MSI MPG Z690 EDGE WIFI DDR4 User manual
I
MPG Z690 EDGE WIFI DDR4
Motherboard
User Guide
Benutzerhandbuch
Manuel d’utilisation
III
Quick Start
Thank you for purchasing the MSI® motherboard. This Quick Start section provides
demonstration diagrams about how to install your computer. Some of the installations
also provide video demonstrations. Please link to the URL to watch it with the web
browser on your phone or tablet. You may have even link to the URL by scanning the
QR code.
Kurzanleitung
Danke, dass Sie das MSI® Motherboard gewählt haben. Dieser Abschnitt der
Kurzanleitung bietet eine Demo zur Installation Ihres Computers. Manche
Installationen bieten auch die Videodemonstrationen. Klicken Sie auf die URL, um
diese Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table anzusehen. Oder
scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen.
Présentation rapide
Merci d’avoir choisi la carte mère MSI®. Ce manuel fournit une rapide présentation
avec des illustrations explicatives qui vous aideront à assembler votre ordinateur.
Des tutoriels vidéo sont disponibles pour certaines étapes. Cliquez sur le lien fourni
pour regarder la vidéo sur votre téléphone ou votre tablette. Vous pouvez également
accéder au lien en scannant le QR code qui lui est associé.
V
Installing DDR4 memory/ Installation des DDR4-Speichers/
DIMMA2 DIMMA2
DIMMB2
DIMMA1
DIMMA2
DIMMB1
DIMMB2
http://youtu.be/T03aDrJPyQs
Youtube
http://v.youku.com/v_show/id_XNzUyMTI5ODI4.html
VI
Connecting the Front Panel Header/ Anschließen der
Frontpanel-Stiftleiste/ Connecter un connecteur du panneau
HDD LED
RESET SW
JFP1
HDD LED
HDD LED +
POWER LED +
POWER LED
1
2 10
9
+
+
+
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch
JFP1
1 HDD LED + 2 Power LED +
3 4
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED
http://youtu.be/DPELIdVNZUI
Youtube
http://v.youku.com/v_show/id_XNjcyMTczMzM2.html
VII
Installing the Motherboard/ Installation des Motherboards/
https://youtu.be/wWI6Qt51Wnc
https://v.youku.com/v_show/id_
XNDUwMDUyNTkwOA==.html
Youtube
1
2
Torque:
3 kgf·cm*
*3 kgf·cm
= 0.3 N·m
= 2.6 lbf·in
XI
Connecting Peripheral Devices/ Peripheriegeräte/ Connecter
XII
4
3
12
1
Contents
Contents
Safety Information................................................................................................. 3
..................................................................................... 4
Avoid collision notification...................................................................................... 4
Specifications......................................................................................................... 5
Package contents ................................................................................................ 12
Rear I/O Panel ..................................................................................................... 13
LAN Port LED Status Table .................................................................................. 13
Audio Ports Configuration.................................................................................... 13
Realtek Audio Console ......................................................................................... 14
Overview of Components .................................................................................... 17
CPU Socket ........................................................................................................... 18
DIMM Slots............................................................................................................ 19
PCI_E1~4: PCIe Expansion Slots.......................................................................... 20
...................................................... 20
M2_1~4: M.2 Slots (Key M) ................................................................................... 21
SATA5~8 & SATAA~B: SATA 6Gb/s Connectors................................................... 23
JAUD1: Front Audio Connector ............................................................................ 23
JFP1, JFP2: Front Panel Connectors................................................................... 24
CPU_PWR1~2, ATX_PWR1: Power Connectors................................................... 25
............................................................ 26
JUSB3: USB 3.2 Gen 1 Connector ........................................................................ 26
JUSB1~2: USB 2.0 Connectors............................................................................. 27
JTPM1: TPM Module Connector........................................................................... 27
CPU_FAN1, PUMP_FAN1, SYS_FAN1~6: Fan Connectors.................................. 28
JCI1: Chassis Intrusion Connector....................................................................... 29
JBAT1: Clear CMOS (Reset BIOS) Jumper........................................................... 30
JDASH1 : Tuning Controller connector................................................................ 30
JRGB1: RGB LED connector................................................................................. 31
JRAINBOW1~3: Addressable RGB LED connectors ............................................ 32
Onboard LEDs...................................................................................................... 33
EZ Debug LED....................................................................................................... 33
LED_SW1: EZ LED Control................................................................................... 33
JPWRLED1: LED power input............................................................................... 33
Installing OS, Drivers & MSI Center.................................................................... 34
Installing Windows 10/ Windows 11..................................................................... 34
English
2Contents
Installing Drivers .................................................................................................. 34
MSI Center............................................................................................................ 34
............................................................................................................. 35
BIOS Setup............................................................................................................ 36
Entering BIOS Setup............................................................................................. 36
BIOS User Guide ................................................................................................... 36
Resetting BIOS...................................................................................................... 37
Updating BIOS....................................................................................................... 37
3
Safety Information
Safety Information
The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
Liquid has penetrated into the computer.
The motherboard has been exposed to moisture.
The motherboard does not work well or you can not get it work according to user
guide.
The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.
4Contents
Case stand-off notification
the motherboard circuits and the computer case is prohibited. The Case standoff keep
out zone signs will be marked on the backside of motherboard (as shown below) to
serve as a warning to user.
Avoid collision notification
Protective paint is printed around each screw hole to prevent parts from being
scratched.
5
Specifications
Specifications
Supports 12th Gen Intel® Core™, Pentium® Gold and
Celeron® Processors*
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® Z690 Chipset
Memory
4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC &
POR)*
Max overclocking frequency:
1DPC 1R Max speed up to 5200+ MHz
1DPC 2R Max speed up to 4800+ MHz
2DPC 1R Max speed up to 4400+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Intel® Extreme Memory Profile (XMP)
*Please refer to www.msi.com for more information on compatible memory
Expansion Slot
3x PCIe x16 slots
PCI_E1 slot (From CPU)
Supports PCIe 5.0 x16
PCI_E3 & PCI_E4 slots (From Z690 chipset)
Supports PCIe 3.0 x4
1x PCIe 3.0 x1 slot (From Z690 chipset)
Supports AMD® CrossFire™ Technology
Onboard Graphics
1x HDMI 2.1 with HDR port, supports a maximum
resolution of 4K 60Hz*/**
1x DisplayPort 1.4 port with HBR3, supports a maximum
resolution of 4K 60Hz*/**
*Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the Processor installed.
Continued on next page
6Specifications
Continued from previous page
Storage
6x SATA 6Gb/s ports
SATA5~8 (From Z690 Chipset)
SATAA~B (From ASMedia ASM1061)
4x M.2 slots (Key M)
M2_1 slot (From CPU)
Supports PCIe 4.0 x4
Supports 2260/ 2280/ 22110 storage devices
M2_2 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports 2260/ 2280 storage devices
M2_3 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
M2_4 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
M2_2~4 support Intel® Optane™ Memory
Supports Intel® Smart Response Technology for Intel
Core™ processors
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices*
Supports RAID 0, RAID 1 and RAID 5 for M.2 PCIe storage
devices
* SATAA & SATAB do not support RAID function.
Audio
Realtek® ALC4080
Supports S/PDIF output
Continued on next page
7
Specifications
Continued from previous page
Intel® Z690 Chipset
panel
2x USB 3.2 Gen 1 5Gbps ports available through the
internal USB connector
4x USB 2.0 ports available through the internal USB
connectors
LAN 1x Intel® I225V 2.5Gbps LAN controller
Wireless LAN &
slot
2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.2
Connectors
1x Flash BIOS button
2x USB 2.0 ports
1x DisplayPort
1x HDMI port
1x 2.5Gbps LAN (RJ45) port
5x audio jacks
1x Optical S/PDIF Out connector
Continued on next page
8Specifications
Continued from previous page
Internal Connectors
6x SATA 6Gb/s connectors
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1xTPM module connector
1x Clear CMOS jumper
1x Tuning controller connector
1x TBT connector (Supports RTD3)
LED Features
1x EZ LED Control switch
4x EZ Debug LED
I/O Controller NUVOTON NCT6687D Controller Chip
Hardware Monitor
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Form Factor ATX Form Factor
12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Continued on next page
Other manuals for MPG Z690 EDGE WIFI DDR4
1
This manual suits for next models
2
Table of contents
Languages:
Other MSI Motherboard manuals
MSI
MSI MS-6137 User manual
MSI
MSI Fuzzy 945GME1 Series Instructions for use
MSI
MSI 845GVM2-V Series User manual
MSI
MSI MS-7101 User manual
MSI
MSI B450M PRO-M2 V2 User manual
MSI
MSI MEG Z590I UNIFY User manual
MSI
MSI PRO Z790-A MAX WIFI User manual
MSI
MSI MAG Z690 TOMAHAWK User manual
MSI
MSI A320M PRO-E User manual
MSI
MSI H67A-G43 (B3) User manual
MSI
MSI G45TM-E53 Series User manual
MSI
MSI X299 RAIDER User manual
MSI
MSI MS-9802 User manual
MSI
MSI A75A-G35 Series User manual
MSI
MSI MPG B550 GAMING PLUS User manual
MSI
MSI PRO B760M-A WIFI DDR4 User manual
MSI
MSI MS-6309 ATX VA5 User manual
MSI
MSI MS-7388 User manual
MSI
MSI MS-7260 User manual
MSI
MSI G31M3-F - Motherboard - Micro ATX User manual
