Motorola MSAT-G2 User manual

Introduction .................................................................... 1
T
ransceiver Unit (TU) ........................................................... 3
Power Port.................................................................. 4
Ethernet and Serial Ports ...................................................... 4
RJ 45 Ethernet Port........................................................... 4
Serial Port................................................................... 5
Antenna Port................................................................. 5
Handset Port................................................................. 6
External Speaker .............................................................. 6
System Power Requirements ..................................................... 7
Standard Cable Connections ..................................................... 9
Horn Alert (Blue Wire - Optional Installation) .................................... 9
Ignition Sense (Orange
Wire) .................................................... 9
Basic Installation Procedure...................................................... 10
Fixed-site Installation............................................................ 10
Choosing a Location .......................................................... 10
Lightning Arrestors . .......................................................... 11
Installing the
TU – Fixed-site and Vehicle .......................................... 11
Installation – General ......................................................... 11
Mounting Bracket Information ................................................ 11
The Antenna Unit (AU) .......................................................... 14
Antenna Cable Lengths and
Types ............................................. 14
Installing the Antenna ......................................................... 14
SpaceCom SPAC-AS-MSV220 Land-Mobile / Fixed-site Antenna .................... 15
Magnetic (T
emporary) Mounting option ........................................ 16
Permanent (Mast) Mounting ................................................... 17
SPAC-AS-MSV320 Maritime Antenna ............................................. 18
Pole Mount Kit ............................................................... 18
Pole Mount Kit Component Description ....................................... 19
SPAC-AS-MSV320 Antenna Installation ......................................... 21
Vibration ..................................................................... 21
Installing the Handset ........................................................... 23
Commissioning Procedure....................................................... 23
T
roubleshooting the Installation .................................................. 26
Steps to Basic
Troubleshooting ................................................ 26
T
roubleshooting Some Typically Encountered Problems: ......................... 27
MSAT-G2 Technical Specifications ................................................. 28
MSAT-G2 Installation Guide

Introduction
The purpose of this guide is to provide assistance to personnel installing the new MSAT-G2
mobile satellite radio equipment. The guide starts off by providing installation-specific
information on each component of the radio. Installation tips are then offered for fixed-site
and vehicular scenarios. A section on commissioning instructions follows. The guide concludes
with a troubleshooting section.
Installation Warning
This product is to be installed by Authorized Service Personnel. Damages resulting in the
failure to conform to the instructions found herein, as well as standard installation practices,
will be the responsibility of the installer.
MSAT-G2 Mobile Satellite Radio
The MSAT-G2 mobile satellite radio is comprised of three core component parts: the
transceiver unit (the small black box), the antenna system (white domes) and the handset.
Figure 1 – MSAT-G2 Mobile Satellite Radio Components
MSAT-G2 Installation Guide 1

An optional external speaker may be connected to the TU for remote monitoring. Serial and
ethernet ports are provided for external interfacing, debugging, software upgrading and future
expansion capabilities.
Figure 2 – System Overview
MSAT-G2 Installation Guide 2
Antenna Unit External Speaker
External Interface Handset
12 power supply
PC
Debug/Upgrade/
Future Expansion
Transceiver Unit
Antenna Cable
Serial
Ethernet Power Cable
External Speaker
Handset Cable

Transceiver Unit (TU)
The TU provides the interface for the handset and antenna unit (AU) and manages the
communications over the MSV network. It also distributes power to the handset and
Antenna Unit (AU).
MSAT-G2 Installation Guide 3
Figure 3 - Transceiver Unit w/o Mounting Bracket
FRONT
BACK

The TU is equipped with the following ports:
Power Port
The power port is the connection from the power supply (vehicle battery or some other 12
VDC power source) to the TU. The power cable has a +12V power line, a +12V ignition
sense line, a horn alert line and a ground line.
Figure 4 – Power Port Cable Colour Reference
Ethernet and Serial Ports
RJ 45 Ethernet Port
The RJ 45 Ethernet port is available for upgrade and future expansion of functionality.
The port supplies standard Ethernet line levels and supports all defined control line signaling.
The pinout of the port supports a direct straight-through connection to a PC with a standard
Ethernet cable. The PC shall be supplied with a dynamic local IP address using a standard
DHCP exchange.
Figure 5 – Ethernet Port Pinout
0.25 A, 1-1/4 BY 1/4 FUSE
HORN ALERT
AWG 20, STRANDED, BLUE
IGNITION SENSE
AWG 20, STRANDED, ORANGE VIEW A
GND
AWG 16, STRANDED, BLACK
5 A, 1 1/4 BY 1/4 FUSE
12 V
AWG 16, STRANDED, RED
MSAT-G2 Installation Guide 4
Line Type Colour
+12VDC Red
Ground Black
Ignition Sense Orange
Horn Alert Blue
Pin
1 RX+
2 RX-
3 TX+
6 TX-

Serial Port
The serial port is a female DB-9F RS 232 and can be used for NMEA output (GPS) and
crossbanding.
Figure 6 – Serial Port Pinout
Antenna Port
The antenna port is a 50 Ohm female TNC. This line carries RF, signaling, and DC power for
the antenna. Note: Grounding the center conductor while power is applied to the transceiver
can cause the transceiver's fuse and/or a fuse in the vehicle to blow. No modifications should
be made to the RF cable under any circumstance
Figure 7 – Antenna Port Detail
MSAT-G2 Installation Guide 5
Pin Data (currently not supported) GPS Crossband
1 CD (Carrier Detect) COR (Carrier Operated Relay)
2 RD (Receive Data) RD (Receive Data)
3 TD (Transmit Data)
4 DTR (Data Terminal Ready)
5 GND (Signal Ground) GND (Signal Ground) GND (Signal Ground)
6 DSR (Data Set Ready)
7 RTS( Request To Send) PTT (Push To Talk)
8 CTS (Clear To Send) CTT (Clear To Transmit)
9 RI (Ring Indicator)

Handset Port
The RJ45 handset port is used to connect the handset to the TU. The connector type is
a modular 8 position and 8 conductor RJ45. The pinout is as follows
Figure 8: Handset Connector Pin-out
External Speaker
A 3.5 mm mono connection is provided for a 4W 8Ohm speaker.
MSAT-G2 Installation Guide 6
Pin Number Signal Name
1 Audio TX + Microphone
2 Audio TX – Microphone
3 Data TX – TU Send
4 Data RX – TU Receive
5 + 12 VDC
6 Ground
7 Audio RX + Speaker
8 Audio RX - Speaker

Figure 9 – Transceiver Unit Front & Back
System Power Requirements
There is only one power connection for the entire radio. This must be connected to a
12 VDC power supply.
Power requirements and consumption are as follows:
Figure 10 – System Power Requirements
MSAT-G2 Installation Guide 7
Voltage Input Minimum 11.5 V DC
Voltage Input Maximum 15.6 V DC
Total Current for AU,TU & Handset (Max.) 3A
Required Fuse 5A

Power Cable
Figure 11 – Power Cable Details
MSAT-G2 Installation Guide 8
0.25 A, 1-1/4 BY 1/4 FUSE
10 + / - 0 . 5 INCHES
20 FEET + / - 4 INCHES
6 + / - 0 . 5 INCHES
VIEW A
HORN ALERT
AWG 20, STRANDED, BLUE
IGNITION SENSE
AWG 20, STRANDED, ORANGE VIEW A
GND
AWG 16, STRANDED, BLACK
5 A, 1 1/4 BY 1/4 FUSE
12 V
AWG 16, STRANDED, RED
IN LINE FUSE HOLDER
HOUSING : MOLEX PART NO. 39-01-2045
TERMINAL:
MOLEX PART NO. 44476-3111 (FOR AWG IG WIRE)
AND 44476-1111 (FOR 20 WIRE)

Standard Cable Connections
In addition to the DC power connection, optional horn alert and ignition sense connections
may be made. These are all done using the four wire power cable. In the case of a vehicle
installation, the power source is typically the vehicle battery. Cables should be routed
appropriately and cable ties and clamps should be used as required to ensure that vibration
and/or rubbing of the cables does not occur.
Horn Alert (Blue Wire - Optional Installation)
To install the Horn Alert, route and splice the blue wire (Horn Alert) as shown below.
Note that the Horn Alert option is not available in Dispatch Radio mode.
Figure 12 – Horn Alert Wiring Diagram
Ignition Sense (Orange Wire)
Route and connect the orange wire (Ignition Sense) to a switched 12 VDC source, such
as ignition switch or fuse block. Extended use of ignition sense in accessory position
(ACC) by the end user may lead to a discharged car battery.
NOTE: Ensure that the connection is a switched source-OFF when ignition is off or in
start and ON only when ignition switch is in ACCESSORIES or RUN position.
MSAT-G2 Installation Guide 9
To TU Horn Alert
(GND) (BLUE Wire)
+12 VDC
To auto horn
12 VDC or ground as
required by vehicle
Note: 0.25
amp fuse
required

Basic Installation Procedure
While the installation of the MSAT-G2 mobile satellite radio is straightforward, it is essential
that the installation be done correctly.
The basic installation procedure is as follows:
1. Decide where you are going to install the antenna, TU and handset.
2. Ensure that the TU is located inside the vehicle or a building and that it is attached
to something structurally sound. Loose mounts that vibrate will degrade performance.
3. Determine the cabling required for the installation of each component.
4. Perform the installation of the antenna, TU and handset.
5. Connect the antenna and the handset to the TU
6. Connect the power to the TU.
7. Power up and commission the radio
Fixed-site Installation
Choosing a Location
It is important to choose a location for the antenna that will have a clear line-of-site to
the satellite(s). Preferably, avoid all obstructions within three (3) meters of the antenna.
Installation during windy conditions may be dangerous. The owner and installer assume all
responsibility to ensure that the equipment is properly installed with adequate structural
stability of mounting surface to withstand all loads (wind, weight, ice, etc.) and is properly
sealed to avoid leaks.
DO NOT ATTEMPT TO INSTALL OR DISMANTLE THE EQUIPMENT NEAR
ANY TYPE OF POWER LINE.
Safety Rules:
1) Select your installation site with safety as well as performance in mind.
2) Plan your installation carefully before beginning. Perform as many tasks as possible
while on the ground.
3) If any part of the equipment (i.e. antenna assembly) comes into contact with a power
line, do not try to remove it yourself. Contact your local power company.
4) When installing an antenna assembly, do not use a metal ladder.
5) If the antenna assembly starts to drop, get away from it and let it fall.
6) Verify that the antenna is properly grounded.
MSAT-G2 Installation Guide 10

Lightning Arrestors
The applicable electrical code(s) may require that lightning arrestors capable of supporting L-
band transmissions be installed on all cabling between the fixed-site antenna and the structure
which the equipment is housed in. It is also suggested that any structure containing the radio
be equipped with a lightning rod connected to the ground. The professional doing the fixed-
site installation is responsible for determining all such requirements with the customer and
installing the equipment such that it complies with all applicable standards.
Installing the TU – Fixed-site and Vehicle
Installation – General
1) For ease of service, route the radio cables and power cables together.
2) Always disconnect the negative side of the vehicle battery prior to any electrical work.
3) Whenever routing cable through holes drilled in metal or through bulkheads, use
grommets and RTV sealant to weatherproof all holes drilled on the outside of the
vehicle.
4) Use cable ties every 30 – 45 cm (12-18”).
5) The TU can be mounted in either the horizontal or vertical position.
6) The main power line should be connected directly to the vehicle battery (or 12 VDC
power supply). If you must connect it to another circuit, ensure sufficient amperage
is available. In the case of a fixed-site installation, tie the Battery and Ignition Sense
wires together on the 12 VDC power source.
7) The ground line should be connected directly to the vehicle’s battery ground.
8) Install the TU in a protected but ventilated area (inside building or vehicle). Allow
at least a one (1) inch space around all surfaces, except for the surface attached to
the mounting bracket to provide adequate cooling. Ensure that the location is
accessible for servicing.
9) The TU is not waterproof.
10) Always provision the wiring into the TU with a drip loop.
11) With the exception of the TU to Antenna cable, do not route the cables outside
the vehicle.
Mounting Bracket Information
NOTE: Use care when drilling through the body of the vehicle to avoid puncturing critical
items.
The bracket is connected to the TU with two (2) provided screws. There is a 5mm gap
between the TU and the bracket.
MSAT-G2 Installation Guide 11

Instructions for the installer:
1. The mounting bracket should be used for mounting the TU.
2. Mount the mounting bracket onto a flat surface using at least four (4) screws (not
supplied). Use screws with diameter between 3 to 4.5 mm. Vibration resistant screws
or lock washers should be used.
3. Choose any suitable holes and slots on the base of the mounting bracket for mounting
the screws. If space is available on the mounting surface, the screws should be spaced
as far as possible towards the corners of the mounting bracket to provide good stability.
4. Place the TU on the mounting bracket so that the holes on the side flanges of the
mounting bracket are aligned with the threaded inserts on the TU. Use only the two
screws and spring washers provided to secure the TU to the mounting bracket. Not
using the supplied bracket screws could result in damage to the TU (especially if
screws are too long).
Figure 13 - Transceiver Unit Mounting Bracket Dimensions
MSAT-G2 Installation Guide 12
MOUNTING HOLE DIMENSIONS
BOUNTING BRACKET, MSV
Dimensions are in mm

MSAT-G2 Installation Guide 13
HANDSET SERIAL PORT ETHERNET
SERIAL PORT ETHERNETHANDSET
176.83
5
33.6
DIMENSIONS WITH MOUNTING BRACKET
MSV TRANSCEIVER UNIT
Figure 14 - Transceiver Unit w/ Mounting Bracket
Dimensions are in mm

The Antenna Unit (AU)
The antenna unit is composed of the antenna element array, necessary high power and low
noise amplifier systems and a tracking system.
Two AU versions exist: a 2-axis unit intended for land-mobile and fixed-site installations and
a 3-axis unit for the maritime environment.
Connection to both AUs is made by a TNC connector. The single co-axial cable carries RX,
TX, power and tracking information.
Antenna Cable Lengths and Types
The radio has been type approved for use with the following cable lengths and types:
Figure 15 – Antenna Cable Lengths and Types
Installing the Antenna
WARNING: Avoid exposure to microwave radiation. Keep a safe distance of minimum
one 1 meter (39 inches) to the side and above the antenna. Always power the MSAT-G2
down prior to disconnecting or connecting the antenna.
The antenna port is a 50 Ohm female TNC. This line carries RF, signaling, and DC power for
the antenna. Note: Grounding the center conductor while power is applied to the transceiver
can cause the transceiver's fuse and/or a fuse in the vehicle to blow. No modifications should
be made to the RF cable under any circumstance.
Keep a clear line-of-sight to the satellite. Preferably, avoid all obstructions within three (3)
meters of the antenna. Obstructions less than 15 cm (6 inches) in diameter can be ignored
beyond this distance.
If the antenna is being mounted on a vehicle it is important to ensure there is a clear line-of-
site to the satellite(s) in all directions. After the radio is commissioned and operational it is
recommended that the signal strength be checked while the vehicle is slowly driven in a 360º
circle. The signal strength should not vary significantly or be degraded in any particular direction.
MSAT-G2 Installation Guide 14
Cable Length Cable Type
Antenna to Radio
20 ft RG223/U
60 ft LMR240 (Equiv.)
150 ft LMR600 (Equiv.)

Do not locate the antenna close to interfering signal sources or receivers. It is recommended
that no other antennas be located within three (3) meters of the MSAT-G2 antenna. If there
is other equipment installed near the MSAT-G2 satellite radio it is recommended to operate
all equipment simultaneously and verify there is no co-interference.
SpaceCom SPAC-AS-MSV220 Land-Mobile / Fixed-site Antenna
Magnetic (Temporary) Mounting option
For temporary use – or where drilling of holes is to be avoided – a Magnetic Mount
Installation Kit is offered. SpaceCom part no: SPAC-AC-1016.
Three (3) magnetic mounts each with an adhesive force of at least 420 N (Newton)
are required to secure the MSV220 antenna.
Figure 16 – SPAC-AS-MSV220 2-axis Antenna W/ Magnetic Mounts
MSAT-G2 Installation Guide 15

Magnetic Mount Installation
The Magnet Mount consists of (3) three individual high intensity magnets with rubber
coating. Each magnet has a stainless steel M5 center bolt.
First attach the magnets to the antenna. There are (3) three “legs” on the antenna where
the magnets are placed. Note the position of the two nylon (plastic) washers just below
and above each “leg”, the stainless steel washer above the upper nylon washer and the M5
protective nut on top.
Now place the antenna with magnets on the roof of the car.
When installing the antenna cable, it’s important to protect against moisture – using self
amalgating tape, or similar, wrapped around the coaxial connector. Also be careful with the
cable run from the antenna and secure it at short intervals. An unsupported length of cable
will vibrate when driving and could negatively affect the connection over time.
Dismounting:
Grab the antenna near one of the magnets and lift. When one magnet is loose, the other
two are easy to “break off”. In some situations the force of the magnet may be too great
and it will be necessary to unscrew the antenna first and remove the magnets separately.
Figure 17 – SPAC-AS-MSV220 2-axis Antenna W/ Magnetic Mounts
MSAT-G2 Installation Guide 16
Hex domed nut
M5 washer
Rubber washer
Rubber washer
High “intensity”magnet

Permanent (Mast) Mounting
For permanent mounting of the SPAC-AS-MSV220, a special Pole Mount Installation Kit is
available. SpaceCom part no.: SPAC-AC-1017. Designed for easy installation, it ensures proper
drainage of the antenna, galvanic insulation and is able to withstand the rigid mechanical stress.
Figure 18 – SPAC-AS-MSV220 2-axis Antenna W/ Optional Pole Mount
SPAC-AS-MSV220 Antenna Pole Mount Installation
The Pole Mount is made of stainless steel. The antenna is placed on the triangular top and
the pole fixed using the U-clamps. (To a short mast or similar)
First mount the antenna on top of the pole with (3) three pcs. M6x50 mm bolts. The (6) six
pcs. nylon washers are used just below and above the antenna “legs”
The 44 mm U-clamps are placed around the pole mount, leaving the 50 mm U-clamps for
the mast. Small tolerances in the mast diameter can be compensated by simply bending the
U-clamps slightly.
When installing the antenna cable, it is important to protect against moisture – using self
amalgating tape, or similar, wrapped around the coaxial connector. Also be careful with the
cable run from the antenna and secure it at short intervals. An unsupported length of cable
will vibrate in strong winds and could negatively affect the connection over time.
MSAT-G2 Installation Guide 17

Figure 19 – SPAC-AS-MSV220 2-axis Antenna W/ Optional Pole Mount
SPAC-AS-MSV320 Maritime Antenna
When installing a SpaceCom Maritime Antenna on a vessel the following important guidelines
must be followed in order to ensure that the antenna will operate trouble-free throughout its
service life. The warranty will be void if the guidelines are not followed.
Pole Mount Kit
The installation is based on a pole mounting kit AC-1005 and is shown in FIG. 21.
The kit consist of the following components: (subject to change)
1pcs. Mounting Pole, Part No. SPAC-M00424
1pcs. Rubber Gasket, Part No. SPAC-M00425
6pcs. Plastic Bushings, Part No. SPAC-M00227
6pcs. Washer, Part No. SPAC-M90-10062
6pcs. Screw, Part No. SPAC-M90-10102
MSAT-G2 Installation Guide 18
U-clamp ø44 mm
M8 self-locking nut
M8 washer
M6X50 screw
M6 washer
Rubber washer
Rubber washer
M6 self-locking nut
Clamp bracket
U-clamp ø50mm
