MultiOne 1 Series User manual

INSTRUCTION
MANUAL
1 SERIES
SELF-MOVING COMPACT WHEEL
LOADER, EQUIPPED WITH
MULTIPURPOSE QUICK COUPLER
MultiOne s.r.l -Translation of the original instructions - COD. CM170001EN- r.03 - EN

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
1/49
MultiOne SRL
INDEX
8.1.1 Adjustment of the driving seat ......................................... 26
8.2 Checks before ignition......................................................... 27
8.3 Normal operations............................................................... 27
8.3.1 Getting on the machine ................................................... 27
8.3.2 Starting up ....................................................................... 28
8.3.3 Handling .......................................................................... 29
8.3.4 Assembly of the attachment ............................................ 29
8.3.5 Disassembly of the attachment ....................................... 31
8.3.6 Use of the attachment ..................................................... 31
8.3.7 Turning off the machine................................................... 32
8.3.8 Parking brake .................................................................. 32
8.3.9 Refuelling......................................................................... 33
8.4 Functions/exceptional situations ......................................... 33
8.4.1 Instability of the machine................................................. 33
8.4.2 Overpressure in the hydraulic circuit ............................... 33
8.4.3 Loss of control ................................................................. 34
8.4.4 Block machine with the lifting boom raised...................... 34
8.4.5 Towing the machine on.................................................... 34
8.4.6 Jump start........................................................................ 35
9 MAINTENANCE.............................................................. 36
9.1 General warnings ............................................................... 36
9.2 Safety status of the machine............................................... 36
9.3 Installation safety block of the lifting boom.......................... 36
9.4 Opening engine cover ......................................................... 36
9.5 Ordinary maintenance......................................................... 37
9.6 Scheduled maintenance...................................................... 37
9.7 Interventions on the machine .............................................. 38
9.7.1 Cleaning of the machine.................................................. 38
9.7.2 Check tyres pressure....................................................... 38
9.7.3 Check structural integrity and tightening bolts................. 38
9.7.4 Battery check................................................................... 38
9.7.5 Hydraulic oil level............................................................. 39
9.7.6 Hydraulic oil filter change ................................................ 40
9.7.7 Hydraulic oil change ........................................................ 41
9.7.8 Greasing points ............................................................... 42
9.8 Engine maintenance............................................................ 44
9.8.1 Check engine oil level...................................................... 44
9.8.2 Air filter check.................................................................. 45
9.9 Troubleshooting................................................................... 46
10 SPARE PARTS ............................................................... 46
10.1 Filter code............................................................................ 46
11 ANNEX............................................................................ 47
11.1 Tyres pressure..................................................................... 47
11.2 Warranty terms.................................................................... 48
11.2.1 General rules ................................................................... 48
11.2.2 Scheduled maintenance .................................................. 48
11.2.3 Exclusion of warranty ...................................................... 48
11.2.4 Warranty expiration.......................................................... 48
11.2.1 Notes ............................................................................... 48
1 DOCUMENT IDENTIFICATION ........................................ 2
1.1 Designation ........................................................................... 2
1.2 Identification .......................................................................... 2
1.3 Glossary ................................................................................ 3
1.4 Abbreviations......................................................................... 3
1.5 Consultation notes................................................................. 4
1.6 Receivers of the document.................................................... 5
1.6.1 Authorized operators ......................................................... 5
1.7 Warranty................................................................................ 5
2 MACHINE IDENTIFICATION ............................................ 6
2.1 Copy of CE accordance statement........................................ 6
2.2 Designation ........................................................................... 7
3 IMPORTANT INFORMATION ABOUT SAFETY .............. 7
3.1 General instructions .............................................................. 7
3.2 Residual risks........................................................................ 7
3.3 Transport and lifting............................................................... 8
3.4 Manutenzione........................................................................ 9
4 DESCRIPTION OF THE MACHINE................................ 10
4.1 Main parts and their functions ............................................. 10
4.2 Seats taken by authorised operators .................................. 12
4.3 Control devices.................................................................... 13
4.3.1 Control panel ................................................................... 13
4.4 Safety and protection devices ............................................. 15
4.5 Intended use........................................................................ 15
4.6 Use limits and technical data............................................... 16
4.6.1 Machine........................................................................... 16
4.6.2 Engine ............................................................................. 16
4.7 Load diagram ...................................................................... 17
4.8 Hydraulic flow/engine speed diagram ................................. 18
4.9 Reasonable foreseeable misuse......................................... 18
4.10 Safety signs......................................................................... 19
4.11 Emissions............................................................................ 23
4.11.1 Sound level...................................................................... 23
4.11.2 Vibrations......................................................................... 23
4.12 Personal protective equipment............................................ 23
5 TRANSPORT AND HANDLING ..................................... 24
5.1 Transport ............................................................................. 24
5.2 Lifting ................................................................................. 24
5.3 Handling .............................................................................. 24
5.4 Storage................................................................................ 24
6 ASSEMBLY AND INSTALLATION ................................. 25
6.1 Assembly............................................................................. 25
6.2 Options................................................................................ 25
6.3 Attachments ........................................................................ 25
6.3.1 Available attachments...................................................... 25
6.3.2 Assembly of the attachments .......................................... 25
7 PRE-START INSPECTION ............................................. 26
8 OPERATION ................................................................... 26
8.1 Adjustments......................................................................... 26
INDEX

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
2/49
WARNING
BEFORE OPERATING THE MACHINE, THE OPERATOR MUST READ AND UNDERSTAND ALL INSTRUCTIONS OF THIS MANUAL.
THE MANUAL MUST BE CAREFULLY KEPT INSIDE THE MACHINE TILL ITS DISMISSION.
Presentation
Dear customer,
We will, first of all, thank you for the confidence you gave us purchasing your new “Self-moving multipurpose loader MULTIONE
1 Series”.
We are sure your expectations will be satisfied since the technological level reached by our products and thank to a continuous
engagement that stimulates us daily to increase to be able to face the continuous, technological, productive and trade transformations.
We are sure we can also face any your future working requirement, we are pleased to remain at your disposal and offer you all our
experience and knowledge for the best solution of any your query.
1 DOCUMENT IDENTIFICATION
1.1 Designation
The following document is called “manual” (later on manual). It has been edited in accordance with the essential requirements of
security 1.7.4 of the Enclosure l of the machine Directive 2006/42/CE.
ATTENTION
THIS MANUAL MUST BE ALWAYS AT AUTHORIZED OPERATORS’ DISPOSAL AND BE NEARBY THE MACHINE WELL KEPT AND
PRESERVED.
THIS MANUAL MUST BE COMPULSORILY DELIVERED TOGETHER WITH THE MACHINE IN CASE IT WILL BE TRANSFERRED TO
ANOTHER USER.
WE ADVISE YOU TO COPY OUT THE IDENTIFICATION DATA OF THE DOCUMENT: CODE, ISSUE AND REVISION (SEE COVER) TO
REQUEST AGAIN COPY OF THE MANUAL TO THE MANUFACTURER IN CASE OF LOSS OR DETERIORATION OF IT.
THIS MANUAL REFLECTS THE STATE OF THE TECHNOLOGY AND KNOW-HOW AT THE MOMENT OF THE MACHINE MARKETING
AND IT CANNOT BE CONSIDERED INADEGUATE ONLY BECAUSE, ACCORDING TO NEW EXPERIENCES, CAN BE UPDATED LATER.
1.2 Identification
The manual is identified though the following data reported in the table on the cover and in annotation:
• Abbreviation of the language.
• Original instructions or translation of them.
• Symbol ISO 7000.
• Identifying code (ID).
• Issue.
• Revision (or revisione date).
TRANSLATION OF THE
ORIGINAL INSTRUCTIONS
Code Issue Revision
CM170001EN 01.03.17 03 (11.07.18)
This manual is the “Translation of original instructions” identified as follows:
ISTRUZIONI ORIGINALI
Code Emissione Revisione
CM170001 10.01.17 03 (11.07.18)
1- DOCUMENT IDENTIFICATION

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
3/49
MultiOne SRL
1.3 Glossary
Term Definition
Basic machine (later machine) Self-moving loader equipped with articulated multipurpose frame planned to carry out various functions
using interchangeable attachments.
Original interchangeable
attachments
(later attachment)
According to the article 2, b) of the Machine Directive 2006/42/CE it is a machine specified as: device
that after the starting up of a machine or of a tractor, is assembled with the machine or with the tractor
by the same authorized operator in order to modify the function or introduce a new function, to the
extent that this attachment is not a tool.
Produced by the Manufacturer and commercialized by the Manufacturer or by his authorized dealers
(see par. 6.3).
Original option
(later original)
Accessory produced by the Manufacturer and commercialized by the Manufacturer or his authorized
dealers (see par. 6.2).
Compatible attachment Attachment suitable to be assembled on a specific basic machine (see par. 6.3.1).
Assembly Attachment assembly onto the basic machine, including the mechanic, hydraulic and electrical
(if required) connection.
Authorized dealer
(later dealer)
He is a dealer authorized by the Manufacturer who the Customer must address to, for assistance and
emergency maintenance or for the purchase of accessories or original interchangeable attachments.
1.4 Abbreviations
ca. Circa about N. Number
Chap. Chapter Pag. Page
PPE Personal protective equipment Par. Paragraph
Right Right Pos. Position
eg. Example Ref. Reference
FIG. Figure/s Left Left
hrs Time TAB. Table
MAX. Maximum See See
MIN. Minimum Q.ty Quantity
min Minutes Etc. Etcetera
DOCUMENT IDENTIFICATION -1

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
4/49
1.5 Consultation notes
Bold type text:
It highlights same significant sentences in the text and the references to paragraphs, figures, tables, etc.
Generic danger sign:
It highlights risks for health and security of the authorized operators and or risks of damage and malfunctioning of the machine.
Generic obligation sign:
It points out a rule (obligation to execute an action)
Generic ban sign or dedicated:
It highlights the ban of executing a specific action.
EX danger sign:
It highlights the danger of an explosion in places with explosive atmosphere.
Crossed vaste bin:
It highlights the ban of throwing electrical and electronic attachments vaste in the garbage bins.
TO USE THE MACHINE IN SAFETY IT IS COMPULSORY TO READ AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS.
TO USE IN SAFETYA COMPATIBLE EQUIPEMENTASSEMBLED WITH THE MACHINE IT IS COMPULSORY TO READAND UNDERSTAND
THIS INSTRUCTION ATTACHMENT MANUAL IN ALL ITS PARTS.
THE SYMBOL PLACED AT THE BEGINNING OF A CHAPTER POINTS OUT WHO ARE THE AUTHORIZED OPERATORS (SEE PAR. 1.6.1)
TO CARRY OUT THE REPORTED INTERVENTIONS.
DANGER
IT HIGHLIGHTS A DANGER WITH A HIGH RISK DEGREE THAT, IF NOT AVOIDED, CAN CAUSE DEATH OR SEVERE INJURIES.
WARNING
IT HIGHLIGHTS A DANGER WITH AN AVERAGE RISK DEGREE THAT, IF NOT AVOIDED, CAN CAUSE DEATH OR SEVERE INJURIES.
ATTENTION
IT HIGHLIGHTS A DANGER WITH A LOW RISK DEGREE THAT, IF NOT AVOIDED CAN CAUSE LIGHT OR NOT SEVERE INJURIES.
1- DOCUMENT IDENTIFICATION

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
5/49
MultiOne SRL
1.6 Receivers of the document
This manual is addressed only, to the operators authorized to use and to maintenance of the machine according to the specific
technical-professional competences required for the type of intervention.
1.6.1 Authorized operators
WARNING
AUTHORIZED OPERATORS MUST CARRY OUT ONLY THE INTERVENTIONS OF THEIR SPECIFIC COMPETENCE ON THE MACHINE.
THE AUTHORIZED OPERATORS, BEFORE EXCUTING ANY INTERVENTION ON THE MACHINE, MUST MAKE SURE OF BEING IN
FULL POSSESSION OF THEIR PSYCO-PHYSICAL FACULTIES, THAT TO GUARANTEE ALWAYS THE OBSERVANCE OF THE SAFETY
CONDITIONS.
OPERATOR IN CHARGE
He is a professionally trained operator who, in full obedience of the legislation in force in the country of use, is qualified to the
driving of the machine and to carry out only:
• The regulations.
• The normal use.
• The normal maintenance.
All the operations must be executed in the absolute observance of the instructions reported in this manual.
OPERATOR ASSIGNED TO HANDLING
He is a professionally trained operator, who has completed 18 years, in full obedience of the legislation in force in the country of
use, to ensure safe transport and handling of the machine and/or parts of it, using the hand signals reported by the European
Directive 92/58 EEC.
AUTHORIZED TECHNICIAN
He is a qualified technician, placed at disposal by the dealer, who has got a specific knowledge of the machine and he is qualified
to carry out the requires technical assistance, normal and extraordinary maintenance and/or operations not reported in this
manual.
TAB. 1
1.7 Warranty
As regards the warranty conditions see il par. 11.2.
If found that the parties do not intend to submit the controversies rising from the supply contract, to an arbitral judgement or in
any other case where it is required the verdict of an organ of the ordinary Court, only the law Court in Vicenza will have territorial
jurisdiction.
DOCUMENT IDENTIFICATION -1

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
6/49
1- DOCUMENT IDENTIFICATION
2 MACHINE IDENTIFICATION
2.1 Copy of CE accordance statement
CE ACCORDANCE STATEMENT
Manufacturer MULTIONE SRL SOCIETÀ UNIPERSONALE
via Palù, 6/8
36040 Grumolo Delle Abbadesse (VI) Italy
Tel. [phone]
[email protected]
Fax [phone]
www.multione.com
We declare that the machine is so identified
Name Self-propelled multipurpose loader with articulated chassis “MULTIONE”
Model M1 1.1
Serial number ....................................
It is conform to the instructions of the following directives
2006/42/CE Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending
Directive 95/16/EC (recast)
2014/30/EU Directive of the European Parliament and of the Council of 26 February 2014 on the harmonisation of the laws of
the Member States relating to electromagnetic compatibility (recast).
2000/14/CE
Directive 2000/14/EC of the European Parliament and of the Council of 8 May 2000 on the approximation of the laws
of the Member States relating to the noise emission in the environment by equipment for use outdoors
Notified organisation
VERICERT SRL - Certificazioni e Verifiche
Via S. Cavina n. 19 - 48100 Ravenna - Italy
NOTIFIED ORGANISATION N. 1878
Evaluation procedure
Internal control of production with assessment of
technical documentation and periodical checking
procedure referred to in Annex VI
Guaranteed sound power level (LWA)100 dB
Sound power level measured (LWA)97 dB
Net installed power 6,7 kW @ 3600 rpm
Test engine rpm 1800 rpm
Main regulations harmonized among those applied
EN 12100-1-2:2003 / A1:2009 Safety of machinery. Basic concepts, general principles for design
EN 474-1:2006 / A1:2009 Earth-moving machinery - Safety - Part 1: General requirements
EN 474-3:2006 / A1:2009 Earth-moving machinery - Safety - Part 3: Requirements for loaders
Person authorized to keep updated the Technical Booklet
Name and roll Carraro Giuseppe - Technical Manager
Person authorized to draw up the statement
Name and roll Carraro Giuseppe - Technical Manager
Place Grumolo delle Abbadesse (VI) Italy Date .........../.........../..........
Signature

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
7/49
MultiOne SRL
2.2 Designation
The machine in question is so named:
Self-moving multipurpose loader Multione - 1 Series - Model M1 1.1
N.B. The model of the machine is reported on the statement CE of conformity and on the marking CE applied to the machine.
3 IMPORTANT INFORMATION ABOUT SAFETY
3.1 General instructions
DANGER
IT IS COMPULSORY TO CONTROL CONSTANTLY THE PROPER FUNCTIONING OF ALL THE SAFETY DEVICES INSTALLED ON THE
MACHINE.
IT IS COMPULSORY TO SUBSTITUTE AT THE RIGHT TIME POSSIBLE AND NOT WORKING WELL AND/OR DAMAGED SAFETY
DEVICES.
DANGER
IT IS FORBIDDEN TO REPLACE ANY SHELTER, SAFETY DEVICE OR ONE OF ITS COMPONENTS WITH NON ORIGINAL SPARE
PARTS.
IT IS FORBIDDEN TO ALTER, EXCLUDE AND/OR REMOVE ANY SHELTER AND SAFETY DEVICE ON THE MACHINE.
3.2 Residual risks
We inform the operator in charge that though the manufacturer has adopted all possible technical structural precautions to make
the machine sure, possibile residual risks remain. They are described in succession.
WARNING
THE RESIDUAL RISKS REPORTED IN SUCCESSION CONCERN THE MACHINE WITHOUT ASSEMBLED EQUIPPING. WE REFER TO
THE EQUIPPING MANUAL FOR THE DESCRIPTION OF THE RESIDUAL SPECIFIC EQUIPPING RISKS.
THERE IS THE RESIDUAL RISK OF INJURIES IN CONSEQUENCE OF FALL OF OBJECTS OR MATERIAL FROM THE POSSIBLE
ATTACHMENT ASSEMBLED TO THE MACHINE. CONSULT THE ASSEMBLED ATTACHMENT MANUAL TO VERIFY THE PRESENCE
OF THIS RISK.
DANGER
TO MINIMIZE THE EXPOSITION TO RESIDUAL RISKS IT IS COMPULSORY TO RESPECT THE SAFETY SIGNS
(SEE PAR. 4.10) AND WEAR THE INDIVIDUAL PROTECTION (SEE PAR. 4.12) REPORTED IN THIS MANUAL.
RESIDUAL RISK N. 1
THERE IS DANGER OF BURN FOR CONTACT IF THE AUTHORIZED OPERATOR GET INTO CONTACT WITH THE HOT PARTS SUCH
AS QUICK CONNECTIONS, HYDRAULIC CYLINDERS, HYDRAULIC HOSES, PARTS OF THE ENGINE THAT, OWING TO PROLONGED
USE OF THE MACHINE CAN REACH HIGH TEMPERATURES.
IT IS COMPULSORY TO RESPECT THE ASSEMBLY PROCEDURES, ATTACHMENT DISASSEMBLY (SEE CHAP. 8) AND ORDINARY
MAINTENANCE PROCEDURES (SEE CHAP. 9) DESCRIBED IN THIS MANUAL.
RESIDUAL RISK N. 2
THERE IS THE DANGER OF INJURIES OWING TO CONTACT WITH MOBILE PARTS IN MOTION IF THE AUTHORISED OPERATOR
DOES NOT RESPECT THE INSTRUCTIONS REPORTED IN THIS MANUAL AND, PARTICULARLY, STRECHES OUT HIS UPPER LIMBS
OUTSIDE THE DRIVING SEAT DURING THE ORDINARY WORKING OF THE MACHINE.
IT SI COMPULSORY TO RESPECT THE PROCEDURES OF ASSEMBLY, DISASSEMBLY OF THE EQUIPPING (SEE CHAP. 8), THE
ORDINARY MAINTENANCE PROCEDURES (SEE CHAP. 9) AND THE INSTRUCTIONS FOR A RIGHT POSITION TO ASSUME DURING
THE USE (SEE PAR. 8.3.1.1) DESCRIBED IN THIS MANUAL.
IMPORTANT INFORMATION ABOUT SAFETY -3

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
8/49
RESIDUAL RISK N. 3
THERE IS THE DANGER OF CRUSHING FOR A POSSIBLE FALL OF THE ATTACHMENT IF THE AUTHORISED OPERATOR DOES NOT
RESPECT THE INSTRUCTIONS REPORTED IN THIS MANUAL.
IT IS COMPULSORY TO RESPECT THE EQUIPPING DISASSEMBLY PROCEDURES (SEE CHAP. 8) DESCRIBED IN THIS MANUAL.
RESIDUAL RISK N. 4
THERE IS THE DANGER OF CRUSHING FOR ROLLING OVER OF THE MACHINE IF THE AUTHORISED OPERATOR DOES NOT
RESPECT THE INSTRUCTIONS REPORTED IN THIS MANUAL.
IT IS COMPULSORY TO RESPECT THE PROCEDURES OF THE ORDINARY USE OF THE MACHINE (SEE CHAP. 8) DESCRIBED IN
THIS MANUAL.
RESIDUAL RISK N. 5
THERE IS THE DANGER OF INJURIES TO HEARING IF THE AUTHORISED OPERATOR DOES NOT RESPECT THE INSTRUCTIONS
REPORTED IN THIS MANUAL AND IF HE DOES NOT WEAR ANTI-NOISE HEADPHONES.
IT IS COMPULSORY TO WEAR PERSONAL PROTECTION EQUIPMENTS INDICATED IN THIS MANUAL (SEE PAR. 4.12).
3.3 Transport and lifting
WARNING
IT IS FORBIDDEN TO LIFT THE MACHINE WITHOUT THE AID OF A PALLET.
THE MACHINE WITH THE ENGINE SWITCHED OFF IS LOCKED IN AN HYDRAULIC WAY AND IT CANNOT BE MOVED.
IT IS FORBIDDEN TO TOW THE SWITCHED OFF MACHINE BY ANY MEAN OF TRANSPORT.
3- IMPORTANT INFORMATION ABOUT SAFETY

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
9/49
MultiOne SRL
3.4 Manutenzione
DANGER
ATTENTION TO CARRY OUT THE MAINTENANCE OPERATION ON THE MACHINE: THIS MUST BE IN THE “SAFETY CONDITION”
(SEE PAR. 9.2).
DANGER
IT IS FORBIDDEN TO THE AUTHORISED OPERATORS TO LEAVE UNATTENDED THE MACHINE DURING THE MAINTENANCE
OPERATIONS WITHOUT MAKING SURE TO HAVE ARRANGED ANY PRECAUTION SUITABLE TO AVOID TO START ACCIDENTALLY
THE MACHINE OR SOME OF ITS PARTS.
DANGER
DURING ALL MAINTENANCE OPERATIONS THAT SHOULD BE CARRIED OUT ON THE MACHINE WITH ITS LIFTING BOOM IT IS
COMPULSORY TO INSERT THE LOCK BRACKET OF THE LIFTING BOOM (SEE PAR. 9.3).
WARNING
THE AUTHORISED OPERATORS MUST CARRY OUT ONLY THE MAINTENANCE OPERATIONS REQUIRED ACCORDING TO THEIR
SPECIFIC PROFESSIONAL COMPETENCE AND ON THE PERMISSION OF THE PERSON IN CHARGE.
LUBRICANT FLUIDS AND POSSIBLE OTHER FLUID COMING FROM MAINTENANCE MUST NOT BE UNLOADEN IN THE
ENVIRONMENT. THESE PRODUCTS ARE CONSIDERED POLLUTING AND DANGEROUS AND THEY MUST BE COMPULSORELY
TAKEN AWAY CHARGING AUTHORISED COMPANIES QUALIFIED FOR DIFFERENT PRODUCT TYPOLOGIES, IN THE ABSOLUTE
RESPECT OF THE REGULATION IN FORCE IN THE COUNTRY WHERE THE MACHINE IS USED.
ATTENTION
KEEP TO A SCRUPULOUS CLEANING OF THE MACHINE.
IMPORTANT INFORMATION ABOUT SAFETY -3

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
10/49
4 DESCRIPTION OF THE MACHINE
The machine has been planned and carried out to operate according to the type of attachment assembled in agricultural environment,
gardening in the private sector. The machine is provided with a (diesel) engine, that powers a series of hydraulic pumps.
These power an hydraulic circuit at high pressure that enables:
1) The three wheels whose the machine is equipped (each is moved by an hydraulic engine).
2) A lifting boom (in the front part of the machine).
3) The control panel is placed on the driving seat.
The steering wheel acts on the single rear wheel allowing a steering angle equal to zero, this gives the machine extreme
manoeuvrability.
4.1 Main parts and their functions
FIG. 1
1
2
34
5
6
8
7
9
10
11
12
13
4- DESCRIPTION OF THE MACHINE

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
11/49
MultiOne SRL
Ref. Part Function
1Rear wheel It supports, steers and allows the movement of the machine.
2Driving seat It support the operator.
3Footrest It supports the left foot.
4Steering wheel It allows to change direction while driving.
5Control panel It assembles operating controls of the machine and of the possible attachment assembled
to the machine.
6Proportional forward and reverse pedal It allows the movement of the machine.
7Engine It powers the hydraulic pumps.
8Opening engine space compartment It protects the engine and prevents the operators in charge to get in touch accidentally
with the mobile parts and high parts.
9Lifting boom It raises the attachment assembled of the machine.
10 Hydraulic circuit hoses They allow the passage of the hydraulic oil to power the attachment.
11 Quick rapid connections They allow the connection to the attachment hydraulic circuit.
12 Quick coupler It allows the mechanic connection to attachment.
13 Front wheels (n.2) They support and allow the machine movement.
TAB. 2
DESCRIPTION OF THE MACHINE -4

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
12/49
4.2 Seats taken by authorised operators
FIG. 2
DANGER
THE OPERATOR IN CHARGE DURING THE WORKING PHASES MUST REMAIN ON BOARD OF THE MACHINE (SEAT B) AND ONLY
WITH THE MACHINE IN “SAFETY STATE” (SEE PAR. 9.2 AND PAR. 9.3) CAN OCCUPY THE OTHER WORKING PLACES SHOWN IN
FIG. 2.
Operator in charge Place Description of the operation
Standing on the left side of the machine:
• for the refuelling (see par. 8.3.9);
• to operate required maintenance operations on the machine and on the engine
(see chap. 9).
Seated at the driving seat in the right position of use during the ordinary working (see par. 8.3).
Standing on the front left side of the machine to carry out the assembly and disassembly of the
attachment (see par. 8.3.4 and par. 8.3.5).
Standing on the front right side of the machine to carry out the assembly and disassembly of the
attachment (see par. 8.3.4 and par. 8.3.5).
TAB. 3
4- DESCRIPTION OF THE MACHINE

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
13/49
MultiOne SRL
DESCRIPTION OF THE MACHINE -4
4.3 Control devices
4.3.1 Control panel
FIG. 3
1
8
2

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
14/49
4- DESCRIPTION OF THE MACHINE
Ref. Name Function
1Parking brake lever
It is used to block the machine during the parking and the waiting. The brake is of a Pin Lock type and
it operates only on the front wheels. It can be inserted only with the machine stopped.
• Pos. “Down”: brake off.
• Pos. “Up to right”: brake engaged and blocked.
N.B.: the brake is correctly inserted when the noise of the insertion click is heard
(see par. 8.3.8).
2Control lever DBS
(Dinamic Block System)
It allows the wheels to turn all at the same speed or at different speeds. It can be inserted with the
machine in motion or stopped.
• Pos. “Vertical”: all the wheels turn at the same speed and the maximum traction is obtained.
• Pos. “Horizontal”: the wheels are free to turn at different speeds when steering and damaging the
work surface is avoided.
3Ignition key
By Key on and turned to the right carries out respectively:
• Pos. “0”: machine off.
• Pos. “1”: electric power supply.
• Pos. “2”: starting the machine.
4Steering wheel It allows to change direction during the machine operating. It is compulsory to carry
out the steering only when the throttle lever (Ref. 5) is in Pos. “Snail”.
5Throttle
It regulates the engine revolutions.
• Pos. “Snail” (lever up): it lowers the engine rpm.
• Pos. “Hare” (lever down): it increases the engine rpm.
6
Control lever of hydraulic
flow of quick hydraulic
couplings
• Pos. “right”: it operates and maintains the interchangeable attachment (eg.:
maintaining closing forage forks).
• Pos. “centre”: turn off the attachment.
• Pos. “left” (maintained action): it reverses the operation of the interchangeable
attachment (eg: opening forage forks).
7Multifunction lever
It controls the movement of the lifting boom and of the quick coupler.
• Pos. “forward” (maintained action): it lowers the lifting boom.
• Pos. “backward” (maintained action): it raises the lifting boom.
• Pos. “right” (maintained action): it inclines the quick coupler forward.
• Pos. “left” (maintained action): it inclines the quick coupler backward.
cont.

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
15/49
MultiOne SRL
DESCRIPTION OF THE MACHINE -4
Ref. Name Function
8Proportional forward and
reverse pedal
Operated with the right foot:
• Pressed “forward” (Right foot): it allows the forward movement of the machine and increases the
speed in proportion to the applied pressure produced on the same.
• Pressed “backward” (Right foot): It allows the backward movement of the machine and increases
the speed in proportion to the applied pressure produced on the same.
TAB. 4
4.4 Safety and protection devices
The safety systems adopted on the machine are the following:
FIG. 4
TOP VIEW
Ref. Device Function
1Lifting boom block bracket It allows to block the lifting boom in the raised position to operate maintenance (see par. 9.3).
2Pressure relief valves They are hydraulic valves installed in the hydraulic circuit of the machine and serve to endure that
the operating pressures never exceed the expected values (see par. 8.4).
3Non-slip strip Placed on footrests avoid slipping of the feet.
4Parking brake It locks the machine during the break and parking of this.
TAB. 5
4.5 Intended use
Range of applications Agriculture, gardening nurseries and gardening.
Location of use Outside the buildings, in a sufficiently lit place suitable to the laws in the country of use in safety.
Intended use The intended use is determined by the type of assembled attachment.
Operators in charge of use Only one authorised operator qualified with the described professional technical requirements
(see par. 1.6.1).
TAB. 6

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
16/49
4- DESCRIPTION OF THE MACHINE
4.6 Use limits and technical data
4.6.1 Machine
MACHINE M1 1.1
Code C926005
MAX. length mm 1864
MAX. width mm 992
MAX. height mm 1316
Steering radius grades 0
MAX. speed km/h 8
Machine weight without accessories kg 390
Standard tyres in 18x9,50-8
Pressure tyres bar 1,8
Tyre model Tractor
Oil tank capability litres 7
Working pressure bar 200
Type of mineral hydraulic oil VG46
Hydraulic pumps N. 2
Hydraulic flow litres/min 19
TAB. 7
4.6.2 Engine
Fuel Diesel
Cylinders N. 1
Cooling air
Power kW/HP 8,8/12
MAX. rpm rpm 3600
Tank capacity litres 4,7
Battery Ah 24
Voltage (DC) V12
Operating temperature °C -10 / +40
TAB. 8
WARNING
FOR FURTHER TECHNICAL DATA REFER TO ENGINE MANUAL ENCLOSED.
ATTENTION
TECHNICAL DATA SUBJECT TO CHANGE WITHOUT NOTICE.

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
17/49
MultiOne SRL
DESCRIPTION OF THE MACHINE -4
4.7 Load diagram
DANGER
IT IS FORBIDDEN TO EXCEED THE LOAD CAPACITY OF THE MACHINE (SEE FIG. 5).
The load diagram shown in FIG. 5 is obtained in accordance with standard ISO 14397-1:2007, and shows the load capacity of the
machine in the different position of the lifting boom.
The load diagrams are intended with the machine stopped in the position of maximum steering, placed on solid and flat surface,
with 100 kg operator in the driving seat and equipped with tyres Tractor model.
ATTENTION
MOVING THE LOAD BARYCENTRE DETERMINES THE CHANGE OF LIFTING CAPACITY OF THE MACHINE.
THE LIFTING CAPACITY INDICATED IS COMPREHENSIVE OF THE WEIGHT OF THE ACCESSORY USED, SO THE NET LIFTING
CAPACITY IS THE VALUE SHOWN IN THE GRAPHIC MINUS THE ACCESSORY WEIGHT.
WHEN WORKING ON UNEVEN OR SOFT GROUND WITH OBSTACLES IT IS COMPULSORY TO KEEP THE ATTACHMENT AS NEAR AS
POSSIBLE TO THE GROUND AND REDUCE THE LOAD UNDER THE MACHINE’S LIFTING CAPACITY. THIS WILL MAKE THE MACHINE
MORE STABLE.
The curves shown in the diagram represent the load capacity respectively (from left to right):
• curve n. 1, operator weighing 100 kg, seated in the driving seat and barycentre 0 mm;
• curve n. 2, operator weighing 100 kg, seated in the driving seat and barycentre 500 mm;
It can be noted that during the movement of the lifting boom the barycentre changes compared to the starting position and
consequently the load capacity of the machine varies.
FIG. 5

Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
18/49
4- DESCRIPTION OF THE MACHINE
4.8 Hydraulic flow/engine speed diagram
The diagram in FIG. 6 represents the trend of hydraulic flow according to the engine’s rpm.
FIG. 6
l/min
65
60
55
50
45
40
35
30
25
20
15
10
5
01000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400 3600 3800 rpm
ATTENTION
CHECK THE MANUAL OF ATTACHMENT USED TO REACH THE CORRECT SETTING.
4.9 Reasonable foreseeable misuse
DANGER
IT’S FORBIDDEN TO TAMPER WITH OR MODIFY IN ANY WAY THE MACHINE.
IT IS FORBIDDEN THE USE OF THE MACHINE FOR MISUSE, DIFFERENT FROM THOSE EXPECTED (SEE PAR. 4.5).
IT IS FORBIDDEN TO ASSEMBLE NON SUITABLE AND/OR NON ORIGINAL ATTACHMENTS TO THE MACHINE (SEE PAR. 6.2 AND
PAR. 6.3).
IT IS FORBIDDEN TO USE THE MACHINE TO CARRY AND/OR LIFT PEOPLE OR ANIMALS.
IT IS FORBIDDEN TO MOVE THE MACHINE KEEPING THE LIFTING BOOM, ATTACHMENT AND POSSIBLE LOAD UP.
IT IS FORBIDDEN TO MAKE STEERINGS AT HIGH SPEED.
IT IS FORBIDDEN TO MOVE AND USE THE MACHINE ON SLOPE OR UNSTABLE LAND.
IT IS FORBIDDEN THE USE OF THE MACHINE ON ROAD.
IT IS FORBIDDEN TO LIFT THE MACHINE BY MEANS OF A CRANE AND STRAPS.
IT IS FORBIDDEN TO GET OFF THE MACHINE WITHOUT HAVING TURN ON THE PARKING BRAKE, SWITCHED THE ENGINE OFF,
AND REMOVED THE IGNITION KEY.
IT IS FORBIDDEN LEANING FROM THE MACHINE IN MOTION.
IT IS FORBIDDEN TO OPERATE THE CONTROLS OF THE MACHINE FROM A POSITION OTHER THAN THE DRIVING SEAT
(SEE PAR. 8.3.3).
IT IS FORBIDDEN TO USE THE LIFTING BOOM TO MOVE ANY OBJECT DIFFERENT FROM THE ATTACHMENT SUPPLIED BY THE
MANUFACTURER.
