Multilin 139 series User manual
•
•
INSTRUCTION MANUAL
139 SERIES
MOTOR PROTECTION RELAY
U.S. PATENTS 4,224,651
4,241,336
CANADIAN
PATENT 1,130,383
UK
PATENT 2,008,345 B
liil
MUlJ"ILIN
DIVISION
OF
DERLAN MANUFACTURING INC.
215 ANDERSON AVENUE
MARKHAM, ONTARIO,
CANADA L3P
4C7
(905) 294-6222
FAX 294-8512
Courtesy of NationalSwitchgear.com
•
•
TABLE
OF
CONTENTS
1.
INTRODUCTION
1.1
Multilm Relay Features.
1.2 Typical Applications
1.3 Relay Selection.
1.4 Technical Specifications
2.
INSTALLATION
Page
1
1
2
4
2.1
Physical Dimensions. . 5
2.2 Option Selection. 6
2.3 Mounting. 8
2.4 External Connections. . 9
2.5 Power Supply. . . . . . . . . 9
2.6 Phase
CTs.
. .
...............................
12
2.7 Ground Fault
CT.
.
......
13
2.8 Main Relay Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.9 Auxiliary Relay Contacts.. . . .
..................
13
2.1o External Reset. . . . . . . . . . . . .
..
13
2
.11
Emergency Restart. . . . . . . . . . . . . . . . . . . . . . .
14
2.12 Temperature Sensing Option. . . . . . . . . . . . .
......
14
2.13 Connecting The Thermal Capacity Meter.
......................
14
2.14 Connecting The Current Output Option. .
................
14
3. SETUP
AND
USE
3.1
Controls and Indicators. . .
......
16
3.2 Maximum Load Control. . . . . . . . . . . . . . . . . . . . . . . . .
..
17
3.3 Unbalance Control. . .
...........................
18
3.4 Start Timer. . . 19
3.5 Undercurrent Control. . . . . . . . . . . . .
..
20
UM-~
.
20
3.
7 Emergency Restart. . .
......
21
3.8 Run Curve Selection. . . . . . . . . . . . . . . . . . . . . . . . . .
21
3.9 Mechanical
Jam-Rapid
Trip....
. . . . . . . . .
..
22
3.10 Option Programming. .
...
23
3.11 Ground Fault . . . . . . . . . . . . .
.................
25
3.12 Overtemperature Option. . . . . . . . .
..
26
3.13 Thermal Capacity. . . . . . . . . . . . . . . .
...
28
3.14
4-20mA
Full Load Output. . . . . . . . . . . . . 28
3.15 Fault Diagnosis.. . . . . . . . . . . . . . . . . . . . .
.......
28
3.16 Control Power.. . .
...................
28
4.
RELAY TESTING
4.1
Secondary Injection Test Equipment. .
4.2 Commissioning Relay Tests.
4.3 Overloads.
4.4 Start Timer
....
4.5 Unbalance.
4.6 Undercurrent.
4.
7 Ground Fault
.............
.
4.8 Overtemperature Option.
4.9 Routine Maintenance Verification.
4.1
o Problem Troubleshooting.
5.
THEORY OF OPERATION
.
....................
30
. . 30
..
. .
.....
30
.
........
32
..
.................
32
....................
32
..
....
32
..
.......
33
.
..
33
.
................
34
...................
36
5.1
Block Diagram
..
5.2 Circuit Diagram.
5.3 Component Locator
...
.
......
BACK PAGE FOLD OUT
BACK PAGE FOLD OUT
Courtesy of NationalSwitchgear.com
Figure
2-1
2-2
2-3
2-4
2-5a
2-5b
2-6
3-1
3-2
3-3
3-4
3-5
4-1
5-1
5-2
5-3
LIST
OF
FIGURES
Tiiie
Page
Relay Dimensions. . . . . . . . . . . . . . . . . . 5
CT
Dimensions. . . . . . . . . . . . . . . . . . . 6
Relay Layout. .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Relay Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Relay Wiring Diagram -AC Control Power
.....................
10
Relay Wiring Diagram
-DC
Control Power
.....................
11
Connecting Phase
CTs.
.. . . . .
................
12
Front Panel Layout. .. . . . . . . . . . .
.....
15
Time/Overload Run
Curves....
. . . . . . . . . .
..
17
RTD
Hot
Motor Compensation. . . .
................
24
Setting
RTD
Trip/Alarm Temperatures. . . . . . . . . .
.......
27
Multilin Fault Finder. . .
...........
29
Secondary Injection
Test
Set Schematic
.......................
30
Relay Block Diagram. . .
.................
37
Relay Schematic. .. . . . . . . . . . . .
.....
BACK PAGE FOLD OUT
Relay Component Locator
................
BACK PAGE FOLD OUT
LIST
OF
TABLES
Table
Trtle
Page
1-1 Multilin Relay Protection
Features.........
. . . . . . . . 1
1-2 Relay Order Code. ... . . . . . . . . . . . . . . . . . . . . 3
1-4
Technical Specifications. . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2-1 External Relay Connections. . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3-1 Controls and Indicators
....................................
16
3-2
Memory Lockout Conditions. . . . .
....................
20
3-3
Overload Level Switch Settings
..............................
22
3-4
Option Switch Settings. .. .. . .
........................
23
3-5
Ground Fault Switch Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . .
26
4-1
RTD
Resistance vs Temperature. . .
.......................
33
4-2 Problem Troubleshooting Guide. . . . . . . . . . . . . . . . .
.....
35
Courtesy of NationalSwitchgear.com
•
1.
INTRODUCTION
1.1
MULTILIN RELAY FEATURES
The Multilin relay is designed to fully protectthree phase
AC
motorsagainstcon-
ditions which can cause damage.
In
addition to motor protection, the relay has
features thatcan protectassociated mechanical equipment, givean alarm before
damage results from a process malfunction, diagnose problems after a fault and
allow verification of correct relay operation during routine maintenance.
One relay is required per motor. Since phase current is monitored through cur-
rent transformers, motors of any line voltage can be protected. The relay is used
as
a pilot device to cause a contactor or breaker to open under fault conditions;
that
is,
it does
not
carry the primary
motor
current.
TABLE
1-1
MULTILIN RELAY PROTECTION FEATURES
PROTECTION FEATURES
Overload (Selectable Curves) Trip/Alarm Outputs
Locked Rotor Status Indication
Stall-Mechanical
Jam Fault Diagnosis I
Repeated Starts Memory Lockout
Single Phase/Unbalance Simple
Adjustment-No
Tools
Ground Fault Easy to Retrofit
Over
Temperature Field Testable
Undercurrent CSA Approval
1.2 TYPICAL APPLICATIONS.
Versatile features and controls allow the relay to protect associated mechanical
equipment
as
well
as
the motor. In addition to the basic electrical protection for
motors listed in table 1-1, the relay can protect against common faults due to
process problems such as:
1)
Personal safety and mechanical
protection
of
pumps using the undercur·
rent feature
to
detect
loss
of
suction
or
a closed discharge valve.
2)
Personnel
safety
and mechanical
protection
of
tans against loss of air flow
in
mines or flow in steam generating boilers using the undercurrent feature.
3)
Electrical protection ofcompressormotorsfrom excessive run-uptimecaused
by
an
open outlet using the start timer.
4)
Mechanical protection
of
gears, pumps, fans, saw mill cutters and com-
pressors against mechanical jam using the rapid trip feature.
