Motorola APX 6000 User manual

APX™ Two-Way Radios
1) Select/copy image from Photo Library
2) Insert and resize selected image
to fill up this white area.
3) Right click on the image,
“Order -> Send to Back”.
APXTM 6000, Model 3

APX TM 6000
2 Index
CONTENTS - 1/4
1
FRONT COVER
2
CONTENTS - 1/4
3
CONTENTS - 2/4
4
CONTENTS - 3/4
5
CONTENTS - 4/4
6
DECLARATION OF CONFORMITY
7
DECLARATION OF CONFORMITY
8
PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE
9
SOFTWARE VERSION
10
COPYRIGHTS & DISCLAIMER
11
GETTING STARTED
12
GETTING STARTED
13
RADIO PARTS AND CONTROLS
14
RADIO PARTS AND CONTROLS
15
RADIO PARTS AND CONTROLS
16
PREPARING YOUR RADIO FOR USE -
Charging the Battery
17
PREPARING YOUR RADIO FOR USE -
Battery Charger
18
PREPARING YOUR RADIO FOR USE -
Charging Impress Battery
19
PREPARING YOUR RADIO FOR USE -
Charging Impress Battery
20
PREPARING YOUR RADIO FOR USE -
Automatic reconditioning
21
PREPARING YOUR RADIO FOR USE -
Manual reconditioning
22
PREPARING YOUR RADIO FOR USE -
Initial Battery Charge
23
PREPARING YOUR RADIO FOR USE -
Attaching the Battery
24
PREPARING YOUR RADIO FOR USE -
Attaching Removing Antenna
25
PREPARING YOUR RADIO FOR USE -
Attaching Accessory Connector
26
PREPARING YOUR RADIO FOR USE -
Using the Carry Holder
27
IDENTIFYING RADIO CONTROLS -
Turning radio on/off
28
IDENTIFYING RADIO CONTROLS -
Adjusting the Volume
29
IDENTIFYING RADIO CONTROLS -
Accessing Programmable Features
30
IDENTIFYING RADIO CONTROLS -
Accessing the Preprogrammed Functions
31
IDENTIFYING RADIO CONTROLS -
Using Navigation Buttons
32 - 35
IDENTIFYING RADIO CONTROLS -
Using the Keypad
36
IDENTIFYING RADIO CONTROLS -
Push-To-Talk
37 - 38
IDENTIFYING STATUS INDICATORS -
Status Icons

APX TM 6000
3 Index
CONTENTS - 2/4
59
GENERAL RADIO OPERATION –
Making a Talkgroup Call
60
GENERAL RADIO OPERATION -
Repeater or Direct Operation
61
ADVANCED FEATURES
62
ADVANCED FEATURES -
Advanced Call Features - Using the Dynamic Regrouping
Feature (Trunking Only)
63
ADVANCED FEATURES -
Advanced Call Features - Classifying Regrouped Radios
64
ADVANCED FEATURES -
Contacts
65
ADVANCED FEATURES -
Contacts - Viewing Details of a Contact
66
ADVANCED FEATURES -
Contacts - Adding a New Contact Entry
67
ADVANCED FEATURES -
Contacts - Adding a New Contact Entry
68
ADVANCED FEATURES -
Contacts - Deleting a Contact Entry
69
ADVANCED FEATURES -
Contacts - Adding a Contact to a Call List
70
ADVANCED FEATURES -
Contacts - Removing a Contact from a Call List
71
ADVANCED FEATURES -
Contacts - Editing a Contact in a Call List (Entry Alias and
Entry ID)
72
ADVANCED FEATURES -
Contacts - Editing a Contact in a Call List (Call Type)
39 - 41
IDENTIFYING STATUS INDICATORS -
Text Messaging Service (TMS) Icons - Status Icons
42
IDENTIFYING STATUS INDICATORS -
LED Indicator
43
IDENTIFYING STATUS INDICATORS -
44 - 45
IDENTIFYING STATUS INDICATORS -
Intelligent Lighting Indicators
46 - 48
IDENTIFYING STATUS INDICATORS -
Alert Tones
49
GENERAL RADIO OPERATION
50
GENERAL RADIO OPERATION
Fleetmap
51
GENERAL RADIO OPERATION -
Selecting a Zone –Side Button
52
GENERAL RADIO OPERATION -
Selecting a Zone –Menu
53
GENERAL RADIO OPERATION -
Selecting a Radio Channel
54
GENERAL RADIO OPERATION -
Using Mode Select Feature - Saving a Zone and Channel to a
Button
55 - 56
GENERAL RADIO OPERATION -
Receiving and Responding to a Radio Call - Receiving and
Responding to a Talkgroup Call
57
GENERAL RADIO OPERATION -
Responding to a Private Call
58
GENERAL RADIO OPERATION –
Making a Radio Call

APX TM 6000
4 Index
CONTENTS - 3/4
73
ADVANCED FEATURES -
Scan Lists
74
ADVANCED FEATURES -
Scan Lists - Viewing a Scan List
75
ADVANCED FEATURES -
Scan Lists - Editing the Scan List (Side Button)
76
ADVANCED FEATURES -
Scan Lists - Editing the Scan List (Menu)
77
ADVANCED FEATURES -
Scan –Priority Status
78
ADVANCED FEATURES -
Scan –Turning Scan On/Off
79
ADVANCED FEATURES -
Scan - Deleting a Nuisance Channel
80
ADVANCED FEATURES -
Scan - Restoring a Nuisance Channel
81
ADVANCED FEATURES -
Responding to a Call Alert Page
82
ADVANCED FEATURES -
Emergency Operation
83
ADVANCED FEATURES -
Emergency Operation - Sending an Emergency Alarm with
Emergency Call
84
ADVANCED FEATURES -
Secure Operations - Selecting Secure/Clear Transmissions
85
ADVANCED FEATURES -
Trunking System Controls - Using the Fail-soft System
86
ADVANCED FEATURES -
Trunking System Controls - Going Out of Range
87
ADVANCED FEATURES -
Trunking System Controls - Using the Site Trunking
Feature
88
ADVANCED FEATURES -
Programming Over Project 25 (POP 25)
89 - 90
ADVANCED FEATURES -
Programming Over Project 25 (POP 25) - Responding to
the notification of Upgrade
91
UTILITIES
92 - 93
UTILITIES –
Viewing the Recent Calls
94 - 95
UTILITIES –
Selecting a Radio Profile
96
UTILITIES –
Enabling a Radio Alias
97
UTILITIES –
Locking and Unlocking the Keypad and Controls
98
UTILITIES –
Turning Keypad Tones On or Off
99
UTILITIES –
Using the Time-Out Timer
100
UTILITIES –
Using the Digital PTT ID Feature
101
UTILITIES –
IMPRES™ Battery Annunciator

APX TM 6000
5 Index
CONTENTS - 4/4
102 - 103
UTILITIES –
Accessing the General Radio Information
104
UTILITIES –
Voice Announcement

APX TM 6000
6 Index
DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party
Name: Motorola Solutions, Inc.
Address: Motorola Solutions, Inc., 1303 East Algonquin Road Schaumburg, IL60196, U.S.A.
Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: APX 7000
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.

APX TM 6000
7 Index
DECLARATION OF CONFORMITY
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

APX TM 6000
8 Index
PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE
Before using this product, read the operating instructions for safe usage contained in the Product Safety and
RF Exposure booklet enclosed with your radio.
ATTENTION!
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements.
Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF
Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF
energy exposure limits.
For a list of Motorola-approved antennas and other accessories, visit the following website: http://www.motorola.com/APX

APX TM 6000
9 Index
SOFTWARE VERSION
All the features described in the following sections are supported by the radio's software version R07.00.00 or later.
See Accessing Radio Information to determine your radio's software version.
Check with your dealer or system administrator for more details of all the features supported.
Notice to Users (FCC and Industry Canada)
This device complies with Part 15 of the FCC rules and RSS 210 of the Industry Canada rules per the conditions listed below:
1 This device may not cause harmful interference.
2 This device must accept any interference received, including interference that may cause undesired operation.
3 Changes or modifications made to this device, not expressly approved by Motorola, could void the user's authority to operate
this equipment.

APX TM 6000
10 Index
COPYRIGHTS & DISCLAIMER
Computer Software Copyrights
The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor
memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for
copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted
computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in
this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express
written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by
implication, estoppels, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the
normal non-exclusive license to use that arises by operation of law in the sale of a product.
Documentation Copyrights
No duplication or distribution of this document or any portion thereof shall take place without the express written permission of
Motorola. No part of this manual may be reproduced, distributed, or transmitted in any form or by any means, electronic or
mechanical, for any purpose without the express written permission of Motorola.
Disclaimer
The information in this document is carefully examined, and is believed to be entirely reliable. However, no responsibility is
assumed for inaccuracies. Furthermore, Motorola reserves the right to make changes to any products herein to improve
readability, function, or design. Motorola does not assume any liability arising out of the applications or use of any product or
circuit described herein; nor does it cover any license under its patent rights, nor the rights of others.

APX TM 6000
11 Index
GETTING STARTED
This Interactive End User Toolkit (IEUTK) covers the basic operation of the APX 7000 Dual Display.
However, your dealer or system administrator may have customized your radio for your specific needs. Check with your dealer
or system administrator for more information.
Adobe Flash player is required to run the demos included with this kit.
Please refer to the Adobe website (http://get.adobe.com/flashplayer/) to update/download/install the Adobe Flash Player.
Notations Used in This Tutorial
Throughout the text in this toolkit, you will notice the use of WARNING, Caution, and Note. These notations are used to
emphasize that safety hazards exist, and the care that must be taken or observed.
Note: An operational procedure, practice, or condition, etc., which is essential to emphasize.
An operational procedure, practice, or condition, etc., which may result in
injury or death if not carefully observed.
An operational procedure, practice, or condition, etc., which may result in
damage to the equipment if not carefully observed.

APX TM 6000
12 Index
The following special notations identify certain items:
Getting Started
Example Description
Home button
or
Buttons and keys are shown in bold print or as an icon.
Phone Menu entries are shown similar to the way they appear on the radio’s display.
This means “Press the right side of the 4-way Navigation button.”
Feature/Procedure applies to Model 3 only
Model 3

APX TM 6000
13 Index
Chan Scan Dir
Zone A
Chan 1
Radio Parts and Controls
Model 3
Home
Button Data Feature
Button
4-Way
Navigation
Button
Menu Select
Buttons
Antenna
Microphone
On/Off/Volume
Control Knob
2-Position Concentric
Switch*
Main Display
Keypad
* These radio controls/buttons are programmable.

APX TM 6000
14 Index
Radio Parts and Controls
* These radio controls/buttons are programmable.
Top Side (Select) Button
Scan On/Off
Push-to-Talk
(PTT) Button
Side Button 1
Zone Up
Side Button 2
Zone Down
Accessory
Connector
Battery Latch
Microphone
Main Speaker
Battery

APX TM 6000
15 Index
Radio Parts and Controls
* These radio controls/buttons are programmable.
16-Position
Select Knob
Top Orange Button
Emergency
3-Position A/B/C
Switch
(Not programmed)
On/Off/Volume
Control Knob
Top Display
LED Indicator
2-Position Concentric
Switch
Keypad Lock

APX TM 6000
16 Index
The Motorola-approved battery shipped with your radio is uncharged. Prior to using a new battery, charge it for a
minimum of 16 hours to ensure optimum capacity and performance.
Note: When charging a battery attached to a radio, turn the radio off to ensure a full charge.
Battery Charger
To charge the battery, place the battery, with or without the radio, in a Motorola-approved charger. The charger’s LED
indicates the charging progress; see your charger’s user guide.
Preparing Your Radio for Use
Charging the Battery
To avoid a possible explosion: until side latches click into place.
• DO NOT replace the battery in any area
labeled “hazardous atmosphere”.
• DO NOT discard batteries in a fire.

APX TM 6000
17 Index
Preparing Your Radio - Charging the Battery
Battery Charger
To charge the battery, place the battery, with
or without the radio, in a Motorola-approved
charger. The charger’s LED indicates the
charging progress.
Multi Unit Charger
Single Unit Charger
Continued…

APX TM 6000
18 Index
Preparing Your Radio - Charging the IMPRES Battery
IMPRES Adaptive Charger
•Monitors the usage pattern of the IMPRES battery
and,
•Stores that information in the IMPRES battery,
then
•Performs a recondition cycle only when needed.
•Will not overheat the battery regardless of how long
it is left in the charger.
•Charger monitors the battery and automatically
“tops off” the battery, as required.
NOTE:
•The battery must be charged before use.
•Memory effect is a phenomenon that causes a loss in battery capacity or
voltage due to repetitive shallow discharging or long-term overcharging.
•This memory effect has been greatly reduced in your batteries through the
use of new cell technology.
•It is still recommended that you discharge your battery as much as possible
before recharging it.
•Recharging after each shift is good standard practice.
•When charging a battery that is attached to your radio, turn the radio off to
ensure a full charge.
Continued…

APX TM 6000
19 Index
Charge Indicator Description
Single Flash Green Charger has successfully powered up.
Steady Red Battery is in rapid charge mode.
Flashing Green Battery has completed rapid charge (>90% available capacity).
Battery is in Top-Off charge (Trickle Charge) and requires approximately 1 hour.
Steady Green Battery has completed charging and is fully charged.
Flashing Yellow Battery is recognized by charger but is waiting to charge.
(Either the battery voltage is too low or the battery temperature is too low or too
high to allow charging. When this condition is corrected, the battery will begin
charging).
Flashing Red Battery is un-chargeable or not making proper contact.
Steady Yellow Battery is in recondition mode. The length of time the charger remains in this
mode is dependent upon the state of charge remaining in the battery when
inserted. (Fully charged batteries require more time to recondition–8 hours or
more–than fully discharged batteries.)
Flashing Red & Green Battery may be approaching the end of its rated service life. This is not a fault
indication, merely a notification to the user that the battery may soon no longer be
able to yield expected service and may need to be replaced.
1x
Charge Indicator Lights

APX TM 6000
20 Index
Preparing Your Radio - Charging the IMPRES Battery
Automatic Reconditioning of the Battery:
When the IMPRES battery is properly inserted
into the charger, the charger determines if it is
appropriate to recondition the battery.
If the battery needs reconditioning, the charger
automatically indicates a STEADY YELLOW.
This process may take 8 hours or more to
complete, depending upon the state of charge
and capacity rating of the battery when inserted.
NOTE: It important that the battery be
allowed to complete the recondition/recharge
process for it to be effective. Leave the
battery in the charger until the charger
indicates a STEADY GREEN.
NOTE:
Toward the end of the rapid charge cycle
(STEADY RED indication), the battery voltage
exceeds the normal operating voltage of the radio.
Voltage returns to a normal level following the
rapid charge mode or when the battery is
removed from the charger.
If the radio is turned on while the charger is in
rapid charge mode, the radio becomes
temporarily inoperable. This condition can be
cleared by removing the radio from the charger
and turning the radio off and on again.
During the reconditioning process, the battery
becomes fully discharged. As a result, the radio
may not function during reconditioning mode.
Continued…
