MQ Multiquip WHITEMAN Series Guide

OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.
MODEL
WM70SH5/WM70PH5
WM70SH8/WM70PH8
WM70SE/WM70PE
PLASTER AND MORTAR MIXER
( HONDA GX160/GX240 SERIES GASOLINE ENGINES
AND 1.5 HP ELECTRIC MOTOR)
Revision #8 (04/18/18)
SERIES
Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.
Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101
Need parts?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and
choose one of the options to help get the right parts and equipment you are looking
for. Please have the machine model and serial number available in order to help us
get you the correct parts. If you don’t find the part on the website or on one of the
online manuals, please fill out the request form and one of our experienced staff
members will get back to you with a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,
Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,
Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,
Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,
Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,
Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,
Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,
APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith
Surface Prep,Small Line, Wanco, Yanmar

PAGE 2 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
itsconstituents,andsomedustcreated
of California to cause cancer, birth
defects and other reproductive harm.
by power sanding, sawing, grinding,
drillingandotherconstructionactivities
contains chemicals known to the State
Someexamplesofthesechemicalsare:
Leadfromlead-basedpaints.
Crystallinesilicafrombricks.
Cementandothermasonryproducts.
Arsenicandchromiumfromchemically
treatedlumber.
Your risk from these exposures varies,
dependingonhowoftenyoudothistype
of work.To reduce your exposure to
these chemicals: work in aALWAYS
well ventilated area, and work with
approved safety equipment, suchas
dust masks that are specially designed
to filter out microscopic particles.
Gasoline engine exhaust and some of
FUEL AND CHEMICAL EXPOSURE WARNINGS
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 3
Grinding/cutting/drillingofmasonry,concrete,metaland
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis.Inaddition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentionedabove.
WARNING
Grinding/cutting/drillingofmasonry,concrete,metaland
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity,or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations.Water should be used for dust
suppression when wet cutting is feasible. When the
hazardsfrom inhalation ofdust,mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHAfor
thematerialsbeingused.
WARNING
SILICOSISWARNING RESPIRATORY HAZARDS
SILICOSIS/RESPIRATORY WARNINGS
Go to Discount-Equipment.com to order your parts

PAGE 4 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
TABLE OF CONTENTS
WM70S/P Series Plaster
And Mortar Mixer
Fuel And Chemical Exposure Warnings.................. 2
Silicosis/Respiratory Warnings ................................ 3
Table Of Contents.................................................... 4
Parts Ordering Procedures...................................... 5
Training Checklist .................................................... 6
Safety Information .............................................. 7-12
Mixer Specifications/Noise And Vibration .............. 13
Engine/Electric Motor Specifications ..................... 14
General Information............................................... 15
Basic Components (Mixer) .................................... 16
Engine Components.............................................. 17
Electric Motor Components .............................. 18-19
Towing Guidelines ................................................. 20
Safety Chain Connection....................................... 21
Inspection ......................................................... 22-24
Start-Up ........................................................... 25-26
Operation.......................................................... 26-29
Maintenance (Engine) ...................................... 30-32
Maintenance (Mixer)......................................... 33-37
Troubleshooting (Mixer/Electric Motor) .................. 38
Troubleshooting (Engine).................................. 39-40
Explanation Of Code In Remarks Column............. 42
Suggested Spare Parts ......................................... 43
Component Drawings
Nameplate And Decals Assembly..................... 44-45
Frame Assembly............................................... 46-47
Paddle Shaft Assembly..................................... 48-49
Steel Drum Assembly....................................... 50-51
Plastic Drum Assembly..................................... 52-53
Drum And Paddle Shaft Compl. Assy. (Plastic) 54-55
Drum And Paddle Shaft Compl. Assy. (Steel)... 56-57
Axle Assembly .................................................. 58-59
Engine Assembly.............................................. 60-61
Electric Motor Assy. ......................................... 62-63
Cabinet Assembly............................................. 64-65
Engine Service Parts........................................ 66-67
Terms And Conditions Of Sale — Parts ................ 68
NOTICE
Specifications and part numbers are subject to change
without notice.
Go to Discount-Equipment.com to order your parts

PAGE 6 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
TRAINING CHECKLIST
Training Checklist
No, Description OK? Date
1Read operation manual
completely.
2
Machine layout, location of
components, checking of engine
oil levels.
3 Fuel system, refueling procedure.
4Operation of controls (machine
not running).
5Safety controls, safety stop switch
operation.
6 Emergency stop procedures.
7 Machine transport and storage.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 7
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION
or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Lethal exhaust gas hazards
Explosive fuel hazards
Burn hazards
Rotating parts hazards
Symbol Safety Hazard
Go to Discount-Equipment.com to order your parts

PAGE 8 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
SAFETY INFORMATION
GENERAL SAFETY
CAUTION

NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.

Avoid wearing jewelry or loose fitting clothes that may
snag on the controls or moving parts as this can cause
serious injury.

NEVER operate this equipment when not
feeling well due to fatigue, illness or when
under medication.

NEVER operate this equipment under the
influence of drugs or alcohol.

ALWAYS clear the work area of any debris, tools, etc.
that would constitute a hazard while the equipment is
in operation.

ALWAYS check the equipment for loosened threads or
bolts before starting.

DO NOT use the equipment for any purpose other than
its intended purposes or applications.
NOTICE

This equipment should only be operated by trained and
qualified personnel 18 years of age and older.

Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.

Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVER
use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
ALWAYS know the location of the nearest
fire extinguisher.
ALWAYS know the location of the nearest
first aid kit.
ALWAYS know the location of the nearest phone or
keep
a phone on the job site.
Also, know the phone numbers
of the nearest ambulance, doctor and
fire department.
This information will be invaluable in the case of an
emergency.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 9
SAFETY INFORMATION
MIXER SAFETY
DANGER

NEVER operate the equipment in an explosive
atmosphere or near combustible materials.An
explosion or fire could result causing severe
bodily harm or even death.

DO NOT mix flammable or explosive substances.
WARNING

NEVER place your hands inside the drum
while starting or operating this equipment.

NEVER disconnect any emergency
or safety devices. These devices are
intended for operator safety. Disconnection of these
devices can cause severe injury, bodily harm or even
death. Disconnection of any of these devices will void
all warranties.

Before operating mixer, ensure that safety grate is in
position and correctly fitted.
CAUTION

NEVER lubricate components or attempt service on a
running machine.
NOTICE

ALWAYS keep the machine in proper running condition.

ALWAYS ensure mixer is on level ground before mixing.

Fix damage to machine and replace any broken parts
immediately.

DO NOT tip mixer onto drum mouth when the drum is
rotating.

Ensure the drum is rotating while filling and emptying
the drum.

ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
ENGINE SAFETY (GASOLINE MODELS ONLY)
DANGER

Engine fuel exhaust gases contain poisonous carbon
monoxide. This gas is colorless and odorless, and can
cause death if inhaled.

The engine of this equipment requires an adequate
free flow of cooling air. NEVER
operate this equipment
in any enclosed or narrow
area where free flow of the
air is restricted. If the air
flow is restricted it will cause
injury to people and property
and serious damage to the
equipment or engine.
WARNING
DO NOT
place hands or fingers inside engine
compartment when engine is running.
NEVER
operate the engine with heat shields or
guards removed.
Keep fingers, hands hair and clothing away
from all moving parts to prevent injury.
DO NOT remove the engine oil drain plug
while the engine is hot. Hot oil will gush out of the oil
tank and severely scald any persons in the general area
of the mixer.
CAUTION
NEVER touch the hot exhaust manifold,
muffler or cylinder. Allow these parts to cool
before servicing equipment.

Make certain the operator knows how to and is capable
of turning the engine OFF in case of an emergency.
NOTICE
NEVER
run engine without an air filter or with a dirty air
filter. Severe engine damage may occur. Service air filter
frequently to prevent engine malfunction.
NEVER tamper with the factory settings
of the engine or engine governor. Damage
to the engine or equipment can result
if operating in speed ranges above the
maximum allowable.
DANGEROUS
GAS FUMES
Go to Discount-Equipment.com to order your parts

PAGE 10 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
SAFETY INFORMATION
FUEL SAFETY (GASOLINE MODELS ONLY)
DANGER

DO NOT start the engine near spilled fuel or combustible
fluids. Fuel is extremely flammable and its vapors can
cause an explosion if ignited.

ALWAYS refuel in a well-ventilated area, away from
sparks and open flames.

ALWAYS use extreme caution when working with
flammable liquids.

DO NOT fill the fuel tank while the engine is running
or hot.

DO NOT overfill tank, since spilled fuel could ignite if it
comes into contact with hot engine parts or sparks from
the ignition system.

Store fuel in appropriate containers, in well-ventilated
areas and away from sparks and flames.

NEVER use fuel as a cleaning agent.

DO NOT smoke around or near the
equipment. Fire or explosion could result
from fuel vapors or if fuel is spilled on a
hot engine.
GENERATOR SAFETY
If using a generator to power mixer, refer to
applicable generator manual safety information
section.
ELECTRIC MOTOR SAFETY
(ELECTRIC MODELS ONLY)
NOTICE

Operate electric motor only at the specified voltage
indicated on the nameplate.

DO NOT spray water onto electric motor.

ALWAYS disconnect AC power plug from power source
before moving mixer.

ALWAYS make sure the ON/OFF switch
on the electric motor is in the OFF position
when not in use and before inserting the
mixer’s power plug into an AC receptacle.
Power Cord/Cable Safety
DANGER
NEVER let power cords or cables lay in water.
NEVER use damaged or worn
cables or cords when
connecting equipment to generator. Inspect for cuts in
the insulation.
NEVER grab or touch a live power
cord or cable with wet hands. The
possibility exists of electrical shock,
electrocution or death.

Make sure power cables are securely connected.
Incorrect connections may cause electrical shock and
damage to the mixer.
CAUTION

Ensure that cables and cords will not be tripped over or
trapped underneath the mixer.
NOTICE
ALWAYS
make certain that proper power or extension
cord has been selected for the job.
TRANSPORTING SAFETY
CAUTION
NEVER
allow any person or animal to stand underneath
the equipment while lifting.
NOTICE
ALWAYS
make sure forklift forks are inserted into pockets
(if applicable) as far as possible when lifting the mixer.
ALWAYS shutdown engine before transporting.
NEVER lift the equipment while the engine is running.

Tighten fuel tank cap securely and close fuel cock to
prevent fuel from spilling.
DO NOT lift machine to unnecessary heights.
ALWAYS
tie down equipment during transport by
securing the equipment with rope.
NEVER
tip the engine to extreme angles during lifting as
it may cause oil to gravitate into the cylinder head, making
the engine start difficult.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 11
SAFETY INFORMATION
TOWING SAFETY
CAUTION

Check with your local county or state safety towing
regulations, in addition to meeting Department of
Transportation (DOT) Safety Towing Regulations,
before towing your mixer.

In order to reduce the possibility of an accident while
transporting the mixer on public roads, ALWAYS make
sure the towing vehicle is mechanically sound and in
good operating condition.

ALWAYS shutdown engine before transporting and
place the fuel valve in the OFF position.

ALWAYS inspect the hitch and coupling for wear. NEVER
tow a mixer with defective hitches, couplings, chains, etc.

Check the tire air pressure on both towing vehicle and
mixer Mixer tires should be inflated to 50 psi cold.Also
check the tire tread wear on the vehicle and mixer.

ALWAYS make sure the mixer is equipped with a safety
chain.

ALWAYS properly attach mixer’s safety chains to towing
vehicle.

The maximum speed for highway towing is 55 MPH unless
posted otherwise.Recommended off-road towing is not to
exceed 15 MPH or less depending on type of terrain.

Avoid sudden stops and starts.This can cause skidding,
or jack-knifing. Smooth, gradual starts and stops will
improve towing.

Avoid sharp turns to prevent rolling.

Mixer should be adjusted to a level position at all times
when towing.

Raise and lock mixer wheel stand in up position when
towing.

Place chock blocks underneath wheel to prevent rolling
while parked.
ENVIRONMENTAL SAFETY/DECOMMISSIONING
NOTICE
Decommissioning is a controlled process used to safely
retire a piece of equipment that is no longer serviceable.
If the equipment poses an unacceptable and unrepairable
safety risk due to wear or damage or is no longer cost
effective to maintain (beyond life-cycle reliability) and is to
be decommissioned (demolition and dismantlement),be
sure to follow rules below.
DO NOT
pour waste or oil directly onto the ground, down
a drain or into any water source.
Contact your country's Department of
Public Works or recycling agency in your
area and arrange for proper disposal of
any electrical components, waste or oil
associated with this equipment.

When the life cycle of this equipment is over, remove
battery if equipped and bring to appropriate facility for
lead reclamation. Use safety precautions when handling
batteries that contain sulfuric acid.

When the life cycle of this equipment is over, it is
recommended that the mixer frame and all other metal
parts be sent to a recycling center.
Metal recycling involves the collection of metal from
discarded products and its transformation into raw
materials to use in manufacturing a new product.
Recyclers and manufacturers alike promote the process
of recycling metal. Using a metal recycling center
promotes energy cost savings.
Go to Discount-Equipment.com to order your parts

PAGE 12 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
SAFETY INFORMATION
EMISSIONS INFORMATION
NOTICE
The gasoline engine used in this equipment has been
designed to reduce harmful levels of carbon monoxide
(CO), hydrocarbons (HC) and nitrogen oxides (NOx)
contained in gasoline exhaust emissions.
This engine has been certified to meet US EPA Evaporative
emissions requirements in the installed configuration.
Attempting to modify or make adjustments to the engine
emmission system by unauthorized personnel without
proper training could damage the equipment or create an
unsafe condition.
Additionally, modifying the fuel system may adversely affect
evaporative emissions, resulting in fines or other penalties.
Emission Control Label
The emission control label is an integral part of the emission
system and is strictly controlled by regulation(s).
The label must remain with the engine for its entire life.
If a replacement emission label is needed, please contact
your authorized engine distributor.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 13
MIXER SPECIFICATIONS/NOISE AND VIBRATION
Figure 1. Dimensions
NOTES:
1. Sound Pressure and Power Levels are “A” weighted Measures per ISO 226:2003 (ANSI S1.4-1981). They are measured with the operating
condition of the machine which generates the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon.
2. The vibration level indicated is the vector sum of the RMS (Root Mean Square) Values of amplitudes on each axis, standardized to an 8 hour
exposure period, and obtained using operating condition of the machine that generates the most repeatable but highest values in accordance
with the applicable standards for the machine.
E
DC
BA
Table 1. WM70SP Series
Dimensions/Specifications
Reference Letter/Parameter Dimensions in. (mm)
A (Height-Grate) 58.0 (1,473)
B (Height-Drum Handle) 67.0 (1,702)
C (Width-Wheelbase) 50 (1,270)
D (Length-Jack Stand/Frame) 67.0 (1,702)
E (Length-Jack Stand/Tow Bar) 92.0 (2,337)
Maximum Mixing Capacity 7.0 cu. ft. (198 liters)
Bag Capacity 1.5 ~ 2.5 bags
Weight Approx. 788 lbs. (357 kg)
Table 2. WM70SP Noise And Vibration (Gasoline)
Guaranteed ISO 11201:2010 Based
Sound Pressure Level at Operator Station in dB(A) TBD
Guaranteed ISO 3744:2010 Based
Sound Power Level in dB(A) TBD
Go to Discount-Equipment.com to order your parts

PAGE 14 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
Table 3. Engine/Electric Motor Specifications
Model HONDA GX160K1HX2
GX160UT1HX2
HONDA GX240K1HA2
GX240UT1HA2 Baldor 35L229S302
Type
Air-cooled 4 stroke, Single
Cylinder, OHV, Horizontal
Shaft Gasoline Engine
Air-cooled 4 stroke, Single
Cylinder, OHV, Horizontal
Shaft Gasoline Engine
1.5 HP, 1Ø-120/240 VAC,
Electric Motor
Bore X Stroke 2.7 in. X 1.8 in.
(68 mm x 45 mm)
2.9 in. X 2.3 in.
(73 mm x 58 mm) N/A
Displacement 9.9 cu. in. (163 cc) 14.81 cu. in. (242 cc) N/A
Max Output 5.5 H.P./3,600 rpm 8.0H.P./3,600 rpm 1.5 HP/1725 R.P.M.
Fuel Tank Capacity 0.95 U.S. Gallons
(3.6 Liters)
1.59 U.S. Gallons
(6.0 Liters) N/A
Fuel Unleaded Automobile
Gasoline
Unleaded Automobile
Gasoline N/A
Lube Oil Capacity 0.63 qt. (0.6 liter) 1.16 qt. (1.1 liter) N/A
Speed Control Method Centrifugal Fly-weight Type Centrifugal Fly-weight Type N/A
Starting Method Recoil Start Recoil Start Electric
Input Voltage N/A N/A 120/240 VAC, 1Ø
Dimension
(L x W x H)
12.3 x 14.3 X 13.2 in.
(312 X 362 X 335 mm)
14.0 x 16.9 X 16.1 in.
(355 X 430 X 410 mm)
13.3 x 8.70 X 9.06 in.
(338 X 220 X 230 mm)
Dry Net Weight 40.8 lbs (15.0 Kg.) 55.1 lbs (25.0 Kg.) Approx. 22 lbs (10 kg.)
ENGINE/ELECTRIC MOTOR SPECIFICATIONS
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 15
GENERAL INFORMATION
APPLICATION
This mixer is only intended for the mixing of plaster and
mortar. The mixer must be used for its intended purpose
and is not suitable for the mixing of flammable or explosive
substances. The mixer must not be used in an explosive
atmosphere.
The drum capacity of this mixer is 7.0 cu. ft. (198 liters)
with a batch capacity between 1-1/2 ~ 2-1/2 bags. Mixer
is shipped completely assembled and has been factory
tested and is ready for use.
POWER PLANTS
The mixer can be powered by a Honda GX160/GX240
air-cooled, 4-stroke gasoline engines or a 1.5 HP electric
motor. Refer to Table 3 to for specific engine or electric
motor data information.
ELECTRICAL
If mixer is equipped with an electric motor, make sure
that the power being supplied to the motor corresponds to
the voltage rating label on the motor. Supplying the wrong
voltage to the electric motor will cause severe electrical
damage to the motor.
Always make sure the OFF/ON switch on the electric motor
is in the OFF position before applying power.
It is strongly recommended when inserting the mixer's
power cord into a receptacle, that a G.F.C.I. (Ground
Fault Current Interrupter) receptacle be used (120 VAC
applications).
HARDWARE
Check all hardware on the mixer before starting. Periodically
inspect all hardware. Loose hardware can contribute
to early component failure and poor performance. Use
Table 4 as general guideline when the torqueing of mixer
hardware is required. Remember to keep all mixer hardware
components tight.
Table 4. Hardware Torque Recommendations
Hardware Diameter Torque (ft-lbs)
5/16-inch x 18 14
3/8-inch x 16 24
3/8-inch x 24 37
1/2-inch x 13 39
1/2-inch x 13 (Grade 8) 90
ENGINE MAINTENANCE
For basic engine maintenance, refer to the engine
maintenance section in this manual. For more detailed
engine maintenance, refer to the Honda Engine Owner's
manual furnished with the engine.
OPTIONAL TOW BARS
This mixer can be configured for use with various types of
tow bars (ball, loop and pin). Reference Figure 2.
Contact Discount-Equipment for the desired tow bar.
Figure 2. OptionalTow Bars
HBC-1
HLC-1
HPC-1
Go to Discount-Equipment.com to order your parts

PAGE 16 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
BASIC COMPONENTS (MIXER)
Figure 3. Mixer Major Components
1. Safety Grill — Provided for operator safety. This safety
grill is designed to keep hands and solid objects out of the
mixing drum when in use. This grill should be closed at all
times when mixer is in use. DO NOT remove the grill or grill
opening bar. Keep the grill clean by washing it down daily.
2. Dump Handle — Pull this handle downward to dump the
contents of the drum. Push the handle upward to return the
drum to its vertical position.
3. Safety Grill Lock Handle — To prevent injury to hands
and arms, the safety grill should ALWAYS be locked when
the mixing of plaster or mortar is required. Also when
transporting the mixer the safety grill should be locked.The
safety grill should only be unlocked when cleaning of the
blades and drum is required.
4. Pivot Point/Zerk Fitting — There is a zerk grease fitting
on each end of the mixing drum. These fittings lubricate the
dumping mechanism. Lubricate both fittings at least once
a month or when the drum becomes difficult to position.
14
17
18
16
15
15
18
19
17
16
12
34
6
7
8
9
10
11
12
13
14 5
5. Drum Head Seals/Zerk Fitting — There is a zerk grease
fitting on each end of the mixing drum. Lubricate both fittings
(drum head seals) every 40 hours of operation.
6. Drum Bearing — There is a sealed bearing on
each end of the mixing drum. Bearings are packed
and sealed at the factory and require no further
maintenance.
7. Drum Lock Pin — Place pin in lock position before
towing. Prevents drum from tipping.
8. Tow Bar/Coupler — This mixer uses various towing
bars, please reference the frame assembly drawing
and parts list in this manual to determine which tow
bar meets your requirements.
9. Safety Chain — This mixer uses a 3/16-inch thick, 72
inches long zinc-plated saftey chain. ALWAYS connect
the safety chain when towing.
10. Chock Blocks (Option) — Place these blocks (not
included as part of the mixer package) under each
mixer wheel to prevent rolling, when mixer is not
connected to the towing vehicle.
11. Rigid Suspension — This mixer uses a rigid type
suspension. Check the mounting hardware for bolt hole
elongation and tightness. See maintenance section of
this manual for recommended maintenance.
12. Tires Ply — The tire ply (layers) number is rated in
letters. This mixer uses 13-inch 2-ply tires. Replace
with only recommended type tires.
13. Cabinet/Latch — Encloses engine and electric motor
(option). NEVER run mixer with cabinet removed. Use
latches to secure engine compartment cabinet.
14. Engine ON/OFF Switch — This pushbutton switch is
located on the side of the mixer frame.When activated
it will shut down the engine. Pull out when starting the
engine.
15. Mixing Paddles — This mixer uses rubber mixing
paddles for the mixing of plaster and mortar. Always
clean paddles after each use.
16. Bag Cutter — This feature allows mixing bags to be
opened easily, therefore allowing the contents of the
bag to fall directly into the mixing drum.
17. Engine Cover — Lift this cover to gain access to the
engine or electric motor.
18. Belt Slip Lever — Placing this lever in the mix position
will tension V-belts which will enable the paddle shaft
to rotate.
19. Mixing Drum — Drum capacity is 7.0 cu. ft (198
liters). Mixing materials such as mortar, plaster are to
be placed into this drum for mixing. Always clean the
drum after each use. DO NOT use this mixing drum
for the mixing of volatile or hot liquids.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 17
ENGINE COMPONENTS
Figure 4. Engine Components
INITIAL SERVICING
The engine (Figure 4) must be checked for proper
lubrication and filled with fuel prior to operation. Refer to the
manufacturer's engine manual for instructions and details
of operation and servicing.
1. Throttle Lever – Used to adjust engine RPM speed.
2. Fuel Filler Cap/Fuel Tank – Remove this cap to add
unleaded gasoline to the fuel tank. Fill with unleaded
gasoline. Refer to Table 3 for fuel tank capacity. Make
sure cap is tightened securely. DO NOT over fill. For
additional information refer to Honda engine owner's
manual.
2
11
10
9
8
54
7
6
1
3
DANGER
Add fuel to the tank only when the engine
is stopped and has had an opportunity to
cool down. In the event of a fuel spill, DO
NOT attempt to start the engine until the
fuel residue has been completely wiped up
and the area surrounding the engine is dry.
3. Engine On/Off Switch – ON position permits engine
starting, OFF position stops engine operation.
4. Recoil Starter (pull rope) – Manual-starting method.
Pull the starter grip until resistance is felt, then pull
briskly and smoothly.
5. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to
stop the flow of fuel.
6. Oil Drain Plug – Remove this plug to remove oil from
the engine's crankcase.
7. Dipstick/Oil Filler Cap – Remove this cap to determine
if the engine oil is low. Add oil through this filler port as
recommended in Table 6.
8. Choke Lever – Used in the starting of a cold engine,
or in cold weather conditions. The choke enriches the
fuel mixture.
9. Spark Plug – Provides spark to the ignition system.
Set spark plug gap according to engine manufacturer's
instructions. Clean spark plug once a week.
10. Muffler – Used to reduce noise and emissions. NEVER
touch when hot!
11. Air Cleaner – Prevents dirt and other debris from
entering the fuel system. Remove wing-nut on top of
air filter canister to gain access to filter element.
NOTICE
Operating the engine without an air filter, with a
damaged air filter, or a filter in need of replacement
will allow dirt to enter the engine, causing rapid engine
wear.
Go to Discount-Equipment.com to order your parts

PAGE 18 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
ELECTRIC MOTOR COMPONENTS
ELECTRIC MOTOR
For lubrication care and operation of the electric motor,
refer to your electric motor instruction booklet furnished
with the motor.
Protect the electric motor from dust as much as possible
and keep ventilating openings clean.
The electric motor used on this mixer is single-phase,
1.5 HP @120/240 VAC motor. Pay special attention to the
nameplate on the electric motor when supplying power to
the electric motor. Applying incorrect power to the motor
can severely damage the motor and may cause serious
bodily injury!
Always make certain that the correct voltage is being
supplied to the motor. The input voltage requirements can
be found on the electric motor's nameplate.
ELECTRIC MOTOR POWER CONNECTIONS
A 12-inch electrical cable (Figure 6) is provided with the
electrical motor for hookup to a power source.
The electric motor supplied with the mixer is configured from
the factory for 120 VAC grounded operation.
Motors can burn out when the line voltage falls 10% below the
voltage rating of the motor. Failure to use proper voltage will
cause the motor to overheat and actuate the overload switch.
If overload protection should actuate because of improper
voltage or any other malfunction, turn the main switch on the
motor to the "OFF" position and correct the problem, press
the reset switch button, and turn the main switch to the "ON"
position.
CAUTION
DO NOT spray water at any time on the electric motor.
DO NOT operate electric motor in an explosive
environment.
NOTICE
It is strongly recommended that all electrical wiring be
done by a licensed electrician.Pay special attention to
the nameplate on the electric motor. Make certain that
the voltage supplied to the electric motor matches the
required operating voltage printed on the nameplate.
ELECTRIC MOTOR VOLTAGE CHANGE SWITCH
1. ALWAYS make certain the electric motor's ON/OFF
switch is in the "OFF" position and the power cord has
been disconnected from the power source.
2. Remove the voltage change lock-out bolt and nut
(Figure 5). Change the position of the voltage change
toggle switch from 120 VAC to 240 VAC. The mixer is
factory wired for 120 VAC operation.
3. Re-install the voltage change lock-out bolt and nut.
Figure 5. Voltage Change Switch
4. Important!, when changing the input voltage to the
electric motor from 120 to 240 VAC, the plug on the
electric motor power cord must also be changed. See
Table 6 and Figure 6.
Table 5. Electric Motor Wiring Information
120-240 VAC -Single Phase
Motor HP
Rating
NEMA Plug
Connector
Mating NEMA
Connector
1.5 HP
(120 VAC)
L5-20P
P/N EM940537
L5-20R
P/N EM940538
1.5 HP
(240 VAC)
L6-20P
P/N 940539
L6-20R
P/N 940540
NOTICE
ALWAYS make certain the electric motor's ON/OFF
switch is working properly. When the mixer is not in
use, place the ON/OFF switch in the "OFF" position
and disconnect the power cord from the power source.
Go to Discount-Equipment.com to order your parts

WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18) — PAGE 19
CAUTION
NEVER disable or disconnect the ON/OFF switch on
the electric motor. It is provided for operator safety.
Injury may result if it is disabled, disconnected or
improperly maintained.
ELECTRIC MOTOR COMPONENTS
Figure 6. Electric Motor
Go to Discount-Equipment.com to order your parts

PAGE 20 — WM70SP SERIES PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #8 (04/18/18)
TOWING GUIDELINES
TOWING SAFETY PRECAUTIONS
To reduce the possibility of an accident while
transporting the mixer on public roads, always make
sure that the mixer towing components and the towing
vehicle are in good operating condition and both units
are mechanically sound.
The following list of suggestions should be used when
towing the mixer:
Make sure that the hitch and coupling of the towing
vehicle are rated equal to, or greater than the trailer
"gross vehicle weight rating" (GVWR).
ALWAYS inspect the hitch and coupling for wear. NEVER
tow the mixer with defective hitches, couplings, chains
etc.
CHECK the tire air pressure on both the towing vehicle
and the trailer. Also check the tire tread wear on both
vehicles.
ALWAYS make sure the mixer is equipped with a "Safety
Chain."
ALWAYS attach trailer's safety chain to the frame of
towing vehicle.
ALWAYS make sure that the towing vehicle's directional,
backup, and brake lights are working properly.
Remember in most cases the maximum speed unless
otherwise posted for highway towing is 55 MPH, however
before towing your mixer, check your local state, and
county vehicle towing requirements. Recommended off-
road towing is not to exceed 15 MPH or less depending
on type of terrain.
Place chocked blocks underneath wheels to prevent
rolling , while parked, if disconnected from towing
vehicle.
Inflate tires to correct pressure, inspect tires for cuts, and
excessive wear. See Table 9 (Tire Wear Troubleshooting).
When towing of the mixer is required, place the drum in
the up position (mouth facing upwards).
Avoid sharp turns to prevent rolling.
CAUTION
Check with your county or state safety towing
regulations department before towing your mixer.
ALWAYS make sure that the fuel valve lever is in the
OFF position (gasoline models only).
Check wheel mounting lug nuts with a torque wrench.
Torque wheel lug nuts as described in the maintenance
section of this manual.
Check tightness of axle mounting hardware, torque
suspension hardware as referenced in the maintenance
section of this manual.
Avoid sudden stops and starts.This can cause skidding,
or jackknifing. Smooth, gradual starts and stops will
improve gas milage.
DO NOT tow or lift the mixer unless the mixing drum is
completely empty.
TOW BAR TO VEHICLE (COUPLER ONLY)
1. Check the vehicle hitch ball, and mixer's coupler for
signs of wear or damage. Replace any parts that are
worn or damaged before towing.
2. Use only a 2-inch ball diameter (towing vehicle), this will
match the mixer's 2-inch coupler. Use of any other ball
diameter will create an extremely dangerous condition
which can result in separation of the coupler and ball
or ball failure.
3. After tow bar has been connected to mixer (see next
page), attach mixer's coupler to the hitch ball on the
towing vehicle securely and make sure the lock lever
is in the down position (locked).
MIXER TOW BAR VEHICLE (PINTLE AND LOOP)
1. Make sure the bumper on the towing vehicle is
equipped to handle either a pintle or loop type tow
bar configuration.
2. After tow bar has been connected to mixer (see next
page), secure either type of tow bar to the towing
vehicle, following state and county towing regulations
3. As a minimum, use a 1/2-inch bolt and nylock nut grade
5 when securing either tow bar to the towing vehicle.
CAUTION
If the mixer tow bar is deformed or damaged replace
entire tow bar. NEVER tow the mixer with a defective
tow bar. There exist the possibility of the trailer
separating from the towing vehicle.
Go to Discount-Equipment.com to order your parts
