Multi Trolley Worker 6.0 Quick setup guide

Smart • Simple • Safe
MULTI TROLLEY
WORKER 6.0
Assembly and Use
Patent protected

Assembly
Contents
For quick and easy assembly, follow these instructions:
•1x Frame with 4x locknut
•4x Wheel
•2x Fixed support poles 16.5"
•2x Adjustable support posts 22"
•2x Adjustable support posts 30"
•4x Mounting brackets for adjustable
support posts
•4x Adjustable handle
Ensure these are properly
mounted and tightened.
Turn handle to adjust post.
Press button to adjust handle
positioning only.
Ensure locknut is screwed
securely before use
19mm wrench.
Attach mounting plates
either side of frame.
Keep assembly and user manual for future reference.

90°
A B
C D
E
SMART • SIMPLE • SAFE
Use
Before use check mountings of wheels, fixed support poles and adjustable support posts.
For secure use observe the following points below:
Technical Specifications
Height: 31"
Width: 20.5"
Adj ustable posts: 30" and 22"
Fixed posts: 16.5"
Weight: 35 lbs
Max. Load 250 kg / 550 lbs Higher objects increase risk of tipping,
ensure object is leaning against adjustable
support posts.
Ensure the wheels are pointing downwards.
Lock the wheels before tipping of object.
In narrow spaces be careful of trapping fingers.
Ensure brakes are locked
before mounting on the object.
Keep assembly and user manual for future reference.
MULTI TROLLEY
WORKER 6.0
550
lbs.

MAJ 2018
MULTI TROLLEY
WORKER 6.0
Fixed pole
16.5 inches
Adjustable post
22 inches
Adjustable post
30 inches
Adjustable post
38 inches
Desk ✓ ✓
Table ✓ ✓
Conference table, large ✓ ✓
Conference table, small ✓ ✓
Bed ✓ ✓
Bed, King Size ✓ ✓
Sofa ✓ ✓
Whiteboard, large ✓ ✓
Whiteboard, small ✓ ✓
Door ✓*✓
Panel ✓*✓
Folding table ✓*✓
Cabinet, bookshelf, etc.
* Replaces Fixed poles 16.5 in.
Applications
Recommended post length
Multi Trolley brand & products are patent-protected
No posts or poles required
