MSI WINDBOX - 1 GB RAM User manual

WindBOX Series
MS-9A25 Fanless Box PC
G52-9A251X1

ii
PREFACE ▍
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR IN-
TERNATIONAL. We take every care in the preparation of this document, but
no guarantee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes without
notice.
Trademarks
All trademarks are the properties of their respective owners.
MSI® is registered trademark of Micro-Star Int’l Co.,Ltd.
NVIDIA® is registered trademark of NVIDIA Corporation.
ATI® is registered trademark of ATI Technologies, Inc.
AMD® is registered trademarks of AMD Corporation.
Intel® is registered trademarks of Intel Corporation.
Windows® is registered trademarks of Microsoft Corporation.
AMI® is registered trademark of Advanced Micro Devices, Inc.
Award® is a registered trademark of Phoenix Technologies Ltd.
Sound Blaster® is registered trademark of Creative Technology Ltd.
Realtek® is registered trademark of Realtek Semiconductor Corporation.
JMicron® is registered trademark of JMicron Technology Corporation.
Netware® is a registered trademark of Novell, Inc.
U.S. Patent Numbers
4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132.
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright protec-
tion technology must be authorized by Macrovision, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
Revision History
Revision Revision History Date
V1.0 First release July 2009
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭

iii
MS-9A25
Upgrade and Warranty
Please be noticed that the memory, hard disk drive and optical disk drive pre-
installed in the product users purchased may be upgradable or replaceable by
user’s request. To learn more about upgrade limitation, please refer to the speci-
󰘰cation in the User’s Manual. For any further information about the product users
purchased, please contact the local dealer. Do not attempt to upgrade or replace
any component of the product, if you are not an authorized dealer or service
center, since it may cause the warranty void. It is strongly recommended that
you contact the authorized dealer or service center for any upgrade or replace
service.
Technical Support
If a problem arises with your system and no solution can be obtained from the
user’s manual, please contact your place of purchase or local distributor. Alterna-
tively, please try the following help resources for further guidance.
Visit the MSI website for FAQ, technical guide, BIOS updates,
driver updates and other information via http://www.msi.com/index.
php?func=service
Contact our technical sta󰘯 via http://ocss.msi.com/
Free DOS Notice
FreeDos Version 3.7.8
Copyright © 1998-2001 Jim Hall <[email protected]>
This program is free software: you can redistribute it and/or modify it under the
terms of the GNU General Public License as published by the Free Software
Foundation, either version 3 of the License, or any later version.
This program is distributed WITHOUT ANY WARRANTY; without even the im-
plied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PUR-
POSE.
GNU General Public License can be seen and downloaded at http://www.gnu.
org/licenses/.
For any question about the use and license of the freeDOS software please visit
http://www.freedos.org.
◙
◙

iv
PREFACE ▍
Safety Instructions
Always read the safety instructions carefully.
Keep this User’s Manual for future reference.
Keep this equipment away from humidity.
Lay this equipment on a reliable 󰘱at surface before setting it up.
The openings on the enclosure are for air convection hence protects the
equipment from overheating. DO NOT COVER THE OPENINGS.
Make sure that the power voltage is within its safety range and has beenad-
justed properly to the value of 100~240V before connecting the equipmentto
the power inlet.
Place the power cord in a way that people can not step on it. Do not place
anything over the power cord.
Always Unplug the Power Cord before inserting any add-on card or module.
All cautions and warnings on the equipment should be noted.
Never pour any liquid into the opening that could damage or cause electrical
shock.
If any of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well or you can not get it work according
to User’s Manual.
The equipment has dropped and damaged.
The equipment has obvious sign of breakage.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDI-
TIONED, STORAGE TEMPERATURE ABOVE 40oC (102oF). IT MAY DAM-
AGE THE EQUIPMENT.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
廢電池請回收
For better environmental protection, waste batteries should be
collected separately for recycleing special disposal.
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
◯
◯
◯
◯
◯
◯
The optical storage devices are classi󰘰ed as CLASS 1 LASER PRODUCT. Use of
controls or adjustments or performance of procedures other than those speci󰘰ed
is prohibited.
Do not touch the lens inside the drive.
1.
2.

v
MS-9A25
FCC-B Radio Frequency Interference Statement
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o󰘯 and on, the user is encouraged to try
to correct the interference by one or more of the measures listed below.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di󰘯erent from that to
which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Notice 1
The changes or modi󰘰cations not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
◯
◯
◯
◯
OIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
this device may not cause harmful interference, and
this device must accept any interference received, including interference that
may cause undesired operation.
1)
2)
Micro-Star International
MS-9A25

vi
PREFACE ▍
WEEE (Waste Electrical and Electronic Equipment) Statement
ENGLISH
To protect the global environment and as an environmentalist, MSI must remind you
that...
Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equip-
ment, Directive 2002/96/EC, which takes e󰘯ect on August 13, 2005, products of “elec-
trical and electronic equipment” cannot be discarded as municipal waste anymore and
manufacturers of covered electronic equipment will be obligated to take back such products at
the end of their useful life. MSI will comply with the product take back requirements at the end
of life of MSI-branded products that are sold into the EU. You can return these products to local
collection points.
DEUTSCH
Hinweis von MSI zur Erhaltung und Schutz unserer Umwelt
Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen Elektro- und
Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden. MSI hat europaweit
verschiedene Sammel- und Recyclingunternehmen beauftragt, die in die Europäische Union in
Verkehr gebrachten Produkte, am Ende seines Lebenszyklus zurückzunehmen. Bitte entsorgen
Sie dieses Produkt zum gegebenen Zeitpunkt ausschliesslich an einer lokalen Altgerätesammel-
stelle in Ihrer Nähe.
FRANÇAIS
En tant qu’écologiste et a󰘰n de protéger l’environnement, MSI tient à rappeler ceci...
Au sujet de la directive européenne (EU) relative aux déchets des équipement électriques et
électroniques, directive 2002/96/EC, prenant e󰘯et le 13 août 2005, que les produits électriques et
électroniques ne peuvent être déposés dans les décharges ou tout simplement mis à la poubelle.
Les fabricants de ces équipements seront obligés de récupérer certains produits en 󰘰n de vie.
MSI prendra en compte cette exigence relative au retour des produits en 󰘰n de vie au sein de la
communauté européenne. Par conséquent vous pouvez retourner localement ces matériels dans
les points de collecte.
РУССКИЙ
Компания MSI предпринимает активные действия по защите окружающей среды, поэтому
напоминаем вам, что....
В соответствии с директивой Европейского Союза (ЕС) по предотвращению загрязнения
окружающей среды использованным электрическим и электронным оборудованием
(директива WEEE 2002/96/EC), вступающей в силу 13 августа 2005 года, изделия,
относящиеся к электрическому и электронному оборудованию, не могут рассматриваться
как бытовой мусор, поэтому производители вышеперечисленного электронного
оборудования обязаны принимать его для переработки по окончании срока службы. MSI
обязуется соблюдать требования по приему продукции, проданной под маркой MSI на
территории EC, в переработку по окончании срока службы. Вы можете вернуть эти изделия
в специализированные пункты приема.

vii
MS-9A25
ESPAÑOL
MSI como empresa comprometida con la protección del medio ambiente, recomienda:
Bajo la directiva 2002/96/EC de la Unión Europea en materia de desechos y/o equipos elec-
trónicos, con fecha de rigor desde el 13 de agosto de 2005, los productos clasi󰘰cados como
“eléctricos y equipos electrónicos” no pueden ser depositados en los contenedores habituales
de su municipio, los fabricantes de equipos electrónicos, están obligados a hacerse cargo de
dichos productos al termino de su período de vida. MSI estará comprometido con los términos
de recogida de sus productos vendidos en la Unión Europea al 󰘰nal de su periodo de vida. Usted
debe depositar estos productos en el punto limpio establecido por el ayuntamiento de su localidad
o entregar a una empresa autorizada para la recogida de estos residuos.
NEDERLANDS
Om het milieu te beschermen, wil MSI u eraan herinneren dat….
De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische en Elec-
tronische producten (2002/96/EC), die op 13 Augustus 2005 in zal gaan kunnen niet meer bes-
chouwd worden als vervuiling. Fabrikanten van dit soort producten worden verplicht om producten
retour te nemen aan het eind van hun levenscyclus. MSI zal overeenkomstig de richtlijn handelen
voor de producten die de merknaam MSI dragen en verkocht zijn in de EU. Deze goederen kun-
nen geretourneerd worden op lokale inzamelingspunten.
SRPSKI
Da bi zaštitili prirodnu sredinu, i kao preduzeće koje vodi računa o okolini i prirodnoj sredini, MSI
mora da vas podesti da…
Po Direktivi Evropske unije (“EU”) o odbačenoj ekektronskoj i električnoj opremi, Direktiva
2002/96/EC, koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju pod “elektronsku
i električnu opremu” ne mogu više biti odbačeni kao običan otpad i proizvođači ove opreme biće
prinuđeni da uzmu natrag ove proizvode na kraju njihovog uobičajenog veka trajanja. MSI će
poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI
oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
POLSKI
Aby chronić nasze środowisko naturalne oraz jako 󰘰rma dbająca o ekologię, MSI przypomina,
że...
Zgodnie z Dyrektywą Unii Europejskiej (“UE”) dotyczącą odpadów produktów elektrycznych i
elektronicznych (Dyrektywa 2002/96/EC), która wchodzi w życie 13 sierpnia 2005, tzw. “produkty
oraz wyposażenie elektryczne i elektroniczne “ nie mogą być traktowane jako śmieci komunalne,
tak więc producenci tych produktów będą zobowiązani do odbierania ich w momencie gdy produkt
jest wycofywany z użycia. MSI wypełni wymagania UE, przyjmując produkty (sprzedawane na
terenie Unii Europejskiej) wycofywane z użycia. Produkty MSI będzie można zwracać w wyznac-
zonych punktach zbiorczych.

viii
PREFACE ▍
TÜRKÇE
Çevreci özelliğiyle bilinen MSI dünyada çevreyi korumak için hatırlatır:
Avrupa Birliği (AB) Kararnamesi Elektrik ve Elektronik Malzeme Atığı, 2002/96/EC Kararnamesi
altında 13 Ağustos 2005 tarihinden itibaren geçerli olmak üzere, elektrikli ve elektronik malze-
meler diğer atıklar gibi çöpe atılamayacak ve bu elektonik cihazların üreticileri, cihazların kullanım
süreleri bittikten sonra ürünleri geri toplamakla yükümlü olacaktır. Avrupa Birliği’ne satılan MSI
markalı ürünlerin kullanım süreleri bittiğinde MSI ürünlerin geri alınması isteği ile işbirliği içerisinde
olacaktır. Ürünlerinizi yerel toplama noktalarına bırakabilirsiniz.
ČESKY
Záleží nám na ochraně životního prostředí - společnost MSI upozorňuje...
Podle směrnice Evropské unie (“EU”) o likvidaci elektrických a elektronických výrobků 2002/96/
EC platné od 13. srpna 2005 je zakázáno likvidovat “elektrické a elektronické výrobky” v běžném
komunálním odpadu a výrobci elektronických výrobků, na které se tato směrnice vztahuje, bu-
dou povinni odebírat takové výrobky zpět po skončení jejich životnosti. Společnost MSI splní
požadavky na odebírání výrobků značky MSI, prodávaných v zemích EU, po skončení jejich
životnosti. Tyto výrobky můžete odevzdat v místních sběrnách.
MAGYAR
Annak érdekében, hogy környezetünket megvédjük, illetve környezetvédőként fellépve az MSI
emlékezteti Önt, hogy ...
Az Európai Unió („EU”) 2005. augusztus 13-án hatályba lépő, az elektromos és elektronikus
berendezések hulladékairól szóló 2002/96/EK irányelve szerint az elektromos és elektronikus
berendezések többé nem kezelhetőek lakossági hulladékként, és az ilyen elektronikus beren-
dezések gyártói kötelessé válnak az ilyen termékek visszavételére azok hasznos élettartama vé-
gén. Az MSI betartja a termékvisszavétellel kapcsolatos követelményeket az MSI márkanév alatt
az EU-n belül értékesített termékek esetében, azok élettartamának végén. Az ilyen termékeket a
legközelebbi gyűjtőhelyre viheti.
ITALIANO
Per proteggere l’ambiente, MSI, da sempre amica della natura, ti ricorda che….
In base alla Direttiva dell’Unione Europea (EU) sullo Smaltimento dei Materiali Elettrici ed
Elettronici, Direttiva 2002/96/EC in vigore dal 13 Agosto 2005, prodotti appartenenti alla catego-
ria dei Materiali Elettrici ed Elettronici non possono più essere eliminati come ri󰘰uti municipali:
i produttori di detti materiali saranno obbligati a ritirare ogni prodotto alla 󰘰ne del suo ciclo di
vita. MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti
all’interno dell’Unione Europea alla 󰘰ne del loro ciclo di vita. È possibile portare i prodotti nel più
vicino punto di raccolta.

















󰘰
 


󰀩

Thank you for choosing the WindBOX, an excellent
industrial computer system from MSI.
The WindBOX eliminates the noise and the risk of
fan’s failure by wide heatsink as fanless solution.
Furthermore, it supports VESA wall-mount interface
for various scenarios like digital signage, thin client,
and POS with a󰘯ordable expenditure, which not only
meets the demand of Industrial applications but also
ful󰘰lls the needs of companies, governments, and in-
stitutes for general application.
Chapter 1
Overview

1-2
OVERVIEW ▍MS-9A25
OVERVIEW ▍MS-9A25
MS-9A25 System
Power Adapter
Power Cord
VESA Mount Plate Wireless LAN Antenna
User’s Manual Driver/Utility Disk
Packing contents
Please contact us immediately if any of the item is damaged or missing.
The picture is for your reference only and your packing contents may slightly
vary depending on the model you purchased.
■
■

OVERVIEW ▍MS-9A25
1-3
OVERVIEW ▍MS-9A25
Right Side View
1
2
3
4
5
6
7
Left Side View
8
9
10
11
12
system overview
1
Gigabit LAN Jack (Optional)
The standard RJ-45 LAN jack is for connection to the Local Area
Network (LAN). You can connect a network cable to it.
2
Gigabit LAN Jack
The standard RJ-45 LAN jack is for connection to the Local Area
Network (LAN). You can connect a network cable to it.
3
Headphone Jack (Green)
- This connector is provided for headphones or speakers.
4
Microphone Jack (Pink)
- This connector is provided for microphones.
5
9
USB Ports
The USB (Universal Serial Bus) port is for attaching USB devices
such as keyboard, mouse, or other USB-compatible devices.

1-4
OVERVIEW ▍MS-9A25
OVERVIEW ▍MS-9A25
6
DVI Port
The DVI (Digital Visual Interface) connector allows you to connect
an LCD monitor. It provides a high-speed digital interconnection
between the computer and its display device. To connect an LCD
monitor, simply plug your monitor cable into the DVI connector,
and make sure that the other end of the cable is properly con-
nected to your monitor (refer to your monitor manual for more
information.)
7
Antenna Connector
This connector allows you to connect an external antenna for
wireless LAN.
8
Antenna Connector (Optional)
This connector allows you to connect an external antenna for
wireless LAN.
10
Power Button
Press this button to turn the system on or o󰘯.
11
Serial Port
The serial port is a 16550A high speed communications port that
sends/ receives 16 bytes FIFOs. You can attach a serial mouse
or other serial devices directly to the connector.
12
Power Jack
The power adapter converts AC power to DC power for this jack.
Power supplied through this jack supplies power to the system.
To prevent damage to the system, always use the supplied power
adapter.

OVERVIEW ▍MS-9A25
1-5
OVERVIEW ▍MS-9A25
system sPecifications
Processor
Intel ATOM N270 1.6GHz
FSB
533MHz
Chipset
North Bridge: Intel 945GSE chipset
South Bridge: Intel ICH7M chipset
Memory
Single channel DDR2 533/667 MHz SO-DIMM, up to 2GB
LAN
Gigabit Fast Ethernet by Intel 82574 GbE controller
Video
Intel GMA950 graphic engine
Up to QXGA (2048 x 1536) resolution
Audio
HDA Codec by Realtek ALC888 7.1 channel
Compliant with Azalia 1.0 specs
Input / Output (I/O)
Left Panel I/O
1 wireless LAN antenna connector (optional)
3 USB ports
1 power button
1 RS-232/422/485 serial port
1 DC power jack
Right Panel I/O
2 Gigabit LAN jacks (optional)
1 headphone/speaker jack (green)
1 microphone jack (pink)
1 USB port
1 DVI-I port
1 wireless LAN antenna connector
■
■
■
■
■
■
■
■
■
■
■-
-
-
-
-
■-
-
-
-
-
-

1-6
OVERVIEW ▍MS-9A25
Power Supply
40 watt power adapter with active PFC
Input: 100-240V~, 50-60Hz, 1.7A
Output: 20V 2.0A
Dimension & Weight
260 mm (W) X 180 mm (D) X 19 mm (H)
1.08 Kg
Regulatory Compliance
FCC Class B, CE, C-Tick, BSMI, VCCI, RoHS compliance
Environmental
Operating Temperature: -10oC to 60oC
Storage Temperature: -20oC to 80oC
Humidity: 5% ~ 90% (non condensing)
■
■
■
■
■
■
■
■
■

This chapter provides you with the information on
hardware setup procedures. While doing the installa-
tion, be careful in holding the components and follow
the installation procedures. For some components, if
you install in the wrong orientation, the components
will not work properly.
Use a grounded wrist strap before handling computer
components. Static electricity may damage the com-
ponents.
Chapter 2
System Setup
Important
Always unplug the power cord before installing
any components.
When the operating temperature reaches 40oC or
higher, please replace your HDD with SSD (Solid-
State Drive) or other types of heat-resistant HDD
to protect your HDD from being damaged by high
temperature.
•
•

2-2
SYSTEM SETUP ▍
installation tools
A Phillips (crosshead) screwdriver and a 󰘱athead screw-
driver, can be used to do most of the installation. Choose
one with a magnetic head would be better.
Pliers, can be used as an auxiliary tool to connect some
connectors or cables.
Forceps, can be used to pick up tiny screws or set up the
jumpers.
Rubber gloves, can prevent yourself from being incised
and su󰘯ering the static charge.

2-3
MS-9A25
system setuP
Step 1:
Locate the VESA mount screw holes on the back of the LCD monitor.
Step 2:
Fasten the VESA mount plate to the monitor with the supplied screws.

2-4
SYSTEM SETUP ▍
Step 3:
Mount the system onto the VESA mount plate.
Step 4:
Tighten the thumbscrew at the bottom of the VESA mount plate to secure the
system.
