MTS Systems HIEMTPRO EMT8-2S PRO User manual

VER:1.0
B31-01-073-011
EMT8-2S PRO
USER MANUAL

~1~~1~
THIS INSTRUMENT IS FOR FITNESS ONLY
Dear user:
Thanks for using our company's products, in order to fully make use of the products,
we sincerely suggests follow:
Please read the instruction in detail and keep it well for further reading and
consulting.
It forbids others to change and maintain the machine except the professional
people.
Please do not remove and change any accessories of the machine.
Please follow the instruction to fit and operate the machine correctly.
It forbids others to open and remove the mainframe except the authorized people in
the company.
Please contact us if there is any trouble during operation.
Warning
◆◆
◆◆
◆◆
◆◆
◆◆
◆◆

~2~
Parts Introduction
Accessories
Any part of instrument made of PMMA material (for example: accessories shelf,
panel, transparent handles,etc.). Do not use alcohol or corrosive solvent to wipe clean.
work handle
Accessories frame
1
3
2
6
9
4
8
7
5
6.USB jack
9.Dust filter uet
1.Touchscreen
4.Distilled water outlet
8.Power supply line jack
5.Accessories frame
2.Distilled water inut
7.General power switch
3.Overflow

~3~
1.The distilled water should be cleared
before transportation.
2.Method:Insert the plug of silicone
tube with seal ring into socket [4] distilled water outlet.
Discharge the distilled water and shake the apparatus to
help the liquid clean out completely. And then use thumb
to press the spring, pull out the silicone tube.
Notice:While discharging the distilled water, the work
hand-rod should be placed at the handle support.
Before Transportation
2.Make sure the distilled water discharge valve[4] is closed;
3.Use special funnel to connect to distilled water inlet[2].
Insert drain pipe into overflow[3];
4.Add distilled water or deionized water from the funnel;
1.Use distilled water or deionized water;
5.Add liquid until overflow outlet;
6.Add cooling fluid successfully first time;
7.Connect power supply line[8], turn on general power
switch[7]. the recharge interface enters the interface as
(Fig 1) shows, click on “ ” to enter interface 。 Click
on “Liquid setting” to enter interface as (Fig 2) shows,
click on “ ” to become counter down 30 seconds.
8.When stopped, please observe the status of distilled
water level. add liquid until overflow outlet .then take off
the funnel. Please click the “ ”button to add liquid
again until it is full and remove the funnel.
2.When could not add into the distilled water, please
open the distilled water discharge valve[6], Add the
distilled water and observe the valve. when the liquid
is smooth outflow, blocked it and continue to fill
30seconds.
NOTE:1.Add about 1.5L distilled water or deionized,
change the water after one week.
3.If do not use the apparatus 15 days or above, we are
recommended to put the distilled water clean and clear.
Steps of Add Distilled Water

(Fig 1)
(Fig 2)

Spring

1.Clean treatment parts.
6.Puteen a bandage for user. and put in the handpiece
in. The output intensity should be regulated from low
gradually to high energy according to endurance of
customers. During operating.The beautician should
communicate with customers in time and the
customers should tell how they feel .
9.Click on “ ” to return to (Fig 1).
4.Set intensity. According to the bearing capacity of
the guests Click on “+” and “-” of “Intensity” to
adjust. The range is 1%(weak) to 100%(strong).
7.The system will pause automatically if the setting
time is over.
8.Please turn off the general power switch and unplug the
power supply line. other parts of the handle shall not be cleaned with
alcohol or other organic solvents to avoid damage to the.
2.In (Fig 1), click “AUTO” to enter (Fig 3)Select item
accord i n g to th e diff e r ent gen d e r. age an d
area(Select high medium and low according to
different parts )energy of the guests than press
“ ”to. Enter the operation interface of(Fig 4).
3.Set work time. The system default work time is 30
minutes. Click on “+” and “-” of “Time setting” to
regulate. The range is 1 to 30 minutes. Each part
about 15 to 20 minutes.
5.Click on “ ”, the system start work. If you need to
pause, Click on “ ”.
(Fig 3)
(Fig 4)
~4~
Basal Operation
2.In the interface as (Fig 1):
(2)Click on “ ” to enter operating interface.
(1)Click on “ ” to select language,。 Attention: The
“Advanced setting” is only for manufacturer,
Users do not use.
1.Insert the plug of Power supply line into [8] socket,
turn on Power switch [7]. the recharge interface
enters the interface as (Fig 1) shows.


~5~
8..Puteen a bandage for user. and put in the handpiece in. The output intensity should be
regulated from low gradually to high energy according to endurance of customers.
During operating.The beautician should communicate with customers in time and the
customers should tell how they feel .
1.Clean treatment parts.
5.Set frequency F1-F3.Click on “+” and “-” to ajgust
output Freguency System output strength starts to
work. font turns green.font does not change. system
output strength stops working. The range is:
2.In (Fig 1), click “MANUAL” to enter the interface
(Fig 5).according to the different gender. It is
suitable for fat rich parts.
The range is 1HZ(slow) to 38HZ(Fast).
The range is 1HZ(slow) to 5HZ(Fast).
3.Set work time. The system default work time is 30
minutes. Click on “+” and “-” of “Time setting” to
regulate. The range is 1 to 30 minutes. Each part
about 15 to 20 minutes.
The range is 1HZ(slow) to 50HZ(Fast).
4.Set intensity. The system default high frequency
wave intensity is 60%.Click on “+” and “-” of
“Intensity” to adjust. The range is 1%(weak) to
100%(strong).
6.Set the storage mode. Select different modes and intensity according to the bearing
capacity of the guests and Click on “ ”store. convenient Next use and query.
7.Click on “ ”, “ ”.the system the system start work. If you need to pause, Click on
startwerk.
10.Please turn off the general power switch and unplug the power supply line. other parts of the
handle shall not be cleaned with alcohol or other organic solvents to avoid damage to the.
11.Click on “ ” to return to (Fig 1).
9.The system will pause automatically if the setting time is over.

(Fig 5)

~6~
QC
Input Voltage: AC220~230V 50/60Hz □ AC110V 50/60Hz □
Output Power: 1500VA
Fuse: RT28-32(RO15)20A 500V(110V) (with spare fuse)
Fuse: FL5*20 T15AL250V(220V) (with spare fuse)
TechnicalParameters
Packing List
4.User manual
3.Power supply line
7.Binding(1.5M)
8.Hexagnal screw wrench
2.Two pieces of liquid addition accessory
1.Host
5.Accessory frame
6.Binding(0.75M)
1SET
1PCS
2PCS
1PCS
1SET
1PCS
1COPY
2PCS
Forbidden Group
3.People with hemorrhagic disease, trauma or who is bleeding.
4.Pregnant women and child.
8.People with an abnormal immune system.
1.People with heart disease or high blood pressure, or configured cardiac pacemaker.
7.Patient with skin inflammation or with edema.
2.Patients with acute inflammation, asthma, deep vein thrombosis, thyroncus, cancer.
6.People with metal inside the body.
5.Medical Plastic parts, or parts with artificial in filling inside.
9.Numb or insensitive to heat.

~7~
(5)The immune system has defects, scar formation history, physical disease;
(4)Patients with feeling numb, no response to cold and heat;
(6)The people who has taken face-lifting or her body has artificial thing.
(9)Patients with severe infection
(2)Children;
(3)Hemorrhagic disease or trauma, inflammation, skin disease, skin infection;
2.The following please use under the guidance of professionals
1.The following symptoms were forbidden to use
(2)The use of artificial bone; Patients with silicosis;
(5)Patients with no independent expression consciousness and can not take
care of themselves.
(3)Drunk or high fever patients;
(4)Patients with higher sensitivity mental disease and epilepsy patients
(7)Severe hypertension and severe patients with cardiovascular and
cerebrovascular disease.
(8)Patients with renal failure.
(1)Women during menstruation;
(1)Patients who used by Heart rate regulator, cardiac pacemaker, ECS;
(6)Patients with metal materials in body (including metal teeth), pregnant
women, cachexia, malignant tumor.
Symbols and Meanings
*Things damage refers to housing, property, livestock and pet damage.
Warning Symbol
Danger
Danger
Waning
Waning
Attention
Device exists high pressure risk of high voltage output terminals!
If used incorrectly will cause personnel injury!
If used incorrectly will cause personnel injury or damage to the goods!
If used incorrectly will cause possibility ill of death or serious injury!
If used incorrectly will bring the risk of death or serious injury!
Meaning
Contraindications
Danger
Warning

~8~
The Company is not responsible for the following circumstances:
(3)Damage caused by using other method(not included in the use manual).
5.After using the machine for over 40 hours, please take off the dust filter and clean it (If have).
3.If there comes a failure, please shut down the power immediately, and send it to the distributor
or manufacturer for maintenance. Do not repair by yourself.
1.Appliances and medical equipment close to the machine may be resulting in operational failure
due to interference.
――Hot and humid environment ――Dusty environment
――Environmental with much smoke or stream
4.Exclusion of liability.
(2)The fault of the user, operator error;
2.Prohibit use of the equipment in the following environment
(1)If fire, earthquake, war occurred;
(4)Operate without the manual's guide.
6.Do not make the machine close to the wall, keeping a 30CM space around for cooling.
Held onto the filter
with hands,pull it out
according to cursor.
after cleaning, push
it back.
Maintenance
Safety and Environmental Considerations
Plastic Board
Printed Circuit
Board
Declaration:
The content of the restricted substances in all homogeneous materials of this part is below the limits set
by the SJ/T11363-2006 standard.
The content of a homogeneous material in the part of the material is beyond the SJ/T11363-2006 standard
requirements. The user's normal use of this product within the time limit of environmental protection, these
substances or elements will not occur leakage or sudden change, will not cause the personal, property damage.
For such substances or elements, the user shall not dispose of it yourself, please according to government
regulations to the relevant departments of the government designated recycling.
Power Supply
Accessory
Toxic and hazardous substances reference list
Electronic information product pollution control and management measures
Table of contents of toxic and hazardous substances or elements
Part Name Remark
Toxic and Hazardous Substance or Element
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
chromium
(Cr(VI))
Polybrominated
biphenyls
(PBB)
Polybrominated
diphenyl ethers
(PBDE)
