Total TD614006 User manual

1
V
MIXER

2
Security instructions
Caution
Read all safety warnings and all instructions. Failure to follow warnings and instructions
can cause electric shock, fire, and / or serious injury.
Note: Save all warnings and instructions for future reference.
1) Work area safety
a. Keep the work area clean and well lit to avoid accidents.
b. Do not use power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases, or dust that can cause fires.
c. Keep children and other unauthorized persons away while using a power
tool. Distractions can cause you to lose control of the tool.
2) Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Using a proper plug reduces the risk of electric shock.
b. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if
your body is grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d. Never use the cord to carry, pull, or unplug the power tool. Keep the cord
away from heat or oil.
e. When using a power tool outdoors, use an extension cord suitable for
outdoor use.
f. If it is unavoidable to use the tool in a humid location, use a residual
current device (RCD) protected supply to reduce the risk of electric shock.
3) Personal security
a. Always be alert, watch what you are doing, and use common sense when
operating the tool.
b. Do not use a power tool if you are tired or under the influence of drugs or
other substances.
c. Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-slip safety shoes, hard
hat, or hearing protection used in the right conditions will reduce personal
injury. Also, do not wear loose clothing or jewelry.
d. Avoid accidentally turning the tool on. Make sure the switch is in the off
position before connecting it to the power supply and moving it.
e. Remove any adjusting key or wrench before turning on the power tool. A
wrench or wrench attached to a rotating part of the power tool can cause
serious injury.
f. If dust extraction and collection devices are used, make sure they are
properly connected. Use these devices properly and you will reduce dust
hazards.
4) Use and care of power tools
a. Do not force the tool. Use the right power tool for each use.

3
Safety rules for correct use
b. Do not use the power tool if its ignition switch does not work. Any power
tool that cannot be controlled with the switch is dangerous and must be
repaired.
c. Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing the tool to avoid
accidentally starting the tool.
d. Use the power tool, accessories and drill bits, etc. in accordance with
these instructions, taking into account the working conditions and the
work to be carried out. Using the power tool for operations other than
those intended could result in a dangerous situation.
e. Store power tools out of the reach of children and do not allow anyone
unfamiliar with the tool to use it.
f. Maintain power tools. Check for misalignment or binding of moving parts,
broken parts, and any other conditions that may affect the operation of
power tools. If damaged, have power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
g. Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to jam and are easier to control.
5) Service
a. Have your power tool repaired by a qualified person and use replacement
parts recommended by the manufacturer. This will ensure that the safety
of the power tool is maintained.
Double insulation for additional protection
Read the instruction manual before use.
CE conformity.
Wear safety glasses, hearing protection and a dust mask.
Waste electrical products must not be disposed of with household
waste. Please recycle at the appropriate facilities. Check with your local
authority or retailer for recycling advice.
Security alert. Use only accessories approved by the manufacturer.

4
Additional safety warnings
•Wear ear protectors. Exposure to noise can cause hearing loss.
•Always route the cable to the rear, away from the machine.
•Do not carry the machine by the cable.
•When working with the machine, always hold it firmly with both hands and stand
firm. Loss of control can lead to injury.
•During breaks in work or when you are not using the tool (eg changing work tools,
repairs, cleaning, adjusting), disconnect the tool from the power supply.
•Unqualified persons cannot use this tool.
•Keep tool accessories out of the reach of children.
•Use only original accessories recommended by the manufacturer.
Other risks
Even when the power tool is used as prescribed, it is not possible to eliminate all residual
risk factors:
a. Health defects resulting from the emission of vibrations if the power tool is used
for a longer period of time or if it is not properly managed and maintained.
b. Injury and property damage from broken accessories suddenly breaking.
Caution
This power tool produces an electromagnetic field during operation.
This field can, in some circumstances, interfere with active or passive
medical implants.
To reduce the risk of serious injury, we recommend that individuals with
medical implants consult their physician before using this power tool.
If the cord is damaged or cut during work, do not touch the cord, immediately unplug the
tool. Never use the machine with a damaged cord.
The machine must not be damp and must not be used in a humid environment.
Attention
Safe working with this machine is only possible when the operating or
safety information is fully read and the instructions contained therein are
strictly followed.
Technical data
Data sheet
Power
1400W
Voltage
220-240V
Frequency
50 / 60Hz
No-load speed
0-500 / 0-800min-1
Mixing bar
M14 (120mm)

5
Product description
The machine has been designed to mix liquid and powder building materials such as
paint, mortar, adhesive, plaster and similar substances. The relevant mixing action
(which depends on the consistency of the materials and the amount to be mixed) must
be set for the appropriate mixing tool.
Please note that our unit is not designed for commercial, industrial, or professional use.
The warranty does not cover whether the unit was used in commercial, industrial or
professional sectors or comparable activities.
Warning
You must adhere to certain safety precautions when using the equipment to prevent
injury and damage from occurring. Therefore, you should always read this operation
manual carefully.
This manual should be kept in a safe place so that the information it contains is always
available. This operating manual must accompany the equipment if it is transferred to
another person.
We do not accept any responsibility for accidents or damages resulting from ignoring this
manual and the safety instructions.
Set up
Mixer Usage Precautions
Attention
You must adhere to the following basic safety measures against electric shock, injury,
and fire hazard when using power tools. Read and follow these instructions before using
any tool. These instructions should be kept in a safe place.
•The equipment must never be used in environments where an explosive
atmosphere exists. Never mix solvents or substances containing solvents that
have flash points below 21 ° C
•Do not let the cord touch any part of your body.
•Use only the extension cord approved for use in the work area.
•The unit should only start and stop when it is inside a mixing container. Make
sure the mixing container is placed on a solid and secure base.
•Never put your hands or any other object into the mixing container during the
mixing process.
•We recommend that you always wear industrial safety gloves, a dust mask and
safety glasses when working with the tool. Also, wear appropriate clothing for this
type of work.
•Always allow the reaction pair.
Assembling the mixer
•First screw the mixer part (6a) together with the mixer part (6b).
•Then screw the mixer 86) onto the mixer holder (5). Use the two keys to do this.
•Use one of the wrenches (a) to hold the mixer stand (5) in place and then use the
second wrench (b) to tighten the mixer (6).
•Proceed in the reverse sequence to disassemble the mixer.

6
Operating modes
Before initial operation check whether the rated frequency of the power supply
corresponds to the details of the type place. Before using the tool, please read the
instruction book carefully.
start
Make sure the data listed on the nameplate matches the mains voltage before
connecting the unit.
On / off switch
•On: press the switch (1)
•Continuous operation: Press the lock knob on the switch (1) (2) to lock it in place
•Off: Briefly press the switch (1)
Speed control
•Use the speed control (3) to select the speed.
•Shift between first - second gear (4)
oThe switch position allows you to work at high or low speeds.
oThe position of the shift switch should only be changed when the unit is
stopped, to avoid damage to the gear.
oI: First gear
oII: Second gear
Using the mixer
•The unit should be run at low speed before submerging or removing it from the
mix.

7
•Speed should only be maximized after it has been fully immersed in the mix, to
ensure the motor stays as cool as possible.
•The machine must move within the mixing container during the mixing process.
•Continue the mixing process until all components of the mixture have been
processed. Always clean the mixer after you have finished using it.
Maintenance
Maintenance
•Remove the plug from the outlet before performing any adjustment, service or
maintenance.
•Your power tool does not require additional lubrication or maintenance. Always
store your power tool in a dry place.
•If the power cord is damaged, it must be replaced by the manufacturer, its official
dealer, or similarly qualified persons to avoid a hazard.
•There are no parts installed inside the unit that require maintenance.
Cleaning
•Keep safety devices, ventilation slots, and motor housing as free from dirt and
dust as possible.
•Clean the unit by wiping it with a clean cloth or clean it with low pressure
compressed air.
•We recommend that you always clean the unit immediately after use.
•Clean the unit regularly by rubbing it with a damp cloth and a little mild soap. Do
not use cleaners or solvents; These will attack the plastic parts of the unit.
•You should also make sure that water does not get inside the unit.
Carbon brushes
•If excessive sparking occurs, you should have a qualified electrician check the
carbon brushes.
•They must be changed by qualified personnel.
Attention
Only qualified personnel can change the brushes.

8
Problem solving
Note: Before doing any maintenance and cleaning work on the machine, disconnect the cable
from the socket.
Environment
•Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
•Contact your local authority for information on available collection systems.
•If electrical appliances are disposed of in landfills, hazardous substances can
seep into groundwater and enter the food chain, damaging your health and well-
being.
•Recycle raw materials instead of disposing of them as waste.
•The machine, accessories and packaging must be classified for environmentally
friendly recycling.
•Plastic components are labeled for categorized recycling.
Possible problem
Possible reason
Solution
The operation switch is
on, but the motor does not
work.
The cables from the mains
plug or socket are loose
have the plug and socket
checked or repaired
The switch is faulty
Replace switch
The operation switch is
on, but unusual noises
can be heard, the engine
does not run or is very
slow.
The switch contact has
failed
replace switch
Component stuck
Have the power tool
serviced or repaired
Too much thrust, as a
result the engine is
dragging.
Use less oomph during
the task
Engine overheats
Foreign substances have
gotten into the engine.
Have foreign substances
removed
Lack of lubricating grease
or is contaminated
Apply or replace
lubricating grease
Pressure too high
Use less oomph during
the task
Frequent or strong sparks
at the switch
Short circuit in armature
Have the armor replaced
Worn or stuck carbon
brushes
Have the carbon brushes
checked
Rough switch
performance
Have the switch surface
cleaned or grounded

9
Exploded view

10
MIXER
