WHAT’S INCLUDED:
•Wired Camera
•60 ft. extension cable
•Mounting hardware
•Quick Start Guide
SYSTEM REQUIREMENTS:
To use this camera you must have the
•Motorola Home Monitoring & Control System
Easy Start Kit
REGULATORY APPROVALS:
•FCC Compliant
Continued on back
At Home. Away From Home. Stay Informed.
Motorola’s Home Monitoring & Control System Wired Camera allows you to capture color
still images or video with sound.
Add this camera to your Home Monitoring & Control System to be aware of what’s happening
in, and around, your home even when you’re not there. Enhance your peace of mind by checking
in on your family while away from home.
BENEFITS:
Use this Wired Camera…
At Home
•Check on the baby without disturbing naptime
•Keep an eye on the kids as they play in the backyard
•See who’s at the front door without opening it
Away From Home*
•Know when the kids get home from school
•Know when a package is dropped off at your front door
•Know when someone enters your home
FEATURES:
•Manage devices with simple-to-use software*
•Add another viewing location**
•Add devices with the touch of a button
•For indoor and/or outdoor use
•Allows for real-time viewing in, and around, the home
•Captures and transmits color still images or video
with sound to Base Station/Gateway via built-in
motion detector and microphone
•Features picture quality adjustment settings
•Includes mounting hardware
•Easy set up and installation
SYSTEM SUPPORT:
•24/7 online and toll-free technical customer support
•One year limited warranty
HHoommeeMMoonniittoorriinngg&&CCoonnttrroollSSyysstteemm
WWiirreeddCCaammeerraa
HHMMWWCC11002200

Continued from front
HHoommeeMMoonniittoorriinngg&&CCoonnttrroollSSyysstteemm
WWiirreeddCCaammeerraa
HHMMWWCC11002200
TECHNICAL SPECIFICATIONS
To get started and customize your Home Monitoring & Control System, visit:
www.motorola.com/homemonitoring
MOTOROLA and the Stylized M logo are registered in the US Patent &Trademark Office. All other product or service names are property
of their respective owners. © Motorola, Inc. 2004.
5627-804-1K
•Color video camera with integrated infrared
motion detection
•80 degree field of view for motion and camera lens
•For indoor and/or outdoor use
•Includes all mounting hardware for table top,
wall or ceiling mounting
•Features auto brightness, auto contrast, and auto white-balance
picture quality adjustments settings
Integrated Lens 4.3 mm, F1.8 fixed focus
Motion and Camera Lens 80 degree field of view
Resolution 360 horizontal TV lines
Signal/Noise Ratio 48 dB
Image Sensor 1/3" CMOS
High-Speed Electronic Shutter 1/60 – 1/15,000 sec
Minimum Illumination 5 lux
Current Consumption approx. 40mA
Focus Range 2 ft. – infinity
OperatingTemperature -10˚ C to +40˚ C (14˚ F to 104˚ F)
Outline Dimensions 2.5" W x 2.75" H x 3.25" D
Weight 3.9 oz
PRODUCT OVER PACK
MODEL DESCRIPTION UPC WEIGHT (lbs.) DIMENSIONS QUANTITY WEIGHT (lbs.) DIMENSIONS
HMWC1020 Home Monitoring & 6 12572 09728 1 2.25 11.97" x 2.99" x 5.98" 12 28.56 12.72" x 12.72" x 19.49"
Control System
Wired Camera
WIRED CAMERA PROGRAMMABLE EVENTS
Customize your system by setting up multiple events to enhance your monitoring capability…
EVENT SELECTABLE ACTION END RESULT VIEWABLE IN ARCHIVE
CHOICES ACTION DEVICES CHOICES OR REMOTE NOTIFICATION VIA EMAIL*
Motion detected None N/A Motion detected message
The same camera
Motion detected used as sensor Image capture Motion detected message with an image capture
The same camera
Motion detected used as sensor Video capture Motion detected message with a video capture
N/A = Not Applicable
NOTE: Limit of one event per camera (i.e. motion detected, image capture or video capture)
* Real-time notifications via Base Station/Gateway and Software. Software included with Motorola’s Home Monitoring & Control System Easy Start Kit (sold separately). Broadband service such
as cable modem or DSL modem is required for notification via cell phone or Email. Either text messages or text messages with color still images are available remote notification options via
cell phones. For Email via computers, text messages including color video with sound is an additional notification option.
** System supports up to three wired cameras.
