MP-Man MID7C User manual

For Model No.
MID7C EN User Manual

Page 1
This manual contains important safety precautions and information of correct use.
Please be sure to read this manual carefully before use so as to avoid any accidents.
Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the product
inside a car with all windows closed.
Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions.
Select a proper volume to avoid ear problem when using earphones.
Do not cross the road or drive vehicles, using headphones to avoid trac accidents.
Be sure to use the provided chargers and accessories in the package.
Be sure to charge the product when the following situations take place,
- The battery icon shows lower or empty.
- System automatically shut down and it turns o soon after restart.
- Operation keys do not respond properly.
- The device shows on the top right corner.

Hardware
7.0” High Denition TFT LCD Touch Screen (800x480 pixel)
Capacitive multi-touch (2 touch) point function
CPU: Telechips TCC8902 ARM processor
RAM : DDR2 256MB (3D accelerator possible for 3D games)
Wi-Fi (IEEE802.11 b/g/n) for internet connection
HDMI port for TV-out (1080p output support)
USB host for OTG function
G-sensor
Micro SD card slot recognizing up to 32GB
Built-in speaker & Built-in MIC
5V DC power adapter
Compatible with keyboard, mouse
Dimension : 124 x 192 x 12.8mm
Andriod 2.3 Ginger Bread
Google browser
Wi-Fi connection
e-Book function (all e-book formats supported by application)
1080p HD le playback
VoIP phone function with Wi-Fi connection
Possible to view/edit MS oce les by application
Video: AVI, RM/ RMVB, FLV, MPG4 – 1, MPEG – 2 etc.
Audio: MP3, WMA, AAC, WAV ect.
Photo: JPEG, BMP, GIF, PNG, TIFF
Page 2
specification
Software

Page 3
Name
Important Notice
- If the device is freezing or stuck, press the
reset button(a small hole).
- When the performance is slow after using
some applications, it is recommended to
close running application in setting menu.
Caution
- For charging, be sure to use the power
adapter(DC5V) that is provided in the package,
otherwise, the device may be damaged
and does not work.
- The device is equipped with high performance
processor. It may heat in case of using long or
while charging.
MID7C
Menu Home Back
Charger Reset MicroSD slot
Speaker
Camera
Volume+
Volume-
Power
USB HDMI Earphone

Long press power button to turn on/o the device. It may take a minute to boot the device.
Short press power button to turn on/o the screen.(Standby mode. Refer to 3. below)
Page 4
1. Power On/Off
After turning on the device, desktop displays with shortcut icons and arrow panel at the right side
2. Desktop

Short press the power button to turn on/o the screen (standby mode on/o).
After standby mode o, slide the lock icon to the speaker icon in order to unlock the screen.
Page 5
3. Standby mode(Screen off mode) /
Unlock the screen

On the desktop, press menu button and select Settings.
4. System settings
Page 6

Press Settings
1.Wireless & networks
Page 7
Wi-Fi – Press Wi-Fi to turn on/o
Wi-Fi settings - Press Wi-Fi settings, press Network
notication, then the device will automatically
search the available Wi-Fi signals.
Select the network you want to connect with.
2. Sound & display
Set up each setting as you like.

Page 8
3. Location & security
Use wireless networks – Location determined by Wi-Fi and/or mobile networks
Set up screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern.
Visible passwords – Show password as you type.
Install from TF card – Install encrypted certicates from TF card.
Set password – Set or change the credential storage password.
4. Applications
Unknown sources
If you want to allow installation of non-Market Applications, Press Unknown sources and presses OK.

Manage applications
All installed application are listing.
Running services
View and control currently running services.
Storage use
View storage used by applications
Development
Set options for application development
Keep pressing an application to manage.
Press Uninstall to uninstall the selected application.
Page 9

Create your Gmail account. After connecting Wi-Fi network, the Gmail e-mailing system synchronizes
your Gmail account with the device. Emails are automatically downloaded into the device.
Page 10
Check device memory and microSD card status.
Unmount SD card – Unmount the SD card for safe removal.
5. Account & sync
6. Storage

Page 11
Select Language – Choose your preferable language.
Android keyboard – Android keyboard settings
On keyboard settings, select Input method and keyboard type.
If you need other languages besides English on keyboard, press the relevant keyboard
and enter the chosen Keyboard settings, select Keyboards, press the language you need.
7. Language & keyboard

Set date
Select time zone
Set time
Use 24-hour format
Select date format
8. Date & time
System updates – Check for system updates
Legal information
9. About device
Page 12

How to connect/disconnect the
device with/from the computer
On main desktop, connect the device with the PC, pull down the status bar on the top of desktop
Press “USB connected”, select “Turn on USB storage”.
The device is recognized at Explorer of the computer.
Now you can use it as an external storage.
After nishing your work,
Press “Turn o USB storage” to unmount it.
Page 13

Note
You may only download adult applications if you are at least 18 years of age, or at least the age of majority in the jurisdiction where you reside or from
which you download adult applications. If you do not meet these requirements, then you do not have permission to download adult applications.
In case of any problems including legal issues from the breach by end-user’s own decision, the manufacturer shall not be responsible.
How to install Applications(.apk file) into the device
Method 1.
1. Connect the device with internet. See above [1.Wireless & networks] in order to connect internet.
2. Run “Market” and search the applications you want to install.
3. Follow the instruction on the screen for installation.
Method 2.
1. With your computer, search application le(.apk) that you want to install into the device.
2. Download the le(.apk) into your computer.
3. Connect the device with your computer.
See above [How to connect/disconnect the device with/from the computer.]
4. Copy and paste .apk le into the device and disconnect it from your computer.
5. Run “ES File Explorer” and nd .apk le that was copied into the device.
6. Press the le to install and follow the instruction on the screen.
Page 14

How to make desktop icons
Long press the blank part of desktop, the pop-up displays.
Shortcuts
Press Shortcuts and press Applications. Press your desired APK icon to put it on the desktop.
Widgets
Press Widgets and press your desired icon to put it on the desktop.
Page 15

Folders
Press Folders and press New folder to create a new folder on the desktop.
Wallpaper
Press Wallpaper and select one of categories of wallpaper.
Select one you desire and press Set wallpaper.
Page 16

Change Input Method
If your device was installed with other more input method, long press Quick Search Box,
and the pop-up displays.
Page 17

Press Input method and select the installed keyboard,
then the keyboard will appear with your desired language you installed.
Page 18

Specification
OS
CPU
SDRAM
Display
Multi-touch screen
Built-in ash memory
ㅤ
ㅤ
ㅤ
IO PORTS
ㅤ
ㅤ
ㅤ
Speaker
G-sensor
Camera
Wi-Fi
Power
Battery
Dimension
Charging time
Android 2.3 Ginger Bread
Telechips 8902 ARM processor
DDR2 256MB (3D accelerator possible for 4D games)
7" TFT 800*480 Capacitive touch panel
Yes : 2 point multi-touch
2 / 4 / 8 / 16GB
3.5ø earphones
1 x 5pin mini USB port (support USB host and OTG)
5V, 2A
Yes
Micro SD card
Same with USB port
Power, VOL-, VOL+, reset, 3 android function key
1.5W, Frequency response : 20Hz – 20k Hz, N/S : >85%
Yes
0.3M pixel (front)
802.11b/g/n
Adaptor 5V -2A
3.7V 3500mAh Li-Polymer
124 x 192 x 12.8mm
approx. 3~4hours
Audio port
USB port
DC port
HDMI port
Micro SD
OTG port
Button
by charger
