Moxa Technologies AirWorks AWK-3191 User manual

P/N: 1802031910011
*1802031910011*
AWK-3191
Quick Installation Guide
Moxa Airworks
Edition 2.0, June 2016
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2016 Moxa Inc. All rights reserved.

- 2 -
Overview
The AWK-3191 900 MHz radio is Moxa’s answer to the need for long
distance wireless communication for industrial applications. By combining
the characteristics of the 33-centimeter band, and the proven 802.11
standard, Moxa is able to provide a reliable long distance wireless solution.
Unlike traditional point-to-point 900 MHz radios, the AWK-3191 also
provides reliable point-to-multi-point communication for higher flexibility
and lower total cost of ownership. Furthermore, the AWK-3191 is
designed for simple deployment, but in case of external interference,
engineers can adjust their 900 MHz central frequency and bandwidth
(5/10 MHz and 20 MHz) to optimize their wireless communication. With
industrial grade standards and wide-temperature models, the AWK-3191
is the most reliable solution for industrial long distance communication.
Package Checklist
Moxa’s AWK-3191 is shipped with the following items. If any of these
items is missing or damaged, please contact your customer service
representative for assistance.
•AWK-3191
•Cable holder with one screw
•2 protective caps
•Quick installation guide (printed)
•Warranty card
Installation and Configuration
Before installing the AWK-3191, make sure that all items in the package
checklist are in the box. In addition, you will need access to a notebook
computer or PC equipped with an Ethernet port. The AWK-3191 has a
default IP address that you must use when connecting to the device for
the first time.
Step 1: Select the power source
The AWK-3191 can be powered by a DC power input or PoE (discontinued
starting with HW Rev 2.0.0). The AWK-3191 will use whichever power
source you choose.
Step 2: Connect the AWK-3191 to a notebook or PC
Since the AWK-3191 supports MDI/MDI-X auto-sensing, you can use
either a straight-through cable or crossover cable to connect the
AWK-3191 to a computer. If the LED indicator on the AWK-3191’s LAN
port lights up, it means a connection has been established.
Step 3: Set up the computer’s IP address
Set an IP address on the same subnet as the AWK-3191. Since the
AWK-3191’s default IP address is 192.168.127.253, and the subnet mask
is 255.255.255.0, you should set the IP address of the computer to
192.168.127.xxx and subnet mask to 255.255.255.0.

- 3 -
Step 4: Use the web-based manager to configure the AWK-3191
Open your computer’s web browser and type http://192.168.127.253
in the address field to access the homepage of the web-based
management system. Before the homepage opens, you will need to enter
the user name and password. For first-time configuration, enter the
default user name and password and then click on the Login button:
User name: admin
Password: root
ATTENTION
For security reasons, we strongly recommend changing the
password. To do so, select
Maintenance

Username/Password
, and then follow the on-screen
instructions.
Step 5: Select the operation mode for the AWK-3191
By default, the AWK-3191’s operation mode is set to AP. You can change
the setting in Wireless Settings Basic Wireless Settings if you
would like to use Client mode.
NOTE
For the change to take effect, you must click Save Configuration
to save the change, or Restart (clicking the Save and Restart
buttons will save all changes).

- 4 -
Panel Layout of the AWK-3191
1. Grounding screw
2.
Terminal block for PWR1, PWR2,
relay, DI1, and DI2
3. Reset button
4. PWR1, PWR2, PoE (
discontinued
starting with HW Rev 2.0.0),
FAULT, and STATE LEDs
5. LEDs for signal strength
6. WLAN LEDs: CLIENT, BRIDGE,
and WLAN LEDs
7. RS-232 console port
8. 10/100BaseT(X) RJ45 Port
9. 10M LED
10.
100M LED
11.
MAIN antenna port
12.
AUX antenna port
13.
Model name
14.
Screw hole for wall-
mounting kit
15.
DIN-rail mounting kit

- 5 -
Mounting Dimensions
DIN-Rail Mounting
DIN-Rail Kit Dimensions:
Unit = mm (inch)
The aluminum DIN-rail attachment plate should be fixed to the back panel
of the AWK-3191 when you take it out of the box. If you need to reattach
the DIN-rail attachment plate to the AWK-3191, make sure the stiff metal
spring is situated towards the top, as shown in the figures below:
STEP 1:
Insert the top of the DIN rail into
the
slot just below the stiff metal spring.
STEP 2:
The DIN
-rail attachment unit will
snap into place as shown below.
To remove the AWK-3191 from the DIN rail, simply reverse Steps 1 and 2.

- 6 -
Wall Mounting (optional)
Wall-Mount Kit Dimensions:
Unit = mm (inch)
For some applications, it may be more convenient to mount the
AWK-3191 to a wall, as illustrated below:
STEP 1:
Remove the aluminum
DIN
-rail attachment plate
from the AWK
-3191, and
then attach the wall
-
mount
plates with M3 screws, as
shown in the adjacent
diagram.
STEP 2:
Mounting the AWK
-3191 to a wall requires 4 screws.
Use the AWK
-3191 device, with wall mount plates
attached as a guide, to mark the correct locations of
the 4 screws. The heads of the screws should be less
than 6.0 mm in diameter, and t
he
shafts should be less
than 3.5 mm in diameter, as shown in the figure at the
right.
NOTE
Test the screw head and shank size by inserting the screws into
one of the keyhole shaped apertures of the
wall-mounting p
lates
before attaching the plate to the wall.
STEP 3:
Once the screws are fixed into the wall,
insert the four screw heads through
the large opening of the
keyhole
-shaped apertures of the
wall
-mounting plate, and then slide
the AWK
-3191 downwards, as
indicated in th
e accompanying
diagram. Tighten the four screws for
added stability.

- 7 -
WARNING
•
This equipment is intended to be used in a Restricted Access
Location, such as a dedicated computer room, where a
ccess
can only be gained by
SERVICE PERSONS or by USERS who
have been instructed about the fact that the metal chassis of
the equipment is extremely hot and may cause burns.
•
Service persons or users should pay special attention and
take special precautions before handling this equipment.
•
Only authorized, well-
trained professionals should be allowed
to access the restricted access location. Access should be
controlled by the authority responsible for the location with
lock and key or a security identity system.
•
External metal parts are hot!!
Pay special attention or use
special protection before handling this equipment.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your M
oxa AWK-3191.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowed for each wire size. If the current goes
above the maximum ratings, the wiring could overheat, causing
serious damage to your equipment.
You should also pay attention to the following items:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
in the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring with similar electrical characteristics can be bundled
together.
•Keep input wiring and output wiring separate.
•It is strongly advised that you label wiring to all devices in the system
when necessary.
ATTENTION
This product is intended to be supplied by a Listed Power Unit
marked “Class 2” or “LPS” and rated O/P: 5.76 W

- 8 -
ATTENTION
Make sure
the external power adapter (inc
ludes power cords and
plug assemblies) provided with the unit is certified and suitable
for use in your country.
Grounding the Moxa AWK-3191
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.
There must be no
pote
ntial difference between two ground potentials; otherwise
there is a risk that the device could be destroyed.
Installations with Cable Extended Antennas for Outdoor
Applications
If the antenna or the AWK device is installed outdoors or in an open-air
setting, proper lightning protection is required to prevent direct lightning
strikes on the AWK device. In order to prevent coupling currents from
nearby lightning strikes, a lightning arrester should be installed as part of
your antenna system. Ground the device, antenna, as well as the arrester
properly to provide maximum outdoor protection for the device.

- 9 -
Arrester Accessories
•SA-NMNF-01: Surge arrester, N-type (male) to N-type (female)
•SA-NFNF-01: Surge arrester, N-type (female) to N-type (female)
Wiring the Redundant Power Inputs
The top two pairs of contacts of the 10-contact terminal block connector
on the AWK-3191’s top panel are used for the AWK-3191’s two DC inputs.
Top and front views of the terminal block connector are shown here.
STEP 1: Insert the negative/positive DC wires
into the
V-/V+ terminals.
STEP 2:
To keep the DC wires from pulling
loose,
use a small flat
-
blade screwdriver to tighten the
wire
-clamp screws on the front of the terminal
block connector.
STEP 3:
Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is
located on the AWK-3191’s t
op
panel.
ATTENTION
Before connecting the
AWK-3191
to the DC power inputs, make
sure that the DC power source voltage is stable.
Wiring the Relay Contact
The AWK-3191 has one relay output, which consists of the two contacts of
the terminal block on the AWK-3191’s top panel. Refer to the previous
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor. These relay contacts are used to indicate
user-configured events. The two wires attached to the Relay contacts
form an open circuit when a user-configured event is triggered. If a
user-configured event does not occur, the Relay circuit will be closed.
Wiring the Digital Inputs
The AWK-3191 has two sets of digital inputs—DI1 and DI2. Each DI
comprises two contacts of the 10-pin terminal block connector on the
AWK-3191’s top panel. Refer to the “Wiring the Redundant Power Inputs”
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor.

- 10 -
Cable Holder Installation (Optional)
Attach the cable holder to the bottom of the AWK-3191 to help keep
cables neat and avoid accidents that result from untidy cables.
STEP 1: Screw the cable holder onto the
bottom of the AWK
-3191.
STEP 2: After mounting the AWK-3191 and plugging in the LAN cable,
tighten the cable along the device and wall.
Communication Connections
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the AWK-3191’s front panel are
used to connect to Ethernet-enabled devices.
Below we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports.
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
Pin
Signal
1
Tx+
1
Rx+
2
Tx-
2
Rx-
3
Rx+
3
Tx+
6
Rx-
6
Tx-
RS-232 Connection
The AWK-3191 has one RS-232 (8-pin RJ45) console port located on the
front panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to connect
the Moxa AWK-3191’s console port to your PC’s COM port. You may then
use a console terminal program to access the AWK-3191 for console
configuration.

- 11 -
Console Pinouts for 10-pin or 8-pin RJ45
10-Pin
Description
8-Pin
1
–
2
DSR
1
3
RTS
2
4
GND
3
5
TxD
4
6
RxD
5
7
DCD
6
8
CTS
7
9
DTR
8
10
–
NOTE
1. The pin numbers for the DB9 and DB25 male connectors,
and hole numbers for the DB9 and DB25 female
connectors
are labeled on the connectors. However, the numbers are
typically quite small, so you may need to use a magnifying
glass to see the numbers clearly.
2. The pin numbers for both the 8-pin and 10-pin RJ45
connectors (and ports) are typically not labeled on the
connector (or port). Refer to the pinout diagram above
for
details.
LED Indicators
The front panel of the Moxa AWK-3191 contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is on (power input 1)
Off
Power is not being supplied
PWR2 Green
On
Power is on (power input 2)
Off
Power is not being supplied
PoE
(
discontinued
starting with
HW Rev
2.0.0)
Amber
On
Power is being supplied via PoE
Off
Power is
not
being supplied via PoE
FAULT Red
Blinking
(slow at
1-
second
intervals)
Cannot get an IP address from the
DHCP server
Blinking
(fast at
0.5-sec
intervals)
IP address conflict
Off
Error condition does not exist
STATE Green/
Red
Green
System booted up correctly and in
operation
Green
Blinking
at 1-sec
intervals
The AWK has been located by the
Wireless Search Utility

- 12 -
Red
System boot up failure
SIGNAL
(5 LEDs)
Green
On
Signal level(for Client/Slave mode
only)
Off
BRIDGE Green
On
WLAN function is in wireless-bridge
(master/slave) mode.
Off
WLAN is not in wireless-bridge
(master/slave) mode.
CLIENT Green
On
WLAN function is in client/slave mode
and the AWK has established a link
with an AP.
Blink
WLAN data communication is running
in client/slave mode.
Off
WLAN is not in client mode or the AWK
has not established a link with an AP.
WLAN Amber
On
WLAN is in AP/master mode.
Blink WLAN’s data communication is
running in AP/master mode
Off
WLAN is not in use or not working
properly
TP Port LED Indicators (Port Interface)
100M Green
On
TP port’s 100 Mbps link is active.
Blink
Data is being transmitted at 100 Mbps.
Off
TP port’s 100 Mbps link is inactive.
10M Amber
On
TP port’s 10 Mbps link is active.
Blink
Data is being transmitted at 10 Mbps.
Off
TP port’s 10 Mbps link is inactive.
Specifications
WLAN Interface
Standards
IEEE 802.11i for Wireless Security
IEEE 802.1Q for VLAN
IEEE 802.3af for Power-over-Ethernet*
*Support for PoE discontinued starting with HW
Rev 2.0.0
Security SSID broadcast enable/disable
Firewall for MAC/IP/Protocol/Port-based filtering
64-bit and 128-bit WEP encryption,
WPA/WPA2-Personal and Enterprise (IEEE
802.1X/RADIUS, TKIP, and AES)
Spread Spectrum and
Modulation (typical)
OFDM with BPSK, QPSK, 16QAM, 64QAM
64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps,
QPSK @ 18/12 Mbps, BPSK @ 9/6 Mbps
Channel Band Width
US: 5 MHz; 10 MHz; 20 MHz
Operating Channels
(central frequency)
US: 902 to 928 MHz (ISM band)
• 915 MHz (BW = 20 MHz)
• 908.5, 915, 921.5 MHz (BW = 10 MHz)
• 905.25, 908.5, 911.75, 915, 918.25, 921.5,
924.75 MHz (BW = 5 MHz)
Transmission Rates
6, 9, 12, 18, 24, 36, 48, 54 Mbps
TX Transmit Power
• Typ. 24±1.5 dBm @ 6 to 24 Mbps
• Typ. 23±1.5 dBm @ 36 Mbps
• Typ. 22±1.5 dBm @ 48 Mbps
• Typ. 21±1.5 dBm @ 54 Mbps

- 13 -
RX Sensitivity
• -90 dBm @ 6 Mbps
• -88 dBm @ 9 Mbps
• -87 dBm @ 12 Mbps
• -85dBm @ 18 Mbps
• -81 dBm @ 24 Mbps
• -77 dBm @ 36 Mbps
• -73 dBm @ 48 Mbps
• -71 dBm @ 54 Mbps
Protocol Support
General Protocols Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP,
TCP, UDP, RADIUS, SNMP, DHCP, VLAN, STP/RSTP
Interface
Connector for
External Antennas
RP-SMA (female), 500 V insulation
LAN Port
1, RJ45, 10/100BaseT(X) auto negotiation speed,
F/H duplex mode, and auto MDI/MDI-X connection
Console Port
RS-232 (RJ45-type)
Reset
Present
LED Indicators
PWR1, PWR2, PoE (discontinued starting with HW
Rev 2.0.0), FAULT, STATE, SIGNAL*, CLIENT
MODE, BRIDGE MODE, WLAN, 10M, 100M
*signal strength indicator
Alarm Contact (digital
output)
1 relay output with current carrying capacity of 1 A
@ 24 VDC
Digital Inputs 2 electrically isolated inputs
• +13 to +30 V for state “1”
• +3 to -30 V for state “0”
• Max. input current: 8 mA
Physical Characteristics
Housing
Metal, providing IP30 protection
Weight
930 g (2.05 lb)
Dimensions
53 x 135 x 105 mm (2.08 x 5.31 x 4.13 in)
Installation
DIN-rail mounting (standard),
wall mounting (optional)
Environmental Limits
Operating
Temperature
Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5% to 95% (non-condensing)
Power Requirements
Input Voltage
12 to 48 VDC, redundant dual DC power inputs or
48 VDC Power-over-Ethernet* (IEEE 802.3af
compliant)
* Discontinued starting with HW Rev 2.0.0
Input Current
0.4 A @ 12 VDC; 0.12 A @ 48 VDC
Connector
10-pin removable terminal block, 500 V insulation
Power Consumption
5.76 W
Reverse Polarity
Protection
Present
Standards and Certifications
Safety
UL 60950-1
EMI
CISPR 22, FCC Part 15B Class B

- 14 -
Radio
FCC ID SLE-WFS001
Note: Please check Moxa’s website for the most up-to-date certification
status.
Reliability
MTBF
484,469 hrs. (standard Telcordia SR332)
Warranty
Warranty Period
5 years
Details
See www.moxa.com/support/warranty.aspx
ATTENTION
The AWK
-3191 is NOT a portable mobile device and should be
located at least 20 cm
away from the human body.
The AWK
-3191 is NOT designed for the general public. A
well
-trained technician is required to deploy the AWK-
3191 units
and safely establish a wireless network.
ATTENTION
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any
interference received, including
interference that may cause undesired operation.
ATTENTION
Do not locate the antenna near overhead power lines or other
electric light or power circuits, or where it can come into contact
with such circuits. When installing the antenna, take extreme
care not to come into contact with such circuits, because they
may cause serious injury or death. For proper installation and
grounding of the antenna, refer to national and local codes (for
exa
mple, U.S.:NFPA 70; National Electrical Code, Article 810;
Canada: Canadian Electrical Code, Section 54).
NOTE
For installation flexibility, either the MAIN antenna or the AUX
antenna may be selected for use. Make sure the antenna
connection matches the antenna configured in the AWK
-3191
web
interface.
To protect the connectors and RF module, all radio ports should
be terminated by either an antenna or a terminator. We strongly
recommend using
resistive terminators for terminating the
unused antenna ports.
