Movies 2 go AVXMTGHR1D Installation and operating instructions

AVXMTGHR1D
7” LCD MONITOR
WITH BUILT-IN DVD PLAYER
FOR REAR SEAT ENTERTAINMENT
128-8944B
OPERATION MANUAL / INSTALLATION GUIDE
PUSH

Important Notice
Installation of headrest products require careful planning and preparation. Be extremely careful
of seats that have airbags built into them. Keep wiring away from any air bag wiring (usually
identified by yellow connectors and yellow wire jackets). Damage to air bag wiring can result in
personal injury to vehicle occupants. If you have any questions regarding wire routing or
installation in a vehicle, please contact Audiovox Technical Support at 1-800-225-6074.
When connecting power and ground in a mobile video installation, insure that the ACC wire is
fused at the point where it is connected to the vehicle ACC wiring. Failure to do so can result in
damage to the vehicle if a short circuit develops between the vehicle connection point and the
mobile video product.
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if
the LCD panel or video monitor is used for vehicle information, system control, rear or side
observation or navigation. If the LCD panel or video monitor is used for television reception,
video or DVD play, the LCD panel or video monitor must be installed so that these features will
only function when the vehicle is in “park” or when the vehicle’s parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that operates
when the vehicle is in gear or when the parking is not applied must be installed to the rear of the
driver’s seat where it will not be visible, directly or
indirectly, to be operator of the motor vehicle.
Licensed under one or more of the following patents:
Patent NOS. 7,245,274 , 6,899,365 and 6,678,892

FEATURES
• 7” Digital Thin Film Transistor (TFT) Active Matrix Liquid Crystal Display (LCD) Monitor
• Built-in DVD Player
• Last position memory for DVD player
• Three Audio / Video Source inputs (DVD, AV and AUX)
• USB 2.0 port / SD Card Reader input
• Screen mode selection (4:3, 16:9)
• On Screen Display (OSD) for control of picture quality and functions
• Full function remote control
• Plays DVD, CD and MP3 discs
• IR headphone (optional)
SPECIFICATIONS
Specifications subject to change without notice.
Resolution
Pixels
Operation Temperature
Storage Temperature
Backlit life
Video Display System
Headphone Audio Output
Video Output
Power Source
Dimension (L x W x H)
480x234
336,960
32 ~113º F (0 ~ 45º C)
-4 ~ 149º F (-20 ~ 65º C)
20,000 Hours
NTSC / PAL / AUTO
0.03W @ 32 ohms
1.0Vp-p @ 75 ohms
12 VDC
147mm x 275mm x 200mm
Type TFT Active Matrix LCD
AVXMTGHR1D 3
5.7in x 10.8in x 7.8in

MATERIAL TO USE IN THIS PACKAGE:
NOTE: Headrest cables are included with the headrest DVD player and the headrest monitor.
1) AVXMTGHR1D System Monitor with DVD Player (AVXMTGHR1D) (1pc)
NOTE: The AVXMTGHR1D monitor has been designed to
be interchangeable from one headrest to the other. The
headrests will still have the Green and Red Din cables on
them and should be connected to their respective
connectors. The headrest cover from the manufacturer is
covered with shale colored vinyl.
1) Remote Control
(P/N 136-5150) - (1pc)
3) AV IN / Power Cable, 8 Pin Din to 3 RCA (Red)
(P/N 112-4149)-(1pc)
5) Black Vinyl Headrest Cover
(P/N 126-1377)-(1pc)
4) AV OUT Cable, 8 Pin Din to 3 RCA (Green)
(P/N 112-4160)-(1pc)
2) AV Adapter Cable
(P/N )-(1pc)112B3227
6) Pewter Vinyl Headrest Cover
(P/N 126-1378)-(1pc)
7) Shrink Tubing, Black
(P/N 138-1495 )-(2pcs)
8)
(P/N )-(1box)
Support Tube Adaptor Box
170-0161
POWER SO URCE
VOLUME
-+
MUTE
ENTER
PIX
PREV NEXT PAUSE
STOPFFPL AYFR
AUDIOSUBTIT LEREPEATSETUP
ZOOM
DVD SOURC E
DISC ME NU DISPLAY
1 2 3 4
5 6 7 8
9 0
FMM ON/O FF CHANNEL SELECT
SYSTEM MENU
AVXMTGHR1D 4
PUSH

HEADREST COVER REPLACEMENT:
1. Using a Philips screwdriver, unscrew the two Philips screws and lift the bottom edge
of the monitor upward.
2. Remove the velcro tabs securing the headrest cover.
3. Replace the headrest cover with the desired color and secure the headrest cover by
re-attaching the velcro tabs.
4.Place the monitor cable into the space on the right side of the headrest and lower the
monitor into position to align the two Philips screws with the screw holes in the headrest.
Close the screen and press the PUSH button to secure the screen.
5.Tighten screws
AVXMTGHR1D 5
NOTE: If desired, replace the headrest cover before installing the headrest in the vehicle.
Unscrew Philips Screws
Remove Velcro Tabs
Push
Tighten Philips Screws

VEHICLE PREPARATION
AVXMTGHR1D 6
1) Decide on the system configuration and the options that will be installed.
2) Read the manuals and get familiar with the electrical requirements and
connections.
3) Decide on the mounting locations and methods of mounting the products that
will be connected to the AVXMTGHR1D.
4) Prepare the vehicle by removing any interior trim necessary to gain access to
the vehicle's wiring as well as all areas where interconnecting wire harnesses
will be located. The mounting method, and the location will vary from vehicle to
vehicle, so this manual will only focus for the installation of the AVXMTGHR1D
Monitors in the supplied configuration. The best location for the AVXMTGHR1D
System components is:
a. Monitors: Vehicle specific Headrest NOTE: The Master Monitor should be
installed in the passenger position most used.)
5) Locate an accessory power source (+12VDC present when the ignition key is in
the accessory and run positions. 0VDC should be present when the ignition key
is in the OFF position), a constant power source (+12vdc) at all times,
regardless of the ignition key and a good ground. Generally, these wires can be
found at the ignition switch or fusebox.
NOTE: Ensure that both the constant and accessory power is fused at the
source. Failure to do so may result in vehicle wiring damage.)
6) Run the wiring harnesses throughout the vehicle as necessary. (Refer to the
Wiring Diagrams on page 8, as well as the wiring instructions for the individual
components and accessory options being installed). Be sure, that all the wiring
is protected from sharp edges and is routed in such a manner that it will not be
pinched, when it is fully installed. Be sure to leave enough slack in the wiring at
each component to allow sufficient working room. Be sure to leave enough slack
in the monitor cables to allow the headrest to move up or down, and seat
movement.
7) Remove all the A/V system components from their packaging and then place
them in the vehicle at their respective locations.

8) Install the headrests:
a. Remove vehicle's original headrests.
b. insert appropriate support tube adaptors in vehicle post guides. (if needed)
c. Hold the headrest above the seat and insert the two cables into the vehicle
support guides Make sure that the headrest is in the correct position (Display
facing the rear).
d. Route the cables through the seat back and out the bottom of the seat while
pulling the cables to remove the slack. Be sure to leave enough slack in the
monitor cables to allow the headrest to move up or down.
9) Connect all the components together (electrically) and verify proper operation of
all the system functions.
AVXMTGHR1D 7
Wireless FM Modulator
The AVXMTGHR1D is equipped with a built-in wireless FM Modulator, that
allows you to listen to the DVD audio signal by tuning your vehicle’s radio to the
selected frequency, (CH1 87.7MHz, (CH2 88.1MHz, CH3 88.5MHz, CH4
88.9MHz, CH5 106.7.1MHz, CH6 107.1MHz, CH7 107.5MHz, CH8 107.9MHz.
This feature is accessed by using the FM transmitter buttons on the remote
(FMM ON/OFF, and CHANNEL SELECT).
Whenever the FM Modulator is on, broadcast reception on the vehicles radio will
be poor. Switching the FM Modulator off will allow normal radio reception.
NOTE: In certain areas where there are a large number of FM radio stations (e.g.
large cities, urban areas), the reception of the FM signal may not be satisfactory,
resulting in static, distorted sound or signal bleed thru from strong local radio
stations. This is not a defect in the product, but the result of a stronger local radio
station overpowering the wireless FM transmitter in your headrest monitor.

AVXMTGHR1D WIRING DIAGRAM
Headrest Monitor
GREEN
RED
AVXMTGHR1D 8
PUSH
8 Pin (M) Din Cable Red with RCA Cable
(P/N 112-4149)-(1pc)
8 Pin (M) Din Cable Green with RCA Cable
(P/N 112-4160)-(1pc)
Video Out Yellow
Audio Out Right Red
Audio Out Left White
12V+VDC
Ground-
Video In Yellow
Audio In Right Red
Audio In Left White

AVXMTGHR1D 9
PUSH
AVXMTGHR1D
(FRONT VIEW)
CONTROLS AND INDICATORS DIAGRAM
POWER/SOURCE
SCREEN RELEASE
PULL DOWN
PLAY/PAUSE
STOP
VOLUME /NEXT
SYSTEM MENU
VOLUME /PREVIOUS
IR SENSOR
IR HEADPHONE
TRANSMITTER LENS
AUX IN SD USB PHONE
AUX IN JACK
USB PORT
SD CARD READER
COVER
LCD PANEL
PUSH
DVD DISC
(FRONT VIEW MONITOR OPEN)
(BOTTOM VIEW)
HEADPHONE JACK

AVXMTGHR1D 10
REMOTE CONTROL OPERATION
NOTE: The remote control has a battery installed with a pull tab to prevent
battery discharge. Remove the pull tab before attempting to use the remote.
Battery Replacement
1. Remove the battery holder.
2. Insert the battery (CR2025) into the battery holder and insert the battery
holder into the remote. Be sure to observe the correct polarity.
3. Align the battery holder with the remote control and push until the holder
clicks.
POWER SOURC E
VOLUME
-+
MUTE
ENTER
PIX
PREV NEXT PAUSE
STOPFFPLAYFR
AUDIOSUBTITLEREPEATSETUP
ZOOM
DVD SOURCE
DISC MENU DISPLAY
1 2 3 4
5 6 7 8
9 0
FMM ON/OF F CHANNEL S ELECT
SYSTEM MENU
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Remote Control Function Description

* Function control is available on the unit and the remote control.
1. POWER ( ) Button*
Press this button to turn the unit ON and OFF.
2. SOURCE Button*
Each time the button is pressed, the audio / video source will change in the
following sequence:
DVD > AV > AUX
NOTE: The USB device and the SD card can be accessed using the DVD
source button. Refer to Item 26.
MUTE Button
Press this button to mute all the audio. Pressing the button again restores the sound
to the previously set level.
4. CURSOR (pqt u) Buttons
Use these buttons to navigate the menu selection on the screen.
5. PREVIOUS (9) Button*
Press to return to the previous chapter or track.
6. FR SCAN BACKWARD (7) Button
Press to search in the backward direction. Press repeatedly to change the search speed
from 2, 4, 8, 16 and 32 times the normal speed. Pressing the fifth time returns to normal
speed..
7. PLAY (u) Button*
Press to activate the play mode when a disc is loaded in the disc compartment,a
USB memory device or a SD card is connected to the unit .
8. SETUP Button
Press the DVD button and SETUP button to display the Setup Menu which allows the
user to change the DVD player options such as OSD Language, Video, Rating, etc.
Refer to the settings and adjustment section for more information.
9. REPEAT Button
Allows the user to repeat a selected track, folder, title, chapter, or all.
11
AVXMTGHR1D

10. ZOOM Button
Press this button to enlarge or decrease the picture size when playing a DVD disc.
Press ZOOM button DVD Player performs
Once Enlarges the picture 2X
Twice Enlarges the picture 3X
3 Times Enlarges the picture 4X
4 Times Reduces the picture 1/2
5 Times Reduces the picture 1/3
6 Times Reduces the picture 1/4
7 Times Picture is returned to original size
11. SYSTEM MENU Button
Press this button to enter the system menu which contains features and options to
customize the screen display and change the OSD language.
12. NUMBER Buttons
Allows the user to enter numbers 0 to 9 for selection of CD tracks, DVD chapters,
and passwords.
13. FMM ON/OFF Button
Turns the wireless FM Modulator on or off.
14. FMM CHANNEL SELECT Button
Selects the wireless FM Modulator Frequency:
(CH1 87.7MHz, CH2 88.1MHz, CH3 88.5MHz, CH4 88.9MHz, CH5 106.7MHz,
CH6 107.1MHz, CH7 107.5MHz, CH8 107.9MHz.
15. DISC MENU Button
Press this button to enter the DVD root menu.
16.
17. SUBTITLE Button
Press to display and select the available subtitle language in DVD mode. Each time he
button the subtitle language changes.
NOTE: The type and number of subtitle languages vary from disc to disc.
18. AUDIO Button
Press to display and select the available AUDIO languages in DVD mode.
Each time you press the button, the language changes.
NOTE: The audio languages vary from disc to disc.
DISPLAY
Press to display current disc information while the disc is playing. The information
displayed will be Title Elapsed, Title Remaining, Chapter Elapsed and Chapter
Remaining. Pressing the button will also turn the display off.
t
is pressed Pressing the button will also turn the
subtitles off.
12 AVXMTGHR1D

19. FF SCAN FORWARD (8) Button*
Press to search in the forward direction. Press repeatedly to change the search speed
from 2, 4, 8, 16 and 32 times the normal speed.
20. STOP (n) Button*
Press to stop playback.
21. NEXT (:) Button*
Press to skip to the next chapter or track.
22. PAUSE ( II ) Button*
Allows the user to pause the playback. Pressing pause again or pressing the Play
button will resume normal playback.
23. ENTER Button
Used to implement a selected setting or menu option.
24. PIX (Picture Select) Button
Each time this button is pressed, the OSD picture adjustment displays the “Adjustment
bar” for BRIGHTNESS, CONTRAST, COLOR, TINT (For NTSC only). Once the
desired adjustment bar is displayed, use the VOLUME+ and VOLUME– button to
adjust the setting. The display will automatically turn or if no adjustments are made
within 6 seconds is pressed.
25. VOLUME DOWN (-) or UP (+)*
Press to select the level of the picture adjustments when the unit is in picture
adjustment mode or to increase or decrease the volume for the wired headphones.
26. DVD Source*
This button is only active when remote control is in the DVD mode. Each time the
button is pressed one of the sources (DVD, USB and SD Card ) will be selected. If a
USB device or SD Card is not plugged in, the unit will remain on DVD Source.
Press to change source in sequence of DVD > USB > SD Card.
NOTE: The DVD Source button is used to access MP3 and audio CDs when these
discs are in the disc compartment.
AVXMTGHR1D 13

MENU ADJUSTMENT
The System Menu contains features and options that allow you to customize your
system.
1) Press the “ ” button on unit or press the TV button and the SYSTEM MENU
button on the remote control, the menu display below will appear on screen.
2) Use the “+” “-” buttons to change the setting .
3) To select the next menu press the “ ” button or the SYSTEM MENU button on the
remote control.
MENU DISPLAY
The first adjustment to appear is the volume adjustment. The volume can be adjusted
from 1 to 32.
The picture can be adjusted under the system menu. The picture adjustments consist
of brightness (BRIGHT), CONTRAST, COLOR, TINT (for NTSC only). The
adjustments range from 1 to 32.
The screen mode select feature allows the user to change the screen format (aspect
ratio from 4:3 or to 16:9).
The IRT can be set to Channel A or Channel B for use with optional wireless
headphones. The IRT function can also be set to off.
SCREEN MODE 16:9
AVXMTGHR1D
14
16
BRIGHT 16
CONTRAST 16
COLOR 16
TINT 0
IRT A

The FM Modulator adjustments consist of turning the FM Modulator on or off and
selecting the FM Modulator frequency. The wireless FM Modulator Frequencies
that can be selected are:
(CH1 87.7MHz, CH2 88.1MHz, CH3 88.5MHz, CH4 88.9MHz,
CH5 106.7MHz, CH6 107.1MHz, CH7 107.5MHz, CH8 107.9MHz.
The OSD Language feature allows the user to select the language for the on-
screen display. The user can either select English, Dutch, French, Spanish,
Russian or Chinese for the OSD language.
The RESET function allows all setting options to be reset to factory settings.
SETTINGS AND ADJUSTMENTS
The Setup Menu contains features and options that let you customize your DVD
player. For example, you can set a language for the on-screen display or prevent
DVD playback for children.
Using the Setup Menu
1. Press the DVD and SETUP buttons on the remote. The Setup Menu appears on
the screen. There are four menu pages which comprise the Setup Menu.
2. To select and set an option, use the cursor buttons (t or u) to move the highlight
to the desired page.
3. After entering the highlighted page, use the cursor buttons ( p or q) to highlight
the desired option.
4. Press u to open the sub menu that contains the different options available.
Press p or q to highlight the desired option, and press ENTER to confirm the
selection.
5. Repeat steps 3 and 4 to set the options that reside on the same menu page.
6. To change to another menu page, use the cursor buttons (t or u) then, repeat
steps 2 through 5.
FMM OFF
OSD LANGUAGE ENGLISH
RESET
15
AVXMTGHR1D

AVXMTGHR1D 16
GENERAL PAGE
TV Display
The TV Display feature allows the user to change the screen format (aspect ratio to
4:3 PScan, 4:3 LB, or 16:9 Wide).
1. To select the screen aspect ratio mode use the cursor button p or q to
highlight TV DISPLAY. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q to
highlight the desired option, and press ENTER to confirm the selection. Use the
cursor button t to return to the options.
Screen Saver
The closed captions feature allows the user to turn the screen saver function on or
off.
1. To select the screen aspect ratio mode use the cursor button p or q to
highlight CLOSED CAPTIONS. Press cursor button u to open the sub menu
that contains the different options available. Press the cursor button p or q to
highlight the desired option, and press ENTER to confirm the selection. Use the
cursor button t to return to the options.
Last Memory
The last memory function allows DVD playback to begin from the point when
playback was last stopped. The last memory feature allows the user to turn the last
memory feature function on or off.
1. To select the screen aspect ratio mode use the cursor button p or q to
highlight LAST MEMORY. Press the cursor button u to open the sub menu
that contains the different options available. Press the cursor button p or q to
highlight the desired option, and press ENTER to confirm the selection. Use the
cursor button t to return to the options.
General Audio
General Setup Page
TV Display
Last Memory
Wide
On
On
Goto General Setup Page
Exit
Preference
Screen Saver

AUDIO SETUP PAGE
Sound Mode
The sound mode feature allows the user to apply preset sound effects to the unit’s
audio output signal. The user may choose from: None ,Rock, Pop, Live, Dance,
Techno, Classic and Soft.
1. To select the sound mode use the cursor button p or q to highlight SOUND
MODE. Press the cursor button u to open the sub menu that contains the
different options available. Press the cursor button p or q to highlight the
desired option, and press ENTER to confirm the selection. Use the cursor
button t to return to the options.
Bass Boost
The bass boost feature increases the audio bass response and allows the function
to be turned on or off.
1. To select the bass boost feature use the cursor button p or q to highlight
BASS BOOST. Press the cursor button u to open the sub menu that contains
the different options available. Press the cursor button p or q to highlight the
desired option, and press ENTER to confirm the selection. Use the cursor
button t to return to the options.
Super Bass
The super bass feature increases the audio bass response and allows the function
to be turned on or off.
1. To select the super bass boost feature use the cursor buttonp or q to highlight
SUPER BASS. Press the cursor button u to open the sub menu that contains
the different options available. Press the cursor button p or q to highlight the
desired option, and press ENTER to confirm the selection. Use the cursor
button t to return to the options.
Treble Boost
The treble boost feature increases the audio treble response and allows the function
to be turned on or off.
1. To select the treble boost feature use the cursor buttonp or q to highlight
TREBLE BOOST. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q to
highlight the desired option, and press ENTER to confirm the selection. Use the
cursor button t to return to the options.
General Audio
Audio Setup Page
Sound Mode
Goto Audio Setup Page
Exit
Preference
Bass Boost
Super Bass
Treble Boost
None
Off
Off
Off
Equalizer
AVXMTGHR1D 17

18 AVXMTGHR1D
PREFERENCE PAGE
NOTE:
seven
The Preference page can only be accessed when the disc compartment is
empty.
TV Type
1. To select the TV type use the cursor button p or q to highlight TV TYPE.
Press the cursor button u to open the sub menu that contains the different
options available. Press the cursor button p or q to highlight the desired
option, and press ENTER to confirm the selection. Use the cursor button t to
return to the options.
This menu page available if there is no disc in the disc tray, the disc tray is open
or the disc in the disc tray is stopped.
There are items in the PREFERENCE PAGE. They are TV TYPE,
AUDIO, SUBTITLE, DISC MENU, PARENTAL, PASSWORD, and DEFAULT.
This function matches video output of the unit to the broadcast system of a connected
TV. The unit supports both National Television System Committee (NTSC) and Phase
Alternating Line (PAL) television broadcasting standards.
Options:
PAL: Select this mode if the connected TV is a PAL system. The video signal
of a NTSC disc will be output in PAL format.
AUTO: Select this mode if the connected TV is multi-system. The output
format of video signal will be in accordance with the video signal of
the disc.
NTSC: Select this mode if the connected TV is a NTSC system. The video
signal of a PAL disc will be output in NTSC format.
General Audio ExitPreference
Preference Page
TV Type
Audio
Subtitle
Disc Menu
Parental
Password
Default
Goto Preference Page
NTSC
Eng
Eng
Eng

Audio Menu
This item allows a user to select a preferred audio language. This function
only applies to discs encoded with different audio languages.
Options: English, French, Spanish, Chinese, Japanese, Korean, Russian,
and Thai.
NOTE: If the selected language is not available for the currently playing disc,
the disc's default setting is applied.
This item allows a user to select a preferred subtitle language. This function only
applies to discs encoded with subtitles.
Options: English, French, Spanish, Chinese, Japanese, Korean, Russian,
and Thai.
NOTE: If the selected language is not available for the currently playing disc,
the disc's default setting is applied.
This item allows a user to select a preferred disc menu language.
Options: English, French, Spanish, Chinese, Japanese, Korean, Russian,
and Thai.
NOTE: If the selected language is not available for the currently playing disc,
the disc's default setting is applied.
1.
1. To select the audio feature use the cursor button p or q to highlight
AUDIO. Press the cursor button u to open the sub menu that contains
the different options available. Press the cursor button p or q to
highlight the desired option, and press ENTER to confirm the selection.
Use the cursor button t to return to the options.
Subtitle
1. To select the subtitle feature use the cursor button p or q to highlight
SUBTITLE. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q
to highlight the desired option, and press ENTER to confirm the
selection. Use the cursor button t to return to the options.
Disc Menu
To select the disc menu feature use the cursor button p or q to highlight
DISC MENU. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q
to highlight the desired option, and press ENTER to confirm the
selection. Use the cursor button t to return to the options.
AVXMTGHR1D 19

Parental
1 G
2 PG
3 PG – 13
4 R
5 NC17
6 Adult
To select the parental feature use the cursor button p or q to highlight
PARENTAL. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q
to highlight the desired option, and press ENTER to confirm the
selection. Use the cursor button t to return to the options
Password
To select the password feature use the cursor button p or q to highlight
PASSWORD. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q
to highlight the desired option, and press ENTER to confirm the
selection.
2. Use the cursor button t to return to the options.
Default
To select the default feature use the cursor button p or q to highlight
DEFAULT. Press the cursor button u to open the sub menu that
contains the different options available. Press the cursor button p or q
to highlight the desired option, and press ENTER to confirm the
selection. Use the cursor button t to return to the options.
This item allows the user to limit the content of movie playback from Kid Safe to
Adult. The lower the value, the more strict the control. Movies rated higher than
the level set for the parental lock can not be viewed without entering the correct
password.
NOTE: The rating level can be changed only when the correct password is
provided. This function only works with those discs with parental function.
This item allows a user to restore all the default settings except the settings in
the Password Setup Page and the PARENTAL item.
Options:
1.
This item allows a user to change the password. The default password is 3308.
1.
To change the password:
1. Enter the old password in the OLD PASSWORD row.
2. Enter the new password in the NEW PASSWORD row.
3. Enter the new password again in the CONFIRM PWD row.
NOTE: You may reset the password if you forget the old password by using the
default password: 3308. This password is always active even after you have
selected your own password and changed it. To avoid the possibility of others
using the default password to set the parental level and change the password,
record this default password in another area and delete it from this manual.
1.
20 AVXMTGHR1D
