CP150™/CP200™
Commercial Series
Two-Way Radio User Guide
Manuel de l'utilisateur
de la radio bidirectionnelle
309N60-A_cvr.qxd 8/19/2003 10:43 AM Page 1

1English
CONTENTS
CONTENTS
Computer Software Copyrights. . . . . . . . . .2
Safety and Warranty . . . . . . . . . . . . . . . . . 3
Product Safety and RF Exposure
Compliance. . . . . . . . . . . . . . . . . . . . . . . .3
Battery Information . . . . . . . . . . . . . . . . . . .3
Charging Batteries . . . . . . . . . . . . . . . . .3
Limited Warranty. . . . . . . . . . . . . . . . . . . . .4
Introduction . . . . . . . . . . . . . . . . . . . . . . . .9
Conventional Radio Systems . . . . . . . . . . .9
CP150™/CP200™ Radio Features . . . . . .9
Radio Wide Features . . . . . . . . . . . . . . .9
Signaling Features. . . . . . . . . . . . . . . . . 9
Radio Overview . . . . . . . . . . . . . . . . . . . . 11
Parts of the Radio . . . . . . . . . . . . . . . . . . .11
CP150/CP200 Models . . . . . . . . . . . . .11
On/Off/Volume Knob . . . . . . . . . . . . . .12
Channel Selector Knob . . . . . . . . . . . .12
Push-to-Talk (PTT) Button. . . . . . . . . . 12
Microphone . . . . . . . . . . . . . . . . . . . . .12
LED Indicator . . . . . . . . . . . . . . . . . . . .12
Programmable Buttons . . . . . . . . . . . .13
Indicator Tones . . . . . . . . . . . . . . . . . . . . .15
Audio Indicators for Programmable
Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .15
Improved Audio Features . . . . . . . . . . . . . 16
Companding . . . . . . . . . . . . . . . . . . . . 16
Getting Started . . . . . . . . . . . . . . . . . . . . 17
Battery Information . . . . . . . . . . . . . . . . . . 17
Charging Your Battery. . . . . . . . . . . . . 17
Wall Charger. . . . . . . . . . . . . . . . . . . . . . . 17
Desktop Chargers. . . . . . . . . . . . . . . . . . . 18
Rapid Charger. . . . . . . . . . . . . . . . . . . 18
Slow Charger. . . . . . . . . . . . . . . . . . . . 19
Accessory Information . . . . . . . . . . . . . . . 20
Attaching the Battery. . . . . . . . . . . . . . 20
Removing the Battery . . . . . . . . . . . . . 20
Attaching the Antenna. . . . . . . . . . . . . 21
Removing the Antenna . . . . . . . . . . . . 21
Attaching the Belt Clip. . . . . . . . . . . . . 22
Removing the Belt Clip . . . . . . . . . . . . 22
Turning the Radio On or Off . . . . . . . . . . . 23
Adjusting the Volume . . . . . . . . . . . . . . . . 23
Selecting a Radio Channel. . . . . . . . . . . . 23
Receiving . . . . . . . . . . . . . . . . . . . . . . . . . 24
Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . 24
Transmitting . . . . . . . . . . . . . . . . . . . . . . . 24
VOX Operation . . . . . . . . . . . . . . . . . . . . . 25
Connecting a VOX Headset . . . . . . . . 25
Enabling or Disabling VOX . . . . . . . . . 25
Enable/Disable Headset Sidetone . . . . . . 25
VOX Headset. . . . . . . . . . . . . . . . . . . . 25
Non-VOX Headset with In-Line PTT . . 26
Non-displayTOC.fm Page 1 Monday, November 17, 2003 1:55 PM

2
English
CONTENTS
Repeater or Talkaround Mode . . . . . . . . . 26
Setting Tight or Normal Squelch. . . . . . . . 26
Setting the Power Level . . . . . . . . . . . . . . 27
Radio Calls . . . . . . . . . . . . . . . . . . . . . . . 29
Receiving a Selective Call . . . . . . . . . . . . 29
Receiving a Call Alert Page . . . . . . . . . . . 29
Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Talkback . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Starting System Scan. . . . . . . . . . . . . . . . 31
Stopping System Scan . . . . . . . . . . . . . . . 31
Starting Auto Scan . . . . . . . . . . . . . . . . . . 31
Stopping Auto Scan . . . . . . . . . . . . . . . . . 31
Deleting a Nuisance Channel. . . . . . . . . . 32
Restoring a Channel to the Scan List . 32
Prioritizing a Scan List Member . . . . . . . . 33
Accessories . . . . . . . . . . . . . . . . . . . . . . 35
Carry Accessories. . . . . . . . . . . . . . . . . . . 35
Chargers. . . . . . . . . . . . . . . . . . . . . . . . . . 35
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Headsets . . . . . . . . . . . . . . . . . . . . . . . . . 36
Surveillance Accessories . . . . . . . . . . . . . 36
Remote Speaker Microphones. . . . . . . . . 37
Ear Microphone Systems . . . . . . . . . . . . . 37
Antennas . . . . . . . . . . . . . . . . . . . . . . . . . 38
Miscellaneous. . . . . . . . . . . . . . . . . . . . . . 38
COMPUTER SOFTWARE
COPYRIGHTS
The Motorola products described in this
manual may include copyrighted Motorola
computer programs stored in semiconductor
memories or other media. Laws in the United
States and other countries preserve for
Motorola certain exclusive rights for
copyrighted computer programs including, but
not limited to, the exclusive right to copy or
reproduce in any form the copyrighted
computer program. Accordingly, any
copyrighted Motorola computer programs
contained in the Motorola products described
in this manual may not be copied, reproduced,
modified, reverse-engineered, or distributed in
any manner without the express written
permission of Motorola. Furthermore, the
purchase of Motorola products shall not be
deemed to grant either directly or by
implication, estoppel, or otherwise, any license
under the copyrights, patents or patent
applications of Motorola, except for the normal
non-exclusive license to use that arises by
operation of law in the sale of a product.
Non-displayTOC.fm Page 2 Monday, November 17, 2003 1:55 PM

3English
SAFETY AND
WARRANTY
SAFETY AND WARRANTY
PRODUCT SAFETY AND RF
EXPOSURE COMPLIANCE
ATTENTION!
This radio is restricted to occupational use
only to satisfy FCC RF energy exposure
requirements. Before using this product, read
the RF energy awareness information and
operating instructions in the Product Safety
and RF Exposure booklet enclosed with your
radio (Motorola Publication part number
68P81095C98) to ensure compliance with RF
energy exposure limits.
For a list of Motorola-approved antennas,
batteries, and other accessories, visit the
following web site which lists approved
accessories: http://www.motorola.com/cgiss/
index.shtml.
BATTERY INFORMATION
Charging Batteries
This product is powered by a nickel-cadmium
(NICd) or lithium-ion (Lilon) rechargeable
battery. Charge the battery before use to
ensure optimum capacity and performance.
The battery was designed specifically to be
used with a Motorola charger. Charging in non-
Motorola equipment may lead to battery
damage and void the battery warranty.
Note: When charging a battery attached to a
radio, turn the radio off to ensure a full
charge.
The battery should be at about 77°F (25°C)
(room temperature), whenever possible.
Charging a cold battery (below 50° F [10°C])
may result in leakage of electrolyte and
ultimately in failure of the battery. Charging a
hot battery (above 95°F [35°C]) results in
reduced discharge capacity, affecting the
performance of the radio. Motorola rapid-rate
battery chargers contain a temperature-
sensing circuit to ensure that batteries are
charged within the temperature limits stated
above.
Before using this product, read
the operating instructions for safe
usage contained in the Product
Safety and RF Exposure booklet
enclosed with your radio.
!
C a u t i o n
00_SafetyNA.fm Page 3 Monday, November 17, 2003 1:55 PM

4
English
SAFETY AND
WARRANTY
LIMITED WARRANTY
MOTOROLA COMMUNICATION
PRODUCTS
I. WHAT THIS WARRANTY COVERS AND
FOR HOW LONG:
MOTOROLA INC. (“MOTOROLA”) warrants the
MOTOROLA manufactured Communication
Products listed below (“Product”) against defects
in material and workmanship under normal use
and service for a period of time from the date of
purchase as scheduled below:
CP150/CP200 Portable Units Two (2) Years
Product Accessories One (1) Year
Motorola, at its option, will at no charge either
repair the Product (with new or reconditioned
parts), replace it (with a new or reconditioned
Product), or refund the purchase price of the
Product during the warranty period provided it is
returned in accordance with the terms of this
warranty. Replaced parts or boards are
warranted for the balance of the original
applicable warranty period. All replaced parts of
Product shall become the property of
MOTOROLA.
This express limited warranty is extended by
MOTOROLA to the original end user purchaser
only and is not assignable or transferable to any
other party. This is the complete warranty for the
Product manufactured by MOTOROLA.
MOTOROLA assumes no obligations or liability
for additions or modifications to this warranty
unless made in writing and signed by an officer
of MOTOROLA. Unless made in a separate
agreement between MOTOROLA and the
original end user purchaser, MOTOROLA does
not warrant the installation, maintenance or
service of the Product.
MOTOROLA cannot be responsible in any way
for any ancillary equipment not furnished by
MOTOROLA which is attached to or used in
connection with the Product, or for operation of
the Product with any ancillary equipment, and all
such equipment is expressly excluded from this
warranty. Because each system which may use
the Product is unique, MOTOROLA disclaims
liability for range, coverage, or operation of the
system as a whole under this warranty.
00_SafetyNA.fm Page 4 Monday, November 17, 2003 1:55 PM

5English
SAFETY AND
WARRANTY
II. GENERAL PROVISIONS:
This warranty sets forth the full extent of
MOTOROLA's responsibilities regarding the
Product. Repair, replacement or refund of the
purchase price, at MOTOROLA’s option, is the
exclusive remedy. THIS WARRANTY IS GIVEN
IN LIEU OF ALL OTHER EXPRESS
WARRANTIES. IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL
MOTOROLA BE LIABLE FOR DAMAGES IN
EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT, FOR ANY LOSS OF USE, LOSS OF
TIME, INCONVENIENCE, COMMERCIAL
LOSS, LOST PROFITS OR SAVINGS OR
OTHER INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES ARISING OUT
OF THE USE OR INABILITY TO USE SUCH
PRODUCT, TO THE FULL EXTENT SUCH MAY
BE DISCLAIMED BY LAW.
III. STATE LAW RIGHTS:
SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES OR
LIMITATION ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE
LIMITATION OR EXCLUSIONS MAY NOT
APPLY.
This warranty gives specific legal rights, and
there may be other rights which may vary from
state to state.
IV. HOW TO GET WARRANTY SERVICE:
You must provide proof of purchase (bearing the
date of purchase and Product item serial number)
in order to receive warranty service and, also,
deliver or send the Product item, transportation
and insurance prepaid, to an authorized warranty
service location. Warranty service will be
provided by Motorola through one of its
authorized warranty service locations. If you first
contact the company which sold you the Product
(e.g., dealer or communication service provider),
it can facilitate your obtaining warranty service.
You can also call Motorola at 1-800-927-2744
US/Canada.
00_SafetyNA.fm Page 5 Monday, November 17, 2003 1:55 PM

6
English
SAFETY AND
WARRANTY
V. WHAT THIS WARRANTY DOES NOT
COVER:
A Defects or damage resulting from use of the
Product in other than its normal and
customary manner.
B Defects or damage from misuse, accident,
water, or neglect.
C Defects or damage from improper testing,
operation, maintenance, installation,
alteration, modification, or adjustment.
D Breakage or damage to antennas unless
caused directly by defects in material
workmanship.
E A Product subjected to unauthorized
Product modifications, disassemblies or
repairs (including, without limitation, the
addition to the Product of non-Motorola
supplied equipment) which adversely affect
performance of the Product or interfere with
Motorola's normal warranty inspection and
testing of the Product to verify any warranty
claim.
F Product which has had the serial number
removed or made illegible.
G Freight costs to the repair depot.
H A Product which, due to illegal or
unauthorized alteration of the software/
firmware in the Product, does not function in
accordance with MOTOROLA’s published
specifications or the FCC type acceptance
labeling in effect for the Product at the time
the Product was initially distributed from
MOTOROLA.
I Scratches or other cosmetic damage to
Product surfaces that does not affect the
operation of the Product.
J Normal and customary wear and tear.
VI.PATENT AND SOFTWARE PROVISIONS:
MOTOROLA will defend, at its own expense, any
suit brought against the end user purchaser to
the extent that it is based on a claim that the
Product or parts infringe a United States patent,
and MOTOROLA will pay those costs and
damages finally awarded against the end user
purchaser in any such suit which are attributable
to any such claim, but such defense and
payments are conditioned on the following:
A that MOTOROLA will be notified promptly in
writing by such purchaser of any notice of
such claim;
00_SafetyNA.fm Page 6 Monday, November 17, 2003 1:55 PM

7English
SAFETY AND
WARRANTY
B that MOTOROLA will have sole control of the
defense of such suit and all negotiations for
its settlement or compromise; and
C should the Product or parts become, or in
MOTOROLA’s opinion be likely to become,
the subject of a claim of infringement of a
United States patent, that such purchaser
will permit MOTOROLA, at its option and
expense, either to procure for such
purchaser the right to continue using the
Product or parts or to replace or modify the
same so that it becomes non-infringing or to
grant such purchaser a credit for the Product
or parts as depreciated and accept its
return. The depreciation will be an equal
amount per year over the lifetime of the
Product or parts as established by
MOTOROLA.
MOTOROLA will have no liability with respect to
any claim of patent infringement which is based
upon the combination of the Product or parts
furnished hereunder with software, apparatus or
devices not furnished by MOTOROLA, nor will
MOTOROLA have any liability for the use of
ancillary equipment or software not furnished by
MOTOROLA which is attached to or used in
connection with the Product. The foregoing
states the entire liability of MOTOROLA with
respect to infringement of patents by the Product
or any parts thereof.
Laws in the United States and other countries
preserve for MOTOROLA certain exclusive rights
for copyrighted MOTOROLA software such as
the exclusive rights to reproduce in copies and
distribute copies of such Motorola software.
MOTOROLA software may be used in only the
Product in which the software was originally
embodied and such software in such Product
may not be replaced, copied, distributed,
modified in any way, or used to produce any
derivative thereof. No other use including,
without limitation, alteration, modification,
reproduction, distribution, or reverse engineering
of such MOTOROLA software or exercise of
rights in such MOTOROLA software is permitted.
No license is granted by implication, estoppel or
otherwise under MOTOROLA patent rights or
copyrights.
VII. GOVERNING LAW:
This Warranty is governed by the laws of the
State of Illinois, USA.
00_SafetyNA.fm Page 7 Monday, November 17, 2003 1:55 PM

8
English
SAFETY AND
WARRANTY
Notes:
00_SafetyNA.fm Page 8 Monday, November 17, 2003 1:55 PM

9English
INTRODUCTION
INTRODUCTION
CONVENTIONAL RADIO SYSTEMS
Conventional radio systems typically refer to
unit-to-unit communications through a single
channel. Conventional systems also allow
radio users to extend communication coverage
by relaying their messages through a repeater.
To ensure coordinated use by multiple users,
each radio user must monitor the channel or
repeater before transmitting to verify that the
system is not currently busy.
CP150™/CP200™ RADIO
FEATURES
Radio Wide Features
• 4 or 16 Channels
• 2 Programmable Feature Buttons
• Busy Channel Lockout
• High/Low Power Settings (Available for 4W
& 5W models only)
• Repeater/Talkaround
• Voice Operated Transmit
• Transmit Time-Out Timer
• Monitor and Sticky Monitor
• System Scan with Single Priority Scan
Signaling Features
• MDC 1200 Signaling (Available for 4W &
5W models only)
• Quik-Call II Signaling (Available for 4W &
5W models only)
• DTMF Signaling
- Selective Radio
Inhibit Decode
- Radio Check
Decode
- PTT ID Decode
- PTT ID Encode
- Selective Inhibit
Decode
- Call Alert
Decode - Selective Call Decode
- DTMF PTT ID
Encode
01_Introduction.fm Page 9 Monday, November 17, 2003 3:49 PM

10
English
INTRODUCTION
Notes:
01_Introduction.fm Page 10 Monday, November 17, 2003 1:56 PM

11 English
RADIO OVERVIEW
RADIO OVERVIEW PARTS OF THE RADIO
CP150/CP200 Models
(programmable)
Side Button 1
Push-to-Talk
(PTT) Button
(programmable)
Side Button 2 Accessory Connector
with a Dust Cover
LED Indicator
On/Off/Volume
Knob
Channel Selector
Knob
Microphone
02_Overview.fm Page 11 Monday, November 17, 2003 1:56 PM

12
English
RADIO OVERVIEW
On/Off/Volume Knob
Turns the radio on or off, and adjusts the
radio’s volume.
Channel Selector Knob
Switches the radio to different channels.
Push-to-Talk (PTT) Button
Press and hold down this button to talk
(transmit); release it to listen.
Microphone
When sending a message, hold the
microphone 1 to 2 inches (2.5 to 5 cm) away
from your mouth, and speak clearly into it.
LED Indicator
Indicates power-up, transmit, receive, scan
status, Call Alert™, Selective Call, Monitor,
and battery status.
Basic Features
LED State/Color Indication
Red Transmitting
Flashing Red Receiving
Scan
Flashing Green Scanning for activity
Call Alert†
Flashing Yellow Indicates receiving a Call Alert
Selective Call†
Flashing Yellow Indicates receiving a Selective
Call
Sticky Monitor/Open Squelch
Yellow While monitoring
Low Battery
Flashing Red
when transmitting Low battery level
†Available for 4W and 5W models only.
02_Overview.fm Page 12 Monday, November 17, 2003 1:56 PM

13 English
RADIO OVERVIEW
Battery Charge Status
You can check battery charge status if your
dealer has preprogrammed one of the
programmable buttons. Hold down the
preprogrammed Battery Indicator button. The
charge status is shown by the color of the
radio’s LED indicator.
Programmable Buttons
The two side buttons on your radio can be
programmed by your dealer as shortcuts to
various radio features.
Check with your dealer for a complete list of
functions your radio supports.
Some buttons can access up to two features,
depending on the type of button press:
•short press — quickly pressing and releas-
ing the programmable buttons
•long press — pressing and holding the
programmable buttons for a period of time
(default 1 1/2 seconds or programmed
value) before releasing
•hold down — pressing and holding down
the programmable buttons while checking
status or making adjustments
Depending on how your radio has been
programmed by your dealer, these functions
are activated EITHER through a short press
OR a long press, but NOT both.
A summary of programmable radio features
and corresponding page references appears
beginning on page 14.
In the “Feature” column, have your dealer write
down the programmable buttons next to the
features that have been programmed to them.
Battery
Level LED Indicator
Good Green
Sufficient Yellow
Low Flashing Red
Very Low None
02_Overview.fm Page 13 Monday, November 17, 2003 1:56 PM

14
English
RADIO OVERVIEW
Feature Short Press/Long Press Hold Down Page Button
Battery
Indicator — Checks the battery charge status. 13
Sticky Monitor/
Monitor
A long press of the Monitor button
initiates. A short press of the
Monitor button cancels.
Monitors the selected channel for
any activity. 24
Volume Set Sounds a tone for adjusting the radio’s volume level. 23
Voice Operated
Transmission
(VOX) Toggle VOX on and off. — 25
Power Level†Toggles your radio’s transmit power
level between High and Low power. —27
Repeater/
Talkaround
Toggles between using a repeater
and transmitting directly to another
radio. —26
Squelch Toggles your radio’s squelch level
between tight and normal squelch. —26
†Available for 4W and 5W models only.
02_Overview.fm Page 14 Monday, November 17, 2003 1:56 PM

15 English
RADIO OVERVIEW
INDICATOR TONES
High pitched tone Low pitched tone
AUDIO INDICATORS FOR
PROGRAMMABLE BUTTONS
Some programmable buttons use tones to
indicate one of two modes:
Scan Starts or stops the Scan operation. — 31
Nuisance
Channel Delete Deletes a nuisance channel while scanning. —31
Feature Short Press/Long Press Hold Down Page Button
Self Test Pass Tone
Self Test Fail Tone
Positive Indicator Tone
Negative Indicator Tone
Button Positive
Indicator Tone Negative Indicator Tone
Scan Start scan Stop scan
Power Level†High power
selected Low power selected
Squelch Tight squelch Normal squelch
Repeater/
Talkaround Does not use repeater Uses repeater
VOX VOX enabled VOX disabled
†Available for 4W and 5W models only.
02_Overview.fm Page 15 Monday, November 17, 2003 1:56 PM

16
English
RADIO OVERVIEW
IMPROVED AUDIO FEATURES
Companding
Companding is a feature that allows further
improvement of voice quality. It compresses
your voice at transmission, and expands it
when receiving while simultaneously reducing
extraneous noise. However, to enjoy this
benefit, all transmitting and receiving radios
must have this feature activated.
02_Overview.fm Page 16 Monday, November 17, 2003 1:56 PM

17 English
GETTING STARTED
GETTING STARTED
BATTERY INFORMATION
Charging Your Battery
If a battery is new, or its charge level is very
low, you will need to charge it before you can
use it. When the battery level is low and the
radio is in transmit mode you will see the LED
indicator flash red. Upon release of the PTT
button, you will hear an alert tone.
Note: Batteries are shipped uncharged from
the factory. Always charge a new
battery 14 to 16 hours before initial
use, regardless of the status indicated
by the charger.
Note: Do not use the wall charger and
desktop charger at the same time
when charging.
WALL CHARGER
Note: Do not use the wall charger if using
lithium-ion (Li-Ion) or nickel-metal hyride
(NiMH) batteries. The wall charger is for
nickel-cadmium (NiCd) batteries only.
To Charge the Battery
1Turn the radio off.
2Lift the dust cover to expose the audio
accessory connector.
3Insert the charging adapter into the
accessory connector.
4Plug the charging adapter into an electrical
outlet.
• The LED on the charging adapter lights
Red while the charger is plugged into an
electrical outlet.
Note: Do not leave the charger connected
to the radio when it is not connected
to the electrical outlet.
5Unplug the charger from the electrical outlet
and radio after 10 hours.
Note: After the initial charge of 14 to 16
hours, do not charge the battery
more than 10 hours.
03_GetStarted.fm Page 17 Monday, November 17, 2003 1:56 PM

18
English
GETTING STARTED
DESKTOP CHARGERS
Rapid Charger
A list of Motorola authorized batteries and
battery chargers appears on page 35. The
listed chargers will charge only Motorola
authorized batteries. Other batteries may not
charge.
1Turn the radio off.
2Place the battery, with or without the radio, in
the charger pocket.
• The charger LED indicates the charging
progress.
LED color Status
No LED Indication Battery inserted incorrectly
or battery not detected.
Single Green Flash Successful charger
power-up.
Flashing Red*Battery unchargeable or not
making proper contact.
Steady Red Battery is in Rapid charge
mode.
Flashing Yellow Battery in charger but wait-
ing to be charged. The bat-
tery temperature may be too
hot or too cold. The voltage
may be lower than the pre-
determined threshold level
for charging.
Flashing Green†Battery 90% (or more)
charged. Trickle charging.
Green Battery fully charged.
* Remove the battery from the charger and
use a pencil eraser to clean the three metal
contacts at the back of the battery. Place the
battery back into the charger. If the LED
indicator continues to flash red, replace the
battery.
† A standard battery may require 90 minutes to
charge to 90% capacity. Even though new
batteries might prematurely indicate a full
charge (steady green LED), charge the
battery for 14 to 16 hours prior to initial use
for best performance.
LED color Status
03_GetStarted.fm Page 18 Monday, November 17, 2003 1:56 PM
