MP-Man MP4 FIESTA User manual

1
DIGITAL VIDEO / MUSIC PLAYER
MP3/WMA/AMV
USER MANUAL
MP-MP4FIESTA
www.mpmaneurope.com
Before connecting, operating or adjusting this product please read these instructions completely.

2
GENERAL
1.1 MP4FIESTA characteristics
zSupport MP1/MP2/MP3/WMA/WMV/ASF/WAV/OGG music format.
zSupport AMV movie format
zSupport JPEG/BMP/GIF picture format
zSupport WAV/MP3 format voice recording
z1.8” high resolution full color display
zGraphic user control interface
z2 built in speakers
1.2 Box set includes
zMP3 player
zStereo earphone
zDriver & utilities CD disc
zQuick guide
zUSB cable
1.3 Computer requirements
zPentium 100 MHz or faster
z32MB RAM or above
zCD- ROM
zHard disk with at least 15MB free memory space
zUSB 1.1/2.0
zWindows 98/ME/2000/XP, Mac OS 10, Linux 2.4.2
1.4 The player appearance interface
1.5 Figure & Keys
(1) MENU” Switch modes, menu selection by pressing on button
(2) NEXT/FWD or volume increase
(3) “VOL” selects Volume adjustments mode or A-B replay
(4) PREV/REV or volume decrease
(5) PLAY “” OPEN/PLAY/PAUSE/STOP/POWER OFF
(6) Earphone
(7) MIC
(8) USB connector
(9) ON/OFF switch
(10) Color screen
(11) Speakers

3
1.6 Battery
MP4FIESTA has an on screen battery monitor:
•When battery level low , recharge immediately (connect MP4FIESTA to external charger or PC)
•Nine level battery indicator (indicator flashes when charging)
Attention: Voice recording can only work at battery level 2 or above!
1.7 Power on/off
zPower on/off the player by switching “POWER” switch to on position
zWhen powered on, press and hold the “PLAY” key for 2 seconds. Player will power-off. Press and hold “PLAY” key to power on
again.

4
OPERATION
2.0 Main Menu
Seven mode at main menu with different featuring, respectively:
zMusic
zMovie
zRecord
zVoice
zJPG View
zSetting
Use “NEXT” or “PREV” keys to select among these modes, then press “MENU” key to enter
2.1 Music mode
From main menu, select MUSIC mode and press MENU button to enter.
Use “PREV” or “NEXT” keys to select music file, press “PLAY” key for specific music playback
There are two sub-modes at Music mode, respectively:
zPlay mode (available during playback)
zStop mode (available during standby)
Play mode
During music playback, press “MENU” key to enter. Seven options:
Repeat
Normal All songs are played once
Repeat One Repeats the current song
Folder Plays all the music of a specific folder
Repeat Folder Repeats the music of a specific folder
Repeat All Repeats all the music
Random Plays music at random
Intro First 10 seconds of each song is played
Equalizer
Natural
Rock
Pop
Classic
Soft
Jazz
DBB

5
Tempo rate
Change music playback speed by pressing “NEXT” and “PREV” keys
Attention: Tempo rate setting works only on MP3 file!
Replay
A-B replay – user can mark certain segment of music for continuous repeat
When replay mode selected, icon appears with letter “A” flashing
Press “NEXT” to set repeat segment starting point A.
Letter “B” starts flashing
Press “NEXT” to set repeat segment ending point B
A-B music segment repeats continuously. Press “MENU” button to return to normal playback
Adding voice to A-B segment
During A-B segment playback, press and hold “NEXT” key, icon appears
Voice is recorded. Press “MENU” key to stop recording
A-B music segment mixed with recorded voice will repeated continuously. Press “MENU” button to return to
normal playback
Replay times
Choose how many times the A-B segment must replayed, range from 1-10 times
Replay gap
Configure the time gap between each A-B segment, range from 1-10 seconds
Exit
Stop mode
During standby, short press “MENU” key to enter. Four options:
Local folder
Here the user is able to browse between all files and folders stored on the device
Use “NEXT” or “PREV” keys and “MENU” key to enter or confirm a selection
Delete file
Here the user is able to delete any file stored on the device
use “NEXT” or “PREV” keys and “MENU” key for delete confirmation
Delete all
Deletes all music files stored on the device
Exit

6
2.2 Movie mode
From main menu, select MOVIE mode and press MENU button to enter
This player can only play AMV movie files.
Remember that most currently popular movie formats such as AVI, RM, 3GP, MP4…are not directly support by MP4FIESTA. File
conversion by computer with AMV Converter software is needed. AMV Converter in included on the CDROM.
Use “NEXT” or “PREV” keys to select AMV file, press “PLAY” key to playback movie
During pause, press “MENU” key to enter movie mode submenu:
zLocal Folder
zDelete
zRepeat
zExit
(Options features and controls are similar to Music mode, see 2.1 for reference)
Attention: Volume cannot be increased or decreased during movie playback. Volume can only be set at movie standby
mode by pressing “VOL” key to recall volume control interface

7
2.3 Record mode
From main menu, select RECORD mode and press MENU button to enter
zPress “PLAY” key to start recording
zPress “PLAY” key again to pause recording (recording time flashes)
zPress “PLAY” key again to continue recording.
zPress and hold “PLAY” button to stop recording and save recorded voice to file (“SAVING…” message appears)
When the device is not recording, short press “MENU” to enter RECORD submenu, options available:
Local folder
REC type ( choose between WAV or MP3 format in SETTING mode)
32K BPS (WAV)
64K BPS (WAV)
192K BPS (WAV)
384K BPS (WAV)
or
192K BPS (MP3)
128K BPS (MP3)
64K BPS (MP3)
32K BPS (MP3)
Exit
Attention: 384K BPS WAV file provides the highest quality, but requires a lot of storage space.
High compression rate MP3 format consumes less storage space than WAV format at same sampling rate
Recorded MP3 music files can replayed in Music mode
Recorded WAV files are stored at [device:\ RECORD \ VOICE] folder and can be replayed in VOICE mode
2.4 Voice mode
From main menu, select VOICE mode and press MENU button to enter
Voice files recorded in Record mode can be replayed in VOICE mode
VOICE mode supports WAV recorded files only; MP3 recorded files need to replayed in Music mode
When playback is paused, short press “MENU” button to enter VOICE submenu:
zLocal folder
zDelete
zDelete all
zExit
(Detail features and controls are similar to MUSIC mode, please check for reference)

8
2.5 JPG View
From main menu, select RECORD mode and press MENU button to enter
JPEG View is designed for picture viewing.
JPEG, BMP and GIF format files are supported.
Use “NEXT” or “PREV” to select pictures file you like to view, then press “PLAY” for confirmation.
Push “MENU” button to enter submenu, options:
zLocal folder
zPlay set
zDelete file
zExit
2.6 Setting Mode
From main menu, select SETTING mode and press MENU button to enter
zRecord type
Selection of voice recording file format. Choose between WAV and MP3.
zDark mode
Setting of standby time before LCD screen switches off.
Push any button to switch the LCD screen back on.
Time can be set between 0 and 30 seconds. 0 seconds means dark mode is deactivated
zLanguage
Selection of display language
zPower off
Off time - Setting of “automatic power off” time from 0-60 minutes with 10 minutes interval.
Sleep time - Setting of “automatic power off” time from 0-120 minutes at 10 minutes interval
Attention: 0 minutes means automatic power off or sleep mode is deactivate
Sleep mode features only once when selected.
zMemory
Showing MP4 FIESTA total storage size (MB) and percentage of storage being used.
zF/W version
Showing current firmware version information.
zExit

9
SPECIFICATION
DISPLAY 1.8" Diagonal CSTN Display
PC CONNECTION USB 2.0 High Speed
FLASH MEMORY 1, 2, 4GB
POWER SUPPLY 3.8V Rechargeable Lithium Battery
MUSIC FORMAT MP1, MP2, MP3, WMA, WMV, ASF, WAV, MTV, OGG
MOVIE FORMAT AMV (16 frames/second)
RECORD FORMAT WAV (32-384K BPS sampling rate)
MP3 (32-192K BPS sampling rate)
DISTORTION Less than 0.1%
FREQUENCY RESPONSE 20Hz~20KHz
HEADSET OUTPUT 5mW (320Ohm)
OPERATION SYSTEM WINDOWS 98/2000/ME/2000/XP, Mac OS 10, Linux 2.4.2
TECHNICAL SUPPORT
Furthermore information, visit our website
www.mpmaneurope.com
