MSI MAG B560M BAZOOKA User manual
I
MAG B560M BAZOOKA
Motherboard
User Guide
Benutzerhandbuch
Manuel d’utilisation
III
Quick Start
Thank you for purchasing the MSI® motherboard. This Quick Start section provides
demonstration diagrams about how to install your computer. Some of the installations
also provide video demonstrations. Please link to the URL to watch it with the web
browser on your phone or tablet. You may have even link to the URL by scanning the
QR code.
Kurzanleitung
Danke, dass Sie das MSI® Motherboard gewählt haben. Dieser Abschnitt der
Kurzanleitung bietet eine Demo zur Installation Ihres Computers. Manche
Installationen bieten auch die Videodemonstrationen. Klicken Sie auf die URL, um
diese Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table anzusehen. Oder
scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen.
Présentation rapide
Merci d’avoir choisi la carte mère MSI®. Ce manuel fournit une rapide présentation
avec des illustrations explicatives qui vous aideront à assembler votre ordinateur.
Des tutoriels vidéo sont disponibles pour certaines étapes. Cliquez sur le lien fourni
pour regarder la vidéo sur votre téléphone ou votre tablette. Vous pouvez également
accéder au lien en scannant le QR code qui lui est associé.
IV
Installing a Processor/ Installation des Prozessors/ Installer un
1
2
3
6
45
7
8
9
Youtube
http://v.youku.com/v_show/id_
XMTg2MjMwOTE2NA==.html
https://youtu.be/Xv89nhFk1vc
V
Installing DDR4 memory/ Installation des DDR4-Speichers/
DIMMA2 DIMMA2
DIMMB2
DIMMA1
DIMMA2
DIMMB1
DIMMB2
http://youtu.be/T03aDrJPyQs
Youtube
http://v.youku.com/v_show/id_XNzUyMTI5ODI4.html
VI
HDD LED
RESET SW
JFP1
HDD LED
HDD LED +
POWER LED +
POWER LED
1
2 10
9
+
+
+
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch
JFP1
1 HDD LED + 2 Power LED +
3 4
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED
http://youtu.be/DPELIdVNZUI
Youtube
http://v.youku.com/v_show/id_XNjcyMTczMzM2.html
VII
Installing the Motherboard/ Installation des Motherboards/
https://youtu.be/wWI6Qt51Wnc
Youtube
https://v.youku.com/v_show/id_
XNDUwMDUyNTkwOA==.html
BAT1
Torque:
3 kgf·cm*
*3 kgf·cm
= 0.3 N·m
= 2.6 lbf·in
2
2
1
XI
XII
4
3
12
1
Safety Information................................................................................................. 2
..................................................................................... 3
Specifications......................................................................................................... 4
Package contents .................................................................................................. 9
Rear I/O Panel ..................................................................................................... 10
LAN Port LED Status Table .................................................................................. 10
Realtek Audio Console ......................................................................................... 10
.................................................................................... 12
CPU Socket ........................................................................................................... 13
DIMM Slots............................................................................................................ 14
PCI_E1~3: PCIe Expansion Slots.......................................................................... 15
SATA1~6: SATA 6Gb/s Connectors....................................................................... 15
M2_1~2: M.2 Slots (Key M) ................................................................................... 16
JFP1, JFP2: Front Panel Connectors................................................................... 18
JAUD1: Front Audio Connector ............................................................................ 18
CPU_PWR1, ATX_PWR1: Power Connectors....................................................... 19
JCOM1: Serial Port Connector ............................................................................. 19
JUSB3: USB 3.2 Gen 1 Connector ........................................................................ 20
JUSB1~2: USB 2.0 Connectors............................................................................. 20
CPU_FAN1, PUMP_FAN1, SYS_FAN1~2: Fan Connectors.................................. 21
JCI1: Chassis Intrusion Connector....................................................................... 22
JTPM1: TPM Module Connector........................................................................... 22
JBAT1: Clear CMOS (Reset BIOS) Jumper........................................................... 23
JDASH1 : Tuning Controller connector................................................................ 23
EZ Debug LED....................................................................................................... 23
JRGB1: RGB LED connector................................................................................. 24
JRAINBOW1: Addressable RGB LED connector .................................................. 25
.................................................................... 26
Installing Windows® 10......................................................................................... 26
Installing Drivers .................................................................................................. 26
MSI Center............................................................................................................ 26
............................................................................................................. 27
BIOS Setup............................................................................................................ 28
Entering BIOS Setup............................................................................................. 28
BIOS User Guide ................................................................................................... 28
Resetting BIOS...................................................................................................... 29
Updating BIOS....................................................................................................... 29
English
2Safety Information
Safety Information
The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
Liquid has penetrated into the computer.
The motherboard has been exposed to moisture.
The motherboard does not work well or you can not get it work according to user
guide.
The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.
3
Safety Information
Before installing the motherboard into the case, install first the necessary mounting
the motherboard circuits and the computer case is prohibited. The Case standoff keep
out zone signs will be marked on the backside of motherboard (as shown below) to
serve as a warning to user.
4Specifications
Specifications
Supports 10th Gen Intel® Core™ Processors, 11th Gen
Intel® Core™ Processors, Pentium® Gold and Celeron®
Processors*
Processor socket LGA1200
* Please go to intel.com for compatibility information
Intel® B560 Chipset
Memory
4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel®
CPU (by JEDEC & POR)*
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen
Intel® CPU (by JEDEC & POR)*
Max overclocking frequency:
1DPC 1R Max speed up to 5066 MHz
1DPC 2R Max speed up to 4600+ MHz
2DPC 1R Max speed up to 4266+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Intel® Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slot
1x PCIe x16 slot
PCI_E1 (From CPU)
Supports up to PCIe 4.0 for 11th Gen Intel® CPU
Supports up to PCIe 3.0 for 10th Gen Intel® CPU
2x PCIe 3.0 x1 slots
PCI_E2 & PCI_E3 (From B560 chipset)
Onboard Graphics
1x HDMI 2.0b with HDR port, supports a maximum
resolution of 4K 60Hz*/**
1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Continued on next page
5
Specifications
Continued from previous page
Storage
6x SATA 6Gb/s ports (From B560 chipset)
2x M.2 slots (Key M)
M2_1 slot
Supports up to PCIe 4.0 x4 for 11th Gen Intel® CPU
(From CPU)
Supports up to PCIe 3.0 x4 for 10th Gen Intel® CPU
(From B560 chipset)
Supports SATA 6Gb/s (From B560 chipset)*
Supports 2242/ 2260/ 2280/ 22110 storage devices
M2_2 slot** (from B560 chipset)
Supports up to PCIe 3.0 x4
Supports 2242/ 2260/ 2280 storage devices
Intel® Optane™ Memory Ready*
Supports Intel® Smart Response Technology for Intel
Core™ processors
* SATA2 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
** Before using Intel® Optane™ memory modules, please ensure that you have
updated the drivers and BIOS to the latest version from MSI website.
Intel® B560 Chipset
panel
back panel, and 2 ports are available through the internal
USB 3.2 Gen 1 5Gbps connector)
USB Hubs GL850G
4x USB 2.0 ports are available through the internal
USB 2.0 connectors
Audio Realtek® AL897 Codec
LAN 1x Realtek® RTL8125B 2.5Gbps LAN controller
Continued on next page
6Specifications
Continued from previous page
6x SATA 6Gb/s connectors
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x Clear CMOS jumper
1x TPM module connector
1x Serial port connector
1x Tuning Controller Connector
LED Features
4x EZ Debug LED
Back Panel
1x PS/2 keyboard/ mouse combo port
1x DisplayPort
1x HDMI port
1x 2.5G LAN (RJ45) port
3x audio jacks
NUVOTON NCT6687 Controller Chip
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Continued on next page
7
Specifications
Continued from previous page
Form Factor
9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
BIOS Features
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.2, SMBIOS 3.0
Drivers
MSI Center
Intel® Extreme Tuning Utility
MSI APP Player (BlueStacks)
Open Broadcaster Software (OBS)
Google Chrome™, Google Toolbar, Google Drive
Norton™ Internet Security Solution
Features
MSI Sound Tune
Gaming Mode
Creator Mode
Gaming Highlights
LAN Manager
Mystic Light
Frozr AI Cooling
User Scenario
True Color
Live Update
Monitor
Super Charger
Speed Up
Continued on next page
8Specifications
Continued from previous page
Special Features
Audio
Audio Boost
Cooling
M.2 Shield Frozr
Pump Fan
Smart Fan Control
LED
Mystic Light Extension (RAINBOW/RGB)
EZ DEBUG LED
Performance
DDR4 Boost
Core Boost
USB 3.2 Gen 2 10G
Lightning Gen 4 M.2
Protection
Experience
Click BIOS 5
Other manuals for MAG B560M BAZOOKA
2
Table of contents
Languages:
Other MSI Motherboard manuals
MSI
MSI 845PE Neo User manual
MSI
MSI MEG X570S UNIFY-X MAX User manual
MSI
MSI MAG X670E TOMAHAWK WIFI User manual
MSI
MSI G41M-P34 User manual
MSI
MSI Z170A MPOWER GAMING TITANIUM User manual
MSI
MSI MS-6570E User manual
MSI
MSI B150-ICAFE/ H110 PC MATE User manual
MSI
MSI 865GM3 Series User manual
MSI
MSI MAG X670E TOMAHAWK WIFI User manual
MSI
MSI K7N420 Pro User manual
MSI
MSI MS-7798 (v2.x) User manual
MSI
MSI 760GM-P43 Series User manual
MSI
MSI MAG B660 TOMAHAWK WIFI DDR4 User manual
MSI
MSI KM3M-V Series User manual
MSI
MSI MICRO ATX BX11 User manual
MSI
MSI Z77A-G45 GAMING series User manual
MSI
MSI B75MA-P33 series User manual
MSI
MSI Z170A KRAIT GAMING User manual
MSI
MSI 970A GAMING PRO CARBON User manual
MSI
MSI 925X Neo Platinum User manual
Popular Motherboard manuals by other brands
SIMCom Wireless Solutions
SIMCom Wireless Solutions SIM5320AL EVB user guide
Nuvoton
Nuvoton NuMicro NuTiny-SDK-NANO120 user manual
Freescale Semiconductor
Freescale Semiconductor Qorivva MPC5746R-176DS user guide
Seco
Seco SECOCQ7-mITX2.0 user manual
Asus
Asus ROG STRIX B365-F GAMING manual
Cypress Semiconductor
Cypress Semiconductor S6SBP401AJ0SA1001 Operation guide
