Multi Nautic 21191 User manual

Suggestion:
Although this plaorm was designed to serve as an
access level, you can also install it above the dock to
serve as a bench or table!
The set includes:
> 2x aluminum bracket suppos with pile clamps
for posts with an outside diameter of 1 11/16"
maximum
(note: all Multinautic posts have an o.d. of 1 11/16")
> The cedar planks, pre-drilled, cut, sanded. And
required screws according to the chosen size (see
cha)
> 4x 1/2" stain. steel set screws for the pile clamps
-2x 4 1/2" carriage bolts.
LOWER DECK PLATFORM
product #21191
Tools Needed :
- Allen Key 1/4"
- Cordless drill with #3 square bit
- Ratchet and 9/16" key
This pamphlet is intended to guide you through the
installation of the 4-foot or 8-foot Low Deck.
The product has been designed to be added to the
QP-400TM and QP-427TM Aluminum Posts Dock
Models, at the end of a section or, for the 8 model,
at the end of two sections installed side by side.
If you want to install it on another dock, note that
the posts must have a maximum diameter of 1
-11/16 "(42.86 mm). Also be sure to adjust the length
of the boards according to the dimensions of your
dock.
If you wish to install it on the side of a dock (8' step),
at least two docks must be installed side by side in
order to stabilize everything and avoid ipping over.
As the step is cantilevered, an excess load on the
end of the step could cause the dock to tip over and
cause serious injury.
Multi
NAUTIC®
product #21190
Aluminum
Brackets
product
# 21190
product
# 21191
4 . 8 .
2" x 6" x 44 5/8" 4
2" x 6" x 94 3/4" 4
2" x 6" x 18" 2 2
2" x 4" x 16,5" 1 3
Wood screws 27 44
Carriage bolts 2 2
3/8" x 4 1/2"
©
Multinautic 2021 Printed in Canada

Should you encounter any difficulties with this product, do not return it to the store.
Please contact our customer service at 1-800-585-1237
product # 21191 : 8 .
Assembly :
> Step 1
Lay the 3 similar boards with their holes for the screws
underneath. Screw the 4th one on the rst one as shown.
> Step 2
Connect these 4 boards on the sides with the 18 "pieces
and 8 screws on each side.
> Step 3
Turn the assembly upside down and add the 2" x 4" x 16.5"
pieces (1 for the 4 deck and 3 for the 8 deck).
base plate
bolt
Installation:
> Ideally, the aluminum suppos of this plaorm should
be added to the posts before the installation of the dock
(slightly tight for a later adjustment), with the long square
tubes toward the inside of the dock.
> For adding to an existing dock, you must clear the post
from the leg holder to li and remove the boom plate to
slide the suppos downwards from the posts (with the
long square tubes toward the inside of the dock), slightly
tight for later adjustments. Leveled the dock.
> Evaluate the ideal height for the low deck; adjust the
level of the 2 suppos as needed then tighten until the set
screws are fully seated on the posts. Do not over tighten.
> Add the long bolts on the sides of the plaorm.
product # 21190 : 4 .
