MSI C847MS-E33 Series User manual
VGA port
COM port
JTPM1
CPUFAN1
SYSFAN1
SYSFAN2
+BAT
JPWR2
JUSB2 JUSB1
SATA4SATA3
PCI2
PCI1
PCI_E2
PCI_E1
DIMM1
DIMM2
JAUD1
JCOM1
JPWR1
SATA2
SATA1
JFP2 JFP1
JLPT1
JCI1
JBAT1
Top :
mouse or
Bottom:USB 2.0 ports
keyboard
Top: LAN Jack
Bottom: USB2.0 ports
T:
M:
B:
Line-In
Line-Out
Mic
Top:
Coaxial S/PDIF
Buttom:
Optical S/PDIF
JUSB_PW2
JUSB_PW1
HDMI port
13.+3.3V
1.+3.3V
14.-12V
2.+3.3V
15.Ground
3.Ground
16.PS-ON#
4.+5V 17.Ground
5.Ground
18.Ground
6.+5V
19.Ground
7.Ground
22.+5V
10.+12V
20.Res
8.PWR OK
23.+5V
11.+12V
21.+5V
9.5VSB
24.Ground
12.+3.3V
4.+12V
2.Ground
3.+12V
1.Ground
10.Ground
14.Ground
8.LPT_SLIN#
12.Ground
6.PINIT#
4.ERR#
2.AFD#
24.Ground
22.Ground
26.NoPin
20.Ground
18.Ground
16.Ground
1.RSTB#
3.PRND0
5.PRND1
7.PRND2
9.PRND3
11.PRND4
13.PRND5
15.PRND6
17.PRND7
19.ACK#
21.BUSY
23.PE
25.SLCT
1.Ground
2.+12V
3.Sensor
4.Control
1.Ground
2.+12V
3.NoUse
1.Ground
2.+12V
3.Sensor
4.No Us e
1.VCC
3.USB0-
10.NC
5.USB0+
7.Ground
9.NoPin
8.Ground
6.USB1+
4.USB1-
2.VCC
1.MICL
3.MICR
10.HeadPhoneDetection
5.HeadPhoneR
7.SENSE_SEND
9.HeadPhoneL
8.NoPin
6.MICDetection
4.PRESENCE#
2.Ground
3.Speaker
4.VCC5
1.Speaker
2.VCC5
1. +
3. -
10.No Pi n
5. -Reset Switch
HDD LED
Power Switch
Power LE D
7. +
9.Reserved
8. -
6. +
4. -
2. +
