Railway Computers
V2616 Series
Introduction
x86-based embedded computer with Intel Core 2 Duo, dual LANs (M12
connectors), serial ports, 6 DIs, 2 DOs, VGA, DVI-D, 3 USB ports, 1
SATA storage connector, 2 removable storage trays, CompactFlash
›High performance network video recorder for rolling stock
applications
›Compliant with EN 50121-4 and essential sections of EN 50155
›IEC 61373 certified for shock and vibration resistance
›Two removable drive trays for 2.5” SSDs or HDDs
›Supports RAID 1/0 functions for data reliability
V2616 Series embedded computers are based on the Intel Core 2 Duo
x86 processor, and feature 2 RS-232/422/485 serial ports, dual LAN
ports, and 3 USB 2.0 hosts. V2616 computers also provide VGA and
DVI-I outputs, and are also compliant with the essential sections of EN
50155 covering operating temperature, power input voltage, power
surges, ESD, and vibration, making them particularly well-suited for
railway and industrial applications.
The V2616's CompactFlash socket provides these computers with the
reliability needed for industrial applications that require data buffering
and storage expansion. Most importantly, the V2616 computers come
with 2 removable slots for inserting additional storage media, such as
hard disks or SSD drives, and can offer RAID 0 and RAID 1 functions
for data reliability.
The V2616 series come pre-installed with Linux or Windows
Embedded Standard 2009 to provide programmers with a familiar
environment in which to develop sophisticated, bug-free application
software at a low cost.
Appearance
Front View
Removabel Trays
for HDD x 2
CompactFlash
Socket
Protection Lock
Protection Lock
System LEDs
(Storage, Power)
Seria/LAN
LEDs
Serial/LAN
LED Definitions

2www.moxa.com [email protected]
Railway Computers
Rear View
Hardware Specifications
Computer
CPU: Intel Core 2 Duo SP9300, dual core 64 bit threaded 2.26 GHz, 6
MB for L2 cache
OS (pre-installed): Linux, or Windows Embedded Standard 2009
System Chipset: Intel GS45 + ICH9-M
FSB: 1066
System Memory: 4 GB capacity, 2 GB pre-installed: 2 slots of 2 GB
DDR3-1066 200 pin SO-DIMM SDRAM
USB: 3 USB 2.0 compliant hosts; 2 with type A connectors supporting
system bootup, 1 with M12 connector
Storage
Built-in: 2 GB onboard industrial CompactFlash card, for root file
system
Storage Device Support:
• 2 removable drive trays, for 2.5” SSD or HDD
• (Optional) Internal SATA II drive slot, for 2.5” SSD or HDD
Other Peripherals
KB/MS: 1 PS/2 interface supporting standard PS/2 keyboard and
mouse through Y-type cable
Audio: Line-in, line-out interface
Display
Graphics Controller: Intel GS45 integrated graphics engine
VGA Interface: DB15 female connector, up to 2048 x 1536 resolution
DVI Interface: DVI-D connector (chrontel CH7307 SDVO to DVI
transmitter), up to 1600 x 1200 resolution
Ethernet Interface
LAN: 2 auto-sensing 10/100/1000 Mbps ports (M12)
Serial Interface
Serial Standards: 2 software-selectable RS-232/422/485 ports* (DB9
male)
Optical Isolation Protection: 2 KV
ESD Protection: 4 KV for all signals
Magnetic Isolation Protection: 1.5 KV built-in
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxDA(-), TxDB(+), RxDB(+), RxDA(-), GND
RS-485-4w: TxDA(-), TxDB(+), RxDB(+), RxDA(-), GND
RS-485-2w: DataA(-), DataB(+), GND
Digital Input
Input Channels: 6, source type
Input Voltage: 0 to 30 VDC at 25 Hz
Digital Input Levels for Dry Contacts:
• Logic level 0: Close to GND
• Logic level 1: Open
Digital Input Levels for Wet Contacts:
• Logic level 0: +3 V max.
• Logic level 1: +10 V to +30 V (Source to DI)
Isolation: 3 KV optical isolation
Digital Output
Output Channels: 2, sink type
Output Current: Max. 200 mA per channel
On-state Voltage: 24 VDC nominal, open collector to 30 VDC
Connector Type: 10-pin screw terminal block (6 DI points, 2 DO
points, DI Source, GND)
Isolation: 3 KV optical isolation
LEDs
System: Power x 1, Storage x 1
LAN: 100M/Link x 2, 1000M/Link x 2
Serial: TX x 2, RX x 2
Physical Characteristics
Housing: Aluminum
Weight: 5 kg
Dimensions:
Without ears: 287 x 250 x 101 mm (11.29 x 9.84 x 3.97 in)
With ears: 287 x 290 x 101 mm (11.29 x 11.41 x 3.97 in)
Mounting: wall
Environmental Limits
Operating Temperature: (with SSD installed) -25 to 55°C (-13 to
140°F)
Storage Temperature: (with SSD installed) -30 to 60°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-vibration: EN 50155 standard
Anti-shock: EN 50155 standard
Conformal Coating: Available on request
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-07, EN 60950-1
VGA
Output
DVI-D
Output
Power Button
Audio Input
Output
10/100/1000 Mbps
LAN Port x 2 (M12)
PS/2
USB 2.0
Host (M12)
USB Port (M12)
Pin Assignment
Antenna Hole x 2
(Reserved for RF SMA type)
Serial Port x 2
(RS-232/422/485)
USB 2.0
Host x 2 (Type A)
DI x 6
DO x 2
Power Input
DC 24V

3www.moxa.com [email protected]
Railway Computers
EMC: EN 55022 Class A, EN 61000-3-2 Class D, EN 61000-3-3, EN
55024, FCC Part 15 Subpart B Class A
Rail Traffic: EN 50155, EN 50121-2-3, EN 50121-4, IEC 61373
Green Product: RoHS, CRoHS, WEEE
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting
1-255 level time interval system reset, software programmable
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
Note: These hardware specifications describe the embedded computer unit itself,
but not its official accessories. In particular, the wide temperature specification
does not apply to accessories such as power adaptors and cables.
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 Kbps (non-standard baudrates supported;
see user’s manual for details)
Power Requirements
Input Voltage: 24 VDC (9 to 36 V), M12 connector
Note: 24 VDC is EN 50155 compliant
Power Consumption: • 50 W
• 2 A @ 24 VDC
Power Button: On/off (front panel)
Dimensions
Unit: mm (inch)
101(3.97)
290(11.41)
250(9.84)
287(11.29)
198(7.79)
Software Specifications
Linux
OS: Debian Linux 5.0, Lenny; kernel 2.6.32
File System: EXT2/EXT3
Internet Protocol Suite: TCP, UDP, IPv4, SNMPv1/v2c/v3, ICMP, ARP,
HTTP, CHAP, PAP, SSH 1.0/2.0, SSL, DHCP, NTP, NFS, Telnet, FTP,
TFTP, PPP, PPPoE
Internet Security: OpenVPN, iptables firewall
Web Server (Apache): Allows you to create and manage web sites;
supports PHP and XML
Terminal Server (SSH): Provides secure encrypted communications
between two un-trusted hosts over an insecure network
Dial-up Networking: PPP (Linux) allows machines to connect to the
Internet through dialup lines as either PPP server or client. Works with
‘chat’, ‘dip’, and ‘diald’, among (many) others. Supports IP, TCP, UDP,
and Novell IPX.
File Server: Enables remote clients to access files and other resources
over the network
Watchdog: Features a hardware function to trigger system reset in a
user specied time interval (Moxa API provided)
Application Development Software:
• Moxa API library (Watchdog timer, Moxa serial I/O control, Moxa DI/
DO API)
• GNU C/C++ compiler
• GNU C library
• Perl
Windows XP Embedded
OS: Windows Embedded Standard 2009 SP3
File System: NTFS
Internet Protocol Suite: DHCP, DNS, FTP, HTTP, SNTP, NTP, Telnet,
SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP,
CHAP, EAP, PPPoE, PPTP, NetBIOS

4
Railway Computers
© Moxa Inc. All Rights Reserved. Updated Feb. 27, 2013. Specications subject to change without notice. Please visit our website for the most up-to-date product information.
Ordering Information
Package Checklist
• V2616 embedded computer
• Wall mounting Kit
• PS2 to KB/MS Y-type cable
• Documentation and software CD or DVD
• Quick installation guide (printed)
• Warranty card
Available Models
V2616-XPE: x86 Embedded computer with Intel Core 2 Duo, VGA, DVI, 2 LANs, 2 Serial Ports, 6 DIs,
2 DOs, 3 USB 2.0 Ports, 24 VDC Power ,Windows XPE, -25 to 55°C operating temperature (EN
50155 Class T1)
V2616-LX: x86 Embedded computer with Intel Core 2 Duo, VGA, DVI, 2 LANs, 2 Serial Ports, 6 DIs,
2 DOs, 3 USB 2.0 Ports, 24 VDC Power, Linux, -25 to 55°C operating temperature (EN 50155 Class
T1)
Note: Conformal Coating is available on request.
Optional Accessories (can be purchased separately)
PWR-24250-DT-S1: Power adaptor
PWC-C7US-2B-183: Power cord with 2-pin connector, USA plug
PWC-C7EU-2B-183: Power cord with 2-pin connector, Euro plug
PWC-C7UK-2B-183: Power cord with 2-pin connector, British plug
PWC-C7AU-2B-183: Power cord with 2-pin connector, Australia plug
PWC-C7CN-2B-183: Power cord with 2-pin connector, China plug
DK-DC50131-01: DIN-Rail mounting kit
M12 Connectors (can be purchased separately)
M12A-5P-IP68: Field-installation A-coded screw-in power connector, 5-pin female M12 connector, IP68-rated
M12A-8PMM-IP68: Field-installation A-coded screw-in Gigabit Ethernet connector, 8-pin female M12 connector, IP68-rated
M12A-5PMM-IP68: D-coded screw-in USB connector, 5-pin male M12 connector, IP68-rated
M12 Cables (can be purchased separately)
CBL-M12(FF5P)/Open-100 IP67: 1-meter A-coded M12-to-5-pin power cable, 5-pin female M12 connector, IP67-rated
CBL-M12MM8PRJ45-BK-100-IP67: 1-meter A-coded M12-to-RJ45 Cat-5E UTP Gigabit Ethernet cable, 8-pin male M12 connector, IP67-rated
Web Server (IIS): Allows users to create and manage websites
Remote Registry Service: Enables remote users to modify registry
settings on this computer
Remote Desktop: The Terminal Server Remote Desktop component
provides remote access for the desktop of a computer running
Terminal Services
Watchdog: Features a hardware function to trigger system reset in a
user specied time interval (Moxa API provided)
Enhanced Writer Filter: Redirect disk write operations to volatile
(RAM) or non-volatile (disk) storage
File Based Write Filter: The File Based Write Filter (FBWF) component
redirects all write requests directed at protected volumes to the overlay
cache, which records and displays the changes while preserving the
protected status of the target volume.
Application Development Software:
• Moxa API library
• Microsoft .NET 3.5, with SP1
• Active Directory Service Interface (ADSI) Core
• Common control libraries
• Common le dialogs
• Direct3D, DirectPlay, DirectShow, and Direct show lters
• Mapi32 libraries
• Message Queuing (MSMQ) Core
• Microsoft Visual C++ run time libraries
• Power management dynamic-link library
• RPC
• Windows API, script engines, and WMI
Silverlight 4: A free runtime framework that powers rich application
experiences and delivers high quality, interactive video across multiple
platforms and browsers, using the .NET framework
