MD2378 INSTALLATION INSTRUCTION
(A8)
Für die Installationsanweisungen auf deutsch, Siehe Seite 10~11.
Pour l'instruction en français, veuillez vous reporter à la page 12~13.
Para las instrucciones de la instalación en español, favor vea la página 14-15.
Per le Istruzioni in italiano, vedi pagina 16~17.
26"~55" Max:400x400mm/16x16"
Min:75x75mm/3x3"
TV
1 2
x3 x1 x1
If you have any questions, please contact us via [e-mail]
or call us at telephone [phone] (USA) Mon - Fri 10am - 6pm (Pacific time).

Before getting started, let’s make sure this mount is perfect for you!
1 Is your TV VESA
equal to/greater than
75x75mm/3x3" and
equal to/less than
400x400mm/16x16"?
2 Does your TV
(including accessories)
weigh less than
66 LBS (30 kg)?
4 Installation Tools
(Not lncluded)
Yes --- Perfect!
No --- This mount is NOT compatible.
MAX:400mm/16"
MAX:
400mm/16"
Yes --- Perfect!
No --- This mount is NOT compatible.
Band Tape
2M2M
5 Safety Caution
Pencil Screwdriver Electrodrill Socket Wrench
1/2"(13mm)
Stud Finder Awl 7/32"(5.5mm)
Wood Drill Bit
3/8"(10mm)
Masonry Drill Bit Hammer
1
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service via
[e-mail] or call us at telephone [phone] (USA)
Mon - Fri 10am - 6pm (Pacific time).
● This product is designed for use in wood stud and solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount
combined.
● Incorrect installation may result in product damage or body injury. Mounting Dream shall
bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
● Do not apply this product to any purpose not indicated by Mounting Dream.
CAUTION:
Drywall with
wood studs?
Solid concrete
wall?
3 What is your wall
made of?

Parts and Hardware
M4x12mm
M5x12mm
M6x12mm
M8x25mm
M4x30mm
M5x30mm
M6x35mm
M8x50mm
TV Brackets
x2
M5/M6x17mm M8x22mm
M5/M4 M6
10mm 2.5mm
M8
M6
M5
M4
1-1 Select TV Screws
TV back
Bracket Washer
Bracket
Long Screw
Spacer
No, go to PAGE 3 for detailed combination.
Yes, go to PAGE 3 for detailed combination.
TV back
2
Washers
Spacers
TV Screws
x4
x4
x4
x4
x4
x4
x4 x4
x4
x4 x4
x4 x8
x4
1-2 Need Spacer?
Short Screw
Washer
WARNING:This product contains small items that could be a choking hazard if
swallowed. Before starting assembly, verify all parts are included and undamaged. For parts
shortage or damage, please contact us via [e-mail].
NOTE: Not all hardware included will be used.

3
Tips: If you need to combine M8(d/h) screw with 2.5mm spacer(n), you have to remove
the inner circle.
1-3 Attach the TV Brackets
Screw and washer
Spacer(s), screw and washer
No!

For wood stud installations, follow STEP 2A
For concrete installations, follow STEP 2B on PAGE 6
<16mm
(5/8") Max.
16"(406mm)
Min. Wood Stud Size:
nominal 2"(51mm)
actual 1 1/2"(38mm)
Min. Wood Stud Size:
nominal 4"(102mm)
actual 3 1/2"(89mm)
Parts and Hardware
Lag Bolt M8x60mm
M8 WasherAllen Key
Wood Stud Installations
O
x1
Wall Plate
Unit
Mounting Template
x1
x4
x4
x1
4
Centre line
Contact us at telephone [phone] (USA)
Mon - Fri 10am - 6pm (Pacific time) or email us by
[e-mail] to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
4pcs
