Multi Trolley STANDARD 6.0 Quick setup guide

Smart • Simple • Safe
Patent protected
MULTI TROLLEY
STANDARD 6.0
Assembly and Use

Assembly
Contents
For quick and easy assembly, follow these instructions:
•1x Frame with 4x locknut
•4x Wheel
•2x Fixed support poles 16.5"
•2x Adjustable support posts 30"
•2x Mounting brackets for adjustable
support posts with handle
Ensure these are properly
mounted and tightened.
Turn handle to adjust post.
Press button to adjust handle
positioning only.
Tighten locknut with a 19
mm wrench.
Attach mounting plates
either side of frame.
Keep assembly and user manual for future reference.

A B
C D
90°
E
SMART • SIMPLE • SAFE
Use
Before use check mountings of wheels, fixed support poles and adjustable support posts.
For secure use observe the following points below:
Technical Specifications
Height: 31 inches
Width: 17 inches
Adjustable posts: 30 inches
Fixed posts: 17 inches
Weight: 26 lbs
Max. Load 250 kg / 550 lbs
In narrow spaces be careful of trapping fingers.
Keep assembly and user manual for future reference.
MULTI TROLLEY
STANDARD 6.0
SMART • SIMPLE • SAFE
Ensure the wheels are pointing downwards.
Lock the wheels before tipping of object.
Tall objects increase
the risk of tipping.
Lean against
adjustable posts.
550
lbs.

MARS 2018
MULTI TROLLEY
STANDARD 6.0
Fixed pole
16.5 inches
Adjustable post
22 inches
Adjustable post
30 inches
Adjustable post
38 inches
Desk ✓ ✓
Table ✓ ✓
Conference table, large ✓ ✓
Conference table, small ✓ ✓
Bed ✓ ✓
Bed, King Size ✓ ✓
Sofa ✓ ✓
Whiteboard, large ✓ ✓
Whiteboard, small ✓ ✓
Door ✓*✓
Panel ✓*✓
Folding table ✓*✓
Cabinet, bookshelf, etc.
* Replaces Fixed poles 16.5 in.
Applications
Recommended post length
Multi Trolley brand & products are patent-protected
No posts or poles required
