MSI MS-6787 User manual

i
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission limits.
VOIR LANOTICE D’NSTALLATION AVANT DE RACCORDERAU RESEAU.
Micro-Star International
MS-6787
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation
G52-M6787X9

ii
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in
the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes without notice.
Trademarks
All trademarks are the properties of their respective owners.
AMD, Athlon™ Athlon™XP, Thoroughbred™ and Duron™ are registered trademarks of AMD Corporation.
Intel® and Pentium® are registered trademarks of Intel Corporation.
PS/2 and OS® 2 are registered trademarks of International Business Machines Corporation.
Microsoft® is a registered trademark of Microsoft Corporation. Windows® 98/2000/NT/XP are registered trademarks
of Microsoft Corporation.
NVIDIA, the NVIDIA logo, DualNet, and nForce are registered trademarks or trademarks of NVIDIA Corporation in the
United States and/or other countries.
Netware® is a registered trademark of Novell, Inc.
Award® is a registered trademark of Phoenix Technologies Ltd.
AMI® is a registered trademark of American Megatrends Inc.
Kensington and MicroSaver are registered trademarks of the Kensington Technology Group.
PCMCIA and CardBus are registered trademarks of the Personal Computer Memory Card International Association.
Revision History
Revision Revision History Date
V2.0 First released for PCB 2.x March 2004
V2.1 Add Dutch version April 2004

iii
Safety Instructions
1. Always read the safety instructions carefully.
2. Keep this User Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence protects the equipment from overheating. Do not
cover the openings.
6. Make sure the voltage of the power source and adjust properly 110/220V before connecting the equipment to the
power inlet.
7. Place the power cord such a way that people can not step on it. Do not place anything over the power cord.
8. Always Unplug the Power Cord before inserting any add-on card or module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage or cause electrical shock.
11. If any of the following situations arises, get the equipment checked by a service personnel:
- The power cord or plug is damaged.
- Liquid has penetrated into the equipment.
- The equipment has been exposed to moisture.
- The equipment does not work well or you can not get it work according to User Manual.
- The equipment has dropped and damaged.
- The equipment has obvious sign of breakage.
12. Do not leave this equipment in an environment unconditioned, storage temperature above 600 C (1400F), it may
damage the equipment.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer.

iv
Table of Content
English.....................................................................1
Deutsch....................................................................17
Français...................................................................33
简体中文...................................................................49
繁體中文...................................................................63
日本語.......................................................................77
Nederlands..............................................................93

1
Introduction
Thank you for choosing the P4MAM-V Series (MS-6787 v2.X) micro ATX mainboard. The P4MAM-V
Series is based on VIA ® VT8751A & VT8235 chipsets for optimal system efficiency. Designed to fit the
advanced Intel ® Pentium ® 4 processors in 478 pin package, the P4MAM-V Series delivers a high
performance and professional desktop platform solution.
Layout
BATT
+
VIA
VT8235
DIMM 1
DIMM 2
CD_IN1
JSPDIF1
JFP2JFP1
JIR1
(Optional)
JCI1
(Optional)
JBAT1
JUSB1JAUDIO1
ATX1
SFAN1
CFAN1
PCI Slot 1
PCI Slot 2
PCI Slot 3
IDE 1
IDE2
Top: Parallel Port
Bottom:
COM A
VGAPort
Top: Mouse
Bottom: Keyboard
Top: LAN Jack
Bottom: USB
Ports
USB
Ports
Codec
JPW1
T: L ine- In
M:
B:Mic
Line-Out
FDD1
SOCKET 478
Winbond
W83697HF
VIA
VT6103
VIA
VT8751A
BIOS
AGP Slot
CNR
JP1

2
Specifications
CPU
zSupports Intel ® Pentium 4/Celeron (Socket 478) processor.
zSupports Intel ® P4 Northwood up to 3.06GHz and P4 Prescott Celeron up to 2.8GHz.
(For the latest information about CPU, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php )
Chipset
zVIA ® VT8751A chipset (664 BGA)
- 64bit P4 processors FSB I/F (533MHz).
- 64bit DDR SDRAM memory I/F (200/266MHz).
- 32bit AGP I/F (66MHz) for 4x/2x mode.
- 8bit V-Link I/F (66MHz) with peak bandwidth of 266MB/s.
zVIA ® VT8235 chipset (376 BGA)
- Dual-channel UDMA 133/100/66/33 master mode EIDE controller.
- 6 ports USB controller (v2.0).
- KBD controller with PS2 mouse support.
- SMBus I/F and ACPI/APM compliance power management.
- LPC I/F for super I/O and 2MB flash ROM (BIOS).
- AC-97 link controller to cooperate w/ external AC97 audio & modem codec.
- 10/100Mbps Fast Ethernet controller.
- Supports HSP modem.
Main Memory
zSupports four memory banks using two 184-pin DDR DIMM.
zSupports up to 2GB PC2100/PC1600 DDR SDRAMs.
zSupports 2.5v DDR SDRAM.
(For the updated supporting memory modules, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php )
Slots
zOne AGP (Accelerated Graphics Port) 4x slot.
zThree PCI 2.2 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).
zOne CNR (Communication Network Riser) slot.

3
On-Board IDE
zAn IDE controller on the VIA ® VT8235 Chipset provides IDE HDD/CD-ROM with PIO, Bus Master
and Ultra DMA 33/66/100/133 operation modes. Can connect up to four IDE devices.
On-Board Peripherals
zOn-Board Peripherals includes:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial port (COM A)
- 1 parallel port supports SPP/EPP/ECP mode
- 6 USB 2.0 ports (Rear * 4/ Front * 2)
- 1 audio (Line-In/Line-Out/Mic) port
- 1 RJ45 LAN jack
- 1 VGA port
Audio
zAC97 link controller integrated in VT8235.
zVIA ® VT1616 6-channel software audio codec.
- Compliance with AC97 v2.2 spec.
LAN
zVIA ® VT6103 PCI local bus single-chip Fast Ethernet Controller.
- With external 10/100 Base-T Lan transformer.
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s and 100Mb/s auto-negotiation operation.
- Compliance with PCI v2.2 and PC99 standard.
- Supports ACPI power management.
BIOS
zThe mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral devices and
expansion cards of the board automatically.
zThe mainboard provides a Desktop Management Interface (DMI) function which records your
mainboard specifications.
Dimension
zMicro-ATX Form Factor: 243 mm x 214mm.
Mounting
z6 mounting holes.

4
Rear Panel
The back panel provides the following connectors:
Keyboard
USBPorts
Mouse
COMport VGAport
Par allel Port LineIn
LineOut
Mic In
LAN
USBPorts
Hardware Setup
This chapter tells you how to install the CPU, memory modules, and expansion cards, as well as how to
setup the jumpers on the mainboard. It also provides the instructions on connecting the peripheral
devices, such as the mouse, keyboard, etc. While doing the installation, be careful in holding the
components and follow the installation procedures.
Central Processing Unit: CPU
The mainboard supports Intel Pentium 4 Northwood & Prescott Celeron processor in the 478 pin
package. The mainboard uses a CPU socket called PGA478 for easy CPU installation. When you are
installing the CPU, make sure the CPU has a heat sink and a cooling fan attached on the top to prevent
overheating. If you do not find the heat sink and cooling fan, contact your dealer to purchase and install
them before turning on the computer. (For the latest information about CPU, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php )
Example of CPU Core Speed Derivation Procedure
If CPU Clock = 133MHz
Core/Bus ratio = 23
then CPU core speed = Host Clock x Core/Bus ratio
= 133MHz x 23
=3.06GHz

5
Memory Speed/CPU FSB Support Matrix
Memory
FSB DDR 200 DDR 266
400 MHz OK OK
533 MHz OK OK
CPU Installation Procedures for Socket 478
1. Please turn off the power and unplug the power cord before installing the CPU.
2. Pull the lever sideways away from the socket. Make sure to raise the lever up to a 90-degree
angle.
3. Look for the gold arrow. The gold arrow should point towards the lever pivot. The CPU can only
fit in the correct orientation.
4. If the CPU is correctly installed, the pins should be completely embedded into the socket and
can not be seen. Please note that any violation of the correct installation procedures may cause
permanent damages to your mainboard.
5. Press the CPU down firmly into the socket and close the lever.As the CPU is likely to move
while the lever is being closed, always close the lever with your fingers pressing tightly on top of
the CPU to make sure the CPU is properly and completely embedded into the socket.
Installing the CPU Fan
As processor technology pushes to faster speeds and higher performance, thermal management
becomes increasingly important. To dissipate heat, you need to attach the CPU cooling fan and
heatsink on top of the CPU. Follow the instructions below to install the Heatsink/Fan:
1. Locate the CPU and its retention mechanism on the motherboard.
2. Position the heatsink onto the retention mechanism.
3. Mount the fan on top of the heatsink. Press down the fan until its four clips get wedged in the
holes of the retention mechanism.
4. Press the two levers down to fasten the fan. Each lever can be pressed down in only ONE
direction.

6
5. Connect the fan power cable from the mounted fan to the 3-pin fan power connector on the
board.
MSI Reminds You...
Overheating…
Overheating will seriously damage the CPU and system, always make sure the cooling fan can work
properly to protect the CPU from overheating.
Replacing the CPU…
While replacing the CPU, always turn off the ATX power supply or unplug the power supply’s power
cord from grounded outlet first to ensure the safety of CPU.
Memory
The mainboard provides two 184-pin unbuffered DDR200/DDR266 DDR SDRAM, and supports the
memory size up to 2GB. To operate properly, at least one DIMM module must be installed. (For the
updated supporting memory modules, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php )
Install at least one DIMM module on the slots. Memory modules can be installed on the slots in any
order. You can install either single- or double-sided modules to meet your own needs.
Installing DDR Modules
1. The DDR DIMM has only one notch on the center of module. The module will only fit in the right
orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then push it in until the golden
finger on the memory module is deeply inserted in the socket.
3. The plastic clip at each side of the DIMM slot will automatically close.

7
NotchVolt
Power Supply
The mainboard supports ATX power supply for the power system. Before inserting the power supply
connector, always make sure that all components are installed properly to ensure that no damage will
be caused. A 300W or above power supply is suggested.
ATX 20-Pin Power Connector: ATX1
This connector allows you to connect to an ATX power supply. To connect to the ATX power supply,
make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned.
Then push down the power supply firmly into the connector.
1
11
3.3V
3.3V
3.3V
-12V
GND
GND
GN D
GND
GN D
GN D
GND
PW_OK
-5V
5V_SB
5V
5V
12V 5V
PS _O N
5V
10
20
ATX 12V Power Connector: JPW1
This 12V power connector is used to provide power to the CPU.
1
3
2
4
GND
GND
12V 12V
Floppy Disk Drive Connector: FDD1
The mainboard provides a standard floppy disk drive connector that supports 360K, 720K, 1.2M, 1.44M
and 2.88M floppy disk types.

8
Chassis Intrusion Switch Connector: JCI1 (Optional)
This connector is connected to 2-pin connector chassis switch. If the Chassis is open, the switch will be
short. The system will record this status. To clear the warning, you must enter the BIOS setting and
clear the status.
GN D
CI NTRU
CD-In Connector: CD_IN1
The connector is for CD-ROM audio connector.
GND
L
R
SPDIF-OUT Connector: JSPDIF1 (Optional)
The connector is used to connect SPDIF interface for digital audio transmission.
SPD I
F
VCC GND
Fan Power Connectors: CFAN1/SFAN1
The CFAN1 (processor fan) and SFAN1 (system fan) support system cooling fan with +12V. They
support three-pin head connector. When connecting the wire to the connectors, always take note that
the red wire is the positive and should be connected to the +12V, the black wire is Ground and should
be connected to GND. If the mainboard has a System Hardware Monitor chipset on-board, you must
use a specially designed fan with speed sensor to take advantage of the CPU fan control.
+12V
GN D SENSOR

9
MSI Reminds You...
1. Always consult the vendors for proper CPU cooling fan.
2. CFAN1 supports the fan control. You can install the PC Alert utility that will automatically control the
CPU fan speed according to the actual CPU temperature.
IDE Connectors: IDE1 & IDE2
The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 33/66/100/133 controller that provides
PIO mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 function. You can connect up to four hard
disk drives, CD-ROM, 120MB Floppy and other devices.
The first hard drive should always be connected to IDE1. IDE1 can connect a Master and a Slave drive.
You must configure second hard drive to Slave mode by setting the jumper accordingly. IDE2 can also
connect a Master and a Slave drive.
MSI Reminds You...
If you install two hard disks on cable, you must configure the second drive to Slave mode by setting its
jumper. Refer to the hard disk documentation supplied by hard disk vendors for jumper setting
instructions.
Front Panel Connectors: JFP1 & JFP2
The mainboard provides two front panel connectors for electrical connection to the front panel switches
and LEDs. JFP1 is compliant with Intel Front Panel I/O Connectivity Design Guide.
HDD
LED
Powe r
LED
Power
LED
Spe ak er
Reset
Switch
Power
Switch
117
9
228
10
JFP1 JFP2

10
Front Panel Audio Connector: JAUDIO1
The front panel audio connector allows you to connect to the front panel audio and is compliant with
Intel ® Front Panel I/O Connectivity Design Guide.
1
29
10
AU D _M I C
AUD_MIC_ BIAS
AU D _G N D
AUD_VCC
AUD_FPOUT_R
AUD_RET _L
AUD_FPOUT_ L
AUD_RET_R
HP _ON
KE Y
MSI Reminds You...
If you do not want to connect to the front audio header, pins 5 & 6, 9 & 10 have to be jumpered in order
to have signal output directed to the rear audio ports. Otherwise, the Line-Out connector on the back
panel will not function.
1
29
10
Front USB Connector: JUSB1
The mainboard provides one standard USB 2.0 pin header JUSB1. USB 2.0 technology increases data
transfer rate up to a maximum throughput of 480Mbps, which is 40 times faster than USB 1.1, and is
ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3
players, printers, modems and the like.
19
210
GNDUS BO C
KEY
GND
VCC
VCC
US B0 -
US B 1 -
USB0+
US B 1 +

11
Clear CMOS Jumper: JBAT1
There is a CMOS RAM on board that has a power supply from external battery to keep the data of
system configuration. With the CMOS RAM, the system can automatically boot OS every time it is
turned on. If you want to clear the system configuration, use the JBAT1 (Clear CMOS Jumper) to clear
data. Follow the instructions below to clear the data:
1
3
1
Keep Data ClearData
3
1
MSI Reminds You...
You can clear CMOS by shorting 2-3 pin while the system is off. Then return to 1-2 pin position. Avoid
clearing the CMOS while the system is on; it will damage the mainboard.
CPU Support Jumper: JP1
This jumper specifies the mainboard’s support for locked or some unlocked CPU.
11
3
Locked CPU Unlocked CPU
1
3
IrDA Infrared Module Header: JIR1 (Optional)
The connector allows you to connect to IrDA Infrared module.
NC
NC
GND
VCC5
IR RX
IRTX
15
26

12
AGP (Accelerated Graphics Port) Slot
The AGP slot allows you to insert the AGP graphics card. AGP is an interface specification designed for
the throughput demands of 3D graphics. It introduces a 66MHz, 32-bit channel for the graphics
controller to directly access main memory. The mainboard supports 4xAGP card.
PCI (Peripheral Component Interconnect) Slots
The PCI slots allow you to insert the expansion cards to meet your needs. When adding or removing
expansion cards, make sure that you unplug the power supply first. Meanwhile, read the documentation
for the expansion card to make any necessary hardware or software settings for the expansion card,
such as jumpers, switches or BIOS configuration.
CNR (Communication Network Riser) Slot
The CNR slot allows you to insert the CNR expansion cards. CNR is a specially designed network,
audio, or modem riser card for ATX family motherboards. Its main processing is done through software
and controlled by the motherboard chipset.
PCI Interrupt Request Routing
The IRQ, abbreviation of interrupt request line and pronounced I-R-Q, are hardware lines over which
devices can send interrupt signals to the microprocessor. The PCI IRQ pins are typically connected to
the PCI bus INT A# ~ INT D# pins as follows:
Order1 Order2 Order3 Order4
PCI Slot 1 INTA# INT B# INT C# INT D#
PCI Slot 2 INT B# INT C# INT D# INT A#
PCI Slot 3 INT C# INT D# INT A# INT B#

13
BIOS Setup
Power on the computer and the system will start POST (Power On Self Test) process. When the
message below appears on the screen, press <DEL> key to enter Setup.
DEL: Setup F11: Boot Menu F12: Network boot TAB: Logo
If the message disappears before you respond and you still wish to enter Setup, restart the system by
turning it OFF and On or pressing the RESET button. You may also restart the system by
simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.
Main Page
Standard CMOS Features
Use this menu for basic system configurations, such as time, date etc.
Advanced BIOS Features
Use this menu to setup the items of Award special enhanced features.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and optimize your system performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
Power Management Setup
Use this menu to specify your settings for power management.
PNP/PCI Configurations
This entry appears if your system supports PnP/PCI.
PC Health Status
This entry shows your PC health status.
Frequency/Voltage Control
Use this menu to specify your settings for frequency/voltage control.
Load High Performance Defaults
Use this menu to load the BIOS values for the best system performance, but the system stability may

14
be affected.
Load Optimized Defaults
Use this menu to load factory default settings into the BIOS for stable system performance operations.
Set Supervisor Password
Use this menu to set Supervisor Password.
Set User Password
Use this menu to set User Password.
Save & Exit Setup
Save changes to CMOS and exit setup.
Exit Without Saving
Abandon all changes and exit setup.
Frequency/Voltage Control
CPU VID
This item specifies the voltage of CPU Vcore. Note that changing CPU Vcore could result in unstable
system; therefore, it is not recommended to change the default setting for long-term purpose.
CPU Clock Ratio
End users can overclock the processor (only if the processor supports so) by specifying the CPU ratio
(clock multiplier) in this field.
Auto Detect PCI/DIMM Clk
This item is used to auto detect the PCI slots. When set to Enabled, the system will remove (turn off)
clocks from empty PCI slots to minimize the electromagnetic interference (EMI).
Spread Spectrum
When the motherboard’s clock generator pulses, the extreme values (spikes) of the pulses creates EMI
(Electromagnetic Interference). The Spread Spectrum function reduces the EMI generated by
modulating the pulses so that the spikes of the pulses are reduced to flatter curves. If you do not have
any EMI problem, leave the setting at Disabled for optimal system stability and performance. But if you
are plagued by EMI, set to Enabled for EMI reduction. Remember to disable Spread Spectrum if you

15
are overclocking because even a slight jitter can introduce a temporary boost in clock speed which may
just cause your overclocked processor to lock up.
CPU Clock
Use this item to select the appropriate clock frequency of the CPU host bus.
For the complete BIOS introduction and setup, please visit MSI website at http://www.msi.com.tw.

16
