Motorola SURFboard SVG1202 User manual

b
User Guide
Motorola SURFboard®
SVG1202 Wireless Voice Gateway

B
©2011 Motorola Mobility, Inc. All rights reserved.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. All
other product or service names are the property of their respective owners. No part of this publication may be
reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or
adaptation) without written permission from Motorola Mobility, Inc.
Motorola Mobility reserves the right to revise this publication and to make changes in content from time to time without
obligation on the part of Motorola Mobility to provide notification of such revision or change. Motorola Mobility provides
this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Motorola Mobility may make improvements or changes in the
product(s) described in this manual at any time.

B
SVG1202 Wireless Voice Gateway • User Guide i
i
Safety and Regulatory Information
IMPORTANT SAFETY INSTRUCTIONS
Read This Before You Begin — When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons, including the following:
•Read all of the instructions listed here and/or in the user manual before you operate this device. Give particular attention to all safety
precautions. Retain the instructions for future reference.
•This device must be installed and used in strict accordance with manufacturer’s instructions, as described in the user documentation
that is included with the device.
•Comply with all warning and caution statements in the instructions. Observe all warning and caution symbols that are affixed to this
device.
•To prevent fire or shock hazard, do not expose this device to rain or moisture. The device must not be exposed to dripping or splashing.
Do not place objects filled with liquids, such as vases, on the device.
•This device was qualified under test conditions that included the use of the supplied cables between system components. To ensure
regulatory and safety compliance, use only the provided power and interface cables and install them properly.
•Different types of cord sets may be used for connections to the main POWER supply circuit. Use only a main line cord that complies
with all applicable device safety requirements of the country of use.
•Installation of this device must be in accordance with national wiring codes and conform to local regulations.
•Operate this device only from the type of power source indicated on the device’s marking label. If you are not sure of the type of power
supplied to your home, consult your dealer or local power company.
•Do not overload outlets or extension cords, as this can result in a risk of fire or electric shock. Overloaded AC outlets, extension cords,
frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard.
•Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular
attention to cords where they are attached to plugs and convenience receptacles, and examine the point where they exit from the
device.
•Place this device in a location that is close enough to an electrical outlet to accommodate the length of the power cord.
•Place the device to allow for easy access when disconnecting the power cord of the device from the AC wall outlet.
•Do not connect the plug into an extension cord, receptacle, or other outlet unless the plug can be fully inserted with no part of the
blades exposed.
•Place this device on a stable surface.
•It is recommended that the customer install an AC surge protector in the AC outlet to which this device is connected. This is to avoid
damaging the device by local lightning strikes and other electrical surges.
•Postpone installation until there is no risk of thunderstorm or lightning activity in the area.
•Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from
lightning. For added protection, unplug the device from the wall outlet and disconnect the cables to avoid damage to this device due to
lightning and power surges.
•Do not use this product near water: for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement, or near a
swimming pool.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
•Disconnect TNV circuit connector before removing the cover.
•Disconnect TNV circuit connector(s) before disconnecting power.
•Do not cover the device or block the airflow to the device with any other objects. Keep the device away from excessive heat and
humidity and keep the device free from vibration and dust.

B
SVG1202 Wireless Voice Gateway • User Guide ii
•Wipe the device with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray cleaners directly on the device or
use forced air to remove dust.
•For added protection, unplug the device from the wall outlet and disconnect the cables to avoid damage to this device due to lightning
and power surges.
CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger (e.g., 24 AWG) UL Listed or CSA Certified Telecommunication Line
Cord, or national equivalent.
•Upon completion of any service or repairs to this device, ask the service technician to perform safety checks to determine that the
device is in safe operating condition.
•Do not open the device. Do not perform any servicing other than that contained in the installation and troubleshooting instructions.
Refer all servicing to qualified service personnel.
•This device should not be used in an environment that exceeds 40º C.
SAVE THESE INSTRUCTIONS
Note to CATV System Installer — This reminder is provided to call the CATV system installer’s attention to Section 820.93 of the
National Electric Code, which provides guidelines for proper grounding and, in particular, specifies that the Coaxial cable shield shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
CARING FOR THE ENVIRONMENT BY RECYCLING
When you see this symbol on a Motorola product, do not dispose of the product with residential or commercial
waste.
Recycling your Motorola Equipment
Please do not dispose of this product with your residential or commercial waste. Some countries or regions,
such as the European Union, have set up systems to collect and recycle electrical and electronic waste items.
Contact your local authorities for information about practices established for your region. If collection systems
are not available, call Motorola Customer Service for assistance. Please visit www.motorola.com/recycle for
instructions on recycling.
IMPORTANT VoIP SERVICE INFORMATION
Please contact your Internet Service Provider (ISP) and/or your local municipality for additional information on
making emergency calls using VoIP service in your area.
IMPORTANT: When using this VoIP device, you CANNOT make any calls, including an emergency call, and
emergency location services (where supported) WILL NOT be available, under the following circumstances:
Your broadband ISP connection goes down, is lost, or otherwise fails.
You lose electrical power.
You have changed the physical address of your VoIP device, and you did not update or otherwise advise your
VoIP service provider of this change.
There are delays in making your location information available in or through the local automatic location
information database.
Note: Your service provider, not Motorola, is responsible for the provision of VoIP telephony services through this
equipment. Motorola shall not be liable for, and expressly disclaims, any direct or indirect liabilities, damages,
losses, claims, demands, actions, causes of action, risks, or harms arising from or related to the services provided
through this equipment.
FCC STATEMENTS
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.



SVG1202 Wireless Voice Gateway tUser Guide iii
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the device off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
xReorient or relocate the receiving antenna.
xIncrease the separation between the device and receiver.
xConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
xConsult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired
operation.
FCC CAUTION: Any changes or modifications not expressly approved by Motorola for compliance could void the user’s authority to
operate the equipment.
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with the FCC RF
exposure compliance requirements, the separation distance between the antenna and any person’s body (including hands, wrists, feet
and ankles) must be at least 20 cm (8 inches).
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at
the factory to match the intended destinations. The firmware setting is not accessible by the end user.
WIRELESS LAN INFORMATION
This device is a wireless network product that uses Direct Sequence Spread Spectrum (DSSS) radio technology. The device is designed to
be inter-operable with any other wireless DSSS product that complies with:
xThe IEEE 802.11 Standard on Wireless LANs (Revision B and Revision G), as defined and approved by the Institute of Electrical
Electronics Engineers
xThe Wireless Fidelity (Wi-Fi) certification as defined by the Wireless Ethernet Compatibility Alliance (WECA).
RESTRICTIONS ON THE USE OF WIRELESS DEVICES
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or responsible
representatives of the organization. For example, using wireless equipment in any environment where the risk of interference to other
devices or services is perceived or identified as harmful.
If you are uncertain of the applicable policy for the use of wireless equipment in a specific organization or environment, you are
encouraged to ask for authorization to use the device prior to turning on the equipment.
The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of the devices included
with this product, or the substitution or attachment of connecting cables and equipment other than specified by the manufacturer.
Correction of the interference caused by such unauthorized modification, substitution, or attachment is the responsibility of the user.
The manufacturer and its authorized resellers or distributors are not liable for any damage or violation of government regulations that
may arise from failing to comply with these guidelines.
Note: The use of the 5150-5250 MHz frequency band is restricted to Indoor Use Only.
SECURITY WARNING: This device allows you to create a wireless network. Wireless network connections may be accessible by
unauthorized users. For more information on how to protect your network, see the SVG1202 User Guide for instructions or visit the
Motorola website.
SECURITY WARNING :This device allows you to create a wireless network. Wireless network connections may be assessidle by
unauthorized users. For more information on how to protect your, see the SVG1202 User Guide for instructions or visit the Motorola
websits.

B
SVG1202 Wireless Voice Gateway • User Guide iv
Contents
Safety and Regulatory Information...................................................................................................................... i
Getting Started...................................................................................................................................................... 1
Inside the Box ......................................................................................................................................................... 1
Minimum System Requirements ............................................................................................................................ 1
Contact Information................................................................................................................................................. 1
Product Overview.................................................................................................................................................. 2
Front Panel .............................................................................................................................................................. 2
Rear Panel ............................................................................................................................................................... 3
MAC Label............................................................................................................................................................... 3
Connecting the Gateway...................................................................................................................................... 4
Installing the SVG1202 ............................................................................................................................................ 4
Testing the Connections ......................................................................................................................................... 5
Wall Mounting the Gateway.................................................................................................................................... 5
Wall Mounting Template ......................................................................................................................................... 7
Connecting to the Internet ................................................................................................................................... 8
Before You Begin .................................................................................................................................................... 8
Configuring TCP/IP for Windows 7 ......................................................................................................................... 8
Configuring TCP/IP for Windows Vista.................................................................................................................... 8
Configuring TCP/IP for Windows XP ....................................................................................................................... 9
Renewing the IP Address in Windows 7 or Vista ................................................................................................... 9
Renewing the IP Address in Windows XP ............................................................................................................ 10
Verifying the IP Address in Windows 7 or Vista.................................................................................................... 10
Verifying the IP Address in Windows XP .............................................................................................................. 10
Setting Up a Wi-Fi Network Connection ............................................................................................................... 10
Monitoring Your Gateway.................................................................................................................................. 11
Starting the Gateway Configuration Manager....................................................................................................... 11
SVG1202 Menu Options Bar ................................................................................................................................. 12
Changing the SVG1202 Default Password ..................................................................................................... 13
Restoring Factory Defaults ............................................................................................................................. 13
Getting Help .......................................................................................................................................................... 13
Exiting the SVG1202 Configuration Manager........................................................................................................ 13
Status Pages ........................................................................................................................................................ 14
Status Software Page............................................................................................................................................ 14
Status Connection Page ........................................................................................................................................ 14
Status Security Page ............................................................................................................................................. 15
Status Diagnostics Page........................................................................................................................................ 15
Ping Utility....................................................................................................................................................... 15
Traceroute Utility............................................................................................................................................. 16
Status Event Log Page .......................................................................................................................................... 17
Status Configuration Page..................................................................................................................................... 17

B
SVG1202 Wireless Voice Gateway • User Guide v
Basic Pages .......................................................................................................................................................... 18
Basic Setup Page .................................................................................................................................................. 18
Basic DHCP Page .................................................................................................................................................. 19
Basic DDNS Page.................................................................................................................................................. 20
Basic Backup Page ................................................................................................................................................ 21
Restoring Your SVG1202 Configuration.......................................................................................................... 21
Backing Up Your SVG1202 Configuration....................................................................................................... 21
Advanced Pages .................................................................................................................................................. 22
Advanced Options Page ........................................................................................................................................ 22
Advanced IP Filtering Page.................................................................................................................................... 24
Advanced MAC Filtering Page............................................................................................................................... 25
Setting a MAC Address Filter ......................................................................................................................... 25
Advanced Port Filtering Page ................................................................................................................................ 26
Advanced Port Forwarding Page........................................................................................................................... 27
Advanced Port Triggers Page ................................................................................................................................ 28
Advanced DMZ Host Page .................................................................................................................................... 29
Setting Up the DMZ Host ............................................................................................................................... 29
Firewall Pages...................................................................................................................................................... 30
Firewall Web Content Filter Page.......................................................................................................................... 30
Firewall Local Log Page......................................................................................................................................... 31
Firewall Remote Log Page .................................................................................................................................... 31
Parental Control Pages ....................................................................................................................................... 32
Parental Control User Setup Page......................................................................................................................... 32
Parental Control Basic Setup Page........................................................................................................................ 33
Parental Control Time of Day Filter Page .............................................................................................................. 34
Parental Control Local Log Page ........................................................................................................................... 34
Wireless Pages..................................................................................................................................................... 35
Wireless 802.11 Radio Page ................................................................................................................................. 35
Wireless 802.11 Primary Network Page ............................................................................................................... 36
Wireless 802.11 Advanced Page........................................................................................................................... 38
Wireless 802.11 Access Control Page .................................................................................................................. 39
Wireless 802.11 Wi-Fi Multimedia Page ............................................................................................................... 40
Wireless 802.11 Bridging Page ............................................................................................................................. 41
Setting Up Your Wireless LAN.............................................................................................................................. 41
Encrypting Wireless LAN Transmissions........................................................................................................ 42
Installing Wireless Clients ..................................................................................................................................... 42
Installing a Wireless Client for WPA ............................................................................................................... 43
Configuring a Wireless Client for WEP ........................................................................................................... 43
Configuring a Wireless Client with the Network Name (SSID) ...................................................................... 43
MTA Pages ........................................................................................................................................................... 44
MTA Status Page .................................................................................................................................................. 44
MTA DHCP Page ................................................................................................................................................... 44
MTA QoS Page...................................................................................................................................................... 45
Troubleshooting .................................................................................................................................................. 46

B
SVG1202 Wireless Voice Gateway • User Guide vi
Solutions................................................................................................................................................................ 46
Front Panel LEDs and Error Conditions ................................................................................................................. 47
Warranty Information ......................................................................................................................................... 48

B
SVG1202 Wireless Voice Gateway • User Guide 1
1
Getting Started
The Motorola SURFboard®SVG1202 Wireless Voice Gateway is designed for use in households with
one or more computers capable of wireless and/or wired connectivity.
This guide provides product overview and setup information for the SVG1202. It also provides
instructions for installing and configuring the gateway.
Inside the Box
Before installing the gateway, check that the following items are included in the box with the gateway.
If any items are missing, please contact Motorola Broadband Technical Support at 1-877-466-8646.
ITEM DESCRIPTION
Power Supply
Provides power to the gateway using an
electrical outlet
10/100Base-T Ethernet
Cable Standard Category 5, or higher, cable for
connecting to the network
Software License &
Regulatory Card
Contains software license, warranty, and
safety information for the gateway
SVG1202 Install Sheet
Provides basic information for connecting the
gateway
Minimum System Requirements
The SVG1202 is compatible with the following operating systems:
•Windows®7
•Windows Vista™, Service Pack 1 or later
•Windows XP, Service Pack 2 or later
•Mac®10.4 or later
•UNIX®
•Linux®
Contact Information
For additional product information, please visit the Motorola support website:
www.motorola.com/us/support

B
SVG1202 Wireless Voice Gateway • User Guide 2
2
Product Overview
Front Panel
LED BLINKING ON (SOLID)
1POWER Not applicable — icon does not flash Green: Power is properly connected
2 RECEIVE Scanning for a downstream
(receive) channel connection
Green: Non-bonded downstream channel
is connected
3 SEND Scanning for an upstream (send)
channel connection
Green: Non-bonded upstream channel is
connected
4 ONLINE Scanning for an Internet connection Green: Startup process completed
5 LINK Transmitting or receiving data on the
Ethernet port
Green: A device is connected to the
Ethernet (10Base-T) or Fast Ethernet
(100Base-T) port
6 TEL1
TEL2
Telephone is off-hook; dialing or call
is in progress
Green: Telephone is connected and
activated; on-hook
7 WIRELESS Green: Wi-Fi enabled with encrypted
wireless data activity; long/short
blinking indicates wireless pairing in
progress
Amber: Wi-Fi enabled with
unencrypted wireless data activity
Green: Wireless pairing successfully
established between the gateway and
another Wi-Fi enabled device on your
network — printer, PDA, laptop, etc.
Amber: Wireless pairing was successful;
LED turns solid green after five minutes
8 WPS button Configures a Wi-Fi Protected Setup (WPS) enabled device to connect to a wireless
network

B
SVG1202 Wireless Voice Gateway • User Guide 3
Rear Panel
PORT/CONNECTOR DESCRIPTION
1TEL 1
TEL 2
VoIP connection for a single or two-line telephone
VoIP connection for a single-line telephone
2 ETHERNET Ethernet port for an RJ-45 cable connection
3 RESET Resets the gateway; may take from 5 to 30 minutes to
scan and connect to the appropriate communications
channels
Press and hold the RESET switch for five seconds or
longer to restore the factory default settings
4 CABLE Coaxial cable connector
5 POWER +12VDC Power connector
MAC Label
The SVG1202 Media Access Control (MAC) label is located on the bottom of the gateway. It contains
specific ID information for the gateway.
To receive data service, you may have to provide the MAC address (HFC MAC ID)and serial number
located on the label to your Internet service provider.
To receive VoIP service, you may have to provide the MTA MAC ID to your VoIP provider.

B
SVG1202 Wireless Voice Gateway • User Guide 4
3
Connecting the Gateway
This product is for indoor use only. Do not route the Ethernet cable or
telephone cord outside of the building. Exposure of the cables to lightning
could create a safety hazard and damage the product.
Installing the SVG1202
Before installing the gateway, choose a location where the computer and gateway are preferably near
existing cable and electrical wall outlets. Also, make sure the computer is powered OFF.
1. Verify that the coaxial cable is connected to a cable outlet or splitter.
2. Connect the other end of the coaxial cable to the Cable connector on the gateway.
Hand-tighten the connectors to avoid damaging them.
3. Plug the power cord into the Power port on the gateway.
4. Plug the other end of the power cord into an electrical wall outlet.
This automatically powers ON the gateway. You do not need to unplug the gateway when it is not
in use.
Note: The first time you plug in the gateway, allow from 5 to 30 minutes for the gateway to scan
and connect to the appropriate communications channels.
5. Connect the Ethernet cable to the Ethernet port on the gateway.
6. Connect the other end of the Ethernet cable to the Ethernet port on the computer.
7. Plug the telephone cord of a single or two-line telephone into the telephone.
8. Plug the other end of the telephone cord into the Tel 1 port on the gateway.
Note: You must contact a VoIP service provider to activate the telephone service.

B
SVG1202 Wireless Voice Gateway • User Guide 5
9. For a second telephone, plug the telephone cord of a single-line telephone into the Tel 2 port on the
gateway.
10. Check that the LEDs on the front panel cycle through one by one in the following sequence:
SVG1202 LED Activity During Startup
LED DESCRIPTION
POWER Turns solid green when AC power is connected to the gateway.
Indicates power is connected properly.
RECEIVE Blinks while scanning for a downstream (receive) channel.
Turns solid green when the downstream channel is connected.
SEND Blinks while scanning for an upstream (send) channel.
Turns solid green when the upstream channel is connected.
ONLINE Blinks during gateway registration and configuration.
Turns solid green when the gateway is registered.
LINK Turns solid when an Ethernet connection is made between the
gateway and computer.
Testing the Connections
Perform the following connectivity test to verify that all the components were connected properly:
1. Power ON the computer and log in.
2. Check that the POWER, RECEIVE, SEND, and LINK front panel LEDs on the gateway are either
solid or blinking. See Front Panel for additional status information.
Note: The ONLINE LED should turn solid after the gateway is provisioned (activated).
Wall Mounting the Gateway
You will need a screwdriver and two M3 (#6) screws.
1. Print the Wall Mounting Template.
Note: You can mount the gateway horizontally or vertically.
2. Remove all cables (power, coaxial, and Ethernet) from the gateway.
3. Choose a location on the wall to mount the gateway.
Notes:
•Locate the unit according to local or national codes governing residential or business cable TV
and communications services.
•Follow all local standards for installing a network interface unit/network interface device
(NIU/NID).
Before drilling holes in the wall, check the structure for potential damage to
the water, gas, or electrical lines.

B
SVG1202 Wireless Voice Gateway • User Guide 6
•It is recommended that you mount the gateway to concrete, masonry, a wooden stud, or some
other solid wall material. Use anchor bolts if necessary (for example, if you mount the unit on
drywall).
4. Position and secure the wall mounting template on the wall to mark the holes.
5. Select an appropriate depth and diameter to drill the holes to a depth of at least 1½ inches (3.8 cm).
Note: There must be .10 inch (2.5 mm) between the wall and underside of the screw head.
6. Insert the #6 screws in the holes and then attach the gateway.
7. Verify the gateway is still securely attached to the wall.
8. Reconnect the coaxial, Ethernet, power cables.
9. Plug the power cord into an electrical outlet.
10. Arrange the cables to prevent any safety hazards.

B
SVG1202 Wireless Voice Gateway • User Guide 7
Wall Mounting Template

B
SVG1202 Wireless Voice Gateway • User Guide 8
4
Connecting to the Internet
Before You Begin
To prevent unauthorized user access, change the default username and password
before proceeding. See Changing the SVG1202 Default Password for more information.
For security reasons, DO NOT configure your SVG1202 Wireless Voice Gateway over a
wireless network connection.
After installing the gateway, you are now ready to connect your computer and other network devices to
the Internet. To do this, you may have to enable the network options on your computer to automatically
obtain an IP address and DNS server address. Follow the steps in this section for your operating
system.
Note: Your computer may already be configured to automatically connect to the Internet. If so, do not
perform any of the steps in this section.
Configuring TCP/IP for Windows 7
1. Click Start and then select Network, Properties.
2. Click Network and Internet to open the Network and Internet window.
3. Click Network and Sharing Center to open the Network and Sharing Center window.
4. Click Change adapter settings to open the Network Connections window.
5. Right-click the network connection for your network interface.
6. Select Properties to open the Local Area Connection Properties window.
7. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties to open the Internet Protocol
Properties window.
8. Select Obtain an IP address automatically and Obtain DNS server address automatically.
9. Click OK to save the TCP/IP settings and close the Internet Protocol Version 4 (TCP/IPv4)
Properties window.
10. Click Close to close the Local Area Connection Properties window.
11. Close the remaining windows and exit the Control Panel.
12. When you complete the TCP/IP configuration, verify the IP address. See Verifying the IP Address in
Windows 7 for more information.
Configuring TCP/IP for Windows Vista
1. Click Start and then right-click Network.
2. Click Network and Internet to open the Network and Internet window.
3. Click Network and Sharing Center to open the Network and Sharing Center window.
4. Click Manage Network Connections.
5. Right-click on the Local Area Connection you want to configure (if more than one is listed).
6. Click Properties to open the Connection Properties window.
7. Click Continue,if prompted for administrator permission.
8. Click Networking tab.

B
SVG1202 Wireless Voice Gateway • User Guide 9
9. Select Internet Protocol Version4 (TCP/IPv4) and then click Properties.
10. Verify that the Obtain an IP address automatically and Obtain DNS server address
automatically options are both selected.
11. Click Advanced. Use the following table to verify the Advanced TCP/IP Settings:
IP SETTINGS TAB DNS TAB WINS TAB
DHCP Enabled listed IP
address box
Default gateways box is
empty
Automatic metric is selected
DNS server addresses box is empty
Append primary and connection
specific DNS suffixes is selected
Append parent suffixes of the
primary DNS suffix is checked
Register this connection’s
addresses in DNS is checked
Append these DNS suffixes (in
order) is not selected
WINS addresses box is empty
Enable LMHOSTS lookup is checked
Default: Use NetBIOS setting from
the DHCP server is selected
12. Click OK.
13. Click Alternate Configuration and verify that Automatic private IP address is selected.
14. Click OK. A prompt to restart your computer will display.
Configuring TCP/IP for Windows XP
1. Click Start and then select Settings and Control Panel.
2. Click Network and Internet Connections or Network Connections (will vary according to
settings).
3. Click Local Area Connection.
4. Click Properties to open the Local Area Connection Properties window.
5. Verify Internet Protocol (TCP/IP) is selected, then click Properties.
6. Verify that Obtain an IP address automatically and Obtain DNS server address automatically are
both selected.
7. Click OK to save the TCP/IP settings.
8. Click OK to exit.
9. When you complete the TCP/IP configuration, verify the IP address. See Verifying the IP Address in
Windows XP for more information.
Renewing the IP Address in Windows 7 or Vista
1. Click Start and then click Start Search.
2. Type cmd and then right-click cmd.exe from the drop-down list.
3. Select Run as administrator.
4. Type ipconfig /renew and press Enter. A new IP address for your computer will display.
5. Type exit and press Enter to return to Windows.
If you still cannot access the Internet, contact your Internet Service Provider.

B
SVG1202 Wireless Voice Gateway • User Guide 10
Renewing the IP Address in Windows XP
1. Click Start and then click Run.
2. Type cmd and click OK to open a command prompt window.
3. Type ipconfig /renew and press Enter. A new IP address for your computer will display.
4. Type exit and press Enter to return to Windows.
If you still cannot access the Internet, contact your Internet Service Provider.
Verifying the IP Address in Windows 7 or Vista
1. Click Start and then click All Programs.
2. Click Accessories.
3. Click Run to open the Run window.
4. Type cmd and click OK to open a command prompt window.
5. Type ipconfig and press Enter to display the IP Configuration.
Verifying the IP Address in Windows XP
1. Click Start and then click Run.
2. Type cmd and click OK.
3. Type ipconfig and press Enter to display your IP configuration.
Setting Up a Wi-Fi Network Connection
Do the following to set up a Wi-Fi network connection using the WPS button on the SVG1202 Wireless
Voice Gateway:
1. Power ON the gateway.
2. Power ON the WPS-enabled devices you want to have access to the network, such as a computer,
router, or telephone.
The Wi-Fi network will automatically detect the WPS devices.
3. Press WPS button on the gateway.
4. If applicable, press WPS button on the other WPS devices.

B
SVG1202 Wireless Voice Gateway • User Guide 11
5
Monitoring Your Gateway
Use the SVG1202 Gateway Configuration Manager to change various default configuration settings on
the gateway.
Note: If the gateway was obtained as part of a service package, your service provider may require
alternative configuration methods. If you cannot access any of the HTML pages in the Configuration
Manager, please contact your service provider for assistance.
Starting the Gateway Configuration Manager
1. Open any web browser on a computer connected to the gateway.
2. In the Address bar, type http://192.168.0.1 for the Gateway Configuration Manager IP address, and
then press Enter. The gateway Login screen displays.
3. Type the default username and password. Both entries are case-sensitive.
Username: admin
Password: motorola
4. Click Login to open the SVG1202 Configuration Manager (CMGR).
The following SVG1202 Status page displays:
Note: If you cannot access the HTML pages in the Gateway Configuration Manager, please contact
your service provider for assistance.

B
SVG1202 Wireless Voice Gateway • User Guide 12
SVG1202 Menu Options Bar
The SVG1202 Menu Options bar is displayed at the top of the SVG1202 Configuration Manager
window.
Configuration Manager Menu Options Bar
MENU OPTIONS FUNCTION
Status Provides information about the gateway hardware and software, MAC
address, voice gateway IP address, serial number, and related
information.
Additional pages provide diagnostic tools and allow you to change your
gateway user name and password.
Basic Views and configures the gateway IP-
related configuration data, includin
Network Configuration, WAN Connection Type, DHCP, and DDNS
Advanced Configures and monitors how the gateway routes IP traffic
Firewall Configures and monitors the gateway firewall
Parental Control Configures and monitors the gateway Parental Control features
Wireless Configures and monitors the gateway wireless networking features
MTA Monitors the telephone features of the gateway
Logout
Closes the SVG1202 Configuration Manager
