MULTIQUIP Rammax RX1575 User manual

OPERATION MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
MODEL
RX1575
TRENCH ROLLER
S/N 3069933 AND ABOVE
(YANMAR 3TNV80F-SPAMM DIESEL ENGINE)
Revision #0 (11/29/23)
To nd the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com

PAGE 2 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
TABLE OF CONTENTS
RX1575 Trench Roller
Proposition 65 Warning ........................................... 3
Safety Notice Symbols ............................................ 4
Product Description ................................................. 5
Nameplate Data Tag................................................ 6
Dimensions ............................................................. 7
Specications ....................................................... 8-9
Major Safety Precautions ................................. 10-13
Safety Decals (Roller)....................................... 14-18
Safety Decals (Remote Control Unit) .................... 19
Hand Signals .................................................... 20-22
Storage............................................................. 23-25
Disposal End Of Service Life ................................ 26
Machine Components....................................... 27-30
Actuators Dashboard Components ....................... 31
Display Unit Lamps........................................... 32-34
Fuses..................................................................... 35
Infrared Remote Control Unit............................ 36-37
Transmitter Status LED's.................................. 38-39
Charging Infrared Remote Control Unit ................ 40
Infrared Remote Control Unit Cable Connection... 41
Handling Infrared Remote Control Unit ................ 42
Proper Use Of Infrared Remote Control Unit ........ 43
Improper Use Of Infrared Remote Control Unit .... 44-45
Operating Infrared Remote Control Unit .......... 46-47
Operating Zones Infrared Remote Control Unit ... 48
Warning Light Beacon ........................................... 49
Unit Pre-Check ..................................................... 50
Protective Cover ................................................... 51
Unit Start-Up..................................................... 52-53
Driving And Braking............................................... 54
Work And Transport Gears.................................... 55
Driving On Slopes.................................................. 56
Unit Shutdown ....................................................... 57
Deadman Button Functions................................... 58
Standby Mode Functions....................................... 59
Opening Front And Rear Cowlings........................ 60
Ace-Econ System.................................................. 61
Telematics.............................................................. 62
Unit Overturning .................................................... 63
Unit Damage Check .............................................. 64
Transporting Unit .............................................. 65-68
Operating Parameters ...................................... 69-70
Maintenance................................................... 71-110
Electrical Wiring Diagram Legend .......................112
Electrical Wiring Diagram .....................................113
Hydraulic System Wiring Diagram Legend...........114
Hydraulic System Wiring Diagram........................115
Spare Parts...........................................................116
NOTICE
Specications are subject to change without notice.

RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 3
PROPOSITION 65 WARNING

PAGE 4 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
SAFETY NOTICE SYMBOLS
3RAMMAX 1575
557062
SYMBOLS OF THE SAFETY NOTICES:
The notice warns of aserious risk of personalinjury or other personal hazards
The notice warns of possible damages to the machine or its parts.
The notice warns of the necessity of environmental protection.
! NOTICE !
As usedin this operating manual, the terms „right“,„left“, „front“ and„rear“indicate the sides ofthe machine
movingforward.
FRONT
REAR
LEFT RIGHT

RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 5
PRODUCT DESCRIPTION
10 RAMMAX 1575
Machine description
The RAMMAX1575 trench roller is a roller specially designed for
trench compacting. The unlimited side clearance of the roller
drums allows compacting in very narrow, tight trenches right
up to the trench walls.
Machine application
The wet, clayey soils found in sewer construction, pipeline
construction, road foundations and construction backlling,
etc., are the areas of application for this modern trench roller.
In hazardous construction site applications, it is possible for the
operator to control the machine from a safe distance with no
personal risk.
Only use the RAMMAX1575 roller for driving on and compact-
ing of non-cohesive (loose) materials.
The machines are designed for operation in arid, temperate and
cold climates according to EN 60721-2-1:2014 with a limited
temperature range from -15 °C (5 °F) to +45 °C (113 °F) and a
maximum absolute humidity of 25 g.m¯³.
1.1 Basic Data
Please llin the following data:
(see Pin label, Label of the Yanmar engine)
Type of machine
................................................................................................................
Product Identication Number
................................................................................................................
Production year
................................................................................................................
Type of engine
................................................................................................................
Serial number of the engine
................................................................................................................
Please refer to the data in the table below always when ap-
proaching the dealer or the manufacturer.

PAGE 6 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
NAMEPLATE DATA TAG
11RAMMAX 1575
MADE IN CZECH REPUBLIC
MONTH / YEAR OF CONSTRUCTION
MODEL YEAR
SHIPPING MASS
REAR AXLE LOAD
MAXIMUM MASS
FRONT AXLE LOAD
OPERATING MASS
ENGINE EMISSIONS NOMINAL POWER
PRODUCT IDENTIFICATION NUMBER
VERSIONTYPE
DESIGNATION
4191
AMMANN CZECH REPUBLIC a.s.
549 01 NOVÉ MĚSTO NAD METUJÍ
Náchodská 145
CZECH REPUBLIC
12
13
11
10
9
8
4191
1
3
2
5
4
6
7
555005
556207
SPECIFICATION MANUAL
Name plate location
The machine that complies with the requirements as to health
protection and safety is identied with aname plate with CE
marking.
1. Name – always mentioned only in the English version
2. Type
3. Product identication number
4. Rated power
5. Operating weight
6. Maximum weight
7. Shipping weight
8. Version
9. Engine emissions
10. Front axle load
11. Rear axle load
12. Model year
13. Month/year of manufacture
Engine name plate location

RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 7
DIMENSIONS
12 RAMMAX 1575
D
B
C
F
G
I
J
A
H
557063
1.2 Dimension Chart
mm
(in) A B C D F G H I J
RAMMAX1575 T4 nal
640
601 302 36 640 1980 1000 525 1282 1317
(23.7) (11.9) (1.4) (25.2) (78.0) (39.4) (20.7) (50.5) (51.9)
850
601 407 36 850 1980 1000 525 1282 1317
(23.7) (16.0) (1.4) (33.5) (78.0) (39.4) (20.7) (50.5) (51.9)

PAGE 8 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
SPECIFICATIONS
13RAMMAX 1575
1.3 Technical Data
RAMMAX1575
EU Stage V / U.S. EPA Tier 4f
640 850
Dimension
Drum width (mm) 640 850
Weight
Operating weight of EN 500-1+A1 (CECE) kg (lb) 1340 (2950) 1440 (3170)
Operating load of EN 500-1+A1 (CECE) on front axis kg (lb) 730 (1610) 780 (1720)
Operating load of EN 500-1+A1 (CECE) on rear axis kg (lb) 610 (1340) 660 (1460)
Weight of half uid capacities kg (lb) 10 (20) 10 (20)
Operating weight of ISO 6016 kg (lb) 1350 (2980) 1450 (3200)
Maximum weight with accessories kg (lb) 1450 (3200) 1450 (3200)
Driving characteristics
Maximum transport speed km/h (MPH) 2,8 (1,7) 2,8 (1,7)
Working speed 1,4 (0,9) 1,4 (0,9)
Climbing ability without vibration % 30 30
Climbing ability with vibration % 25 25
Lateral static stability % 80 80
Lateral stability during driving without vibration % 25 25
Lateral stability during driving with vibration % 15 15
Turning radius inner (edge) mm (in) 1540 (60,6) 1440 (56,7)
Turning radius outer (contour) mm (in) 2190 (86,2) 2290 (90,2)
Type of drive - Hydrostatic
Number of driving axles - 2
Oscillation angle ° ± 7
Angle of steering ° ± 30
Steering
Type of steering - Joint
Steering control - Hydraulic
Linear hydraulic motors - 2
Engine
Manufacturer - YANMAR
Type - 3TNV80F-SPAMM
Power according to ISO 3046-1 kW (HP) 14,6 (20)
Number of cylinders - 3
Cylinder capacity cm³ (cu in) 1266 (77)
Nominal speed min¯¹ (RPM) 2400
Maximum torque Nm (ft lb)/rpm 68,4/1800
Average fuel consumption l/h (gal US/h) 3,2 (0,8)
Engines complies with emission regulations - EU Stage V, U.S. EPA Tier 4 Final
Cooling system of engine - Liquid
Brakes
Operating - Hydrostatic
Parking - Mechanical multiple-disc
Emergency - Mechanical multiple-disc

RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 9
SPECIFICATIONS
14 RAMMAX 1575
1.3 Technical Data
RAMMAX1575
EU Stage V / U.S. EPA Tier 4f
640 850
Vibration
Frequency I Hz (VPM) 40 (2400)
Amplitude I mm (in) 0,6 (0,024)
Amplitude II mm (in) 1,1 (0,043)
Fluid capacities
Fuel l (gal US) 28 (7,4)
Engine (oil lling) l (gal US) 3,4 (0,9)
Cooling system l (gal US) 1,2 (0,3)
Hydraulic system l (gal US) 16 (4,2)
Wiring
Voltage V 12
Battery capacity Ah 77
Noise and vibration emissions
Measured sound power level A, LpA at the operator's
position * dB 70
Uncertainty KpA * dB 1
Guaranteed sound power level A, LWA ** dB 101
Optional equipment
Drum extension set
Scrapers
Filter set 250 operating hours
Filter set 500 operating hours
Filter set 1000 operating hours
Cover tarpaulin
* measured according the EN 500-4
** measured according the DIRECTIVE 2000/14/EC

PAGE 10 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
MAJOR SAFETY PRECAUTIONS
19RAMMAX 1575
OPERATION MANUAL2.1 Major Safety Precautions
2.1.1 Safety Measures during Machine
Operation
• Safety measures given in the individual chapters of Engin-
ering Documentation supplied with the Machine shall be
added with Safety Precautions in force within arespective
country that uses the Machine at workplace with regard to
work organization, work process and personnel involved.
2.1.1.1 Compaction Work Commencement
• Constructional Supplier (Machine User) is liable to issue in-
structions for driver and maintenance before compaction
work is started, that will include requirements on work safe-
ty provision during Machine operation.
• He must verify and mark:
- utility lines,
- underground areas (direction, depth),
- seepage or escape of hazardous materials,
- soil bearing capacity, slope of travelling plane,
- other obstractions incl. their removal.
• He must make Machine driver, who will carry out earth work,
familiar with these conditions.
• He must specify Code of Practice (C.O.P.) part of which is
work procedure for a given work operation and this work
procedure will specify inter alia:
- measures when working under extraordinary condi-
tions (work within protective zones, within extreme
slopes, etc.),
- precautions for any natural disaster hazards,
- requirements on work performance while observing job
safety principles,
- technical and organizational measures to secure safety
of personnel, workplace and environment.
• He must make Machine driver evidently familiar with the
Code of Practice.
2.1.1.2 Work Safety Secured by User
• User shall promptly communicate any damage to the utility
lines to their operator, and at same time he make measures
to prevent unauthorized persons from entering endangered
area.
• He must ensure an employee does not work alone at awork-
place. Another worker must always be in sight and within an
ear-shot, who in case of accident will provide or call for help
unless another eective form of monitoring or communica-
tion exists.
