Multi Trolley Standart Quick setup guide

Do it smart and simple
ENG
MULTI TROLLEY
STANDARD
Assembly and Use
For Retailers

1 2
4
3
Assembly
Contents
For quick and easy assembly, follow these instructions:
The following parts are included in your Multi Trolley package:
•1x Frame
•4x Wheel
•2x Fixed support
poles (42cm)
•2x Adjustable support
posts (78cm)
•2x Mounting brackets for
adjustable support posts
•1x Plastic bag containing:
4x Hex socket (Allen)
head screws, 4x O-rings,
4x spring washers
•1x Hex (Allen) key
Adjustable support post mountings:
slide O-rings onto the Hex socket head
screws between mounting brackets.
Adjustable support posts: attach
mounting brackets to the posts
using the supplied Hex (Allen) key.
Spring Washers:
place onto the screws
before attaching wheels
to the frame
Fixed support poles:
ensure that these are
tightened.
Keep assembly and user manual for future reference

A B
C D
90°
E
Use
Check mountings of wheels, fixed support poles and adjustable support
posts before use.
Technical Specifications
Height: 780 mm
Width: 420 mm
Adjustable posts: 780 mm
Fixed posts: 420 mm
Weight: 10 kg
Max. Load 250 kg. Risk of tipping.
Align wheels at 90 degrees to the frame and
lock wheels before use.
Increased risk of injury in narrow spaces
A.Apply brakes to lock the wheels before
tilting.
Keep assembly and user manual for future reference
MULTI TROLLEY
STANDARD

Nastagatan 2, 702 27 Örebro, Sweden
[e-mail] | multitrolley.se
Tel. [phone]
MAJ 2013
www.facebook.com/multitrolley
https://twitter.com/multitrolley
http://instagram.com/multitrolley
MULTI TROLLEY
STANDARD
Fixed pole
42 cm
Adjustable post
58 cm
Adjustable post
78 cm
Adjustable post
98 cm
Desk ✓ ✓
Table ✓ ✓
Conference table, large ✓ ✓
Conference table, small ✓ ✓
Bed ✓ ✓
Bed, King Size ✓ ✓
Sofa ✓ ✓
Whiteboard, large ✓ ✓
Whiteboard, small ✓ ✓
Door ✓*✓
Panel ✓*✓
Folding table ✓*✓
Cabinet, bookshelf, etc.
* Replaces Fixed poles 42cm
Applications
Recommended post length
Multi Trolley brand & products are patent-protected
No posts or poles required
