MPP Solar MPI 12KW WP User manual

MPI 12KW WP/MPI 15KW WP
Hybrid PV Inverter
Version: 1.1
User Manual

Table Of Contents
1. Introduction.......................................................................................... 1
2. Important Safety Warning...................................................................... 2
3. Unpacking & Overview .......................................................................... 4
3-1. Packing List................................................................................... 4
3-2. Product Overview .......................................................................... 4
4. Installation ........................................................................................... 5
4-1. Precaution .................................................................................... 5
4-2. Selecting Mounting Location........................................................... 5
4-3. Mounting Unit ............................................................................... 5
5. Grid (Utility) Connection ........................................................................ 6
5-1. Preparation ................................................................................... 6
5-2. Connecting to the AC Utility ........................................................... 7
6. PV Module (DC) Connection ................................................................... 9
7. Battery Connection...............................................................................13
8. Load (AC Output) Connection ...............................................................14
8-1. Preparation ..................................................................................14
8-2. Connecting to the AC output .........................................................14
9. Communication Connection ..................................................................16
10. Dry Contact Signal ...............................................................................17
10-1. Electric Parameter ......................................................................17
10-2. Function Description ...................................................................18
11. Application with Energy Meter...............................................................19
12. Commissioning.....................................................................................20
13. Initial Setup .........................................................................................21
14. Operation ............................................................................................33
14-1. Interface....................................................................................33
14-2. LCD Information Define ..............................................................33
14-3. Touchable function keys..............................................................35
14-4. LCD Setting................................................................................36
14-5. LCD Display Information .............................................................45
14-6. Operation Mode & Display...........................................................50
15. Charging Management .........................................................................54
16. Maintenance & Cleaning .......................................................................56
17. Trouble Shooting..................................................................................57
17-1. Warning List...............................................................................57
17-2. Fault Reference Codes ................................................................58
18. Specifications.......................................................................................61
Appendix I: Parallel Installation Guide ..........................................................63
Introduction........................................................................................63
Parallel cable.......................................................................................63
Overview ............................................................................................63

Mounting the Unit ...............................................................................64
Wiring Connection ...............................................................................64
Inverters Configuration........................................................................66
Setting and LCD Display ......................................................................69
Commissioning....................................................................................72
Trouble shooting .................................................................................73
Appendix II: BMS ........................................................................................74
Appendix III: Wi-Fi Operation Guide.............................................................75

1
1. Introduction
This hybrid PV inverter can provide power to connected loads by utilizing PV power,
utility power and battery power.
Battery
Figure 1 Basic hybrid PV System Overview
Depending on different power situations, this hybrid inverter is designed to generate
continuous power from PV solar modules (solar panels), battery, and the utility. When
MPP input voltage of PV modules is within acceptable range (see specification for the
details), this inverter is able to generate power to feed the grid (utility) and charge
battery. This inverter is only compatible with PV module types of single crystalline and
poly crystalline. Do not connect any PV array types other than these two types of PV
modules to the inverter. Do not connect the positive or negative terminal of the solar
panel to the ground. See Figure 1 for a simple diagram of a typical solar system with this
hybrid inverter.
Note: By following the EEG standard, every inverter sold to German area is not allowed
to charge battery from Utility. The relevant function is automatically disabled by the
software.
PV modules
Hybrid inverter
Distribution Box
Electric grids
Load

2
2. Important Safety Warning
Before using the inverter, please read all instructions and cautionary
markings on the unit and this manual. Store the manual where it can be
accessed easily.
This manual is for qualified personnel. The tasks described in this manual may be
performed by qualified personnel only.
General Precaution-
WARNING! Before installing and using this inverter, read all instructions and cautionary
markings on the inverter and all appropriate sections of this guide.
WARNING! Normally grounded conductors may be ungrounded and energized when a
ground fault is indicated.
WARNING! This inverter is heavy. It should be lifted by at least two persons.
CAUTION! Authorized service personnel should reduce the risk of electrical shock by
disconnecting AC, DC and battery power from the inverter before attempting any
maintenance or cleaning or working on any circuits connected to the inverter. Turning off
controls will not reduce this risk. Internal capacitors can remain charged for 5 minutes
after disconnecting all sources of power.
CAUTION! Do not disassemble this inverter yourself. It contains no user-serviceable
parts. Attempt to service this inverter yourself may cause a risk of electrical shock or fire
and will void the warranty from the manufacturer.
CAUTION! To avoid a risk of fire and electric shock, make sure that existing wiring is in
good condition and that the wire is not undersized. Do not operate the Inverter with
damaged or substandard wiring.
Conventions used:
WARNING! Warnings identify conditions or practices that could result in personal
injury;
CAUTION! Caution identify conditions or practices that could result in damaged to the
unit or other equipment connected.

3
CAUTION! Under high temperature environment, the cover of this inverter could be hot
enough to cause skin burns if accidentally touched. Ensure that this inverter is away
from normal traffic areas.
CAUTION! Use only recommended accessories from installer. Otherwise, not-qualified
tools may cause a risk of fire, electric shock, or injury to persons.
CAUTION! To reduce risk of fire hazard, do not cover or obstruct the cooling fan.
CAUTION! Do not operate the Inverter if it has received a sharp blow, been dropped, or
otherwise damaged in any way. If the Inverter is damaged, please call for an RMA
(Return Material Authorization).
CAUTION! AC breaker, DC switch and Battery circuit breaker are used as disconnect
devices and these disconnect devices shall be easily accessible.
Symbols used in Equipment Markings
Refer to the operating instructions
Caution! Risk of danger
Caution! Risk of electric shock
Caution! Risk of electric shock. Energy storage timed
discharge for 5 minutes.
Caution! Hot surface
Before working on this circuit
-Isolate inverter/Uninterruptible Power System (UPS)
-Then check for Hazardous Voltage between all
terminals including the protective earth.
Risk of Voltage Backfeed

4
3. Unpacking & Overview
3-1. Packing List
Before installation, please inspect the unit. Be sure that nothing inside the package is
damaged. You should have received the following items inside of package:
Inverter unit PV connectors AC connector Fixing screws Parallel cables
Software CD Manual RS-232 cable Share current cable
3-2. Product Overview
1) Battery connectors
2) PV connectors
3) RS-232 communication port
4) BMS
5) Dry contact
6) EPO
7) Battery thermal sensor
8) USB communication port
9) Touchable buttons
10) LCD display panel (Please check
section 14 for detailed LCD
operation)
11) AC Grid connectors
12) AC output connectors (Load
connection)
13) Parallel communication port
14) Current sharing port
15) Intelligent slot
16) DC switch
17) Cold start button

5
4. Installation
4-1. Precaution
This Hybrid inverter is designed for indoor or outdoor use (IP65), please make sure the
installation site meets below conditions:
Not in direct sunlight
Not in areas where highly flammable materials are stored.
Not in potential explosive areas.
Not in the cool air directly.
Not near the television Antenna or antenna cable.
Not higher than altitude of about 2000 meters above sea level.
Not in environment of precipitation or humidity (>95%)
Please AVOID direct sunlight, rain exposure, snow laying up during installation and
operation.
4-2. Selecting Mounting Location
Please select a vertical wall with load-bearing capacity for installation, appropriate
for installation on concrete or other non-flammable surfaces.
The ambient temperature should be between -25~60℃to ensure optimal
operation.
Be sure to keep other objects and surfaces as shown in the diagram to guarantee
sufficient heat dissipation and have enough space for removing wires.
For proper air ventilation to dissipate heat, allow a clearance of approx. 50cm to
the side and approx. 50cm above and below the unit. And 100cm toward the front.
4-3. Mounting Unit
Installation to the wall should be implemented with the proper screws. After that, the
device should be bolted on securely.
WARNING!! FIRE HAZARD.
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE
ONLY.
WARNING!! Remember that this inverter is heavy! Please be carefully when lifting
out from the package.

6
1. Drill six holes in the marked
locations with supplied six screws.
The reference tightening torque is
35 N.m.
2. Fix the inverter on the wall.
3. Check if the inverter is firmly
secured.
5. Grid (Utility) Connection
5-1. Preparation
NOTE: The overvoltage category of the AC input is III. It should be connected to the
power distribution.
NOTE2: Before connecting to grid, please install a separate AC breaker between
inverter and grid. The recommended of AC breaker is 40A.
WARNING! It's very important for system safety and efficient operation to use
appropriate cable for grid (utility) connection. To reduce risk of injury, please use the
proper recommended cable size as below.
Suggested cable requirement for AC wire:
Nominal Grid Voltage
230VAC per phase
Conductor cross-section (mm2)
10-16
AWG no.
8-6

7
5-2. Connecting to the AC Utility
Overview of AC Connection Socket
Component
Description
A
Pressure dome
B
Clip
C
Sealing nut
D
Protective element
E
Socket element
Step 1: Check the grid voltage and frequency with an AC voltmeter. It should be the
same to “VAC” value on the product label.
Step 2: Turn off the circuit breaker.
Step 3: Remove insulation sleeve 13 mm for five conductors.
Step 4: Thread the five cables through pressure dome
(A), clip (B), sealing nut (C) and protective element (D) in
sequence.
Step 5: Thread five cables through socket element (E)
according to polarities indicated on it and tighten the screws to fix wires after
connection.
L1→LINE 1 (Black)
L2→LINE 2 (Grey)
L→LINE 3 (Brown)
→Ground (Yellow-Green)
N→Neutral (Blue)
The reference tightening torque is 1.5-2.5 N.m.
Step 6: Push protective dome (D) on to socket element (E) until both are locked tightly.
Then, twist protective element (D) and pressure dome (A) so that all cables are firmly
connected.
A
B
C
D
E

8
Step 7: Plug the AC connection socket into AC grid terminal of the inverter.
CAUTION: To prevent risk of electric shock, ensure the ground wire is properly earthed
before operating this hybrid inverter no matter the grid is connected or not.

9
6. PV Module (DC) Connection
NOTE1: Please use 1000VDC/20A circuit breaker.
NOTE2: The overvoltage category of the PV input is II.
Please follow below steps to implement PV module connection:
Step 1: Check the input voltage of PV array modules. The acceptable input voltage of the
inverter is 350VDC - 1000VDC. This system is only applied with two strings of PV array.
Please make sure that the maximum current load of each PV input connector is 23A.
Step 2: Disconnect the circuit breaker and switch off the DC switch.
Step 3: Assemble provided PV connectors with PV modules by the following below steps.
Components for PV connectors and Tools:
Female connector housing
Female terminal
Male connector housing
Male terminal
CAUTION: Exceeding the maximum input voltage can destroy the unit!! Check the
system before wire connection.
WARNING: Because this inverter is non-isolated, only two types of PV modules are
acceptable: single crystalline and poly crystalline with class A-rated.
To avoid any malfunction, do not connect any PV modules with possibility of leakage
current to the inverter. For example, grounded PV modules will cause leakage current to
the inverter.
CAUTION: It’s requested to have PV junction box with surge protection. Otherwise, it
will cause inverter damage when lightning occurs on PV modules.

10
Crimping tool and spanner
Cable preparation and connector assembly process:
Strip one cable 8 mm on both end sides and be careful NOT to
nick conductors.
Insert striped cable into female terminal and crimp female
terminal as shown below charts.
Insert assembled cable into female connector housing as shown below charts.
Insert striped cable into male terminal and crimp male terminal as shown below charts.
Insert assembled cable into male connector housing as shown below charts.
Then, use spanner to screw pressure dome tightly to female connector and male
connector as shown below.

11
Step 4: Check correct polarity of connection cable from PV modules and PV input
connectors. Then, connect positive pole (+) of connection cable to positive pole (+) of
PV input connector. Connect negative pole (-) of connection cable to negative pole (-) of
PV input connector.
WARNING! It's very important for system safety and efficient operation to use
appropriate cable for PV module connection. To reduce risk of injury, please use the
proper recommended cable size as below.
Conductor cross-section (mm2)
AWG no.
6
10
CAUTION: Do NOT touch the inverter to avoid electric shock. When PV modules are
exposed to sunlight, it may generate DC voltage to the inverter.
CAUTION: Never directly touch terminals of the inverter. It will cause lethal electric
shock.

12
Recommended Panel Configuration
Solar panel
Nominal Max. Power (Pmax) (W)
430
455
520
535
Opt. Operating Voltage (Vmp) (V)
40.3
41.3
41.6
41.9
Opt. Operating Current (Imp) (A)
10.68
11.02
12.5
12.77
Open Circuit Voltage (Voc) (V)
48.3
49.3
49.14
49.44
Short Circuit Current (Isc) (A)
11.37
11.66
13.23
13.5
For 16KW input recommendation
Numbers in series of MPPT1
19
18
16
15
Numbers of strings in MPPT1
1
1
1
1
Maximum input voltage of MPPT1 (V)
917.7
887.4
786.24
741.6
Input power of MPPT1 (W)
8170
8190
8320
8025
Numbers in series of MPPT2
19
18
16
15
Numbers of strings in MPPT2
1
1
1
1
Maximum input voltage of MPPT1 (V)
917.7
887.4
786.24
741.6
Input power of MPPT2 (W)
8170
8190
8320
8025
Total input power (W)
16340
16380
16640
16050
Minimum input recommendation
Numbers in series of MPPT1
10
10
10
10
Numbers of strings in MPPT1
1
1
1
1
Maximum input voltage of MPPT1 (V)
483
493
491.4
494.4
Input power of MPPT1 (W)
4300
4550
5200
5350
Numbers in series of MPPT2
10
10
10
10
Numbers of strings in MPPT2
1
1
1
1
Maximum input voltage of MPPT1 (V)
483
493
491.4
494.4
Input power of MPPT2 (W)
4300
4550
5200
5350

13
7. Battery Connection
CAUTION: Before connecting to batteries, please install separately a DC circuit
breaker between inverter and batteries.
NOTE1: Please only use sealed lead acid battery, vented and Gel battery. Please check
maximum charging voltage and current when first using this inverter. If using Lithium
iron or Nicd battery, please consult with installer for the details.
NOTE2: Please use 60VDC/300A circuit breaker.
NOTE3: The overvoltage category of the battery input is II.
Please follow below steps to implement battery connection:
Step 1: Check the nominal voltage of batteries. The nominal input voltage for inverter is
48VDC.
Step 2: Use two battery cables. Remove insulation sleeve 12
mm and insert conductor into cable ring terminal. Refer to
right chart.
Step 3: Remove battery cover and follow battery polarity guide
printed near the battery terminal! Place the external battery cable ring terminal over the
battery terminal.
RED cable to the positive terminal (+);
BLACK cable to the negative terminal (-).
WARNING! Wrong connections will damage the unit permanently.
Step 4: Make sure the wires are securely connected. The reference tightening torque is
5.5~7.0 N.m.
WARNING! It's very important for system safety and efficient operation to use
appropriate cable for battery connection. To reduce risk of injury, please use the proper
recommended cable size as below.
Model
Nominal Battery
Voltage
Conductor cross-
section (mm2)
AWG
no.
Protective earthing
(battery side)
MPI 12KW
WP
48V
107
4/0
150mm2(300kcmil)
MPI 15KW
WP
48V
151
300
150mm2(300kcmil)

14
8. Load (AC Output) Connection
8-1. Preparation
CAUTION: To prevent further supply to the load via the inverter during any mode of
operation, an additional disconnection device should be placed on in the building wiring
installation.
WARNING! It's very important for system safety and efficient operation to use
appropriate cable for AC connection. To reduce risk of injury, please use the proper
recommended cable size as below.
Nominal Grid Voltage
208/220/230/240 VAC per phase
Conductor cross-section (mm2)
5.5-10
AWG no.
10-8
8-2. Connecting to the AC output
Overview of Load Connection Socket
Component
Description
A
Pressure dome
B
Clip
C
Sealing nut
D
Protective element
E
Socket element
Step 1: Remove insulation sleeve 8.5 mm for five conductors.
Step 2: Thread the five cables through pressure dome
(A), clip (B), sealing nut (C) and protective element (D)
in sequence.
Step 3: Thread five cables through socket element (E)
according to polarities indicated on it and tighten the
screws to fix wires after connection.
A
B
C
D
E

15
L1→LINE 1 (Black)
L2→LINE 2 (Grey)
L→LINE 3 (Brown)
→Ground (Yellow-Green)
N→Neutral (Blue)
The reference tightening torque is 1.0-1.5 N.m.
Step 4: Push protective dome (D) on to socket element (E) until both are locked tightly.
Then, twist protective element (D) and pressure dome (A) so that all cables are firmly
connected.
Step 5: Plug the socket into the terminal.
CAUTION: It’s only allowed to connect load to “AC Output Connector”. Do NOT connect
the utility to “AC Output Connector”.
CAUTION: Be sure to connect L terminal of load to L terminal of “AC Output Connector”
and N terminal of load to N terminal of “AC Output Connector”. The G terminal of “AC
Output Connector”is connected to grounding of the load. Do NOT mis-connect.

16
9. Communication Connection
Serial Connection
The inverter is equipped with several communication ports and it is also equipped with a
slot for alternative communication interfaces in order to communicate with a PC with
corresponding software. This intelligent slot is suitable to install with SNMP card and
Modbus card. Follow below procedure to connect communication wiring and install the
software.
For RS232 or BMS port, use a RJ45 cable
as follows:
For USB port, use a USB cable as follows:
For Dry contact port, please remove
insulation sleeve 8 mm for three
conductors and insert three cables into
ports
For SNMP or MODBUS port, use the RJ45
cables as follows:
Please install monitoring software in your computer. Detailed information is listed in the
chapter 12. After software is installed, you may initial the monitoring software and
extract data through communication port.
Wi-Fi Connection
Wi-Fi module can enable wireless communication between off-grid inverters and
monitoring platform. Users have complete and remote monitoring and controlling
experience for inverters when combining Wi-Fi module with SolarPower APP, available for
both iOS and Android based device. All data loggers and parameters are saved in iCloud.

17
For quick installation and operation, please refer to Appendix III - The Wi-Fi Operation
Guide for details.
10. Dry Contact Signal
There is one dry contact available on the bottom panel. It could be used to
remote control for external generator.
10-1. Electric Parameter
Parameter
Symbol
Max.
Unit
Relay DC voltage
Vdc
30
V
Relay DC current
Idc
1
A
Note: The application of the dry contact should not exceed the electric
parameter shown as above. Otherwise, the internal relay will be damaged.
