mPTech HAMMER BLADE 3 User manual

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
20
QUICK START GUIDE
HAMMER BLADE 3
Lot number: 202006
1. Table of contents
1. Table of contents ........................................................................ 20
2. Safety ............................................................................................. 21
3. The use of the manual ............................................................. 24
4. Important information ............................................................. 24
4.1 Trademarks ....................................................................... 25
5. Package content ........................................................................ 26
6. Technical Specifications ........................................................... 26
7. Appearance of the phone ......................................................... 27
8. Buttons ......................................................................................... 29
9. Using the touch screen ............................................................ 29
9.1 Touch .................................................................................. 29
9.2 Swipe ................................................................................. 30
9.3 Triple click ......................................................................... 30
9.4 Hold and swipe ............................................................... 30
9.5 Slide in and out .............................................................. 30
10. Communication ......................................................................... 30
10.1 Making calls .................................................................... 30
10.2 SMS - Messages ............................................................ 31
11. Maintenance of the device ...................................................... 31
12. Correct disposal of used equipment ................................... 31
13. Correct disposal of used battery ........................................ 32

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
21
CAUTION!
Statement
The manufacturer is not
responsible for the
consequences of
situations caused by
improper use of the phone
or failure to follow the
instructions in the
operating manual.
The software version can
be upgraded without earlier
notice. The manufacturer’s
representative reserves the
right to decide on the
correct interpretation of
this manual.
2. Safety
—DO NOT RISK—
All wireless devices may cause interferences, which could
affect the quality of other connections. Do not switch the
device on in places which are prohibited from using cell
phones, or when it may cause interferences or other
dangers. Always abide by any kinds of prohibitions,
regulations and warnings conveyed by the personnel of the
facility.
—RESTRICTIONS IN USE—
Wi-Fi wireless connectivity uses the 2.4 GHz band
and the 5 GHz band. The 5 GHz Wi-Fi band shall
not be used outdoors in the European Union.
Please observe the national and local
regulations at the place of use.
—QUALIFIED SERVICE—
Only qualified personnel or an authorized service center may
install or repair this product. Repairing by an unauthorized
or unqualified service may cause device damage and
warranty loss.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
22
—ALARM CALLS—
Making alarm calls may not be possible in some areas or
circumstances. It is recommended to find an alternative way
to notify emergency services if you are going to this type of
remote areas.
—PETROL STATIONS—
Do not use your mobile phone while refuelling at a petrol
station or in the vicinity of chemicals.
CAUTION! In places where there is a risk of explosion (i.e.
Petrol stations, chemical factories etc.), it is advisable to
turn off the phone. Please refer to regulations governing the
use of GSM equipment in these places.
—ROAD SAFETY—
Apart from emergency situations, using the phone while
driving should be carried out only with use of a headset or
a speakerphone, which ensures safety and does not limit
motor abilities of the user. If you do not own a headset and
still want to use the phone, you should pull over and stop
the car. Pay attention to the legal regulations concerning
the use of mobile phone while driving. Some electronic
components of the car without adequate protection can be
affected by waves emitted by the phone; it is therefore
advisable to use the phone in the car only when the external
antenna of the vehicle is secured. Use the services of a
professional when installing the phone in the car.
—CHILDREN AND PHYSICALLY OR MENTALLY DISABLED
PEOPLE—
This device should not be operated by people (including
children) with limited physical or mental abilities, as well as
by people with no earlier experience in operation of
electronic equipment. They may use the device only under
supervision of people responsible for their safety. This
device is not a toy. Memory card and SIM card are small
enough to be swallowed by a child and cause choking. Keep
the device and its accessories out of reach of children.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
23
—BATTERY AND ACCESSORIES—
Avoid exposing the battery to very high/low temperatures
(below 0°C/32°F and over 40°C/104°F). Extreme
temperatures may influence capacity and battery life. Avoid
contact with liquids and metal objects as it may cause
partial or complete battery damage. The battery should be
used only according to its purpose. Do not destroy, impair
or throw the battery into flames - it is dangerous and may
cause fire. Worn-out or impaired battery should be placed
in a dedicated container. Excessive charging the battery can
cause damage. Therefore a single battery charge should not
last longer than 1 day. Installing an incorrect battery type
can cause an explosion.
Never open the battery. Please dispose of battery according
to the instructions. Disconnect an unused charger from
power grid. In case of the charger wire damage, it should
not be repaired but replaced with a new one. Use only the
original manufacturer’s accessories.
—WATER AND OTHER LIQUIDS—
The device has resistance certificate IP69. It means that the
device is dust-proof and waterproof when all of the rubber
seals are intact and properly put in place.
IP6x - The standard indicates total protection against the
ingress of dust.
IPx9 - The symbol indicates protection against flooding with
a jet of pressurized water (force applied to the surface of
the device 0.9-1.2 N, water temperature up to +80°C). The
jet of water directed at angles of 0°, 30°, 60° and 90° for 30
seconds.
As far as possible protect the device from water and other
liquids. Water and other fluids do not have a positive effect
on phone electronic components. If wet, wipe and dry the
device as soon as possible.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
24
The device is not resistant to salt water.
Make sure the USB cable is dry before connecting it
to the phone’s charging socket. Plugging the cable into a
wet or damp outlet exposes it to slow corrosion and may
cause problems with charging your phone.
—SOUNDS—
To avoid hearing damage, do not use the device
at high volume levels for a long period of time,
do not put operating device directly to the ear!
—EYESIGHT—
To avoid eyesight damage do not look closely
onto the flash light when it flashes. A strong
bean of light may cause permanent eye
damage!
3. The use of the manual
The device and the screenshots shown in the illustrations in
this manual may differ from those in the actual product.
Accessories attached to the smartphone set may differ from
the illustrations included in manual.
Options described in the manual are found in Android™
system. Those descriptions may differ, depending on the
version of the operating system and applications installed
on the device.
Without prior written consent of the manufacturer, no part
of this manual may be photocopied, reproduced, translated
or transmitted any form or by any means, electronic or
mechanical, including photocopying, recording or storing in
any systems of storing and sharing information.
4. Important information
The majority of applications which can be installed on the
device are mobile apps. Modus operandi of such applications
may be different from their counterparts installed on a

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
25
personal computer. Apps installed on the device may vary
depending on country, region, and hardware specifications.
The manufacturer is not liable for problems caused by third
party software. The manufacturer is not responsible for
anomalies that may occur when editing the registry
settings and modifying the operating system software.
Attempts to modify the operating system can cause
malfunctions and problems with applications. It may cause
a loss of warranty.
Android System™
The Android 10 system includes several new solutions that
are essential for better interaction between the
smartphone and the user. The system is equipped with live
subtitles, a dark theme, a sound amplifier and many privacy
and security improvements. Google Play
Google Play is your entertainment unbound. It brings
together all of the entertainment you love and helps you
explore it in new ways, anytime, anywhere. We’ve brought
the magic of Google to music, movies, TV, books, magazines,
apps and games, so you get more from your content every
day.
4.1 Trademarks
•Google, Android, Google Play, and other marks are
trademarks of Google LLC.
•Oracle and Java are a registered trademarks of Oracle
and/or its affiliates.
•Wi-Fi® and Wi-Fi logo are a registered trademarks of
Wi-Fi Alliance association.
•All other trademarks and copyrights belong to their
respective owners.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
26
The Android robot is reproduced or modified from work
created and shared by Google and used according to
terms described in the Creative Commons 3.0 Attribution
License.
Manufacturer:
mPTech Sp. z o. o.
Nowogrodzka street 31
00-511 Warsaw
Poland
www.myphone-mobile.com
Made in China
5. Package content
•Mobile phone HAMMER BLADE 3
•Charger (adapter + USB cable)
•User manual
If any of the above items is missing or damaged, please
contact your dealer.
6. Technical Specifications
Processor: Octa-Core MTK6762
Display: 6.2" HD+, 720 x 1520px IPS Gorilla Glass 3
Main camera (rear): 48.0Mpx
Front camera (selfie): 8.0Mpx
RAM memory: 4 GB
Internal memory: 64 GB
Card reader: microSD (max. 128 GB)
Operating system: Android 10
Dual SIM: eSIM + nanoSIM or 2x nanoSIM (hybrid)
Connector: USB-C
Resistance: IP69, IK07
Connectivity: NFC, Wi-Fi 2.4GHz/5.0Ghz, GPS, Glonass,
Bluetooth 5.0
2G (GSM): 850/900/1800/1900 Mhz
UMTS: 850/900/2100 Mhz

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
27
LTE: 800/850/900/1800/2100/2300/2600 Mhz
Battery: 5000mAh Express Charging
Charger input parameters: 100-240V – 0.5A, 50/60Hz
Charger output parameters: 5, 7, 9V 1.67A; 12V 1.25A,
8.3W
Average efficiency during operation (for 230V, 50hz): 77.06%
Energy consumption in no-load condition: less than 0.3W
Weight: 245g
Dimensions: 163.6 x 78.2 x 12mm
7. Appearance of the phone
Function
1
Notification diode
2
Brightness and proximity sensors
3
Internal speaker
4
Digital camera lens 8Mpx (selfie)
5
Digital camera lenses 48Mpx (main)
6
Lighting diode / Camera flashlight
7
The tray for SIM cards/ microSD (under a waterproof
seal)
8
Volume increase/decrease buttons
9
Fingerprint reader
10
Programmable button
11
Blockade on/off button
12
Touchscreen 6.2"
13
External speaker
14
Multifunctional microUSB-C port
15
Microphone
16
SOS button

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
28
17
Installation positioning for SIM and microSD cards -
hybrid Dual SIM
8. eSIM function
A Wi-Fi or mobile data network connection is required for
eSIM connection.
8.1 Start-up and activation of the eSIM card
Select from the menu list and start eSIM application.
Activation of the card is done by downloading its profile
using a special eSIM code (received from your network
operator). You can scan the eSIM card code with a QR code
scanner or enter it manually by pressing the icon at the
bottom right of the application. After scanning or entering
the code, the card profile will download automatically.
When the profile is
downloaded, a
window with card
information and a
network coverage icon
in the top status bar
appears.
8.2 Turning off and deleting the profile
The card profile can be disabled by clicking the icon .
Clicking the icon again will turn the profile back on. When it
is turned off, the coverage icon disappears.
To delete the eSIM card profile completely, select the bin
symbol .
If you want to deactivate eSIM, go to the advanced
functions in the phone settings and deactivate eSIM by
sliding the slider. The phone then returns to the normal
DualSIM function (2x nanoSIM).

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
29
9. Buttons
Menu (virtual)
Pressing it will cause the list of open apps to appear - there
you can switch in-between or turn them off.
Home (virtual)
One quick press takes you to main screen. A longer press
launches Google Assistant.
Back (virtual)
Press to exit the application / return to the previous screen.
Blockade on/off button
•One quick press locks / unlocks the screen.
•Pressing the button for about 2 sec. will cause:
oif the smart phone is off - the device switches on,
oif your smartphone is on - activates a menu to
shut down the device or reboot the system.
Volume increase and decrease buttons
Pressing during a voice call will cause an increase or
decrease of the audio connection volume.
Programmable button
Pressing on an unlocked smartphone launches the camera
application. You can change its function using the settings
menu.
10. Using the touch screen
The smartphone’s touchscreen makes it easy to select
items, perform operations and gestures. The touchscreen
can be controlled by the
following actions.
10.1 Touch
Touch one to start options, an
app, menu.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
30
10.2 Swipe
Quickly swipe up, down, to the
left or to the right, to scroll the
list or the screen.
10.3 Triple click
Quickly tap the screen three
times to start zooming - if this
option is enabled in your
smartphone settings.
10.4 Hold and swipe
Touch an element (an icon
perhaps) and hold it for about 1
second. Then you can move,
delete/uninstall that element.
10.5 Slide in and out
Touch the screen with two
fingers and slide them together
or apart to zoom in or out a
photo or a map.
11. Communication
11.1 Making calls
To make a call touch [Phone] , icon placed on the main
screen or in Android applications menu and choose the
keyboard icon . Insert the phone number you wish to
call. Press „handset” placed at the bottom of the screen and
choose which SIM card you wish to use.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
31
11.2 SMS - Messages
You can manage messages using the [Messages]
application situated on the main screen or in applications
menu. Start the application and touch the icon
, enter the phone number, contact, or choose from the list.
When you have chosen the contact a screen will appear
where you type the message itself. Enter message content.
Before you send a text message you can transform it into
a multimedia message by pressing symbol , located on
the left side of the content window and add a sticker, photo,
video, audio or location. To send the message press .
12. Maintenance of the device
Follow the instructions below.
•For cleaning use only a dry cloth. Never use any agent
with a high concentration of acids or alkalis.
•Use the original accessories only. Violation of this rule
may result in an invalidation of the warranty.
13. Correct disposal of used equipment
The device is marked with a crossed-out
garbage bin, in accordance with the European
Directive 2012/19/EU on used electrical and
electronic Equipment (Waste Electrical and
Electronic equipment - WEEE). Products
marked with this symbol should not be
disposed of or dumped with other household waste after a
period of use. The user is obliged to get rid of used electrical
and electronic equipment by delivering it to designated
recycling point in which dangerous waste are being recycled.

EN © 2020 mPTech. All Rights Reserved. HAMMER BLADE 3
32
Collecting this type of waste in designated locations, and
the actual process of their recovery contribute to the
protection of natural resources. Proper disposal of used
electrical and electronic equipment is beneficial to human
health and environment.
To obtain information on where and how to dispose of used
electrical and electronic equipment in an environmentally
friendly manner user should contact their local government
office, the waste collection point, or point of sale, where the
equipment was purchased.
14. Correct disposal of used battery
According to the EU directive 2006/66/EC with
changes contained in EU directive 2013/56/UE
on the disposal of batteries, this product is
marked with crossed-out garbage bin symbol.
The symbol indicates that the batteries used
in this product should not be disposed with regular
household waste, but treated according to the legal
directives and local regulations. It is not allowed to dispose
of batteries and accumulators with unsorted municipal
waste. Users of batteries and accumulators must use the
available collection points of these items, which allows them
to return, recycle and disposal. Within the EU, the collection
and recycling of batteries and accumulators is a subject to
separate procedures. To learn more about existing
procedures of recycling of batteries and accumulators
please contact your local office or an institution for waste
disposal or landfill.
