MTE Matrix Filter D Series User manual

MATRIX FILTER®
SERIES D
380-415 Volts, 50HZ
USER MANUAL
PART NO. INSTR–025
REL. 071207
© 2007 MTE Corporation

Matrix Series D Users Manual
1
Part No. INSTR-025 REL. 071207
IMPORTANT USER INFORMATION
NOTICE
The MTE Corporation Matrix Filter® is designed for harmonic mitigation of six pulse inverter drives supplying
variable torque loads in a wide variety of applications. The suitability of this filter for a specific application
must therefore be determined by the customer. In no event will MTE Corporation assume responsibility or
liability for any direct or consequential damages resulting from the use or application of this filter. Nor will
MTE Corporation assume patent liability with respect to the use of information, circuits or equipment
described in this instruction manual. The series D Matrix Filter® uses patented Harmonics Mitigating Reactor
(HMR) technology to limit full load current distortion to less than 5% THID.
MDP0482C

Matrix Series D Users Manual
2
Part No. INSTR-025 REL. 071207
TABLE OF CONTENTS
IMPORTANT USER INFORMATION....................................................................................................................................1
TABLE OF CONTENTS .......................................................................................................................................................2
IMPORTANT SAFETY INFORMATION ...............................................................................................................................3
INTRODUCTION...................................................................................................................................................................4
PART NUMBER CODES......................................................................................................................................................5
SPECIFICATIONS:...............................................................................................................................................................6
AGENCY APPROVALS...........................................................................................................................................................6
RATINGS..............................................................................................................................................................................7
WATTS LOSS.......................................................................................................................................................................7
REGULATION TABLE .............................................................................................................................................................8
CAPACITOR CURRENTS........................................................................................................................................................9
OVER TEMPERATURE SWITCH RATINGS...............................................................................................................................10
OPEN STYLE SIZE AND WEIGHTS ..................................................................................................................................11
ENCLOSED UNIT SIZE AND WEIGHTS ...........................................................................................................................12
PERFORMANCE DATA .....................................................................................................................................................13
LOAD EFFECT ON THID......................................................................................................................................................13
HARMONIC SPECTRUM 100% LOAD ....................................................................................................................................13
POWER FACTOR ...............................................................................................................................................................14
PERFORMANCE WITH UNBALANCED LINE VOLTAGE (TYPICAL)................................................................................................14
ALTITUDE DERATING CURVE ..............................................................................................................................................15
TEMPERATURE DERATING CURVE .......................................................................................................................................15
INSTALLATION INSTRUCTIONS ......................................................................................................................................16
HMR BOLT HOLE MOUNTING PATTERNS .............................................................................................................................17
CAP-PANEL BOLT HOLE MOUNTING PATTERNS ....................................................................................................................18
HMR MOUNTING &TERMINAL LOCATIONS ...............................................................................................................19
HMR 6 - 44 Amps ......................................................................................................................................................19
HMR 52 -103 Amp.....................................................................................................................................................20
HMR 128 - 240 Amp..................................................................................................................................................21
HMR 320 - 482 Amp..................................................................................................................................................22
HMR 636 - 786 Amp..................................................................................................................................................23
CAP-ASSEMBLY MOUNTING &TERMINAL LOCATIONS............................................................................................24
ENCLOSED UNIT INTERNAL DETAILS &TERMINAL LOCATIONS.............................................................................25
CAB-12C 6-44 AMPS ..............................................................................................................................................25
CAB-17C 52-103 AMPS ..........................................................................................................................................26
CAB-26C 128-240 AMPS ........................................................................................................................................27
CAB-26D 320-482 AMPS ........................................................................................................................................28
CAB-30D 636-786 AMPS ........................................................................................................................................29
POWER WIRING CONNECTION .......................................................................................................................................30
INPUT AND OUTPUT TERMINAL SPECIFICATIONS ...................................................................................................................31
OPEN PANEL UNIT INTERCONNECTION DIAGRAM ..................................................................................................................32
ENCLOSED UNIT INTERCONNECTION DIAGRAM .....................................................................................................................33
FILTER DESCRIPTION ......................................................................................................................................................34
BLOCK DIAGRAM ...............................................................................................................................................................35
CONTACTOR OPTIONS .......................................................................................................................................................36
CONTACTOR COIL SWITCHING CURRENTS .............................................................................................................................42
STARTUP.......................................................................................................................................................................43
SEQUENCE OF OPERATION.................................................................................................................................................43
TROUBLESHOOTING ...................................................................................................................................................44

Matrix Series D Users Manual
3
Part No. INSTR-025 REL. 071207
IMPORTANT SAFETY INFORMATION
WARNING
ONLY A QUALIFIED ELECTRICIAN CAN CARRY OUT THE ELECTRICAL INSTALLATION OF
THIS FILTER
WARNING
High voltage is used in the operation of this filter. Use Extreme caution to avoid contact with high
voltage when operating, installing or repairing this filter.
INJURY OR DEATH MAY RESULT IF SAFETY PRECAUTIONS ARE NOT OBSERVED.
After removing power, allow at least five minutes to elapse and verify that the capacitors have
discharged to a safe level before contacting internal components. Connect a DC voltmeter across
the capacitor terminals. Start with the meter on the highest scale and progressively switch to a
lower scale as the indicated voltage falls below the maximum value of the scale used.
WARNING
The opening of the branch circuit protective device may be an indication that a fault current has
been interrupted. To reduce the risk of fire or electrical shock, current-carrying parts and other
components of the filter should be examined and replaced if damaged.
WARNING
An upstream disconnect/protection device must be used as required by the National Electrical Code
(NEC) or governing authority.
WARNING
Even if the upstream disconnect/protection device is open, the drive down stream of the filter may
feed back high voltage to the filter. The drive safety instructions must be followed.
INJURY OR DEATH MAY RESULT IF SAFETY PRECAUTIONS ARE NOT OBSERVED
WARNING
The filter must be grounded with a grounding conductor connected to all grounding terminals.
WARNING
Only spare parts obtained from MTE Corporation or an authorized MTE distributor can be used.
WARNING
Loose or improperly secured connections may damage or degrade filter performance.
Visually inspect and secure all electrical connections before loading the filter.

Matrix Series D Users Manual
4
Part No. INSTR-025 REL. 071207
INTRODUCTION
This manual was specifically developed to
assist in the installation, interconnection
and operation of the MTE Corporation
Series “D” Matrix Filter®.
This manual is intended for use by
personnel experienced in the operation and
maintenance of electronic drives. Because
of the high voltages required by the filter
and drive and the potential dangers
presented by rotating machinery, it is
essential that all personnel involved in the
operation and maintenance of this filter
know and practice the necessary safety
precautions for this type of equipment.
Personnel should read and understand the
instructions contained in this manual before
installing, operating or servicing the filter
and the drive to which the filter is
connected.
Upon Receipt of this Filter:
The MTE Matrix Filter® has been
subjected to demanding factory tests before
shipment. Carefully inspect the shipping
container for damage that may have
occurred in transit. Then unpack the filter
and carefully inspect for any signs of
damage. Save the shipping container for
future transport of the filter.
In the event of damage, please contact
and file a claim with the freight carrier
involved immediately.
If the equipment is not going to be put into
service upon receipt, cover and store the
filter in a clean, dry location. After storage,
ensure that the equipment is dry and that
no condensation has accumulated on the
internal components of the filter before
applying power.
Repair/Exchange Procedure
MTE Corporation requires a Returned
Material Authorization Number before it can
accept any filters that qualify for return or
repair. If problems or questions arise during
installation, setup, or operation of the filter,
please call the Director of Corporate Quality
for assistance at:
Phone: [phone] ext. 148
FAX: [phone]

Matrix Series D Users Manual
5
Part No. INSTR-025 REL. 071207
PART NUMBER CODES
MD X _ _ _ _ X _ _ _
Matrix Series D
TYPE
P Panel mounts
G General Purpose NEMA 2
W Weather NEMA 3R
CURRENT RATING
0006 is 6 Amps
0786 is 786 Amps
VOLTAGE FREQUENCY CODE
C 385 volts – 415 volts 50 Hz
D 480 volts 60 Hz
BLANK for Options shows none selected
ENCLOSURE OPTIONS
0 – None
1 – 3R / White paint
2 – 3R / Stainless / White paint
3 – Standard grey / rodent screen
4 – 3R / white paint / rodent screen
5 – 3R / Stainless / White / rodent screen
CONTACTOR OPTIONS
00 – None
02 – Contactor for capacitor Removal
09 – Adjustable Contactor capacitor removal
12 – Contactor for capacitor Removal / Transformer power
10 – Bypass contactor
11 – Bypass contactor / Transformer power
13 – Bypass contactor / Contactor for capacitor Removal / Transformer power

Matrix Series D Users Manual
6
Part No. INSTR-025 REL. 071207
Specifications:
Service Conditions
Load: 6 pulse variable torque rectifier only
Input voltage: 380-415 VAC +/- 10%, 50 + 0.75 Hz, 3 phase
Input voltage line unbalance: 1% maximum
Maximum source impedance: 6.00%
Minimum source impedance: 1.5%
Service Factor: 1.00
Ambient Temperature (Operating)
Enclosed Filters: -40 to +40 degrees C
Open Panel Filters: -40 to +50 degrees C
Storage Temperature: -40 to +90 degrees C
Altitude: 0 to 3300 Feet above sea level. Refer to figure 4 for altitude de-rating.
Relative Humidity: 0 to 95% non-condensing
Agency Approvals
UL and cUL listed to UL508 Type MX and CSA-C22.2 No 14-95
File E180243 (3 – 1000 HP, 120VAC through 600 VAC
50, 50/60, 60 Hz Three Phase
Note: Short Circuit rating not required under Exception No.1 of UL508A SB4.2.1 effective 4/25/06
Performance
Total Harmonic Current Distortion:
Five Percent Filter: 5% MAX at FULL LOAD
Standby Current:
Without Optional Capacitor Contactor: 70% of the full load capacitor current listed in Table 3
With Optional Capacitor Contactor: Refer to Drive Users Manual

Matrix Series D Users Manual
Specifications - Continued
7
Part No. INSTR-025 REL. 071207
Ratings
Watts loss
Table 1
Maximum
Output Amps
RMS
Efficiency
(Typical)
(%)
Power Dissipation @
Rated Current
(Typical)
(Watts)
6 97.4 132
8 97.6 161
11 97.8 197
14 98.0 232
21 98.3 294
27 98.5 343
34 98.6 399
44 98.7 472
52 98.8 533
66 98.9 621
83 98.9 735
103 99.0 844
128 99.1 959
165 99.2 1143
208 99.2 1355
240 99.2 1493
320 99.3 1829
403 99.4 2098
482 99.4 2371
636 99.4 2929
786 99.5 3402

Matrix Series D Users Manual
Specifications - Continued
8
Part No. INSTR-025 REL. 071207
Regulation table
Table 2
FILTER VOLTAGE REGULATION 380-415
VAC
MAXIMUM OUTPUT VOLTAGE AT
NO LOAD
RMS
PEAK
397
560
MINIMUM OUTPUT VOLTAGE AT
FULL LOAD
RMS
PEAK
364
475
*MAXIMUM PCC VOLTAGE WITH
6% SOURCE IMPEDANCE
RMS
PEAK
388
548
Note: PCC is the point of common coupling with the power distribution system

Matrix Series D Users Manual
Specifications - Continued
9
Part No. INSTR-025 REL. 071207
Capacitor Currents
Table 3
Capacitor Current at Full Load
Filter Current Rating Amps
Rms
Capacitor Current
(Typical)
Amps RMS
6 2.3
8 3.1
11 4.2
14 5.4
21 8.1
27 10.4
34 13.1
44 16.9
52 20.0
66 25.3
83 31.9
103 39.6
128 49.2
165 63.4
208 79.9
240 92.2
320 122.9
403 154.8
482 185.1
636 244.2
786 301.8

Matrix Series D Users Manual
Specifications - Continued
10
Part No. INSTR-025 REL. 071207
Over Temperature Switch Ratings
Table 6
NC Switch opens at 180 Deg. +/- 5 deg C
Current Amps Voltage Contact Load
6 120 AC Resistive Loads
3 120 AC Inductive Loads
3 240 AC Resistive Loads
2.5 240 AC Inductive Loads
8 12 VDC Resistive Loads
4 24 VDC Resistive Loads

Matrix Series D Users Manual
Specifications - Continued
11
Part No. INSTR-025 REL. 071207
Open Style Size and Weights
Table 4
Amps
rating
Catalog Part
Number
Total
Weight
Lbs
HMR Size Inches
HMR
Ref.
Figure
Cap-
Panel
P.N.
Capacitor assemblies
size Inches
Cap Ref.
Figure
6 MDP0006C 22 11.3''H x 6''W x 6.2''D Figure 5 201 5.6''H x 5.6''W x 7.3''D Figure 10
8 MDP0008C 24 11.3''H x 6''W x 6.3''D Figure 5 202 5.6''H x 5.6''W x 8.2''D Figure 10
11 MDP0011C 29 12.4''H x 7.2''W x 5.7''D Figure 5 223 5.6''H x 5.6''W x 7.3''D Figure 10
14 MDP0014C 35 12.4''H x 7.3''W x 6.3''D Figure 5 204 5.6''H x 5.6''W x 7.3''D Figure 10
21 MDP0021C 46 15.8''H x 9''W x 6.5''D Figure 5 224 5.6''H x 5.6''W x 6.3''D Figure 10
27 MDP0027C 61 15.8''H x 9''W x 7''D Figure 5 225 5.6''H x 5.6''W x 7.3''D Figure 10
34 MDP0034C 72 15.8''H x 9''W x 7.5''D Figure 5 208 5.6''H x 5.6''W x 7.3''D Figure 10
44 MDP0044C 84 15.8''H x 9''W x 8''D Figure 5 226 5.6''H x 5.6''W x 7.3''D Figure 10
52 MDP0052C 125 16.5''H x 12.3''W x 9.6''D Figure 6 227 5.6''H x 5.6''W x 8.2''D Figure 10
66 MDP0066C 150 16.5''H x 12.3''W x 10.7''D Figure 6 228 5.6''H x 5.6''W x 8.2''D Figure 10
83 MDP0083C 176 16.5''H x 12.3''W x 11.3''D Figure 6 229 8''H x 7.3''W x 12''D Figure 11
103 MDP0103C 180 16.5''H x 12.3''W x 11''D Figure 6 230 8''H x 8.1''W x 12''D Figure 11
128 MDP0128C 213 23''H x 15.3''W x 11.3''D Figure 7 231 8''H x 9.1''W x 12''D Figure 11
165 MDP0165C 278 23''H x 15.3''W x 11.5''D Figure 7 232 12''H x 8.1''W x 12''D Figure 12
208 MDP0208C 289 23''H x 15.3''W x 12''D Figure 7 233 12''H x 9.1''W x 12''D Figure 12
240 MDP0240C 298 23''H x 15.3''W x 12.4''D Figure 7 234 15''H x 8.1''W x 12''D Figure 12
234 15''H x 8.1''W x 12''D Figure 13
320 MDP0320C 460 35.5''H x 18''W x 20.2''D Figure 8 235 5.6''H x 5.6''W x 9.3''D Figure 10
234 15''H x 8.1''W x 12''D Figure 13
403 MDP0403C 504 35.5''H x 18''W x 22.5''D Figure 8 236 8''H x 9.1''W x 12''D Figure 11
237 15''H x 9.1''W x 12''D Figure 13
482 MDP0482C 598 35.5''H x 18''W x 23''D Figure 8 238 12''H x 9.1''W x 12''D Figure 12
239 15''H x 9.1''W x 12''D Figure 13
240 15''H x 9.1''W x 12''D Figure 13636 MDP0636C 866 35.5''H x 24''W x 23.5''D Figure 9
227 5.6''H x 5.6''W x 8.2''D Figure 10
237 15''H x 9.1''W x 12''D Figure 13
237 15''H x 9.1''W x 12''D Figure 13786 MDP0786C 1087 35.5''H x 24''W x 24''D Figure 9
241 12''H x 9.1''W x 12''D Figure 12

Matrix Series D Users Manual
Specifications - Continued
12
Part No. INSTR-025 REL. 071207
Enclosed Unit Size and Weights
Table 5
Filter Amps NEMA 2 Enclosure Weight NEMA 3R Enclosure Weight Figure
6 MDG0006C CAB-12C2 76 MDW0006C CAB-12C3 86 Figure 14
8 MDG0008C CAB-12C2 79 MDW0008C CAB-12C3 89 Figure 14
11 MDG0011C CAB-12C2 83 MDW0011C CAB-12C3 93 Figure 14
14 MDG0014C CAB-12C2 89 MDW0014C CAB-12C3 99 Figure 14
21 MDG0021C CAB-12C2 100 MDW0021C CAB-12C3 110 Figure 14
27 MDG0027C CAB-12C2 115 MDW0027C CAB-12C3 125 Figure 14
34 MDG0034C CAB-12C2 126 MDW0034C CAB-12C3 136 Figure 14
44 MDG0044C CAB-12C2 138 MDW0044C CAB-12C3 148 Figure 14
52 MDG0052C CAB-17C2 190 MDW0052C CAB-17C3 199 Figure 15
66 MDG0066C CAB-17C2 215 MDW0066C CAB-17C3 224 Figure 15
83 MDG0083C CAB-17C2 241 MDW0083C CAB-17C3 250 Figure 15
103 MDG0103C CAB-17C2 244 MDW0103C CAB-17C3 253 Figure 15
128 MDG0128C CAB-26C2 382 MDW0128C CAB-26C3 403 Figure 16
165 MDG0165C CAB-26C2 446 MDW0165C CAB-26C3 467 Figure 16
208 MDG0208C CAB-26C2 457 MDW0208C CAB-26C3 478 Figure 16
240 MDG0240C CAB-26C2 467 MDW0240C CAB-26C3 488 Figure 16
320 MDG0320C CAB-26D2 659 MDW0320C CAB-26D3 790 Figure 17
403 MDG0403C CAB-26D2 703 MDW0403C CAB-26D3 834 Figure 17
482 MDG0482C CAB-26D2 796 MDW0482C CAB-26D3 928 Figure 17
636 MDG0636C CAB-30D2 1198 MDW0636C CAB-30D3 1240 Figure 18
786 MDG0786C CAB-30D2 1420 MDW0786C CAB-30D3 1462 Figure 18
Note: Weight is shown in pounds
See page 16 for NEMA enclosure type explanations

Matrix Series D Users Manual
Specifications - Continued
13
Part No. INSTR-025 REL. 071207
Performance Data
Figure 1
Load effect on THID
Figure 2
Harmonic Spectrum 100% Load
5% Matrix Filter Typical Harmonic
Spectrum For 100% Load
0
1
2
3
4
5 7 11 13 17 19 23 25
Harmonic order
Harmonic Current %
5% Filter THID vs. Load
0
1
2
3
4
5
6
7
8
9
020 40 60 80 100
Percent Load
Typical
Percent THID

Matrix Series D Users Manual
Specifications - Continued
14
Part No. INSTR-025 REL. 071207
Figure 3
Power Factor
Performance with Unbalanced Line Voltage (Typical)
Table 7
All Components at Nominal Values and Worse Case
Service Conditions
100% Load
Nominal THID 3.93%
1% Unbalance 4.06%
2% Unbalance 4.47%
3% Unbalance 5.10%
30% Load
Nominal THID 7.06%
1% Unbalance 7.45%
2% Unbalance 8.21%
3% Unbalance 10.46%
Filter Power Factor vs Load
Leading PF For All Loads
0.20
0.30
0.40
0.50
0.60
0.70
0.80
0.90
1.00
1.10
020 40 60 80 100 120
Percent Filter Load
Power Factor
Typical Worst Case

Matrix Series D Users Manual
15
Part No. INSTR-025 REL. 071207
Altitude Derating Curve
Figure 4
Altitude Derating Curve
0.70
0.75
0.80
0.85
0.90
0.95
1.00
1.05
0 3300 6600 9900 13200 16500
Altitude (Feet)
Current De-Rating Factor
Temperature Derating Curve
Figure 4A
Series D Matrix Filter Temperature Derating Table
0.9
0.91
0.92
0.93
0.94
0.95
0.96
0.97
0.98
0.99
1
0 2 4 6 8 10 12 14 16 18 20
Temperature Above Rated Ambient Deg. C
Filter Current Derating Factor
Note: Contact factory if Ambient is 20 °C above temperature rating.
See or click Specifications for temperature ratings

Matrix Series D Users Manual
16
Part No. INSTR-025 REL. 071207
INSTALLATION INSTRUCTIONS
Filter Installation
Matrix Filter® are supplied in the following
mechanical configurations:
Panel mounted assemblies
Floor mounted general purpose NEMA 2,
& 3R cabinets,
Select a well ventilated, dust-free area away
from direct sunlight, rain or moisture. Do not
install in or near a corrosive environment.
Avoid locations where the filter would be
subjected to excessive vibrations.
Panel mounted filters are designed for
mounting in the vertical plane within the
customer’s enclosure. Panel mount units are
made up of a Harmonic Mitigating Reactor
(HMR) and one or more capacitor panel
assemblies referred to as cappanels on
drawings and diagrams.
The capacitor assembly should be located in
the lowest temperature regions of the
enclosure - generally toward the bottom and
away from high temperature components.
Mount the Harmonic Mitigating Reactor in a
location where the ambient temperature does
not exceed 50 degrees C. Allow a minimum
side clearance of four (4) inches and a
vertical clearance of six (6) inches for proper
heat dissipation and access.
Figure 5 - 18 contain outline drawings for the
various ratings and show mounting orientation
with bolt patterns.
Include the power dissipation of the filter
along with all the other components located in
the enclosure to determine the internal
temperature rise and cooling requirements of
the enclosure.
General purpose NEMA 2, and 3R enclosed
filters are designed for floor mounting in the
vertical plane in an environment suitable for
the enclosure type. Do not install in or near a
corrosive environment. Avoid locations where
the filter would be subjected to excessive
vibrations. Allow a minimum side and back
clearance of eight (8) inches and front
clearance of thirty-six (36) inches for proper
heat dissipation and access.
Refer to Article 430 Table 430.91 of the
National Electrical code for the selection of
the appropriate enclosure Type Number for
your application.

Matrix Series D Users Manual
Installation Instructions Continued
17
Part No. INSTR-025 REL. 071207
HMR Bolt Hole Mounting Patterns
Table 8
Part
Number Lbs Overall Size Rear Mount
Centerline
Base Mount
Centerline
Mounting
Holes Figure
MDP0006C 14 11.3''H x 6''W x 6.2''D 10.25''A x 5''B 3''C x 2.5''E 0.281 DIA Figure 5
MDP0008C 16 11.3''H x 6''W x 6.3''D 10.25''A x 5''B 3''C x 2.5''E 0.281 DIA Figure 5
MDP0011C 21 12.4''H x 7.2''W x 5.7''D 11.38''A x 5''B 3''C x 2.38''E 0.281 DIA Figure 5
MDP0014C 26 12.4''H x 7.3''W x 6.3''D 11.38''A x 5''B 3''C x 2.88''E 0.281 DIA Figure 5
MDP0021C 42 15.8''H x 9''W x 6.5''D 14.25''A x 6''B 4.26''C x 3.2''E 0.358 DIA Figure 5
MDP0027C 51 15.8''H x 9''W x 7''D 14.25''A x 6''B 4.26''C x 3.75''E 0.358 DIA Figure 5
MDP0034C 61 15.8''H x 9''W x 7.5''D 14.25''A x 6''B 4.26''C x 4.25''E 0.358 DIA Figure 5
MDP0044C 71 15.8''H x 9''W x 8''D 14.25''A x 6''B 4.26''C x 4.75''E 0.358 DIA Figure 5
MDP0052C 80 16.5''H x 12.3''W x 9.6''D 12.24''A x 11''B 6.5''C x 11''E 0.413 DIA Figure 6
MDP0066C 90
16.5''H x 12.3''W x 10.7''D 12.14''A x 11''B 6.5''C x 11''E 0.413 DIA Figure 6
MDP0083C 101
16.5''H x 12.3''W x 11.3''D 12.15''A x 11''B 6.5''C x 11''E 0.413 DIA Figure 6
MDP0103C 125 16.5''H x 12.3''W x 11''D 12.21''A x 11''B 6.5''C x 11''E 0.413 DIA Figure 6
MDP0128C 150 23''H x 15.3''W x 11.3''D 17.83''A x 14''B 8''C x 14''E 0.413 DIA Figure 7
MDP0165C 200 23''H x 15.3''W x 11.5''D 17.86''A x 14''B 8''C x 14''E 0.413 DIA Figure 7
MDP0208C 250 23''H x 15.3''W x 12''D 17.91''A x 14''B 8''C x 14''E 0.413 DIA Figure 7
MDP0240C 275 23''H x 15.3''W x 12.4''D 17.95''A x 14''B 8''C x 14''E 0.413 DIA Figure 7
MDP0320C 375 35.5''H x 18''W x 20.2''D 31''A x 16.5''B 17.5''C x 16.5''E 0.413 DIA Figure 8
MDP0403C 480 35.5''H x 18''W x 22.5''D 31''A x 16.5''B 17.5''C x 16.5''E 0.413 DIA Figure 8
MDP0482C 560 35.5''H x 18''W x 23''D 31''A x 16.5''B 17.5''C x 16.5''E 0.413 DIA Figure 8
MDP0636C 725 35.5''H x 24''W x 23.5''D 31''A x 22.5''B 17.5''C x 22.5''E 0.413 DIA Figure 9
MDP0786C 900 35.5''H x 24''W x 24''D 31''A x 22.5''B 17.5''C x 22.5''E 0.413 DIA Figure 9
Use the above table and referenced figures to establish suitable reactor mounting.

Matrix Series D Users Manual
Installation Instructions Continued
18
Part No. INSTR-025 REL. 071207
Cap-panel Bolt Hole Mounting Patterns
Table 9
Part Number CAP
P.N.
Cap-panel
Weight
Lbs
Overall Size Rear Mount
Centerline
Mounting
Holes Figure
MDP0006C 201 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0008C 202 3.75 5.6''H x 5.6''W x 8.2''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0011C 223 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0014C 204 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0021C 224 3.75 5.6''H x 5.6''W x 6.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0027C 225 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0034C 208 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0044C 226 3.75 5.6''H x 5.6''W x 7.3''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0052C 227 3.75 5.6''H x 5.6''W x 8.2''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0066C 228 3.75 5.6''H x 5.6''W x 8.2''D 5.06''A x 5.06''B 0.218 Figure 10
MDP0083C 229 7.5 8''H x 7.3''W x 12''D 7.25''A x 4.5''B 0.218 Figure 11
MDP0103C 230 7.5 8''H x 8.1''W x 12''D 7.25''A x 4.5''B 0.218 Figure 11
MDP0128C 231 7.5 8''H x 9.1''W x 12''D 7.25''A x 4.5''B 0.218 Figure 11
MDP0165C 232 11.25 12''H x 8.1''W x 12''D 11.25''A x 4.5''B 0.218 Figure 12
MDP0208C 233 11.25 12''H x 9.1''W x 12''D 11.25''A x 4.5''B 0.218 Figure 12
MDP0240C 234 15 15''H x 8.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 12
234 15 15''H x 8.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
MDP0320C 235 3.75 5.6''H x 5.6''W x 9.3''D 5.06''A x 5.06''B 0.218 Figure 10
234 15 15''H x 8.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
MDP0403C 236 7.5 8''H x 9.1''W x 12''D 7.25''A x 4.5''B 0.218 Figure 11
237 15 15''H x 9.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
MDP0482C 238 11.25 12''H x 9.1''W x 12''D 11.25''A x 4.5''B 0.218 Figure 12
239 15 15''H x 9.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
240 15 15''H x 9.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
MDP0636C
227 3.75 5.6''H x 5.6''W x 8.2''D 5.06''A x 5.06''B 0.218 Figure 10
237 15 15''H x 9.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
237 15 15''H x 9.1''W x 12''D 14.25''A x 4.5''B 0.218 Figure 13
MDP0786C
241 11.25 12''H x 9.1''W x 12''D 11.25''A x 4.5''B 0.218 Figure 12
Note: Units above 240 amps require multiple parallel cap panels
Use the above table and referenced figures to establish suitable Cap-panel mounting

Matrix Series D Users Manual
Installation Instructions Continued
19
Part No. INSTR-025 REL. 071207
HMR MOUNTING & TERMINAL LOCATIONS
HMR 6 - 44 Amps
Figure 5 6 - 44 AMP
