Overview
The UC-8112-ME-T computing platform is designed for embedded data
acquisition applications. The UC-8112-ME-T computer comes with one or
two RS-232/422/485 serial ports and dual 10/100 Mbps Ethernet LAN
ports, as well as a Mini PCIe socket to support cellular modules. These
versatile communication capabilities let users efficiently adapt the
UC-8112-ME-T to a variety of complex communications solutions.
Package Checklist
Before installing the UC-8112-ME-T, verify that the package contains the
following items:
•UC-8112-ME-T embedded computer (with SD card)
•Power jack
•3-pin terminal block for power
•5-pin terminal block for UART x 2
•Quick installation guide (printed)
•Warranty card
IMPORTANT: Notify your sales representative if any of the above items
are missing or damaged.
UC-8112-ME-T Panel Layout
The following figures show the panel layouts of the UC-8112-ME-T.
Top Panel View

- 3 -
Bottom Panel View
Front Panel View
LED Indicators
LED Name
Color
Function
USB Green
Steady On
USB device is connected and
working normally.
Off
USB device is not connected.
SD Green
Steady On
SD Card inserted and working
normally.
Off
SD card is not detected.
Power Green Power is on and the computer is working
normally.
Off
Power is off.
LAN1/
LAN 2
(RJ45
connector)
Green
Steady On
100 Mbps Ethernet link
Blinking
Data transmission in progress
Yellow
Steady On
10 Mbps Ethernet link
Blinking
Data transmission in progress
Off
Ethernet is not connected.

- 4 -
Wireless
Signal
Strength
Green
Yellow
Red
The number of glowing LEDs indicates the
signal strength.
3 (Green + Yellow + Red): Excellent
2 (Yellow + Red): Good
1 (Red): Poor
Off
Wireless module is not detected.
Programm
able
diagnostic
LEDs
Green
Yellow
Red
These three LEDs are programmable. For
details, refer to the “
Default Programmable
Button Operation" section in the Hardware
User’s Manual.
Installing the UC-8112-ME-T
Two sliders are provided at the back of the unit for DIN-rail mounting or
wall mounting.
DIN-Rail Mounting
1. Attach the DIN-rail mounting kit on the rear panel of the
UC-8112-ME-T as shown in the following illustration. Make sure
that the two screws are securely fastened.
2. Pull down the bottom slider of the DIN-rail bracket located at
the back of the unit
3. Insert the top of the DIN rail into the slot just below the upper
hook of the DIN-rail bracket.
4. Latch the unit firmly on to the DIN rail as shown in the
illustrations below.
5. Push the slider back into place.

- 5 -
Connector Description
Power Connector
Connect the power jack (in the package) to the UC-8112-ME-T’s DC
terminal block (located on the top panel), and then connect the power
adapter. It takes about 30 seconds for the system to boot up. Once the
system is ready, the Power LED will light up.
Grounding the UC-8112-ME-T
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI).
SG:
The Shielded Ground (sometimes called
Protected Ground) contact is the
top
contact of
the 3
-
pin power terminal block connector when
viewed from the angle shown here. Connect the
SG wire to an appropriate grounded metal
surface.
Ethernet Ports
The two 10/100 Mbps Ethernet ports (LAN 1 and LAN 2) use RJ45
connectors.
Pin
Signal
1
ETx+
2
ETx-
3
ERx+
6
ERx-
Serial Ports
The two serial ports (P1 and P2) use terminal connectors. Each port can
be configured by software for RS-232, RS-422, or RS-485. The pin
assignments for the ports are shown in the following table:
Pin
RS-232
RS-422
RS-485
1
TXD
TXD+
–
2
RXD
TXD-
–
3
RTS
RXD+
D+
4
CTS
RXD-
D-
5
GND
GND
GND
SD/SIM Card Sockets
The UC-8112-ME-T comes with an SD socket for storage expansion, and
a SIM card socket for cellular communication. The SD card/SIM card
sockets are located at the lower part on the front panel. To install the
cards, remove the screw and the protection cover to access the sockets,
and then insert the SD card or the SIM card into the sockets directly. You
will hear a click when the cards are in place. To remove the cards, push
the cards in before releasing them.

- 6 -
Console Port
The console port is an RS-232 port that can be connected to with a 4-pin
pin header cable. You can use this port for debugging or firmware
upgrade. Note that the cable is not included in the package.
Pin
Signal
1
TxD
2
RxD
3
NC
4
GND
USB
The USB 2.0 port is located at the lower part of the front panel and
supports a USB storage device driver. By default, the USB storage is
mounted at /mnt/usbstorage.
Real-Time Clock
The real-time clock in the UC-8112-ME is powered by a lithium battery.
We strongly recommend that you do not replace the lithium battery
without the help of a Moxa support engineer. If you need to change the
battery, contact the Moxa RMA service team.
ATTENTION
There is
a risk of explosion if the battery is replaced with an
incorrect type of battery.
Cellular Module
The UC-8112-ME-T comes with a built-in PCIe socket for wireless
communication. To install a cellular module, do the following:
1. Remove the two screws on the
DIN-rail mounting bracket and
detach the bracket from the unit.
2. Remove the two screws on
the rear panel.

- 7 -
3. Remove the four screws on the
silver cover on the right panel
and
remove the cover.
4. Remove the screw on the
metal cover.
5. Remove the three screws on
the top panel.
6. Remove the two screws on
the bottom panel.
7. Check the contents of the cellular module package. The package
should contain the items shown below:

- 8 -
8. Remove the metal cover of the computer and locate the cellular
module socket.
9. Remove the screw next to the socket and replace it with the bronze
screw (in the package) as shown below:
10. Attach one thermal pad to the cellular module cover and the other
thermal pad to the module pad.

- 9 -
11. Attach the cellular module to the module pad.
12. Mount the module cover on the cellular module and use screws on
both sides to secure the cover.
13. Insert the module into the socket and secure it using a screw from the
package.

- 10 -
14. Connect antenna cables to the cellular module. There are three
antenna connectors on the cellular module: W1 and W3 are for
cellular antennas and W2 is for GPS antenna.
15. Insert the antenna connectors through the antenna cable holes on
the front panel of the cover as shown below:
16. Secure the antenna connectors to the cover using a locking washer
and nut as shown below:

- 11 -
17. Arrange the antenna cables and use a cable tie to attach the cables to
the bronze screw. You may cut the cable tie if it is too long.
18. Plug the antenna onto the connector.
19. Replace the cover of the computer and fasten the screws to secure
the cover.
Accessing the UC-8112-ME-T Using a PC
You can use a PC to access the UC-8112-ME-T by one of the following
methods:
A. Through the serial console port with the following settings:
Baudrate=115200 bps, Parity=None, Data bits=8, Stop bits =1,
Flow Control=None
ATTENTION
Remember to choose the
“VT100” terminal type. Use the console
cable to connect a PC to the UC-8112-ME-T's serial console port

- 12 -
B. Using SSH over the network. Refer to the following IP addresses and
login information:
Default IP Address
Netmask
LAN 1
192.168.3.127
255.255.255.0
LAN 2
192.168.4.127
255.255.255.0
Login: moxa
Password: moxa
