MP-Man MP132 User manual

MP132
MP3 & Video Player
Instruction Manual
Please read this manual carefully before operation

Page 2
Table of Contents
TABLE OF CONTENTS...............................................2
PACKAGE CONTENTS ............................................. 4
FEATURES .................................................................5
CONTROLS AT A GLANCE ......................................6
Disabling the Controls ...........................................7
GETTING STARTED ................................................... 8
Charging the Battery.............................................8
Charging with a Computer ..........................8
Turning the Player On/Off .....................................8
Resetting the Player ...............................................9
MAIN MENU .......................................................... 10
Main Menu Controls.............................................10
MUSIC MODE ........................................................ 11
Music Browser Controls........................................ 11
Now Playing Controls (Music Playback)........... 13
Quick Option Menu ..................................... 14
PHOTO MODE........................................................ 16
Photo Browser Controls........................................ 16
Photo Viewer Controls ......................................... 17
VIDEO MODE......................................................... 18
Video Browser Controls .......................................18
Video Playback Controls .................................... 19
TEXT MODE ............................................................20
Text Browser Controls ...........................................20
Text Reader Controls............................................20
RECORD MODE .....................................................23
Voice Playing Controls ........................................23
Quick Option Menu .............................................23

Page 3
Table of Contents
EXPLORER MODE ..................................................26
Explorer Controls ..................................................26
SETUP MODE..........................................................27
TRANSFERRING FILES TO THE PLAYER ..................29
Transferring with Microsoft Windows .................30
Transferring with Macintosh OS X.......................30
Disconnecting from a Computer ...................... 31
Microsoft Windows....................................... 31
Macintosh OS X.............................................32
VIDEO CONVERSION ...........................................33
TROUBLESHOOTING..............................................34
SPECIFICATIONS...................................................37

Page 4
Package Contents
Please make sure that the items shown below are
included in the package. Should an item be missing,
please contact the local retailer from which you
purchased this product.
1. MP132
2. USB Cable
3. Instruction Manual & Documentation
4. Professional Stereo Earphones
5. Installation CD

Page 5
Integrated ash memory
1.5” full-color LCD display
Plays music, video, photos and text
ID3 and LRC support for song and synchro-
nized lyric information display
Integrated Microphone for Digital Voice
Recording
USB 2.0 Hi-speed for fast le transfers
Features

Page 6
2
4
8
1
3
56
7
Reset
9
Controls at a Glance

Page 7
Front View
1. LCD Display
2. Menu Button <MENU>
3. Control Buttons
<UP>
<DOWN>
<LEFT>
<RIGHT>
4. Enter Button <ENTER>
5. Option Button <OPTION>
Side View
6. Power/Hold Switch
Slide and hold the switch
down for Power, slide it up for
Hold.
<POWER>
Bottom View
7. USB Port/Charge
8. 3.5mm Headphone Jack
Rear View
9. Reset Button <RESET>
Controls at a Glance

Page 8
Getting Started
Charging the Battery
Your player has an integrated rechargeable battery.
Upon initial use, the battery should be charged fully
to ensure optimal performance and battery life.
If the player has not been used in a while, the bat-
tery may need to be recharged overnight (about 8
hours).
The battery used in this device may present a re or
chemical burn if mistreated. Do not disassemble, in-
cinerate, or heat the battery. Do not leave the battery
in a place subject to direct sunlight, or in a car with its
windows closed.
Do not connect the player to a power source other
than that which is indicated here or on the label as this
may result in the risk of re or electric shock.
Charging with a Computer
Your player can be charged through a USB com-
puter connection. Use the supplied USB cable to
connect the player to a high-power USB port of a
computer. The computer must be powered on and
not in sleep mode.
When the player is connected and charging, a USB
symbol will be displayed on the player’s screen.
Turning the Player On/Off
To turn the player on, slide and hold the
<POWER> switch down until the screen turns on.

Page 9
To turn the player off, slide and hold the
<POWER> switch down until the screen turns off.
Resetting the Player
Reset the player if it should freeze and not respond
or otherwise malfunction.
1. Disconnect your player if it is connected to a
computer.
2. Use a paper clip to gently press the <RESET>
button located on the rear of the player.
Disabling the Controls (Hold)
When the <POWER> switch is set to the “Hold”
position, your player’s controls are disabled.
You may want to disable the controls to avoid turn-
ing on the player or activating the controls acciden-
tally when it is in your pocket or bag.
To disable the controls, slide the <POWER>
switch up until it clicks into the “Hold” position.
To enable the controls, slide the <POWER> switch
down to release it from the “Hold” position.
A lock icon will appear on the screen when the con-
trols are disabled. Re-enable the controls to continue.
Getting Started

Page 10
Main Menu
When you turn on the player, you will see the Main
menu. The Main menu gives you access to the differ-
ent function modes of your player. These modes are:
Music: Browse and play music.
Photo: Browse and view Photos.
Video: Browse and play Videos.
Text: Browse and read text les.
Record: Make or play voice recordings.
Explorer: Browse all les.
Setup: Adjust the player’s options.
Select “Extras” from the Main Menu to get the “Text”,
“Record”, and “Explorer” menus.
Main Menu Controls
To browse through the different modes, press
<UP> or <DOWN>.
To select a mode, press the <ENTER> button.

Page 11
Browse for and play your music les.
If you have loaded new music les onto the player, the
music library will need to be refreshed when you enter
Music mode. This process may take several minutes.
You will not be able to access the Music Browser
screen until you refresh the music library.
For more information about how to get music onto
your player, please refer to the section “Transferring
Files to the Player”.
Music Browser Controls
When you choose MUSIC
mode from the Main menu,
you will see the Music Browser
screen. You can choose to
browse your music by song
name, album, artist, or genre,
or you may choose “Browser”
to view the music les and
folders on the player.
Function Key Action
To browse through the list Press <UP> or
<DOWN>
To select an item Press <ENTER>
To return to the previous screen Press <MENU>
To return to the Main menu Hold <MENU>
Music Mode

Page 12
Music Mode
If your music les contain ID3 song information tags,
you will be able to view your tracks by Artist, Album,
or Genre. To view all les (including those that do not
contain ID3 information), select “All Songs” or use the
“Browser” option.
If music is already playing, you will have the additional
option to return to the Now Playing screen.
Lyric display requires a “.LRC” lyric le which may be
found on the internet or may be created with a Lyric
le editor. Lyric les can contain synchronized timing
information as well as lyric information.
Lyric les must have the same name as its correspond-
ing music le (e.g., “SongTitle1.lrc” and “SongTitle1.
mp3”) and must be placed in the same directory.
Using the Quick Play List
To create a quick Play List that contains your
favorite songs:
1. Select “Browser” from the Music Browser screen.
2. Use the Browser controls to select a song to add.
3. Press <OPTION>. The screen will display “Add
to List”.
4. Press <ENTER> to nish adding the song to
the Play List.
This quick Play List can be played from the Quick Op-
tion menu of the Now Playing screen (see page 15 for
more details).

Page 13
Now Playing Controls (Music Playback)
To start playing music, browse for a song and then
press <ENTER> to start playback.
When a song is playing, the Now Playing screen
appears (see below).
Play Status
Lock Icon
Battery Level
Elapsed Time
Remain Time
Progress Bar
Current Track /
Total Tracks
Album Cover
Repeat Mode
Equalizer
ID3
Information
Music Mode

Page 14
The following functions may be performed from the
Now Playing screen.
Function Key Action
To play the next track Press <RIGHT>
To play the previous track Press <LEFT>
To forward-scan quickly through the
current track Hold <RIGHT>
To reverse-scan quickly through the
current track Hold <LEFT>
To pause/resume playback Press <ENTER>
To access the Quick Option menu
(see below for details) Press <OPTION>
To adjust the volume level Press <UP> or
<DOWN>
To return to the Music Browser
screen Press <MENU>
To return to the Main menu Hold <MENU>
Quick Option Menu
To access the quick option menu, press <OPTION>
on the Now Playing screen.
To browse through the settings, press <UP> or
<DOWN>
To select a setting, press <ENTER>
To return to the previous screen, press <MENU>
Music Mode

Page 15
Equalizer
Select a digital equalizer preset to optimize the way
the player processes audio signals. The options are:
Normal, Pop, Rock, Classic, Jazz, and Bass.
Repeat
Change the repeat options to adjust the order in
which tracks are played.
Item Description
No Repeat Play tracks in normal order and no repeat.
One Play the current track repeatedly.
All Play all tracks repeatedly.
RandomAll Play all tracks in random order.
Dir Normal Repeat all tracks in the current folder.
Library
Return to the Music Browser screen.
Play List
Selet "Play List" and then "My List" to play a list of
your favorite songs.
To add songs to the list, see the section “Music Mode
> Music Browser Controls > Using the Quick Playlist” .
Lyric
Set the Lyric display ON or OFF.
Music Mode

Page 16
Browse for and view your photo les (JPG and
BMP).
For more information about how to get Photos onto
your player, please refer to the section “Transferring
Files to the Player”.
Photo Browser Controls
When you choose PhotoS mode from the Main
menu, you will see the Photo Browser screen. Your
Photos will be displayed as thumbnail images.
Use the Photo Browser to nd all Photo les loaded
on your player.
Function Key Action
To browse through the Photos
& folders
Press<UP>,<DOWN>,
<LEFT>,<RIGHT>
To select/view an item Press <ENTER>
To return to the previous screen Press <MENU>
Photo Mode
2
1
3
Pictures
Picture 001.jpg
2
1
1. Folder
2. Photo
3. Name of the
selected folder
or photo

Page 17
Function Key Action
To return to the Main menu Hold <MENU>
Photo Viewer Controls
To view a Photo, browse through the thumbnail
Photos and then press <ENTER>.
The following functions may be performed from the
Photo Viewer screen.
Function Key Action
To view the next Photo Press <RIGHT>
To view the previous Photo Press <LEFT>
To start or stop slideshow mode Press <ENTER>
To return to the Photo Browser
screen Press <MENU>
To return to the Main menu Hold <MENU>
Photo Mode

Page 18
Browse for and play your Video les.
Your player supports MTV les encoded at 128 x 128
and 25 fps. Videos may need to be encoded with the
included software for device playback.
For more information about converting video, please
refer to the section “Video Conversion”.
For more information about how to get Videos onto
your player, please refer to the section “Transferring
Files to the Player”.
Video Browser Controls
When you choose VideoS mode from the Main
menu, you will see the Video Browser screen.
Use the Video Browser to nd all Video les loaded
on your player.
Function Key Action
To browse through the list of Video
les & folders
Press <UP> or
<DOWN>
To select/play an item Press <ENTER>
To return to the previous screen Press <MENU>
To return to the Main menu Hold <MENU>
Video Playback Controls
The following functions may be performed from the
Now Playing screen.
Video Mode

Page 19
Function Key Action
To play the next Video Press <RIGHT>
To play the previous Video Press <LEFT>
To forward-scan quickly through the
current Video Hold <RIGHT>
To reverse-scan quickly through the
current Video Hold <LEFT>
To pause/resume playback Press <ENTER>
To adjust the volume level Press <UP> or
<DOWN>
To return to the Video Browser screen Press <MENU>
To return to the Main menu Hold <MENU>
Video Mode

Page 20
Read text les loaded on your player (TXT).
For more information about how to get text les onto
your player, please refer to the section “Transferring
Files to the Player”.
Text Browser Controls
When you choose Text from the Main menu, you will
see the Text Browser Screen.
Choose “All EBooks” to view all text les on the
player.
If text is already reading, you will have the
additional option to return to the “Now Reading”
screen.
Use the Text Browser to nd all text les loaded on
your player.
Function Key Action
To browse through the list of
text les & folders
Press <UP> or <DOWN>
To select/view an item Press <ENTER>
To return to the previous screen Press <MENU>
Text Reader Controls
The following functions may be performed from the
Text Display screen.
Text Mode
