MULTIQUIP ST-1500 Guide

OPERATION AND PARTS MANUAL
Revision #0 (10/04/04)
Submersible Pumps
Model ST-1500 Series
THIS MANUAL MUST ACCOMPANY
THE EQUIPMENT AT ALLTIMES.

PAGE 2 — ST-1500 SERIES SUBMERSIBLE PUMPS — OPERATION & PARTS MANUAL — REV. #0 (10/04/04)
©COPYRIGHT2004,MultiquipINC.
MultiquipInc,theMQlogoareregisteredtrademarksofMultiquipInc.andmaynotbeused,reproduced,oralteredwithoutwritten
permission.Allothertrademarksarethepropertyoftheirrespectiveownersandusedwithpermission.
ThismanualMUSTaccompanytheequipment atalltimes.Thismanualisconsidereda permanentpartoftheequipmentandshould
remainwiththe unit if resold.
The information and specifications included in this publication were in effect at the time of approval for printing. Illustrations are
basedon the
MQModel ST-1500SeriesSubmersiblePumps. Illustrations,descriptions,referencesandtechnicaldata containedin
thismanual are for guidance only and may notbeconsideredasbinding.MultiquipInc. reserves the right to discontinue or change
specifications,designorthe informationpublishedinthispublication atanytimewithoutnotice andwithoutincurringanyobligations.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
HERE'S HOW TO GET HELP
PLEASEHAVETHEMODELANDSERIAL
NUMBER ON-HAND WHENCALLING
MULTIQUIP CORPORATE OFFICE
18910Wilmington Ave. 800-421-1244
Carson,CA 90746 FAX: [phone]
Email: [email protected]
Internet:www.multiquip.com
PARTS DEPARTMENT
800-427-1244 FAX: [phone]
310-537-3700
FAX: [phone]
MAYCO PARTS
800-306-2926 FAX: [phone]
310-537-3700 FAX: [phone]
SERVICE DEPARTMENT
800-421-1244 FAX: [phone]
310-537-3700
TECHNICALASSISTANCE
800-478-1244 FAX: [phone]
WARRANTYDEPARTMENT
800-421-1244, EXT. 279 FAX: [phone]
310-537-3700, EXT. 279

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 3
ST-1500 SERIES SUB.PUMP —TABLE OF CONTENTS
Submersible Pump
ComponentDrawings
ST-1503A Pump Assembly ................................26-29
ST-1503CUL Assembly ......................................30-33
ST-1503A/CUL Electric Motor Assembly........... 34-35
Terms and Condition of Sale — Parts .....................36
Multiquip ST-1500 Series
Submersible Pumps
Here's How To Get Help............................................ 2
Table Of Contents ..................................................... 3
Parts Ordering Procedures ....................................... 4
Safety Message Alert Symbols................................. 5
Rules For Safe Operation ......................................6-7
Dimensions ............................................................... 8
Specifications (Pump/Control Box) ...........................9
General Information................................................10
Components............................................................11
Float Switches.........................................................12
Float Switch (Piggy-Back) .......................................13
Float Switch (Control Box) ......................................14
Operation ................................................................15
Control Box Installation ..................................... 16-17
Clean-up .................................................................18
Maintenance ...........................................................19
Troubleshooting (Pump)..........................................20
Performance Curves ...............................................21
Wiring Diagrams (Electric Motor/Control Box) ........22
Explanation Of Codes In Remarks Column ............24
Suggested Spare Parts...........................................25
As a continuing effort to update
our parts book, contact the
MULTIQUIPliteraturedepartment
for the latest revision of your
"Operation and Parts Manual"
NOTE

PAGE 4 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —PARTS ORDERING PROCEDURES
When ordering parts,
please supply the following information:
❒❒
❒❒
❒Dealeraccountnumber
❒❒
❒❒
❒Dealernameandaddress
❒❒
❒❒
❒Shippingaddress(if different thanbillingaddress)
❒❒
❒❒
❒Returnfaxnumber
❒❒
❒❒
❒Applicable model number
❒❒
❒❒
❒Quantity,part numberand descriptionofeach part
❒❒
❒❒
❒Specifypreferredmethodofshipment:
✓FedExorUPS Ground
✓FedEx or UPS Second Day orThird Day
✓FedEx or UPS Next Day
✓FederalExpressPriorityOne
✓DHL
✓Truck
Note:Unlessotherwiseindicatedbycustomer,all
orders are treated as “Standard Orders”, and will
ship within 24 hours.We will make every effort to
ship“AirShipments”thesameday thatthe orderis
received,ifpriorto2PMwestcoasttime.“Stock
Orders”must be so noted on fax or web forms.
Extra Discounts!
All parts orders which include complete part numbers
andare receivedbyourautomated web parts order
system, or by fax qualify for the following extra
discounts:
Ordered Standard Stock orders
via orders ($750 list and above)
Fax 3% 10%
Web 5% 10%
Special freight allowances
when you order 10 or more
line items via Web or Fax!**
FedExGround Service at no charge for freight
Nootherallowances on freight shipped by any other
carrier.
Place Your Parts Order Via Web or Fax
For Even More Savings!
NOTE:DISCOUNTSARESUBJECTTOCHANGE
MULTIQUIP INC.
18910WILMINGTONAVENUE
POSTOFFICE BOX6254
CARSON,CALIFORNIA90749
310-537-3700 •800-421-1244
FAX:[phone]
E-MAIL:[email protected]
WWW:multiquip.com
DirectTOLL-FREE access
to our Parts Department:
Toll-free nationwide —800-427-1244
Here’s how to get help...
Please have the model and serial number
on hand when calling.
MULTIQUIP CORPORATE OFFICE
18910 Wilmington Ave. 800-421-1244
Carson, CA 90746
FAX: [phone]
Email: [email protected]
Internet: www.multiquip.com
PARTS DEPARTMENT
800-427-1244 FAX: [phone]
310-537-3700 FAX: [phone]
MAYCO PARTS
800-306-2926 FAX: [phone]
310-537-3700 FAX: [phone]
SERVICE DEPARTMENT
800-421-1244 FAX: [phone]
310-537-3700
TECHNICAL ASSISTANCE
800-478-1244 FAX: [phone]
WARRANTY DEPARTMENT
800-421-1244, EXT. 279 FAX: [phone]
310-537-3700,
EXT. 279

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 5
ST-1500 SERIES SUB.PUMP —SAFETY MESSAGE ALERT SYMBOLS
Safety precautions should be followed at all times when
operating this equipment. Failure to read and understand the
Safety Messages and Operating Instructions could result in
injury to yourself and others.
FORYOUR SAFETY ANDTHE SAFETY OF OTHERS!
This Owner's Manual has been
developed to provide complete
instructions for the safe and efficient
operation of the Multiquip
Model ST-
1500 Series Submersible Pumps.
Before using these pumps, ensure
thattheoperatingindividual has read
and understands all instructions
in this manual.
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure to
theoperator,andare precededbyone of three words: DANGER,
WARNING, or CAUTION.
HAZARD SYMBOLS
Potential hazards associated with the ST-1500 series
submersible pumps operation will be referenced with Hazard
Symbols which appear throughout this manual, and will be
referenced in conjunction with Safety Message Alert Symbols.
Rotating Parts
NEVER operate equipment with covers,
or guards removed. Keep fingers, hands,
hair and clothing away from all moving
parts to prevent injury.
NOTE
Accidental Starting
ALWAYS place the power source circuit
breaker or ON/OFF switch in the OFF
position, when the pump is not in use.
ALWAYS wear approved eye and
hearing protection, if required.
Sight and Hearing hazard
Respiratory Hazard
ALWAYS wear approved respiratory
protection, if required.
Equipment Damage Messages
Other important messages are provided throughout this manual
tohelp prevent damageto yoursubmersiblepump,other property,
or the surrounding environment.
This submersible pump, other
property, or the surrounding
environment could be damaged if
you do not follow instructions.
NOTE
You WILL be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
You CAN be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
You CAN be INJURED if you DO NOT follow directions.
CAUTION
WARNING
CAUTION
DANGER

PAGE 6 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —RULES FOR SAFE OPERATION
Failuretofollowinstructionsinthis manualmaylead toserious
injury or even death! This equipment is to be operated by
trained and qualified personnel only! This equipment is for
industrial use only.
The following safety guidelines should always be used when
operatingthe ST-1500 SeriesSubmersiblePumps:
GENERAL SAFETY
■ DO NOT operate or servicing this equipment
before reading this entire manual.
■ This equipment should not be operated by persons under 18
yearsof age.
■ NEVER operate this equipment without proper protective
clothing, shatterproof glasses, steel-toed boots and other
protectivedevicesrequired by the job.
■ NEVER operate this equipment when not feeling
wellduetofatigue, illnessor takingmedicine.
■ NEVERoperatethisequipmentundertheinfluence
ordrugs or alcohol.
■ NEVER use accessories or attachments, which are not
recommendedbyMultiquip for this equipment. Damage to the
equipmentand/orinjurytousermayresult.
■ Manufacturerdoesnotassumeresponsibilityforanyaccident
duetoequipment modifications.
■ Whenevernecessary,replace nameplate,operationandsafety
decalswhen they become difficult read.
■ ALWAYS check the machine for loosened threads or bolts
beforestarting.
■ NEVER operate the submersible pump in an explosive
atmosphereornearcombustible materials.Anexplosion orfire
could result causing severe
bodily harm or even death.
■ ALWAYS makesure submersible pump is grounded.
■ NEVER usegaspiping as an electrical ground.
■ DONOT place handsorfingers insidepumpwhen pumpis
running.
■ ALWAYS makecertainthatthevoltagesuppliedtothepump
iscorrect. Always read the pump'snameplatetodetermine
what the power requirements are. The ST-1500 series
submersiblepumpsrequire115VAC,60 Hz (single-phase)
fornormaloperation.
■ DO NOT restrict the flow of the discharge hose as it may
causeoverheating.
■ Becarefulofdischarge whipping under pressure.
■ Make sure pump installation is accordance with national
andlocalelectrical codes.
■ ALWAYS have a qualified electrician perform the pump
wiringinstallation.
■ ALWAYS mount the control box in a vertical position
protectedfrom theelements.
■ NEVER handlepump's AC power cord with wet hands .
■ NEVERletanextensioncordorplugconnection layinwate r.
■ NEVER stand in water whileACpowercordis connected
toapowersource.
■ NEVER use a pump with a defective, frayed power cord.
Checkthepowercordonthe pumpfor cutsintheinsulation.
■ NEVER use a extension cord that is frayed or damaged
wheretheinsulation has been cut.
■ ALWAYS makecertainthatproperextensioncordhasbeen
selected for the job.SeeTable 4.
■ NEVERattempttousethepowercordasaliftingorlowering
deviceforthesubmersible pump.
■ When raising or lowering of the submersible pump is
required, always attach an adequate rope or lifting device
tothecorrectliftingpoint(handle) on the pump.
■ ALWAYSplacethepumpinanuprightpositiononaplatform
before using. The platform will prevent the pump from
burrowingitselfonsoftsandormud.
■ NEVER operatepumpon its side.
■ DO NOT allow the pump to freeze in water.
■ NEVER leaveanopenpumpchamberunattended.
■ The electrical voltage required to operate the pump can
causesevere injury orevendeaththrough physical contact
with live circuits.
ALWAYS disconnect the electrical power
fromthepumpbeforeperformingmaintenanceonthepump.
CAUTION

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 7
ST-1500 SERIES SUB.PUMP —RULES FOR SAFE OPERATION
.Emergencies
■ ALWAYS knowthelocationofthenearest fireextinguisher .
■ ALWAYS know the location of the nearest first aid kit .
■ In emergencies always know the location of the
nearest phone or
keep a phone on the job site .
Also know the phone numbers of the nearest
ambulance , doctor and fire department . This
information will be invaluable in the case of an
emergency.
■ ALWAYS make sure that electrical circuits are properly
grounded per the National Electrical Code (NEC) and
local codes before operating pump.
Severe injury or death
by electrocution canresultfromoperatingan ungrounded
pump.
■ NEVERusethispumptoremovewaterfromaswimmingpool
when people are in the water .
■ ALWAYS be sure the operator is familiar with proper safety
precautions and operations techniques before using
submersible pump.
■ ALWAYS check pump oil level only when pump is cool.
Expansion due to heat may cause hot! oil to spray from the oil
plug when the oil plug is removed.
■ DO NOT attempt to thaw-out a frozen pump by using a torch
or other source of flame. Application of heat in this manner
may heat the oil in the seal cavity above the critical point,
causing pump damage.
■ DO NOT pump water greater than 104°Fahrenheit. Also DO
NOT pump liquids containing acid or alkali.
■ ALWAYS check strainer before pumping. Make sure strainer
is not clogged. Remove any large objects, dirt or debris from
the strainer to prevent clogging.
■ ALWAYS use a large basket strainer when pumping water
that contain large debris.
■ ALWAYS flush pump after use when pumping water
concentrated with heavy debris.
Flush with clean fresh
water . It is very important to always flush the pump before
turning it off to prevent clogging.
■ ALWAYS store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the
reach of children.
■ ALWAYS read, understand, and follow procedures in
Operator’s Manual before attempting to operate equipment.
Maintenance Safety
■ NEVERlubricatecomponentsorattemptserviceonarunning
machine.
■ ALWAYS allowthe machine a proper amountoftimetocool
beforeservicing.
■ Keepthemachinery in proper running condition.
■ Fixdamage tothemachine immediately andalwaysreplace
brokenparts.

PAGE 8 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —DIMENSIONS
Figure 1. ST-1503A, CUL Dimensions
NPT 2
13.81 in.
(351 mm.)
7.20 in.
(183 mm.)
ST-1503A, AND CUL
25 ft.
(7.6 m.)

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 9
ST-1500 SERIES SUB.PUMP —SPECIFICATIONS
1. Motor Rotation –Upon start-up, the pump " kicks " in the opposite direction of motor rotation. The correct rotation is
counterclockwise(CCW)asviewedfromtheimpeller end of the pump.
2. Mechanical Oil Seal –Useagood grade10weightnon-detergenthydraulicoil(i.e.ShellTurbo32or equivalent).Filloilcavity
75%to 85% full (allow air space for expansion).
3. Control Box - Control box (Table 2) may be required for certain pumping applications.
snoitacificepSxoBlortnoC.2elbaT
.oNledoMepyTegatloV ASC/LU detsiL
lamrehT daolrevO noitcetorP
taolF hctiwS ytilibapaC
3BC -elgniSzH06,CAV511 esahP SEYONSEY
SNOITACIFICEPS.1ELBAT
ledoMA3051-TSLUC3051-TS
epyT hsarTelbisrembuS pmuP lagufirtneC pmuPelbisrembuS
rellepmIelitcuDnorItsaCelitcuDnorItsaC
eziSegrahcsiD&noitcuS)mm15(.ni00.2)mm83(.ni05.1
yticapaCgnipmuPmumixaM etunim/snollag27 )etunim/sretil372( etunim/snollag54 )etunim/sretil071(
retemaiDsdiloS.xaM).mm52(.ni00.1A/N
daeHxaM)sretem3.01(.tf43)sretem5.8(tf82
rewoP)wk73.0(PH5.0)wk52.0(PH33.0
esahPegatloVV511Ø1V511Ø1
spmAgnitratS5224
spmAgninnuR2.66
deriuqeRxoBlortnoC)3etoN(ON)3etoN(ON
noitcetorPdaolrevOlamrehTSEYSEY
noitatoR)1etoN(WCC)1etoN(WCC
yticapaClaesliOlacinahceM)2etoN(.cc081)2etoN(.cc051
ycneuqerFkcehC).srh003(ylhtnoM).srh003(ylhtnoM
)deepS(PMR03±055303±0553
htgneLelbaCrewoP).mc6.7(.tf52).mc6.7(.tf52
thgiewteNyrD).gK51(.sbl33).gK71(.sbl83

PAGE 10 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —GENERAL INFORMATION
Introduction
The Multiquip Model ST-1500 series submersible pumps are
designed to pump water and is used for the draining (de-
watering) of swimming pools, well casings construction sites,
cofferdams,manholes, transformervaultsand excavations.
Acast iron ductiletypeimpeller is attachedtothe output shaftof
a 0.5 HP (ST-1503A) or 0.3 HP (ST-1503CUL) electric motor
whichprovides adequate power for general purpose pumping.
This submersible pump is supplied complete with an electric
powercable,anda discharge port whichaccepts a 2-inch(ST-
1503A)or1.5-inch(ST-1503CUL) hose.
Thispumpis ideal for portability because of its lightweight and
carrying handle. For reliability and long life, a mechanical seal
providesshaft sealing,withan oilchamberseparating thepump
sectionfrom themotor.
The pump when in use, should be installed as free standing
(upright position) on its strainer base. A discharge hose (not
supplied) should be connected to the discharge port. The
dischargehose should beadequatelysupported to avoidstress
onthepump.
Formaximum waterflow,thedischargehoseshouldbekeptas
shortas possible,andwithminimum elevationabovethe pump.
Rememberasthe length and/or height of the discharge hose is
increased,theflow of water will be reduced. Also any reduction
inthehosesize,andanyfittingssuch asvalvesoroutletnozzles,
willrestrict the waterflow.
Toavoidback-siphonagewhenthepumpis switchedoff,ensure
that the end of the discharge hose is installed above the water
levelatthe final discharge point.
Whenthe pump is switchedoff,thewater remaining in thehose
willrun back through the pump.This can be avoided byplacing
anon-returnvalvein the hose nearest the pump.
NEVER usethissubmersible pump to pump flammable liquids
oroperateinaexplosive or flammable environment.
Avoidusing thispumpinconditions wheremud,grit,silt orother
debris are present.These conditions could causeblockageand
causeexcessive pump wear.
DO NOT install the pump directly into an area where there is a
heavybuildupofmud,grit,siltordebris.Ifthisconditionispresent,
installthepumponaplatform before operating.
Thispumpmustalwaysbepositionedona platformin anupright
position. NEVER operate the pump by a suspended rope.To
preventlarge solids from enteringthepump,install a wire mesh
screenorsimilarbarrier around the pump.
If the pump was used to pump water containing mud, silt, use
cleanwatertoflushoutthepumpaftereachuse.
DO NOT allow the pump to run dry, as this will damage the
pump.Duringmaintenance,dryrunningispermissiblebutonly
fora fewseconds.
NEVER lift the pump by its electrical power cord. ALWAYS lift
thepumpby its carrying handle or attach aropeto the carrying
handle.
A pump fully submerged pump in liquid will not freeze, unless
theliquid freezes.DONOT allowa partiallysubmergedpumpto
freeze.The expansionofwaterfreezingin the volutemaycrack
the pump, causing expensive repairs. If there is any danger of
thepumpbeing subjectedtofreezingtemperatures,liftthepump
from water and allow it to drain thoroughly.
If the pump jams or the pump rotor locks for any reason,
disconnect the pump from the power source immediately.
AllowingthepumpmotortocycleON andOFF underanoverload
conditioncanburnoutthemotor.
When replacement of nuts and bolts is required, use only
recommended parts as referenced in the parts section of this
manual.This pump uses
metric threads.DO NOT use English
measurementthreads.
Control Box Installation Warnings
When installing the CB3 control box, the
possibility exists of
electrical shock ,
electrocution and possibly death! NEVER have
untrained personnel perform the installation.
ALWAYS have qualified service personnel (licensed
electrician)performthe installation.
Explosion or Fire Hazard exists if this
pumpisusedwith
flammableliquids .DO
NOT use this pump with
flammable
liquids
. DO NOT install this pump in
hazardous locations as defined by the National Electrical
Code,ANSI/NFPA 70.
Failure to follow the above referenced precautions could result
in serious injury or death! Replace pump cord immediately if
cordbecomesdamaged orsevered.Thispumpmustbeinstalled
inaccordance with National ElectricCode ANSI/NFPA 70 so as
topreventmoisturefromenteringoraccumulatingwiththeboxes,
conduitbodiesfittings,floathousingorcable.
DANGER
WARNING

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 11
ST-1500 SERIES SUB.PUMP —COMPONENTS
Figures 2 shows the location of the basic components, for the
ST-1500 series submersible pumps. Listed below is a brief
explanationofeach component.
1. Strainer Base –This strainer base is made of stainless
steel which is resistant to hardware corrosion. DO NOT
pumplargeobjects or debriswith this pump.Thispump is
forpumping wateronly.Forde-watering purposes,always
placethestrainer base on a platform.
2. Volute/Impeller–Impellersareconstructedofhigh-chrome
ductileironto minimizes wear and prolong servicelife.
3. ElectricMotor –TheST-1503Asubmersiblepumputilizes
a60Hz,single-phase,115VAC,0.5HP electricmotor.The
ST-1503CUL submersible pump utilizes a 60 Hz, single-
phase, 115 VAC, 0.33 HP electric motor. Consult with a
licensed electrician beforeconnectingmotortoa power
source.Observeall city and local safety codes.
4. Discharge Port –Connect a 2-inch (ST-1503A) or 1.5-
inch (ST-1503CUL) hose to this port. Remember to
adequatelysupportthedischargehosetoavoidstresson
thepump.
5. AC Power Cable –This unit is supplied with a 25 ft.(7.6
meters) ACpowercable.Always checkthecable forsigns
ofwear.NEVER! use adefectivepowercable.Replace the
cableimmediatelyifthe cable is worn or defective.
6. Carrying Handle –Always carry the submersible pump
by its handle. NEVER! carry the pump by its power cord.
Carrying or lifting the pump by the power cord, will cause
undue stress on the cord, and ultimately the cord will
becomedislodgedfromthe pump.
7. Thermal Overload Protection –This pump is equipped
withathermaloverloadprotectiondevicethatwillshutdown
themotor in the event ofhighoperatingtemperatures.The
motorwillautomaticallyrestartoncethetemperaturereturns
toanacceptable operating temperature.
8. Mechanical Oil Seal –This oil filled seal provides
lubrication when running the pump dry.NEVER! run the
pumpdry. Runningthepumpdrywillcauseseveredamage
tothe pump.
9. Mechanical Oil Seal Plug –Remove this plug to check
and add hydraulic oil (Shell 32 or equivalent) to the oil
cavity.Thisoilprotectsthemechanicalseal.Oilcavityshould
be full enough to cover seal spring.
Figure 2. Submersible Pump Components

PAGE 12 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —FLOAT SWITCHES
Float SwitchTheory
Mercury monitoring is a mercury-switch actuated, liquid level
controlthathasproventobemoreeconomicalandlongerlasting
thanother types of liquid-levelcontrolsystems,easily replacing
and improving upon diaphragm switches, air bubble systems
and electromechanical switches most often relied upon in the
past.
How ItWorks
Thereisa tilt-sensitivemercuryswitchhermeticallysealedwithin
eachfloat.Astheliquidlevel(water)risesorfalls,thefloatchanges
its angle until the mercury switch makes (closed, Figure 4) or
breaks(open,Figure5)the circuit. Maximum pumping range is
120 degrees.See Figure 3 below.
Figure 3. Pumping Range (Float Switch)
Figure 5. Float Switch (Open)
Figure 4. Float Switch (Closed)
Design Features
Constructedofrigid, durableABSpolymerultrasonicallywelded.
Theall-steelmercuryswitchisheldbypositioningpins.Interior
isfilled with cell foam.
■ Suitableformost liquid environments.
■ Hermeticallysealed.
■ Thick-wallednon-corrosivePVCplasticenclosure.
■ Pressuretestedto60 ft.(18.2meters).
■ Mercury switchreliability,provento 500,000 cycles.
■ StandardSJO, 16-gauge, 2 conductorcord(20ft./6.09m).
Pumping Range
Thepumpingrangeofthepumpisdeterminedbythefloatswitch
tethercord.UseTable3asguide linetodetermineyourrequired
pumpingrange. Pumping ranges are basedon
non-turbulent
conditions.Range may vary duetowatertemperatureand cord
shape.Pleasenote as the tether length increases, so does the
varianceofthepumpingrange.
egnaRgnipmuP.3elbaT
htgneLrehteT .ni2 .mc80.5 .ni4 .mc61.01 .ni6 .mc42.51 .ni8 .mc23.02 .ni01 .mc4.52 .ni21 .mc84.03 .ni41 .mc65.53 .ni61 .mc46.04
egnaRgnipmuP .ni6 .mc42.51 .ni01 .mc4.52 .ni41 .mc65.53 .ni81 .mc27.54 .ni22 .mc88.55 .ni72 .mc85.86 .ni13 .mc47.87 .ni53 .mc9.88

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 13
Float Switch
Single or dual controlfloatswitches can be used for the unattended operationofthe submersible pump. When using the piggy-
back power configuration
(plug), the ST-1500 series pumps DO NOT require theuseof a controlbox.Inthis configuration (piggy-
back),theSW-1(singlefloatswitch)orSW-2(dualfloatswitch)arerequired. Figure6 is an example of a single floatswitchapplication.
ST-1500 SERIES SUB.PUMP —FLOAT SWITCH (PIGGY-BACK)
Figure 6. Single Float Switch
Application Diagram
Figure6showsa single float switch
application. For dual float switch
capabilityusea
ModelSW-2 mercury
typefloatswitch.
NOTE
MountingThe Float Switch
1. Determine the required
cord tether length as shown in
Figure 6 andTable 3.
2. Place the cord into the clamp as shown in Figure 6.
3. Securetheclamptothedischargehoseas showninFigure
5.DO NOT install cord under hose clamp.
4. Usingascrewdriver,tighten thehose clamp.DONOTover-
tighten.Makesurethe floatcordis notallowedto touchthe
excesshoseclampband during operation.

PAGE 14 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
Control Box (CB3)
Forspecial remotepumpingapplications ofthesubmersiblepump,acontrol box(
ModelCB3 )maybe required.This waterresistant
controlbox provideswatertighthousing andglandstopreventwater fromleakinginto thebox,andafloatswitchinterface.Whenusing
theCB3controlbox,onlythe
SW-1WOPfloatswitch(2) canbeused(noplug,barewires).Shownbelow(Figure7)isawiringlayoutof
theCB3controlbox.Seepage22forawiringdiagramofthecontrolbox.
ST-1500 SERIES SUB.PUMP —FLOAT SWITCH (CONTROL BOX)
Figure 7. CB3 Control Box and Dual Float Switch
Application Diagram

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 15
ST-1500 SERIES SUB.PUMP —OPERATION
Hose Connections
1. Connect a 2-inch (ST-1503A) or 1.5-inch (ST-1503CUL)
hosetothedischarge portonthe pumpasshown inFigure
8. Make sure that the hose is attached correctly to the
dischargeport.
Pump Power Connections (Piggy-Back Cord Only)
1. Makesurethecircuit breakersupplying powertothe pump
is in the OFF position.
2. Connect the float switch or switches to the AC power
receptacle as shown in Figure 6.
Attaching Lifting Rope
1. Attach a suitable lifting cable (rope) to the carrying handle
(Figure8) on the pump and lowerthepumpinto place. For
applicationswherethereisanexcessiveamountofmud,grit
or silt, the use of a support platform is desirable. When
pumpingwaterfromswimmingpooltypeapplicationswhere
thereislittleor nodebris,thesupportplatformisnotrequired.
Figure 8. Submersible Pump Upright Position
(Correct)
2. Makesurethepumpisalwaysplacedinanuprightposition,
nottilted(Figure9).Neverpositionthepumpdirectlyonasoft,
loose bottom. Remember to attain maximum pumping ca-
pacityandprevent excessivewear, position the pump soit
will not burrow itself into sand or clay.
Figure 9. Submersible Pump Upright Position
(Incorrect)
3. If all of the pump's electrical requirements have been met,
placethe
circuit breaker orpower ON/OFF switchinthe ON
position.
4. Waitafewsecondsandwatershouldbegintoflowfromthe
dischargehose.
5. Ifwaterisnotflowingfromthedischargehoseornotflowing
freelyafterafewminutes,removethepowerfromthepump
andcheckthesystemforleaks.
6. To stopthe pumpfrom pumping,placethe
circuitbreaker
or ON/OFF switch in the OFF position.
NEVER! grab or touch a live power cord (Figure 10). DO
NOTstandinwaterwhenconnecting thepump'spowercord
intoavoltagesource.Thepossibilityexistof
electrical shock ,
electrocution and possibly death!
POWER
CORD
(POWER ON)
WET
HANDS
Figure 10. Power Cord (Wet Hands)
DANGER

PAGE 16 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP—CONTROL BOX INSTALLATION
The ST-1500 series submersible
pumps are also designed to work
withacontrolbox(
ModelCB3 ).This
control box contains the necessary
electronics(floatswitchconnections)tooperatethepump.
Rememberthiscontrolboxcontainshazardousvoltages.
Disconnect all sources of power before installing or
servicing. There exists the possibility of electrocution,
electric shock or burn, which can cause severe bodily
harm or even
death !
This control box should only be installed or serviced by a
licensed electrician or qualified personnel .
Control Box Mounting
Mountthecontrolboxinan
uprightverticalposition .Makesure
thecontrolboxissecurelyfastenedtoaflatsurface,thatisfree
ofdust,dirt, moistureor anyelementsthatmaycontaminateor
erodetheelectroniccomponentsofthecontrolbox.
Single-Phase Power Installation (Input)
AllST-1500seriessubmersiblepumpsrequire115V,60Hz.,
single-phase power for
normal operation .
If you cannot determine what your pump's power
requirementsare,lookatthevendorsuppliedidentification
nametagattachedtothepumporpleasecontactMultiquip's
Service/TechnicalAssistancedepartment.
Applying incorrect power (
voltage phasing ) to the
submersiblepumpcancauseseveredamagetothepump.
Pleasemakesurethatthecorrect voltageandphaseare
transferredtothepumpatalltimes.
Power Cord Requirements
When routing the 115 VAC, 60 Hz., single phase power via a
powercordtothecontrolbox,
ALWAYS usethecorrectwiresize.
Please reference Table 4 below (Cord Length/Wire Size) to
determinethecorrectwiresize.Incorrectwire sizecanadversely
affecttheperformanceofthepump.
Connecting Dual float Switch (SW-1WOP)To Control Box
1. Remove the float switch input connector housing, then
routethefloatswitch wires through the cable gland on the
control box. Attach the wires of the float switch to the
terminal block as indicated byTable 5 and Figure 6.
2. Tightentheconnectorhousingtoensure atightfitbetween
thecordandthe connectorbody.Thiswillpreventthecable
from pulling out of the terminal block and also prevent
moisturefrom entering the control box.
3. Determinethe lengthofthefloat switch wires, thensecure
floatswitchwires to pump discharge hose. See Figures3
and 6 andTable 3 to determine the pumping range.
EZISERIWDNAHTGNELDROC.4ELBAT S
SPMA.TF05.TF001.TF051
6GWA61GWA61GWA41
8GWA61GWA41GWA21
01GWA61GWA41GWA21
21GWA41GWA41GWA21
41GWA41GWA21GWA01
61GWA21GWA21GWA01
SNOITCENNOCHCTIWSTAOLF.5ELBAT S
HCTIWSTAOLF KCOLBLANIMRET REBMUN
TRATS )KCALB(1LANIMRET )ETIHW(2LANIMRET
POTS )ETIHW(7LANIMRET )KCALB(8LANIMRET
DANGER
CAUTION
CAUTION

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 17
2. Remove the pump AC input connector housing from the
control box, then route the power cord through the cable
glandonthe control box.
3. Connectthepumppowercordtothecontactorasshownin
Figure 7 andTable 7.
Connecting AC Power to the Control Box
1. TheAC power cord (input) should have three wires. Each
wire is color coded.The colors are WHITE, BLACK and
GREEN.
2. Removethe ACinputconnectorhousingfromthecontrol
box,then route the power cordthroughthecablegland on
thecontrolbox.
3. Connect the AC power cord to the contactor as shown in
Figure 7 andTable 6.
Electrical connections to the power
source should only be performed by
a
licensed electrician or qualified
personnel.
4. Tightentheconnectorhousingtoensure atightfitbetween
the power cord and the connector body.This will prevent
the cable from pulling out of the terminal block and also
preventmoisture from entering the control box.
NOTE
5. Connect theotherend ofthe ACpower cordtothe voltage
source. Remember to provide a means of disconnecting
the power from the control box (circuit breaker or quick
disconnectswitch).Also makesure toprovideagoodearth
groundtothecontrolbox.
Connecting AC Power to the Pump
1. AC power is transferred to the pump via a contactor.The
coil of the contactor is energized or de-energized by the
openingandclosingof thefloatswitchcontacts.Thepower
cord should have three wires. Each wire is color coded.
Thecolorsare WHITE, BLACK andGREEN.
Itisrecommendedthatthepowerbeing
supplied to the control box
ALWAYS
beconnectedtoa circuitbreaker or
a
quick disconnect switch. This
safetyfeatureallowsforquickremoval
of power from the control box in the
eventof an emergency.
NOTE
Turning On The Pump
1. If all of the pump's electrical requirements have been met,
placethe
circuit breaker orpower ON/OFF switchinthe ON
position.
2. The CB3 control box has an
operation switch located on
thefront cover.Thisswitchhas3positions, AUTO,MANUAL
andOFF. The AUTO position allowsthepumptorunin an
unattendedmode.TheMANUALpositionwill let thepump
runwithoutthefloatswitchescontrollingthepump.Whenin
the manual mode be careful not to let the pump run dry.
Severedamagetothepumpmayoccurifitisallowedtorun
dry.NEVERletthepump
rundry .
3. Place the operation switch in the AUTO position.The AC
power indicator lamp should be lit (ON).
4. Waitafewsecondsandwatershouldbegintoflowfromthe
dischargehose.
5. Ifwaterisnotflowingfromthedischargehoseornotflowing
freelyafterafewminutes,removethepowerfromthepump
andcheckthesystemforleaks.
6. Tostopthepumpfrompumping,placetheoperationswitch
in the OFF position.
ST-1500 SERIES SUB.PUMP—CONTROL BOX INSTALLATION
REWOPTUPNICA.6ELBAT ROTCATNOCOTSNOITCENNOC S
ROLOCERIWELBACROTCATNOC
KCALB1L
ETIHW2L
NEERGDNUORG
REWOPTUPTUOCA.7ELBAT PMUPOTSNOITCENNOC
ROLOCERIWELBACROTCATNOC
KCALB1T
ETIHW2T
NEERGDNUORG

PAGE 18 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —CLEAN-UP
Pump Shut-Down/Clean-up
1. Remove thepowerfromthe pump by turning off the circuit
breakerorswitchthatprovidespowertothepump.Remem-
bertomakesurethathandsaredry(notwet),andfeetarenot
standinginwaterwhenremovingdisconnectingpowerfrom
thepump.
2. Usingtheliftingrope,liftthepumpupfromitscurrentposition.
Removethedischargehosefromthedischargeportonthe
pump.
3. Removeallpowercablesandfloatswitchesfromthecontrol
box.Placecablesandfloatswitchesinasuitablecontainer
wherethey will not get damaged.
4. Ifthepumpwasusedtopumpmud,gritorsilt,flush vigorously
withcleanwater.
5. Removethepumpfromthewater.Wipeoffanymudordebris
thatmighthaveattacheditselftothepump.
6. Store pump in a clean dryplaceawayfromdirtand debris.

ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04) —PAGE 19
ST-1500 SERIES SUB.PUMP —MAINTENANCE
LUBRICATION
To check the oil level of the mechanical seal, perform the
following:
1. Laythepump (Figure11)onitssidewiththeoilplugfacing
upwards.
2. Remove oil fill plug.
3. Visually inspect oil plug hole to verify that oil cavity is full
enoughtocoversealspring.Checkevery300hours,change
hydraulicoilevery 6 months (1,000 hours) or as needed.
4. While checking the hydraulic oil level, also check the
conditionofthehydraulicoilinthesealcavity.Blockthe
opening with a finger and roll pump to one side to drain
oilintoasmalltransparentcontainer.Ifoiliscloudyorhas
waterinit,drainoil frompumpcavityandreplacehydrau-
lic oil. Check the seal for wear damage.
5. If oil level is low fill with SAE 10 weight non-detergent
hydraulicoil(i.e.ShellTurbo32 orequivalent). Filloilcavity
75% to 85% full (allow air space for expansion).SeeTable
1forpump oil cavitycapacity.
IMPELLER
1. Make sure the clearance between the impeller and the
frictiondiskisapproximately.012-.020inches(.304-.508
mm.)
2. Ifimpellerisdefectiveorbadlyworn,replaceimpellerimme-
diately.
Figure 11. Checking Hydraulic Oil
OIL FILL
PLUG
FILL TO 75-80% CAPACITY
SEE TABLE 1 FOR FILLING
CAPACITY.
LAY PUMP FLAT
ON ITS SIDE
FILL WITH 10 WEIGHT NON-
DETERGENT HYDRAULIC
OIL. USE SHELL TURBO 32
OR EQUIVALENT.
REMOVE FILL PLUG, AND
VISUALLY INSPECT THAT
OIL CAVITY IS FULL ENOUGH
TO COVER SEAL SPRING.
CHECK HYDRAULIC OIL
EVERY 300 HOURS. CHANGE
EVERY 6 MONTHS OR AS
NEEDED.
DISCOLORATION OF OIL
(MILKY)INDICATES A LEAKING
PUMP WATER SEAL.
SUBMERSIBLE
PUMP

PAGE 20 —ST-1500 SERIES SUBMERSIBLE PUMPS —OPERATION & PARTS MANUAL —REV. #0 (10/04/04)
ST-1500 SERIES SUB.PUMP —TROUBLESHOOTING
GNITOOHSELBUORTPMUP.8ELBAT
MOTPMYS MELBORPELBISSOP NOITULOS
tratSoTsliaFpmuP
?spma/egatlovtcerrocnI gniebsi)esahp-elgnis,zH06,CAV511(egatlovreporptahtkcehC tnuomaetauqedanasierehttahtkcehcoslA.pmupehtotdeilppus tiucricecruosrewopkcehC.pmupehtnurot)spma(tnerrucfo .rekaerb
?snoitcennoclacirtcelekcehC .drocrewoptcepsni,gniriwkcehcsehctiwstaolfgnisufI
?esufrewopnwolB .esufnwolbfoesuackcehc,esufecalpeR
?dekcolrellepmI rellepmireporpmidnagniggolcrofkcehcdnadrocrewoptcennocsiD .ecivednoitcetorpdaolrevokcehC.pmupgolcnU.ecnaraelc
?sgnidniwrotomteW tsumecnatsisernoitalusnI.noitalusnirotomkcehcotretemitlumesU elbmessasid,wolsiecnatsiserfI.smhoagem51yletamixorppaeb .mehtyrdotsgnidniwekabdnarotompmup
pmupdnarotomevitcefeD ?sgniraeb ecalpeR.sgniraebecalpernrowfi,raewgniraebevissecxerofkcehC .evitcefedfirotom
lluFrevileDotsliaFpmuP tuptuO
egrahcsiddetcirtserrodetsiwT ?esoh .enilesohmorfgolcevomeR.deknik-nutalfesohyaL
?reniartspmupdeggolC .reniartsnaelC
?egatlovwoL egatloV.dezigrenesipmupelihwegatlovkcehcotretemtlovaesU nafI.)daoldnadaolon(ecruosrewopkcehC.%01±nihtiwebtsum gniyrrac-tnerrucetauqedasahtierusekam,desusidrocnoisnetxe .4elbaTeeS.htgnelderiuqerehtrofyticapac
?nrowrellepmI .rellepmiecalpeR
liOlaeSniretaW ?laesretawevitcefeD .laesretawecalpeR
?gulPlliFliOesooL .ylerucesnethgiT
Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a
breakdown,useTable8 (PumpTroubleshooting)as abasic guideline fortroubleshootingthe pump. If theproblemcannotbe
remedied, contact Multiquip's service department.
