as File Transfer Protocol
(FTP) or Web servers. The DMZ Hosting feature allows
one local computer to be exposed to the Internet for use
of a special-purpose service such as Internet gaming and
video conferencing.
The Motorola SBG1000 Wireless Cable Modem Gateway
serves as a DMZ to enable firewall security of protected
LAN resources. It not only offers NAT but also has
Network Address Port Translation (NAPT) to identify
source ports. For example, the firewall supports multiple
popular gaming protocols, including Quake, Unreal
Tournament, Hexen and EverQuest. The LAN administrator
can easily add support for a new gaming protocol so
online games can be established through the firewall.
The private LAN can remain secure, yet these specialized
sessions can be easily established.
The Efficiency of Shared Resources with the Security
of a Firewall
The Motorola SBG1000 Wireless Cable Modem Gateway
allows secure LAN connections to shared broadband
networks. It is a complete, out-of-the-box firewall solution
that combines vigorous security with compact, full-featured
wired and wireless networking.
This “plug ‘n’ play” solution comes with default settings
including a firewall that addresses the needs of most users
but can be easily configured and customized to support
even more rigorous levels of security. The Motorola
SBG1000 Wireless Cable Modem Gateway offers the
mobility of a wireless LAN and the flexibility of multi-port
Ethernet — behind the security of a firewall. Motorola,
the leading supplier of cable modems worldwide, offers
“plug ‘n’ play” router connectivity so multi-PC homes,
SOHO and SME business customers can cost effectively
share high speed Internet connections.
The Motorola SBG1000 Wireless Cable Modem Gateway
is available from both cable operators and retail channels
and is backed by the quality and reliability offered by
Motorola. Additional networking accessories are also
available from Motorola, including:
• 802.11b client cards for wireless access to the
Motorola SBG1000
• 802.11b Universal Serial Bus (USB) adapters for
adding wireless capabilities to a desktop computer
• External wired diversity high-gain antenna for
extending the reach of the wireless LAN
White Paper

Wireless Cable Modem Gateway Family White Paper
Motorola, Inc.
Broadband Communications Sector
101 Tournament Drive
Horsham, PA 19044
1.800.523.6678
www.motorola.com/broadband
MOTOROLA and the Stylized M Logo are registered in the
US Patent & Trademark Office. All other product or service
names are the property of their respective owners.
© Motorola, Inc. 2002.
Specifications subject to change.
5419-402-5K
Residential users, SOHO customers and SME businesses
alike can deploy secure wireless and wired LANs
while managing the safety of computing resources
and the privacy of personal and business information.
Integrated firewall capabilities allow users to secure
LANs while gaining the peace of mind that comes
from knowing that their information and resources
are well protected.
