Motorola Avigilon H4SL-MT-NPTA User manual

InstallationGuide
Avigilon H4 SL DomeCamera Models with Pendant Mount
Adapters:
H4SL-D/H4SL-DO plus H4SL-MT-NPTA and CM-MT-WALL

Important Safety Information
This manual provides installation and operation information and precautions for the use of this device.
Incorrect installation could cause an unexpected fault. Before installing this equipment read this manual
carefully. Please provide this manual to the owner of the equipment for future reference.
This Warning symbol indicates the presence of dangerous voltage within and outside the product
enclosure that may result in a risk of electric shock, serious injury or death to persons if proper
precautions are not followed.
This Caution symbol alerts the user to the presence of hazards that may cause minor or moderate
injury to persons, damage to property or damage to the product itself if proper precautions are not
followed.
WARNING — Failure to observe the following instructions may result in severe injury or death.
lInstallation must be performed by qualified personnel only, and must conform to all local codes.
lFor EN 50121-4 compliance, this product is intended to be supplied by a EN 50121-4 power source.
lThe H4SL-D product is intended to be supplied by Power over Ethernet (PoE) that is a “Limited Power
Source” or “LPS” rated 48 VDC, 4W min.
lThe H4SL-DO product is intended to be supplied by Power over Ethernet (PoE) that is a “Limited
Power Source” or “LPS” rated 48 VDC, 7W min.
lAny external power supply connected to this product may only be connected to another Avigilon
product of the same model series. External power connections must be properly insulated.
lDo not connect directly to mains power for any reason.
CAUTION — Failure to observe the following instructions may result in injury to persons or damage
to the device.
lDo not expose the camera directly to high levels of x-ray, laser, or UV radiation. Direct exposure may
cause permanent damage to the image sensor.
lDo not install near any heat sources such as radiators, heat registers, stoves, or other sources of heat.
lDo not subject the device cables to excessive stress, heavy loads or pinching.
lDo not open or disassemble the device. There are no user serviceable parts.
lRefer all device servicing to qualified personnel. Servicing may be required when the device has
been damaged (such as from a liquid spill or fallen objects), has been exposed to rain or moisture,
does not operate normally, or has been dropped.
lDo not use strong or abrasive detergents when cleaning the device body.
lUse only accessories recommended by Avigilon.
lThis product should be installed in restricted access locations.
ii

Regulatory Notices
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and the receiver.
lConnect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
lConsult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by Avigilon Corporation or
parties authorized by Avigilon Corporation could void the user’s authority to operate this equipment.
Disposal and Recycling Information
When this product has reached the end of its useful life, please dispose of it according to your local
environmental laws and guidelines.
Risk of fire, explosion, and burns. Do not disassemble, crush, heat above 100 °C (212 °F), or incinerate.
European Union:
This symbol means that according to local laws and regulations your product should be disposed of
separately from household waste. When this product reaches its end of life, take it to a collection point
designated by local authorities. Some collection points accept products for free. The separate collection
and recycling of your product at the time of disposal will help conserve natural resources and ensure that it
is recycled in a manner that protects human health and the environment.
iii

Legal Notices
©2016 - 2020,Avigilon Corporation. All rights reserved. AVIGILON, the AVIGILON logo,
AVIGILONCONTROL CENTER, and ACC are trademarks of Avigilon Corporation. ONVIFis a trademark of
Onvif, Inc. Other names or logos mentioned herein may be the trademarks of their respective owners. The
absence of the symbols ™ and ® in proximity to each trademark in this document or at all is not a disclaimer of
ownership of the related trademark. Avigilon Corporation protects its innovations with patents issued in the
United States of America and other jurisdictions worldwide (see avigilon.com/patents). Unless stated
explicitly and in writing, no license is granted with respect to any copyright, industrial design, trademark,
patent or other intellectual property rights of Avigilon Corporation or its licensors.
Disclaimer
This document has been compiled and published using product descriptions and specifications available at
the time of publication. The contents of this document and the specifications of the products discussed
herein are subject to change without notice. Avigilon Corporation reserves the right to make any such
changes without notice. Neither Avigilon Corporation nor any of its affiliated companies: (1) guarantees the
completeness or accuracy of the information contained in this document; or (2) is responsible for your use
of, or reliance on, the information. Avigilon Corporation shall not be responsible for any losses or damages
(including consequential damages) caused by reliance on the information presented herein.
Avigilon Corporation
avigilon.com
PDF-H4SL-MT-NPTAWALL-A
Revision: 3 - EN
20200102
iv

Table of Contents
Overview 1
Cover View 1
NPT Adapter View 2
Pendant Wall Mount Bracket View 3
Pendant Wall Mount View 4
Camera Base Bottom View 5
Camera Base Front View 6
Camera Base Rear View 7
Installation 8
Required Tools and Materials 8
Package Content 8
Installation Steps 9
Removing the Dome Cover 9
Inserting Cables through the Sealing Grommet 9
Mounting the Dome Camera to a Pipe 10
(Optional) Mounting the Dome Camera to the Pendant Wall Mount 11
Installing the Camera Base to the Mounting Adapter 14
(Optional) Using the USB Wi-Fi Adapter 16
Assigning an IP Address 16
Accessing the Live VideoStream 17
Aiming the Dome Camera 17
(Optional) Configuring microSD Card Storage 19
Installing the Dome Cover 20
Zooming and Focusing the DomeCamera 20
Configuring the Camera 20
For More Information 21
Connection Status LED Indicator 22
Removing the Dome Camera from the Mounting Adapter 23
Resetting to Factory Default Settings 24
Setting the IP Address Using the ARP/Ping Method 25
Specifications 26
Limited Warranty and Technical Support 29
v

Overview
Cover View
1. NPT adapter
Used to mount the dome camera to NPT pipes.
2. Pendant wall mount (optional)
Used with the NPT adapter to mount the dome camera to a wall in pendant installations.
3. Tamper resistant screws
Star-shaped captive screws to fix the dome cover to the base.
4. Dome cover
Vandal resistant dome cover.
Only available on H4SL-DO models.
Overview 1

NPT Adapter View
1. Camera housing clips
Snaps to hold camera module during installation.
2. Lanyard
Connects to the lanyard anchor on the camera base.
3. 1-1/2” NPT thread mount
Standard male 1-1/2” NPT thread mount for mounting the dome camera to a pole or bracket.
NPT Adapter View 2

Pendant Wall Mount Bracket View
1. Bracket mounting holes
Points for mounting the pendant wall mount bracket to a mounting surface.
2. Mounting tabs
Tabs for placing the pendant wall mount onto the bracket.
3. Mounting points
Points for securing the pendant wall mount to the mounting bracket.
Pendant Wall Mount Bracket View 3

Pendant Wall Mount View
1. 1-1/2” NPS thread mount
Female NPS thread mount for pendant camera installations.
2. Pendant wall mount screws
Screws for securing the pendant wall mount to the mounting bracket.
3. NPT pipe entry hole
A 3/4” NPT threaded hole for NPT pipe conduits.
Pendant Wall Mount View 4

Camera Base Bottom View
1. Cable entry hole
An entry hole for the cables required for camera operation.
2. Lanyard anchor
The safety lanyard attaches to the anchor to prevent the camera from falling during installation.
3. Vent
Vent to allow moisture vapor to escape the sealed housing and equalize pressure.
Only available on H4SL-DO models.
Camera Base Bottom View 5

Camera Base Front View
1. IR illuminator
Provides scene illumination in the IR spectrum.
Only available on -IR models.
2. Ethernet port
Accepts power and Ethernet connection to the network.
The camera can only be powered by Power over Ethernet (PoE). Server communication and image
data transmission also occur over this connection.
3. Connection status LED indicator
Provides information about device operation. For more information, see Connection Status LED
Indicator on page22.
4. Link LED indicator
Indicates if there is an active connection in the Ethernet port.
5. microSD card slot
Accepts a microSD card for onboard storage. For more information, see (Optional) Configuring
microSD Card Storage on page19.
Camera Base Front View 6

Camera Base Rear View
Displayed IR illuminators only available on -IR models.
1. Azimuth control
Provides control of the image angle.
2. Tilt lock thumb screw
Provides a locking mechanism for the image tilt adjustment.
3. Pan lock latch
Provides a locking mechanism for the image pan adjustment.
4. Micro USB port
Accepts a micro USB to USB adapter. Only required when using the Avigilon USB Wi-Fi Adapter.
5. Serial number tag
Device information, product serial number and part number label.
Camera Base Rear View 7

Installation
Required Tools and Materials
The following tools are required to complete the installation but are not included in the package:
lNo. 2 Phillips screwdriver — for attaching the pendant wall mount bracket to the mounting surface.
Package Content
Ensure the dome camera package contains the following:
lAvigilon H4 SL Dome Camera (Indoor model — H4SL-D)
lT20 Pin-In star-shaped driver
oProvided accessories that are not required for this installation:
lMounting template sticker
l4 screws and anchors for solid walls
lSurface mount adapter
lSide conduit cover
lAvigilon H4 SL Dome Camera (Outdoor model — H4SL-DO)
oRJ-45 grommet piercing cap
oT20 Pin-In star-shaped driver
oProvided accessories that are not required for this installation:
lMounting template sticker
l4 screws and anchors for solid walls
lSurface mount adapter
lSide conduit cover (2 sizes)
lSide conduit plate (2 sizes)
Ensure the NPT adapter (H4SL-MT-NPTA) package contains the following:
lNPT adapter for the H4 SL Dome Camera
lT20 Pin-In star-shaped driver
lLock nut
lRJ-45 grommet piercing cap
lTeflon sealing tape
If you are also installing the pendant wall mount (CM-MT-WALL1), ensure the package contains the following:
Installation 8

lPendant wall mount
lMounting template sticker
lT20 Pin-In star-shaped driver
l4 concrete anchors (#8-10)
l4 screws (#8 x 1.25)
lRJ-45 grommet piercing cap
lTeflon sealing tape
Installation Steps
Complete the following sections to install the device.
Removing the Dome Cover
Note: Be careful not to scratch or touch the dome bubble. The resulting marks or fingerprints may
affect the overall image quality. Keep the protective covers on the outside of the dome bubble
until the installation is complete.
lRemove the dome cover by releasing the elastic strap holding the dome cover to the camera base.
Inserting Cables through the Sealing Grommet
Always use the provided sealing grommet to prevent dust and debris from entering the camera.
Installation Steps 9

1. Remove the sealing grommet from the camera base.
2. Push the Ethernet cable through the grommet.
If you are installing the indoor model (H4SL-D), you should be able to simply push the cable, crimped
or uncrimped, through the grommet by hand.
If you are installing the outdoor model (H4SL-DO), use one of the following methods:
a. If the Ethernet cable is uncrimped, push the cable through the grommet.
b. If the Ethernet cable is already crimped, place the grommet piercing cap on the Ethernet
connector then push the cable through the grommet.
Ensure that the orientation of the cable and grommet matches the one shown in the image.
Mounting the Dome Camera to a Pipe
If the dome camera needs to be installed to a pipe for a pendant installation, you can discard the surface
mount adapter that is provided with the dome camera and use the NPT adapter.
Note: This procedure requires a 1-1/2” NPT-female to NPT-female pipe adapter. It is recommended
that the NPT adapter be mounted to a 1-1/2” conduit pipe.
1. Pull the required cables through the NPT conduit pipe.
2. Apply thread seal tape to the pipe and screw on the 1-1/2” NPT female to NPT female pipe adapter.
3. Screw the lock nut onto the NPT adapter.
4. Apply thread seal tape to the NPT adapter and screw it into the pipe adapter.
Make sure the parts are assembled in this order from NPT conduit pipe to camera adapter:
Mounting the Dome Camera to a Pipe 10

a. NPT conduit pipe
b. 1-1/2" NPT female to female pipe adapter
c. Lock nut
d. NPT adapter
(Optional) Mounting the Dome Camera to the Pendant Wall Mount
If the dome camera will be using the pendant wall mount, you will need to install the NPT adapter as well.
1. Determine where the cables will enter the pendant wall mount.
lIf the cables will be pulled from inside the mounting surface, use the cable entry hole at the
rear of the pendant wall mount.
lIf the cables will be coming out of an external conduit pipe, use the 3/4” NPT pipe entry hole
on the bottom of the pendant wall mount.
2. Use the provided mounting template to drill four mounting holes into the mounting surface.
lIf you are using the rear cable entry hole, also drill the cable entry hole into the mounting
surface.
(Optional) Mounting the Dome Camera to the Pendant Wall Mount 11

3. Fasten the pendant wall mount bracket to the mounting surface.
4. Insert the pendant wall mount over the bracket mounting tabs.
5. Pull the required cables through the preferred cable entry hole on the pendant wall mount.
lIf you are using the pipe entry hole, pull the cables through the pipe conduit then the wall
mount. Next, apply thread seal tape to the pipe conduit and screw it into the pipe entry hole.
(Optional) Mounting the Dome Camera to the Pendant Wall Mount 12

6. Tighten the wall mount screws to secure the wall mount to the bracket. Use the T20 star-shaped key
provided in the camera package.
(Optional) Mounting the Dome Camera to the Pendant Wall Mount 13

7. Loosely thread the lock nut onto the NPT adapter, then secure the NPT adapter into the pendant wall
mount.
8. Carefully tighten the lock nut until the NPT adapter is secured to the wall mount.
Installing the Camera Base to the Mounting Adapter
After you install the mounting adapter, mount the camera base to the adapter.
Installing the Camera Base to the Mounting Adapter 14

1. Attach the lanyard on the mounting adapter to the anchor on the camera base.
2. Pull the required Ethernet cable through the cable entry hole on the camera base.
3. Install the grommet into the cable entry hole on the camera base.
Make sure the grommet flange is securely seated on the inside and outside of the cable entry hole.
4. Connect the cable to the Ethernet port.
The Link LED will turn on once a network link has been established.
Installing the Camera Base to the Mounting Adapter 15
