Motorola APX NEXT User manual

APX TWO-WAY
RADIOS
APX NEXT User Guide
*MN005642A01*
MN005642A01-AA
APRIL 2019
© 2019 Motorola Solutions, Inc. All rights reserved

Declaration of Conformity
This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.
Declaration of Conformity
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party
Name: Motorola Solutions, Inc.
Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.
Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: APX NEXT
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d), and section 15.109(a)
Class B Digital Device
English
12

As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. This device complies with
Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
1This device may not cause harmful interference, and
2This device must accept any interference received, including interference that may cause undesired operation.
NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules and Industry Canada license-exempt RSS standard. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment gen-
erates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio or TV technician for help.
English
13

Important Safety Information
RF Energy Exposure and Product Safety
Guide for Portable Two-Way Radios
ATTENTION!
This radio is restricted to Occupational use only. Before
using the radio, read the RF Energy Exposure and Product
Safety Guide for Portable Two-Way Radios which contains
important operating instructions for safe usage and RF
energy awareness and control for Compliance with
applicable standards and Regulations.
For a list of Motorola Solutions-approved antennas,
batteries, and other accessories, visit the following website:
http://www.motorolasolutions.com
Under Industry Canada regulations, this radio transmitter
may only operate using an antenna of a type and maximum
(or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other
users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful
communication.
This radio transmitter has been approved by Industry
Canada to operate with Motorola Solutions-approved
antenna with the maximum permissible gain and required
antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain
greater than the maximum gain indicated for that type, are
strictly prohibited for use with this device.
English
14

Notice to Users (FCC and
Industry Canada)
This device complies with Part 15 of the FCC rules and
Industry Canada's license-exempt RSS's per the following
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
• Changes or modifications made to this device, not
expressly approved by Motorola Solutions, could void
the authority of the user to operate this equipment.
English
15

Software Version
All the features described in the following sections are
supported by the software version R19.00.00 or later.
See Accessing the Radio Information on page 209 to
determine the software version of your radio.
Check with your dealer or system administrator for more
details of all the features supported.
English
16

Déclaration de conformité
Cette déclaration est applicable à votre radio uniquement si elle porte l'étiquette du logo de la FCC ci-dessous.
Déclaration de conformité
Règlement CFR 47 partie 2 section 2.1077(a) de la FCC
Partie responsable
Nom : Motorola Solutions, Inc.
Adresse : 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.
Numéro de téléphone : 1 800 927-2744.
Déclare par les présentes que le produit :
Nom de modèle : APX NEXT
sont conformes aux réglementations suivantes :
Partie 15, sous-partie B, section 15.107(a), 15.107(d) et section 15.109(a) des règlements de la FCC
Appareil numérique de Classe B
Français (Canada)
15

En tant que périphérique d'ordinateur personnel, cet appareil est conforme aux stipulations de la partie 15 des
règlements de la FCC. Cet appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. Son utilisation est assujettie aux deux conditions suivantes :
1Cet appareil ne doit pas causer d'interférence nuisible.
2Cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un
fonctionnement indésirable.
AVIS:
Cet équipement a fait l'objet de tests et a été déclaré conforme aux limites établies pour un appareil
numérique de classe B, conformément à la section 15 des règlements de la FCC et aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence. Ces limites sont fixées afin d'offrir une
protection suffisante contre des interférences nuisibles dans une installation résidentielle. Cet équipement
génère, utilise et peut émettre de l'énergie de radiofréquence et, s'il n'est pas installé ou utilisé
conformément aux instructions, il peut provoquer un brouillage nuisible aux communications radio.
Cependant, il est impossible de garantir qu'il n'y aura aucune interférence dans une installation particulière.
Si cet appareil cause une interférence nuisible à la réception de la radio ou de la télévision, ce qui peut être
déterminé en éteignant et en allumant l'appareil, vous êtes encouragé à remédier à la situation en prenant
une ou plusieurs des mesures suivantes :
• Réorienter ou déplacer l'antenne réceptrice.
•Augmenter la distance entre l'équipement et le récepteur.
• Brancher l'appareil dans une autre prise sur un circuit différent de celui du récepteur.
• Consulter un revendeur ou un technicien de radio ou de télévision chevronné pour obtenir de l'aide.
Français (Canada)
16

Consignes de sécurité
importantes
Radios bidirectionnelles portatives :
exposition aux radiofréquences et sécurité du
produit
ATTENTION!
Cette radio ne doit être utilisée qu'à des fins
professionnelles. Avant d'utiliser la radio, lisez le guide
Radios bidirectionnelles portatives : exposition aux
radiofréquences et sécurité du produit, qui contient
d'importantes instructions de fonctionnement pour une
utilisation sécuritaire et des informations sur l'exposition
aux fréquences radioélectriques, dans le but d'assurer
votre conformité aux normes et règlements en vigueur.
Visitez le site Web suivant pour obtenir la liste des
antennes, des batteries et des autres accessoires
approuvés par Motorola Solutions :
http://www.motorolasolutions.com
Selon la réglementation d'Industrie Canada, cet émetteur
radio ne peut être utilisé qu'avec une antenne dont le type
et le gain maximal (ou minimal) sont approuvés par
Industrie Canada pour cet émetteur. Afin de limiter les
interférences radio pour les autres utilisateurs, le type et le
gain de l'antenne doivent être choisis de façon à ce que la
puissance isotrope rayonnée équivalente (P.I.R.E.) ne soit
pas plus forte qu'il ne le faut pour établir la communication.
Cet émetteur radio a été approuvé par Industrie Canada
pour utilisation avec une antenne approuvée par Motorola
Solutions offrant le gain maximal autorisé et l'impédance
requise pour le type d'antenne indiqué. Il est strictement
interdit d'utiliser avec cet appareil tout type d'antenne ne
figurant pas dans cette liste et présentant un gain supérieur
au maximum indiqué pour le type.
Français (Canada)
17

Avis aux utilisateurs (FCC et
Industrie Canada)
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence
et à la partie 15 des règlements de la FCC :
• Cet appareil ne doit pas causer d'interférence nuisible.
• Cet appareil doit accepter toute interférence reçue, y
compris les interférences pouvant entraîner un
fonctionnement indésirable.
• Toute modification effectuée à cet appareil sans
l'autorisation explicite de Motorola Solutions peut
annuler l'autorisation d'utiliser cet appareil.
Version logicielle
Toutes les fonctions décrites dans les sections suivantes
sont prises en charge par les versions logicielles R19.00.00
ou plus récentes.
Reportez-vous à Accès aux renseignements sur la radio à
la page 209 pour déterminer la version logicielle de votre
radio.
Pour obtenir davantage de renseignements à propos des
fonctions prises en charge, adressez-vous à votre détaillant
ou à votre administrateur de système.
Français (Canada)
19

Computer Software
Copyrights
The Motorola Solutions products described in this manual
may include copyrighted Motorola Solutions computer
programs stored in semiconductor memories or other
media. Laws in the United States and other countries
preserve for Motorola Solutions certain exclusive rights for
copyrighted computer programs including, but not limited
to, the exclusive right to copy or reproduce in any form the
copyrighted computer program. Accordingly, any
copyrighted Motorola Solutions computer programs
contained in the Motorola Solutions products described in
this manual may not be copied, reproduced, modified,
reverse-engineered, or distributed in any manner without
the express written permission of Motorola Solutions.
Furthermore, the purchase of Motorola Solutions products
shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Motorola
Solutions, except for the normal non-exclusive license to
use that arises by operation of law in the sale of a product.
English
17

Documentation Copyrights
No duplication or distribution of this document or any
portion thereof shall take place without the express written
permission of Motorola Solutions. No part of this manual
may be reproduced, distributed, or transmitted in any form
or by any means, electronic or mechanical, for any purpose
without the express written permission of Motorola
Solutions.
English
18

Disclaimer
The information in this document is carefully examined, and
is believed to be entirely reliable. However, no
responsibility is assumed for inaccuracies. Furthermore,
Motorola Solutions reserves the right to make changes to
any products herein to improve readability, function, or
design. Motorola Solutions does not assume any liability
arising out of the applications or use of any product or
circuit described herein; nor does it cover any license under
its patent rights, nor the rights of others.
English
19

Getting Started
This User Guide covers the basic operation of the APX
Portables .
However, your dealer or system administrator may have
customized your radio for your specific needs. Check with
your dealer or system administrator for more information.
Notations Used in This Manual
Throughout the text in this publication, you will notice the
use of Warning, Caution, and Notice. These notations are
used to emphasize that safety hazards exist, and the care
that must be taken or observed.
WARNING:
An operational procedure, practice, or condition and
so on, which may result in injury or death if not
carefully observed.
CAUTION:
An operational procedure, practice, or condition and
so on, which may result in damage to the equipment
if not carefully observed.
NOTICE:
An operational procedure, practice, or condition and
so on, which is essential to emphasize.
Top Control
Voice Control
Simple Touch
What Your Dealer/System
Administrator Can Tell You
Check with your dealer or system administrator for the
correct radio settings, if the radio is to be operated in
extreme temperatures (less than -30 °C or more than +60
°C).
You can consult your dealer or system administrator about
the following:
• Is your radio programmed with any preset conventional
channels?
English
10

• Which buttons have been programmed to access other
features?
• What optional accessories may suit your needs?
NOTICE:
Specifications may vary for different radio models.
Check with your dealer or system administrator for
more information.
English
11

Preparing Your Radio For
Use
This section provides simple instructions to prepare your
radio for use.
Installing the Battery
NOTICE:
User is notified if radio detects non-Motorola
Solutions battery upon powering up, charging, or
removing from the charger. This feature is
applicable for IMPRES and Non-IMPRES battery.
When the radio is attached with the non-Motorola
Solutions battery, a tone sounds, display shows
Unknown Battry temporarily and battery indicator
is not shown in the radio display. Battery menu
screen displays Unknown Battry permanently and
IMPRES battery information is not shown on the
radio display.
• Attaching the battery.
a. Align the battery with bottom rails on the back of
the radio and slide the battery into the radio
frame until the side latches click into place.
• Removing the battery.
a. Press the latches on both sides.
b. Pull the battery away from the radio.
English
12

Installing the Antenna
Ensure the radio is turned off before attaching the antenna.
• Attaching the antenna.
a. Set the antenna in the receptacle.
b. Turn the antenna clockwise and tighten the
antenna by hand securely to the radio.
• Removing the antenna.
a. To remove the antenna, turn the antenna
counterclockwise.
English
13

NOTICE:
When removing the antenna, ensure that
the radio is turned off.
Charging the Radio
WARNING:
To avoid possible explosion:
• Do not replace the battery in any area labeled
Hazardous Atmosphere.
• Do not discard batteries in a fire.
Place the radio in a Motorola Solutions-approved
charger.
English
14

Figure 1: Charging the Radio using a Single-Unit
Charger
Powering On the Radio
NOTICE:
Ensure to fully charge the battery before the first
use.
• Turn on the radio.
a. Rotate the On/Off/Volume Control Knob
clockwise until you hear a click.
• Turn off the radio.
a. To turn off the radio, rotate the On/Off/Volume
Control Knob counterclockwise until you hear a
click.
English
15

Radio Controls
This chapter explains the buttons and functions to control
the radio.
APX NEXT Overview
Front View
English
16
