Multitech MultiModem ISI ISI3334/4 User manual

Models ISI3334/4
ISI3334/8
Intelligent Serial Interface Card
with
Integrated Data/Fax Modems
Quick Start uide

Quick Start Guide
82085401 Revision B  8/25/00
ISI3334-4/8
This publication ma not be reproduced, in whole or in part, without prior expressed written permission from Multi-Tech
S stems, Inc. All rights reserved.
Cop right © 2000, b Multi-Tech S stems, Inc.
Multi-Tech S stems, Inc. makes no representations or warranties with respect to the contents hereof and specificall
disclaims an implied warranties of merchantabilit or fitness for an particular purpose. Furthermore, Multi-Tech
S stems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Multi-Tech S stems, Inc. to notif an person or organization of such revisions or changes.
Revision Description
A Manual released at Revision A, 7/15/98.
B Revised for universal ISI drivers, Rev B. 8/25/00.
Trademarks of Multi-Tech S stems, Inc.:MultiModem, MultiModemISI, Multi-Tech and the Multi-Tech logo.
MNP, Microcom Network Protocol is a trademark of Microcom Inc.
AT&T is a trademark of American Telephone and Telegraph Co.
UNIX: X/Open Co. Ltd.
MS-DOS: Microsoft Corporation
SCO: The Santa Cruz Operation, Inc.
Pentium: Intel Corporation
PC-DOS: International Business Machines Corporation
Novell, NetWare, NetWare Connect and UNIXWare: Novell Corporation
Xenix:Xerox Corporation
All brand and product names mentioned in this publication are trademarks or registered trademarks of their respective
companies.
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112 U.S.A.
[phone] or [phone]
U. S. FAX [phone]
Technical Support [phone]
Internet Address: http://www.multitech.com

iii
Contents
Chapter 1 - Introduction and Description ...................................................... 5
Introduction .............................................................................................................................................................. 6
Modem Features ...................................................................................................................................................... 6
Fax Features ........................................................................................................................................................... 6
Product Description ................................................................................................................................................. 6
How to Use This Manual .......................................................................................................................................... 7
Chapter 2 - Installation ...................................................................................... 9
Safet Warnings .................................................................................................................................................... 10
Hardware Installation Summar ............................................................................................................................ 10
Determining Current S stem Settings .................................................................................................................... 10
Hardware Installation Procedure ............................................................................................................................. 10
Software/Driver Installation ..................................................................................................................................... 12
Introduction .................................................................................................................................................. 12
WINDOWS 2000
Installing ISI3334 Software for Windows 2000 .............................................................................................. 12
Recommended Base I/O Address and IRQ Values ....................................................................................... 12
Installing Modems to COM Ports in Windows 2000 ..................................................................................... 15
ISI3334 for Windows 2000: Installing ISI Management Software (server OSs onl ) ....................................... 16
Remove ISI3334 Driver (Windows 2000) ....................................................................................................... 16
WINDOWS NT
ISI3334 Software Installation Procedure for Windows NT 3.51/4.0 ................................................................ 16
Recommended Base I/O Address and IRQ Values ....................................................................................... 16
Installing ISI3334 Modems to COM Ports in Windows NT ............................................................................18
Removing ISI3334 Card and Driver in Windows NT 3.51/4.0 .........................................................................20
WINDOWS 95/98
ISI3334 Software Installation Procedure for Windows 95/98 ......................................................................... 20
Recommended Base I/O Address and IRQ Values ....................................................................................... 20
Installing ISI3334 Modems to COM Ports in Windows 95 /98 ...................................................................... 23
Removing the ISI3334 Driver (Windows 95/98) .............................................................................................. 26
NOVELL NETWARE
NetWare Driver Installation ........................................................................................................................... 27
Configuring Ports for NetWare Connect ........................................................................................................ 27
Removing the Driver (Novell) ......................................................................................................................... 27
SCO Open Server 5
SCO Open Server 5 Driver Installation .......................................................................................................... 28
To install from CD-ROM: ............................................................................................................................... 28
To format a flopp disk for SCO5: ................................................................................................................. 28
To untar the driver file and cop files onto flopp disk: .................................................................................. 28
To install driver from flopp disk .................................................................................................................... 29
MultiTech Installation Script ......................................................................................................................... 30
Activating Ports in SCO Open Server 5 ........................................................................................................ 31
Multi_Setup Utilit ........................................................................................................................................ 32
Multi_View Utilit Installation ....................................................................................................................... 33
Description File Format ................................................................................................................................ 34
Hot Ke Entries............................................................................................................................................ 34
Terminal Escape Sequences ........................................................................................................................ 34
Timing Specification ..................................................................................................................................... 35
Administration Utilit .................................................................................................................................... 36
Removing the Driver (SCO Open Server 5) .................................................................................................... 36

iv
LINUX
Linux Driver for ISI3334 Server Cards ........................................................................................................... 37
LINUX: Pre-Installation Issues ...................................................................................................................... 37
LINUX: Cop ing the driver from the media .................................................................................................... 37
LINUX: Cop ing and untarring the driver from CD-ROM ................................................................................. 37
LINUX: Cop ing and untarring the driver from a flopp ................................................................................... 37
Steps for cop ing the driver from a flopp : .................................................................................................... 37
LINUX: Driver installation and loading ........................................................................................................... 38
LINUX: Setting the baud rate ........................................................................................................................ 38
LINUX: Verif ing the ports ............................................................................................................................. 38
LINUX: TTY Devices Created b the Drivers: ................................................................................................ 38
LINUX -- Dial-in configuration: ....................................................................................................................... 39
LINUX -- PPP setup: ..................................................................................................................................... 40
Removing the ISI Driver (Linux) ..................................................................................................................... 40
Chapter 3 - Service, Warranty & ech Support ........................................... 41
Introduction ............................................................................................................................................................ 42
Multi-Tech Warrant & Repair Policies ................................................................................................................... 42
Addendum for North American Products ................................................................................................................ 42
Addendum for International Products ..................................................................................................................... 43
Recording MultiModemISI Information .................................................................................................................... 43
Out of Warrant Repair Cost Charts ...................................................................................................................... 43
Index ................................................................................................................. 45

Chapter 1 - Introduction and Description

ISI3334-4/8 Quick Start Guide
6
Introduction
Welcome to the world of data communications. You have acquired one of the finest Intelligent Serial Interface cards
available toda , the MultiModemISI. The MultiModemISI integrates ISI mutiport and Enhanced V.34 modem
technolog on a single board. It is a "full sized" add-on card which supports a high-speed interface up to 115.2K
bps per port. This card has multiple on-board Enhanced V.34 (33.6K bps) data/V.17 (14.4K bps) fax modems
providing high speed buffering for multiple serial ports.
This User Guide contains product information specific to the modem aspect of this card (e.g., AT Commands and
S-Registers), as well as hardware and driver installation procedures. Driver and hardware installation is also covered
in the MultiModem ISI Quick Start Guide included in our shipping package.
Modem Features
Your MultiModemISI meets the proposed Enhanced V.34 ITU standard for data signalling rates as high as 33.6/
31.2K bps full-duplex mode, and supports and is compatible with those features, including EIA extended
Automode, adaptive line probing, automatic s mbol rate and carrier frequenc during start-up, and retrain and rate
renegotiation (in 2400 bps increments).
Your MultiModemISI features CCITT V.42 error correction and V.42bis data compression, providing 100% error-free
data transmission. V.42 error correction incorporates MNP Classes 3 and 4, and LAP-M. You ma select V.42bis
data compression for 4-1 throughput, or MNP Class 5 for 2-1 throughput.
Your MultiModemISI offers interactive automatic dialing, as well as Command Mode option configuration. You ma
store up to ten command line/telephone numbers, of up to 60 characters each, in the MultiModemISIs nonvolatile
memor .
The MultiModemISI pulse or tone dials, and recognizes dial tones and bus signals for reliable call-progress
detection. The MultiModemISI can detect AT&T calling card tones. It is FCC-Registered for connection to telephone
networks without an Data Access Arrangements (DAAs).
Your MultiModemISI also features Remote Configuration which permits ou to assist users at remote sites, saving
ou the time and trouble of site visits and preventing misinterpretation of configuration instructions.
Fax Features
Your MultiModemISI meets the CCITT V.17 standard for sending and receiving faxes. When linked to a compatible
fax machine or modem, it can transmit faxes at 14.4 K bps. It also meets the CCITTs Group 3 Designation for
sending and receiving faxes at 9600 bps; and Group 2 Designation for sending and receiving faxes at 4800 bps. The
MultiModemISI is also downward-compatible to speeds as low as 300 bps, so it can send and receive faxes with
virtuall an fax machine in the world.
Product Description
The MultiModemISI is ideall suited to use in PC networks environments because it provides an integrated
hardware solution for remote access for both Windows 95/98, Windows NT, Windows 2000 and Novell-based
LANs. In particular, to ensure smooth Novell network integration, the MultiModemISI ships with NetWare Loadable
Module for NetWare ConnectTM communication servers that enable it to support state-of-the-art features such as
remote dialing and modem pooling. And, the MultiModemISI easil integrates into the Windows 95/98, Windows NT
and WIndows 2000 platforms since it full supports Microsoft's Remote Access Server software. This allows it to
operate with popular network protocols such as TCP/IP and NetBIOS. Also, the MultiModemISI ships with drivers
for SCO Open Server 5®.
The MultiModemISI includes an Intel 16 MHz 80186 proccesor and 256K of RAM that work d namicall to allocate
resources to the most active modems.
Simple to install, the MultiModemISI can be used to add multiport, Enhanced V.34 modem communications to a
network host or server as easil as plugging in an expansion card, running the driver software, and connecting the
phone lines.

Chapter 1 - Introduction and Description
7
Network managers have the option of starting with the basic four modem configuration (model #ISI334/4), and then
adding four more modems at a later date without having to use another PC expansion slot.
This is accomplished b pairing one MultiModemISI with an auxiliar module (model #ISI3334/EC) interfacing both
with on-board connectors.
Some MultiModemISI on-board components include one jumper block for activating the number of ports in
increments of 4 or 8. One bank of 8 DIP-Switches for I/O address selection and one IRQ jumper block, that control
both the MultiModemISI and auxiliar module I/O addressing and IRQ values.
When installing a single MultiModemISI in our PC, the installation scripts create 8 devices. The first 4 devices are
active, however, the 4 devices on the auxiliar module are not active until connected to the MultiModemISI.
How to Use his Manual
This manual is divided into four chapters and six appendices. The information contained in each chapter and
appendix is as follows:
Chapter 1 Introduction and Description
Chapter 1 begins with a short product introduction and description; followed b a guide (which ou are now reading)
to the use of this manual.
Chapter 2 Hardware and Driver Installation
This chapter will guide ou through the installation of our MultiModem ISI card(s). This includes installation of our
card and the loading of a driver that is specific to our operating s stem. In addition this chapter also gives
descriptions of the Multi-Tech installation script and Multi_View Utilit .
Chapter 3 "AT" Commands and S Registers
This chapter focuses on the use of AT Commands and S-Registers. Chapter 3 provides basic steps for originating
and answering calls and a summar of commands that enable the user to establish, read, and modif parameters
in addition to dialing. Information on Remote Configuration commands is also provided in this chapter.
Chapter 4 Service, Warranty & Technical Support/BBS
Chapter 4 provides instructions for getting the MultiModemISI serviced at the factor and warrant information.
Includes instructions for accessing technical support via the Internet.
Appendices
Appendix A - Technical Specifications
Appendix B - ISI Testing Utilities
Appendix C - Tone Dial Frequencies
Appendix D - Regulator Information
Appendix E - I/O Addressing
Appendix F - Auxiliar Module (ISI3334/EC) Installation

ISI3334-4/8 Quick Start Guide
8

Chapter 2 - Installation

ISI3334-4/8 Quick Start Guide
10
Safety Warnings
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specificall designed for wet locations.
3. This product is to be used with UL and CUL listed computers.
4. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the
network interface.
5. Use caution when installing or modif ing telephone lines.
6. Avoid using a telephone (other than a cordless t pe) during an electrical storm. There ma be a remote risk of
electrical shock from lightning.
7. Do not use the telephone to report a gas leak in the vicinit of the leak.
Hardware Installation Summary
This section provides ou with procedures for installing the MultiModemISI card(s) in our ISA or EISA bus personal
computer (or compatible with 16 bit ISA slot).
Hardware installation involves:
1) Opening our PC.
2) Setting card configuration (determining I/O address DIP-Switch setting and IRQ jumper setting).
3) Installing the card into the PC.
Determining Current System Settings
When ou install a device into our computer, the processor must have a means of routing information to and from
the device and the device must have a means of gaining the processor's attention. These are called Input/Output (I/
O) addresses and Interrupt Requests (IRQs), respectivel . The MultiModemISI card requires 16 I/O addresses and
one IRQ value which are not used b an other device in our s stem. When selecting a unique base I/O address,
be sure that the next address is also unused. You can install up to four MultiModemISI cards into our s stem.
Each card is shipped with its IRQ set at level 10 and a base I/O address of 210 hex. Check our s stems device
settings to see if these values can be used. If the defaults are alread in use, select a unique IRQ and I/O address
and record those values for the hardware and software installation sections that follow. For more information on I/O
addressing, see Appendix E.
Note If ou choose IRQ 3 or 4, ou ma have to disable a COM device from our BIOS setup. Also, most 386 or
higher compatible computers will not be able to assign IRQ2 to the MultiModemISI card because IRQ2 is used for
slave interrupt control.
Hardware Installation Procedure
Perform the following procedures to install the MultiModemISI card(s) into our PC-ISA bus computer. Installation
procedures include setting the I/O address switch block and the IRQ jumper. If ou have selected the default values
of: I/O Address 210 Hex and IRQ 10, certain steps ma be unecessar . However, if ou are installing multiple
cards, step 4a of the following procedure describes how to configure our card(s).

Chapter - Installation
11
Installation Procedure
Step Procedure
1 Make sure our computer and an peripheral equipment connected to it are turned off. Failure to do so ma
damage both our ISI card(s) and our PC. The MultiModemISI ma be installed in a PC-AT, 386, 486, or
Pentium equivalent ISA or EISA bus computer.
2 Remove the cover of our computer as instructed in our computers documentation.
3 Locate the unused slot(s) which ou will be using for our MultiModemISI card(s), and remove the slot cover(s)
per the instructions in our computers documentation.
4 Check the settings of the I/O address switch and the IRQ jumper to ensure that the are set properl for our
installation.
Note One MultiModemISI can be paired with an auxiliar module (model #ISI3334/EC) when it interfaces with
on-board connectors attaching both cards; effectivel providing 8 modem functionalit . For details on this
process, see Appendix F.
4a The default setting for the MultiModemISIs base I/O address is 210 hex. The default value for the IRQ jumper is
IRQ 10. Choose the IRQ value b covering the appropriate pins with the shorting plug (supplied). If our s stem
requires a different setting or if ou are installing multiple cards, refer to Appendix E for a table of valid address
settings.
5 Install the MultiModemISI card(s) into the selected expansion slot(s) in the same manner as an other add-on
card, as instructed in our computers documentation.
6 Fasten the retaining bracket to the computer chassis and replace the cover.
7 Your MultiModemISI card(s) requires a modular LINE JACK. This is t picall an RJ11C or RJ11W jack, but
could also be an RJ12 or RJ13 jack. To connect the modem(s) to the PSTN line(s), plug one end of the RJ11
cable(s) that is provided with the modem into the LINE JACK connector(s) and the other end into the phone-
compan -provided RJ11C or RJ11W modular phone jack(s).
Note An cables connected to the computer must be shielded to reduce interference.
8 Turn power on to the computer and proceed to the next section, Driver Installation, to install the MultiModemISI
drivers.

ISI3334-4/8 Quick Start Guide
1
Software/Driver Installation
Introduction
This chapter describes software/driver installation for the ISI cards when used in Windows 2000, Windows NT4,
Windows NT3.51, Windows 95/98, Novell Netware, Linux, and SCO Open Server 5 (with informationon the
MultiTech Installation Script and other SCO-related utilities). We also describe installation of MultiTechs
Management Software for use with ISI cards under Windows 2000.
The process of installing a device driver consists of a modification to our s stem. For this reason, onl the "super
user" (s stem administrator) is allowed to perform the installation. If ou cannot login as the root, supervisor or
admin ou must find the person in our organization who has this authorization (i.e., password). To begin the driver
installation, login as root, supervisor or admin. Then proceed with the appropriate section.
Installing ISI3334 Software for Windows 2000
1. Turn off the PC.
2. The ISI3334 card must already be installed in an ISA expansion slot in the PC. If it is not follow the PC manufacturer's
instructions concerning installation of expansion cards. Observe standard precautions regarding electro-static discharge
(ESD) when handling the ISI3334 board (the board should be kept in its shipping bag until used). During installation
handle the ISI3334 circuit card by its edges and keep one hand in contact with the PC chassis. Set the Base I/O Address
and the Interrupt Request (IRQ) values per the table below:
Recommended Base I/O Address and IRQ Values
ISI3334 Base I/O Address IRQ
Initial 8 port board 210h 10
First 8 port upgrade 220h 11
Second 8 port upgrade 230h 12
Third 8 port upgrade 240h 15
The I/O Address DIP Switch and the IRQ Jumper Block are located in the corner of the card that lies diagonally across from
the ISA bus.
3. Turn on the PC and start Windows 2000.
4. Insert the diskette containing the driver files for Windows 2000 into the floppy drive (the driver files may be on CD-ROM
instead).
5. Go to Start | Settings | Control Panel | Add/Remove Hardware.
Click Next.
6. At the C oose a Hardware Task screen select "Add/Troubleshoot a device." Click Next.
7. At the C oose a Hardware Device screen select "Add a new device." Click Next.
8. At the Find New Hardware screen select "No I want to select the hardware from a list." Click Next.
9. At the Hardware Type screen select "Multi-port serial adapters." Click Next.
10. At the Select a Device Driver screen click on Have Disk.
11. At the Install from Disk screen enter the path of the driver files (i.e. the file directory location in most cases on CD-
ROM). Click OK.

Chapter - Installation
13
12. In the Models list highlight "Multi-Tech ISI4608-ISA 4 Port Serial Card" for ISI3334-4 or "Multi-Tech ISI4608-ISA 8 Port
Serial Card" for ISI3334-8. Click Next.
A comment screen appears indicating that the Base I/O Address and IRQ must be specified for the ISI3334 card. Click OK.
13. The Add New Hardware Wizard Properties screen appears.

ISI3334-4/8 Quick Start Guide
14
A. In the Resource Settings field select "Input/Output Range" and click on Change Setting. The Edit Input/Output Range
screen appears.
Select the value that matches the Base I/O Address value that you have already set on the ISI3334 board in Step 2. Click
OK.
B. In the Resource Settings field select "Interrupt Request" and click on C ange Setting. The Edit Interrupt Request
screen appears.
Select the value that matches the IRQ value that you have already set on the ISI3334 board in Step 2. Click OK. At the
Resources tab click OK again.
14. At the Start Hardware Installation screen click Next.
15. The Digital Signature Not Found screen appears. (Dont worry. This screen merely indicates that the ISI driver was
created after the Windows 2000 native device list was created and was therefore not included. The ISI driver is
nonetheless designed to operate in Windows 2000.) Click Ye s.
A transient progress screen appears while files are being copied.
16. A completion screen appears. Click Finis .
17. You will be prompted to restart your computer. Click Ye s .

Chapter - Installation
15
Installing Modems to COM Ports in Windows 2000
1. After the ISI driver has been installed and rebooting is complete, the ISI ports will be detected (the Found New
Hardware screen will appear).
2. When all of the modem ports of the ISI3334 have been detected, the Found New Hardware Wizard -
Welcome screen will appear. Click Next.
3. The Install Hardware Device Drivers screen will appear. Select "Search for a suitable driver ... ." Click Next.
4. The Locate Driver Files screen will appear. Select "CD-ROM drives ... ." Click Next.
5. The Driver Files Search Results screen will appear. Click Next.
6. A completion screen will appear. Click Finish.
7. The Found New Hardware screen will appear repeatedl , once for each modem on the ISI3334 card (4 or 8
times, depending on the model).
8. To confirm the installation of the ISI3334 modems to COM ports, go to Start | Settings | Control Panel |
System. Click on the Hardware tab. Click on the Device Manager button.
9. Installation of ISI3334 modems to COM ports is complete.

ISI3334-4/8 Quick Start Guide
16
ISI3334 for Windows 2000: Installing ISI Management Software (server OSs
only)
If ou are using a Windows 2000 Server operating s stem ("Server" or "Advanced Server"), ou must decide
whether ou want to use the MultiTech ISI Management Software in conjunction with our ISI3334 board. The ISI
Management Software is shipped with the ISI card and, alternativel , can be downloaded from the MultiTech web
site (www.multitech.com).
1. Turn on your computer and start Windows 2000.
2. Insert the CD-ROM or diskette containing the ISI Management Software into your CD-ROM or floppy drive.
3. Go to Start | Run. In the Run window enter the file path at which the ISI Management Software setup program is located;
for example D:\MANAGEMENT\SETUP.EXE.
Click OK.
4. The ISI Management setup screen appears. At the Welcome screen click Next.
5. A progress screen appears while files are copied. If the Error Creating Virtual WWW Server message appears it may
indicate that there was an attempt to install the ISI Management Software on a client version of Windows 2000. (The ISI
Management Software can be installed only in the Windows 2000 Server and Windows 2000 Advanced Server operating
systems.)
6. A completion screen appears. Select "Yes I want to restart my computer now" and click Finis .
After the computer has restarted the installation of the driver and of the ISI Management Software will be complete.
##?## begin insert ##?##
Remove ISI3334 Driver (Windows 2000)
1. Go to Start | Settings | Control Panel.
2. Click on Add/Remove Hardware. Click Next.
3. Click on Uninstall/Unplug a device and click Next.
4. In the subsequent screen click on Uninstall a device and click Next.
5. At the Add/Remove Hardware WIzard screen highlight the ISI driver file for the specific server card that you intend to
remove. Click Next.
6. When you are asked to confirm removal click on the Yes radio button and click Next.
7. Click Finis . You can remove the driver for only one ISI3334 card at a time.
ISI3334 Software Installation Procedure for Windows N 3.51/4.0
1. Turn off the PC.
2. The ISI3334 card must be installed in an ISA expansion slot in the PC. If it is not already installed install the ISI3334
card according to the PC manufacturer's instructions. Observe standard precautions regarding electro-static discharge
(ESD) when handling the ISI3334 board (the board should be kept in its shipping bag until used). During installation
handle the ISI3334 circuit card by its edges and keep one hand in contact with the PC chassis. Set the Base I/O Address
and the Interrupt Request (IRQ) values per the table below:
Recommended Base I/O Address and IRQ Values
ISI3334 Base I/O Address IRQ
Initial 8 port board 210h 10
First 8 port upgrade 220h 11
Second 8 port upgrade 230h 12
Third 8 port upgrade 240h 15
The I/O Address DIP Switch and the IRQ Jumper Block are located in the corner of the card that lies diagonally across from
the ISA bus.

Chapter - Installation
17
3. Turn on the PC and start Windows NT.
4. Insert the ISI driver CD-ROM into the CD-ROM drive. (In some cases drivers may be downloaded from the MultiTech
web site and saved onto diskette. If so insert diskette into floppy driver now.)
5. Click Start | Settings | Control Panel | Network | Adapters. Then click Add.
6. The Select Network Adapter dialog box appears. Click Have Disk.
7. The Insert Disk dialog box appears. Type the path (file directory location) of the Windows NT driver. Click OK.
8. The Select OEM Option dialog box appears. Click OK.
A transient dialog box will appear indicating the progress of the setup program.
9. The ISI Cards dialog box appears. Click Add.
10. Then the ISI Card Settings dialog box appears. Enter the correct port count:
 allocate 4 ports for the ISI3334-4;
 allocate 8 ports for the ISI3334-8.
Select the first port number for ISI modems which is usually COM3.
Click "ISA" in the Bus Type field. Enter the Base I/O Address and IRQ as in Step 2 above.
11. The ISI Cards dialog box appears again and shows the port resource allocation just made. To add more cards click
Add and repeat Step 9.

ISI3334-4/8 Quick Start Guide
18
After the last ISI card has been added click Close.
12. The file is copied and "Multi-Tech ISI3334 Adapter" or "Multi-Tech 4 8 16-port ISI Card" will appear in the Network
Adapters box. Click Close.
13. When prompted about restarting your computer click Ye s .
The ISI3334 card software is now installed in Windows NT.
Installing ISI3334 Modems to COM Ports in Windows N
To install modems:
1. Go to Start | Settings | Control Panel | Modems. In the General tab of the Modems Properties dialog box click Add.
2. The Install New Modem dialog box appears. Check the box marked Don't detect my modem; I will select it from a list.
Then click Next.
3. The Install New Modem dialog box appears. In the Manufacturers list select "MultiTech Systems." From the Models list
select MultiTec ISI3334. Then click Next.
4. Select ports for modem use.

Chapter - Installation
19
 For the ISI3334-4 you should have reserved 4 modem ports during driver installation.
 For the ISI3334-8 you should have reserved 8 modem ports during driver installation.
Click Next. The modems will be installed to the selected COM ports.
5. After the modems install to the ports click Finis to return to the General tab.
6. To view COM port assignments and make necessary changes use the Modems Properties dialog box (accessible from
Start | Settings | Control Panel | Modems).
7. Close the Modems Properties dialog box. You will be prompted to configure dial-up networking.
Click Ye s .
8. The Remote Access Setup dialog box appears. Click Add.
9. Each COM port appears in a separate Add RAS Device dialog box.
To add the highlighted device click OK.
10. The Remote Access Setup dialog box displays again. Repeat steps 7 - 9 until all devices are added.

ISI3334-4/8 Quick Start Guide
0
11. When all devices have been added click Continue.
12. After the bindings have been reviewed and stored you will be prompted to restart your computer. Click Ye s .
Removing ISI3334 Card and Driver in Windows N 3.51/4.0
1. Go to Start | Settings | Control Panel | Network. Click on the Adapters tab.
2. Select "MultiTech 4 8 16-port ISI card " and then click Remove.
To complete the un-install procedure, restart your computer.
ISI3334 Software Installation Procedure
for Windows 95/98
1. Turn off the PC.
2. The ISI3334 card must be installed in an ISA expansion slot in the PC. If it is not already installed install the ISI3334
card according to the PC manufacturer's instructions. Observe standard precautions regarding electro-static discharge
(ESD) when handling the ISI3334 board (the board should be kept in its shipping bag until used). During installation
handle the ISI3334 circuit card by its edges and keep one hand in contact with the PC chassis.
Set the Base I/O Address and the Interrupt Request (IRQ) values per the table below:
Recommended Base I/O Address and IRQ Values
ISI3334 Base I/O Address IRQ
Initial 8 port board 210h 10
First 8 port upgrade 220h 11
Second 8 port upgrade 230h 12
Third 8 port upgrade 240h 15
The I/O Address DIP Switch and the IRQ Jumper Block are located in the corner of the card that lies diagonally across from
the ISA bus.
3. Turn on the PC and start Windows 95/98.
4. Insert the ISI driver CD-ROM into the CD-ROM drive. (In some cases drivers may be downloaded from the MultiTech
web site and saved onto diskette. If so insert diskette into floppy drive now.)
5. (Follow either 5A or 5B but not both.)
A. From Windows Explorer open the 95-98 directory on the CD-ROM or floppy drive that contains the ISI driver file.
Highlight the file setup.exe.
B. From the Start menu go to Run. Browse to the path of the 95-98 directory.
