Moxa Technologies AirWorks AWK-5222 User manual

2014 Moxa Inc. All rights reserved.
P/N: 1802052220012
AWK-5222
Quick Installation Guide
Moxa AirWorks
Third Edition, June 2014

- 2 -
Overview
The AWK-5222 dual-RF wireless AP/Bridge/Client provides a flexible and
highly reliable solution for your industrial wireless networks.
The AWK-5222 is rated to operate at temperatures ranging from 0 to
60°C for standard models and -40 to 75°C for extended temperature
models, and it is rugged enough for industrial applications.
With two independent RF modules, the AWK-5222 supports a greater
variety of wireless configurations and applications, and the redundant
wireless connections increase the reliability of your entire wireless
network.
The AWK-5222’s two DC power inputs make the power supply more
reliable, and it can also be powered via PoE for easier deployment.
Package Checklist
Moxa’s AWK-5222 is shipped with the following items. If any of these
items is missing or damaged, please contact your customer service
representative for assistance.
•1 AWK-5222
•2 Swivel-type Antennas (2dBi, RP-SMA, 2.4&5GHz)
•1 Quick Installation Guide
•1 Software CD
•1 Moxa Product Warranty Booklet
•1 Cable Holder with a Screw
•2 Protective Caps
Installation and Configuration
Before installing the AWK-5222, make sure that all items in the Package
Checklist are in the box. In addition, you will need access to a notebook
computer or PC equipped with an Ethernet port. The AWK-5222 has a
default IP address that you must use when connecting to the device for
the first time.
Step 1: Select the power source
The AWK-5222 can be powered by a DC power input or PoE (Power over
Ethernet). The AWK-5222 will use whichever power source you choose.
Step 2: Connect the AWK-5222 to a notebook or PC
Since the AWK-5222 supports MDI/MDI-X auto-sensing, you can use
either a straight-through cable or crossover cable to connect the
AWK-5222 to a computer. If the LED indicator on the AWK-5222’s LAN
port lights up, it means the connection is established.
Step 3: Set up the computer’s IP address
Set an IP address on the same subnet as the AWK-5222. Since the
AWK-5222’s default IP address is 192.168.127.253, and the subnet mask
is 255.255.255.0, you should set the IP address of the computer to
192.168.127.xxx and subnet mask to 255.255.255.0.

- 3 -
Step 4: Use the web-based manager to configure AWK-5222
Open your computer’s web browser and then type
http://192.168.127.253 in the address field to access the homepage of
the web-based management. Before the homepage opens, you will need
to enter the user name and password. For first-time configuration, enter
the default user name and password and then click on the Login button:
User name: admin
Password: root
ATTENTION
For security reasons, we strongly recommend
changing the
password. To do so,
select Maintenance

Password
, and then
follow the on-screen instructions.
Step 5: Select the operation mode for the AWK-5222
By default, the AWK-5222’s operation mode is set to Wireless
Redundancy. You can change the setting in Wireless Settings 
Operation mode if you would like to use the Wireless Bridge or AP-Client
mode.
NOTE
To make the change effective, you must click Save
Configurati
on to save the change or Restart

Save and
Restart button to apply all changes).

- 4 -
Panel Layout of the AWK-5222
1. Grounding screw
2. Terminal block for PWR1, PWR2,
relay, DI1, and DI2
3. Reset button
4. Heat dissipation orifices
5. AUX1 and AUX2 antenna ports
6. System LEDs: PWR1, PWR2,
PoE, FAULT, and STATE LEDs
7. WLAN LEDs: WLAN 1 and
WLAN2 LEDs
8. RS-232 console port
9. 10/100BaseT(X) RJ45 Port :
LAN1 and LAN2
10.
10M LED
11.
100M LED
12.
MAIN 1 antenna port
13.
MAIN 2 antenna port
14.
Model name
15.
Screw hole for wall mounting kit
16.
DIN-Rail mounting kit
Mounting Dimensions

- 5 -
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should be fixed to the back
panel of the AWK-5222 when you take it out of the box. If you need to
reattach the DIN-Rail attachment plate to the AWK-5222, make sure the
stiff metal spring is situated towards the top, as shown in the figures
below.
STEP 1:
Insert the top of the DIN
-Rail into
the slot just
below the stiff metal
spring.
STEP 2:
The DIN
-Rail attachment unit will
snap into place as shown below.
To remove the AWK-5222 from the DIN-Rail, simply reverse Steps 1 and
2.
Wall Mounting (optional)
For transportation applications that require an EN50155 certification
report, you should purchase the optional wall mount for the AWK-5222,
since the wall mount has passed EN50155 testing. The wall mount is also
convenient for other applications that require mounting the AWK-5222 to
a wall.
STEP 1:
Remove the aluminum
DIN
-Rail attachment plate
from the AWK
-5222, and
then attach the wall mount
plates with
M3 screws, as
shown in the adjacent
diagrams.
STEP 2:
Mounting the AWK
-5222 to a wall requires 4 screws.
Use the AWK
-5222 device, with wall mount plates
attached, as a guide to mark the correct locations of
the 4 screws. The heads of the screws should be less
than 6.0 mm in diameter, and the
shafts should be
less than 3.5 mm in diameter, as shown in the figure
at the right.
Do not screw the screws in all the way—leave a space of about 2 mm to
allow room for sliding the wall mount panel between the wall and the
screws.

- 6 -
NOTE
Test the screw head and shank size by inserting the screw into
one of the keyhole shaped apertures of the Wall Mounting Plates
before it is screwed into the wall.
STEP 3:
Once the screws are fixed into the
wall, insert the four screw heads
through the large opening of the
keyhole
-shaped apertures, and
then sli
de the AWK-5222
downwards, as indicated to the
right. Tighten the four screws for
added stability.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before in
stalling and/or
wiring your Moxa AWK-5222.
WARNING
Safety First!
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allow
ed for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
You should also pay attention to the following items:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
in the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring with similar electrical characteristics can be bundled
together.
•Keep input wiring and output wiring separate.
•It is strongly advised that you label wiring to all devices in the system
when necessary.

- 7 -
ATTENTION
This product is intended to be supplied by a Listed Power Unit
marked
“Class 2” or “LPS” and rated O/P: 12 to 48 VDC,
max 800
mW, 25°C.
ATTENTION
Make sure
the external power adapto
r (includes power cords and
plug assemblies) provided with the unit is certified and suitable
for use in your country.
Grounding the Moxa AWK-5222
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to
be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Redundant Power Inputs
The top two pairs of contacts of the 10-contact terminal block connector
on the AWK-5222’s top panel are used for the AWK-5222’s two DC inputs.
Top and front views of the terminal block connector is shown here.
STEP 1: Insert the negative/positive DC wires
into the
V-/V+ terminals.
STEP 2:
To keep the DC wires from pulling
loose,
use a small flat
-
blade screwdriver to tighten the
wire
-clamp screws on the front of the terminal
block connector.
STEP 3:
Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is
located on the AWK-5222’s t
op
panel.
ATTENTION
Before connecting
the AWK-5222
to the DC power inputs, make
sure the DC power source voltage is stable.

- 8 -
Wiring the Relay Contact
The AWK-5222 has one relay output, which consists of the two contacts of
the terminal block on the AWK-5222’s top panel. Refer to the previous
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor. These relay contacts are used to indicate
user-configured events. The two wires attached to the Relay contacts
form an open circuit when a user-configured event is triggered. If a
user-configured event does not occur, the Relay circuit will be closed.
Wiring the Digital Inputs
The AWK-5222 has two sets of digital input—DI1 and DI2. Each DI
comprises two contacts of the 10-pin terminal block connector on the
AWK-5222’s top panel. You can refer to the “Wiring the Redundant Power
Inputs” section for detailed instructions on how to connect the wires to
the terminal block connector, and how to attach the terminal block
connector to the terminal block receptor.
Cable Holder Installation (Optional)
You can attach the cable holder to the bottom of the AWK-5222. This
helps to keep cabling neat and avoid accidents that result from untidy
cables.
STEP 1:
Screw the cable holder onto the bottom of the
AWK
-5222.
STEP 2:
After mounting the AWK
-
5222 and plugging in the LAN cable, tighten the
cable along the device and wall.

- 9 -
Communication Connections
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the AWK-5222’s front panel are
used to connect to Ethernet-enabled devices.
Below we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports.
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
Pin
Signal
1
Tx+
1
Rx+
2
Tx-
2
Rx-
3
Rx+
3
Tx+
6
Rx-
6
Tx-
RS-232 Connection
The AWK-5222 has one RS-232 (8-pin RJ45) console port located on the
front panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to connect
the Moxa AWK-5222’s console port to your PC’s COM port. You may then
use a console terminal program to access the AWK-5222 for console
configuration.
Console Pinouts for 10-pin or 8-pin RJ45
10-Pin
Description
8-Pin
1
-----
2
DSR
1
3
RTS
2
4
GND
3
5
TxD
4
6
RxD
5
7
DCD
6
8
CTS
7
9
DTR
8
10
-----
NOTE
1. The pin numbers for male DB9 and DB25 connectors, and
hole numbers for female DB9 and DB25 connectors are
labeled on the connector. However, the numbers are
typically quite small, so you may need to use a magnifying
glass to see the numbers clearly.
2. The pin numbers for both 8-pin and 10-
pin RJ45 connectors
(and ports) are typically not labeled on the connector (or
port). Refer to the Pinout diagram above to see how RJ45
pins are numbered.

- 10 -
LED Indicators
The front panel of the Moxa AWK-5222 contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is being supplied from power
input 1.
Off Power is
not
being supplied from
power input 1.
PWR2 Green
On
Power is being supplied from power
input 2.
Off
Power is not being supplied from
power input 2.
PoE Amber
On
Power is being supplied via PoE.
Off
Power is not being supplied via PoE.
FAULT Red Blinking
Cannot get an IP address from the
DHCP server (interval: 1 sec)
Off
There is no error condition.
STATE Green/Red
Green
Software Ready.
Blinking
Green
The AWK has been located by AWK
Search Utility (interval: 1sec)
Red
Booting or Error condition.
WLAN1
Green/Amber
Green On
WLAN1 functions in Client mode.
Blinking
Green
WLAN1’s data communication is
running in Client mode.
Amber On
WLAN1 functions in AP/Bridge
mode.
Blinking
Amber
WLAN1’s data communication is
running in AP/Bridge mode.
Off
WLAN1 is not in use.
WLAN2
Green/Amber
Green On
WLAN2 function is in Client mode.
Blinking
Green
WLAN2’s data communication is
running in Client mode.
Amber On WLAN2 function is in AP/Bridge
mode.
Blinking
Amber
WLAN2’s data communication is
running in AP/Bridge mode.
Off
WLAN2 is not in use.
TP Port (LAN1, LAN2) LED Indicators (Port Interface)
10M Yellow
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10
Mbps
Off
TP port’s 10 Mbps link is inactive.
100M Green
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100
Mbps
Off
TP port’s 100 Mbps link is inactive.

- 11 -
Specifications
WLAN
Standards
IEEE 802.11a/g/b for Wireless LAN
IEEE 802.11i for
Wireless Security
IEEE 802.3u for 10/100BaseT(X)
IEEE 802.3af for Power
-over-Ethernet
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
Spread Spectrum and
Modulation
DSSS with DBPSK, DQPSK, CCK
OFDM with BPSK, QPSK, 16QAM, 64QAM
Operating Channels
(Central Frequency)
US: 2.412 to 2.462 GHz (11 channels)
5.18 to 5.24 GHz (4 channels)
EU:
2.412 to 2.472 GHz (13 channels)
5.18 to 5.24 GHz (4 channels)
Security
64-bit and 128-bit WEP encryption, WPA /WPA2
Personal or Enterprise (IEEE 802.1X
/ RADIUS,
TKIP and AES)
Protocol
General Protocols:
Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP,
TCP, UDP, RADIUS, SNMP, PPPoE, DHCP, LLDP
AP-only Protocols:
ARP, BOOTP, DHCP, dynamic VLAN-Tags for
802.1X-Clients, STP/RSTP (IEEE 802.1D/w)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Transmit Power
802.11b:
1 to 11 Mbps: Typ. 18±1.5 dBm
802.11g:
6 to 24 Mbps: Typ. 18±1.5 dBm
36 to 48 Mbps: Typ. 16±1.5 dBm
54 Mbps: Typ. 15±1.5 dBm
802.11a:
6 to 24 Mbps: Typ. 16±1.5 dBm
36 to 48 Mbps: Typ. 14±1.5 dBm
54 Mbps: Typ. 13±1.5 dBm
Receiver Sensitivity
802.11b:
-92 dBm @ 1 Mbps, -90 dBm @ 2 Mbps,
-88 dBm @ 5.5 Mbps, -
84dBm @ 11 Mbps
802.11g:
-87 dBm @ 6 Mbps, -86 dBm @ 9 Mbps,
-85 dBm @ 12 Mbps, -
82dBm @ 18 Mbps,
-80 dBm @ 24 Mbps, -
76 dBm @ 36 Mbps,
-72dBm @ 48 Mbps, -
70 dBm @ 54 Mbps
802.11a:
-87 dBm @ 6 Mbps, -86 dBm @ 9 Mbps,
-85 dBm @ 12 Mbps, -
82dBm @ 18 Mbps,
-80 dBm @ 24 Mbps, -
76 dBm @ 36 Mbps,
-72dBm @ 48 Mbps, -70 dBm @ 54 Mbps

- 12 -
Interface
Default Antenna
2dBi dual-band, Omni-directional antenna
Antenna Connector
RP-SMA (male)
Connection
10-pin Removable Terminal Block
Alarm Contact
1 relay output (capacity: 1A @24VDC)
Digital Input
2 electrically
-isolated inputs
3
to -30V for state “0” (OFF)
1
3 to 30V for state “1” (ON)
Max. input current: 8 mA
Console
RS-232 (RJ45 type)
LAN Port
10/100BaseT(X) auto negotiation speed
LED Indicators
PWR1, PWR2, PoE, FAULT, STATE, WLAN1,
WLAN2, 10M, 100M
Power
Input Voltage
12 to 48 VDC, redundant dual DC power inputs or
48 VDC Power-over-Ethernet (IEEE 802.3af)
Input Current
800mA @ 12-48VDC
Input Current @ 24VDC
0.3 A
Overload Current
Protection
1.6 A
Reverse Polarity
Protection
Present
Mechanical
Casing
IP30 protection, aluminum case
Dimensions
62.05 x 135 x 105 mm (2.44 x 5.31 x 4.13 in)
Weight
880g
Installation
DIN-Rail, or wall mounting
Environmental
Operating
Temperature
Standard models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85ºC (-40 to 185ºF)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals*
Radio
EN300.328
EMC
EN301 489-1/-17
EMI
FCC Part 15
Safety
EN60950-1, UL60950-1
* Please check Moxa’s website for the most up-to-date
certification status.
WARRANTY
5 years
For details see http://www.moxa.com/warranty
ATTENTION
The AWK
-5222 is NOT a portable mobile device and should be
located
at least 20 cm away from the human body.
The AWK
-5222 is NOT
designed for the general public. To deploy
AWK
-5222s and establish a wireless network safely, a
well-trained technician is required for installation.

- 13 -
ATTENTION
Use the ant
ennas correctly: Two dual-band 2.4 GHz & 5 GHz
antennas
, are included with the product. Either antenna can be
installed in MAIN1 or MAIN2.
If you want to use a single band
antenna, please use 2.4 GHz antennas for IEEE 802.11b/g mode
and 5 GHz
antennas for IEEE 802.11a mode
. In order to improve
the quality of the signal received by the Main antennas, you may
connect additional antennas to AUX1 and AUX2.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
:
Tel:
[phone]
Fax:
[phone]
Moxa Asia
-Pacific:
Tel:
[phone]
Fax:
[phone]
