Mounting Solutions CMT Series User manual

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
Installation Guide for CMT series Ceiling Plates.
CMT-P
CMT-T50
CMT-CH
CMT-TP
SAFETY INSTRUCTIONS
1. Only entrust loudspeaker mounting equipment to experienced professionals. Also strictly follow the provided safety
instructions. Improperly installed mounting equipment may result in property damage, personal injury and/or liability
for the installing contractor.
2. Always use safety cables! This will prevent equipment from falling during/after setup and while exploiting.
3. Always check if the wall surface is structurally strong enough to support load. Make sure the wall and/or ceiling
structure allows to hold the weight of the speaker including its bracket.
4. Only use appropriate fasteners.
5. Always make sure to securely use and tighten/lock all mounting bolts provided. Loose bolts may become unscrewed
over time due to vibration which could potentially create a safety hazard when not tightened securely.

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
CMT-D telescopic
CMT-D xed

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
Installation Instructions:
1. Screw the bracket to the ceiling by
using all (4) screw.
CMT-P
2. Install (screw) the distance tubes
that bracket. And tighten the xing
bolts to lock.
2
1
CMT-T50
1
2
1. Screw the bracket to the ceiling by
using all (4) screw.
2. Install (screw) the distance tubes
that bracket. And tighten the xing
bolts to lock.

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
1
CMT-TP
2
3. Adjust the tilt distance tubes of the
bracket and tighten the xing bolts to
lock in the position of your need.
3
1. Screw the bracket to the ceiling
by using all (4) screw. Use for uneven
ceilings.
2. Install (screw) the distance tubes
that bracket. And tighten the xing
bolts to lock.

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
CMT-CH
1
1. Insert the channel retainer nut into
the U-shaped prole and turn it 90°
until it stops.
3. Install (screw) the distance tubes
that bracket. And tighten the xing
bolts to lock.
2. Screw the bracket into the channel
retainer nuts to the U-prole by using
all (2) screw.
2
3

Installation Guide
CMT series
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
CMT-D telescopic
When using a telescopic tube, set the position as you want and x it with bolts.
