Zte MF668A User manual

1
ZTE MF668A HSPA+ USB Modem
User Manual

2
Contents
1 Modem Introduction........................................................4
1.1 Introduction ..........................................................................................4
1.2 Warning and Notice..............................................................................4
1.3 Applicability Scope...............................................................................6
1.4 System requirements...........................................................................6
1.5 Functions..............................................................................................7
1.6 Specification.........................................................................................7
2 Installation........................................................................8
2.1 Outline and Parts .................................................................................8
2.2 Hardware Installation ...........................................................................8
2.3 Software Installation...........................................................................10
2.4 Run the Application Software.............................................................14
2.5 Hardware Uninstall.............................................................................15
2.6 Software Uninstall..............................................................................15
3 Functions & Operation..................................................18
3.1 Interface introduction..........................................................................18
3.1.1 Main Interface.........................................................................18
3.1.2 Description of Mini Icons.........................................................19
3.2 Connecting to the Internet..................................................................20
3.3 SMS....................................................................................................21
3.3.1 Check SMS.............................................................................22
3.3.2 Create a new message...........................................................23
3.3.3 The SMS box operating guide................................................25
3.4 Phonebook.........................................................................................25
3.5 Settings ..............................................................................................27
3.5.1 Connection settings ................................................................28
3.5.2 Selection settings....................................................................30
3.5.3 Preference settings.................................................................30
3.5.4 SMS Settings..........................................................................31
3.5.5 Sound settings........................................................................32
3.5.6 Security settings......................................................................32

3
3.5.7 System settings.......................................................................33
3.5.8 Update settings.......................................................................33
3.6 Data record ........................................................................................34
3.7 MicroSD card .....................................................................................34
3.8 Help....................................................................................................34
4 FAQ .................................................................................35

4
1 Modem Introduction
1.1 Introduction
Thank you for purchasing ZTE MF668A HSPA+ USB Modem.
To guarantee that the modem is always in its best condition, please read this
manual carefully and keep it for further use.
The pictures, symbols and contents in this manual are just for your reference.
They might not be completely identical with your modem. ZTE operates a policy
of continuous development and reserves the right to update the technical
specifications in this document at any time without prior notice.
The ZTE MF668A HSPA+ USB Modem is a type of multi-mode, 3G modem,
suitable for GSM/GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA+ networks. With a
USB interface connecting to a laptop or a desktop PC, it integrates the
functionality of a modem and a mobile phone (SMS and phonebook), combining
mobile communication with internet perfectly. While connected to the mobile
network, it can help you get SMS, data service and will help you break away
from the limit of time and space, and realize wireless communication at any
moment everywhere.
1.2 Warning and Notice
To the owner
The use of electronic transmitting devices is forbidden in aircraft, at petrol
stations and in hospitals. Please observe and obey all warning signs and
switch off your modem in these conditions.
Operating USB modem may interfere with medical devices like hearing aides
and pacemakers.
Be aware of warning signs in places such as oil refineries or chemical
factories where there are explosive gases or explosive products being
processed.
Store the USB modem out of the reach of children. The USB modem may
cause injury if used as a toy or may be damaged by rough play or moisture.
Do not open the cover and touch the metallic (U)SIM bracket when the
modem is working. Otherwise, you may get a burn.
Modem
The USB modem must only be used with a PC that is certified to IEC 60950-1
(or equivalent) or a PC that has a power supply that is certified to IEC
60950-1 (or equivalent) or a PC that is powered by an internal battery and
that has no connection to mains power.

5
Only use original accessories supplied by the manufacturer. Using
unauthorised accessories may invalidate your warranty.
Avoid using the USB modem near or inside metallic structures or
establishments that can emit electromagnetic waves.
The USB modem is not waterproof. Please keep it dry and store it in a cool
place out of direct sunlight.
Handle the USB modem with care. Don’t drop, bend, knock or treat it harshly
to avoid damage to the unit.
There are no user serviceable parts. Dismantling the unit will invalidate the
warranty.
Operating temperature range of -10℃～+60℃and humidity 5%~95% are
recommended.
Health and safety information
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government:
The exposure standard for wireless USB modem employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted
by the FCC with the phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the poser required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower the power output.
The highest SAR value for the USB modem as reported to the FCC when tested for
use at body is 1.18 W/kg.
While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
SAR information on this model phone is on file with the FCC and can be found under
the Display Grant section of http://www.fcc.gov/oet/fccid after searching on
FCC ID: Q78-MF668A
FCC Compliance （only Part 15B）

6
This device complies with part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
Caution: Changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
1.3 Applicability Scope
ZTE MF668A HSPA+ USB Modem supports the present mainstream types of
laptops and desktop PCs, such as HP, IBM, Toshiba, Lenovo, Dell, Sony, Apple,
etc.
1.4 System requirements
Operating System: Windows XP, Vista, Windows 7, MAC OS
Configuration (Recommended):
CPU 1GHz Pentium or above
Hard Disk 20MB or above
RAM 512MB or above

7
The performance of the modem may be influenced if configuration is below the
recommendation.
1.5 Functions
SMS service, data service, application management, microSD card supported,
etc.
1.6 Specification
Interface Type USB 2.0 high speed
Systems supported Supports most types of laptop and desktop PC.
Operating systems Windows XP, Vista, Windows 7, MAC OS
Functions SMS service, Data service, Applications
management, support microSD card, etc.
Network Standards HSPA+/HSUPA/HSDPA
/UMTS/EDGE/GPRS/GSM
Frequency band HSDPA /UMTS: 2100MHz
GSM/GPRS/EDGE: 1800/900MHz
Transmission
(Max. data rate) HSPA+: 21.6Mbps DL
5.76Mbps UL
Temperature Storage: -40℃～+80℃
Operation: -10℃～+60℃
Dimension 76.77mm×28.0mm×11.92mm
Weight About 30g
MicroSD Capability Up to 8G

8
2 Installation
2.1 Outline and Parts
1. Back cover
2. LED Indicator
3. Rotating USB connector
4. External antenna port
2.2 Hardware Installation
1. Insert the SIM/USIM card into the USB Modem
Your SIM/USIM card stores your service details, phonebook and text messages.
You can obtain it from a mobile phone service provider when you sign on as a
subscriber.
To install SIM/USIM card
Remove the back cover on the modem.
Hold your SIM/USIM card with the cut corner oriented as shown and then
slide it into the card holder with the metal contacts facing the modem.

9
Remove the back cover Slide the card into place
Replace the back cover.
To remove SIM/USIM card from the USB modem
Remove the modem from the computer.
Remove the back cover.
Pull out the SIM/USIM card from the card holder.
Pull out the card Replace the back cover
2. Install memory card
You can use a compatible microSD card to save more data. Only microSD card
is supported by the modem and do not insert other memory card into the
modem.
Remove the back cover of the USB modem.
Insert the microSD card into the holder until you hear a click. Make sure
that the memory card is orientated as shown in the following picture.

10
Replace the back cover.
The driver of the microSD card will be installed automatically when the modem
driver is installed.
3. Connect the USB modem to your PC
Plug the modem to the USB port of your computer. Make sure that it is
tightly inserted.
Your PC system will automatically detect and recognize the new hardware
and display a new icon in the desktop taskbar, indicating that the computer
and the USB modem have been connected properly.
If you are using Windows XP, Vista, Windows 7 or Mac OS X system, the
installation program will start automatically after a few seconds.
2.3 Software Installation
If your laptop or destop PC supports automatic installation, the following
installation interface will appear on the screen a few seconds after your PC
recognizes the new hardware.
If your PC doesn’t support automatic installation, start the installation program by
running the Install.exe from the new CD-ROM drive in My Computer or
Computer. The following installation interface will show how to start installation.

11
1. It is strongly recommended that you exit all other Windows programs, before
clicking on “Next”;

12
2. Select the folder that you want to install the software to. You can select a
different path by clicking “Change”;
4. Click “Next” to start the installation of the MF668A Modem connection
manager software;

13
5. The system shows the installation progress. Wait a minute until the following
screen appears;

14
6. Click “Finish” to complete the installation.
Note: After the software is installed, pull out the modem before restarting the
computer to avoid damages to your modem. If you have problems with the
installation steps above, please contact your service provider or ZTE.
After the installation, select Start > Programs > Join Air. You can find Join Air
and Uninstall. There will be a shortcut icon on the desktop just as follows.
2.4 Run the Application Software
After the modem is correctly connected to the computer, click Start >
Programs > Join Air > Join Air on the computer to run the application software.

15
You can also launch the application software by double-clicking the shortcut icon
shown above.
After the modem is initialized, the main interface of the connection manager
appears. The standby icon appearing in the taskbar indicates the modem
working normally.
2.5 Hardware Uninstall
Close the software then remove the hardware following the procedures below.
1. Click the close button ;
2. Click “OK” to close the software;
3. Safely remove the USB modem.
2.6 Software Uninstall
1. Close the application program before uninstall;
2. Click Start > Programs > Join Air > Uninstall on the PC;
3. Click Yes to confirm the removal of the software;
4. Make sure to remove the modem device from the computer before clicking
Yes to start uninstall.
The following interface indicates the uninstall progress.

16
5. Click “Finish” to complete the uninstall of Join Air.

17

18
3 Functions & Operation
3.1 Interface introduction
3.1.1 Main Interface
The following picture is the starting screen of your MF668A connection manager.
The whole interface is divided into four parts. Related functions can be executed
by operation in the related areas.
System information area
Icons in this area show the system status and different kinds of tips.
Icon
Explanation
Indication of signal strength, which is divided into 6 stages from
none to the strongest.
Indication of current network type.
Roaming.
Packet switched
Circuit switched
Internet information area
This area shows the name of the current service provider, device condition and
connection information.
Function
button area
System
information
area
Main menu
button area
Internet
information
area

19
Function button area
There are five function button icons.
SMS: Send, read and manage SMS.
Phonebook: Manage contact information.
Settings: Setting options for the modem.
Data record: Show connection information.
Connect: Connect to the Internet.
Main menu button area
Click the icon to popup the following menu:
Log: The record of software operation.
Diagnostics: View hardware information, operational information and network
settings.
Help: Enter connection manager software help.
Exit: Close the software.
3.1.2 Description of Mini Icons
Click the minimize button and the software will minimize as an icon on the
taskbar. This will not influence data transfer or sending and receiving of SMS.
Double click the icon on the taskbar to restore the window.
Taskbar icons description
The USB modem is ready to connect to the Internet.
The USB modem is connected to the Internet.
The uses of taskbar icons
Right click the taskbar icons, the following menu will appear. Please refer to
Main menu button area in Section 3.1.1.

20
Log: The record of software operation.
Diagnostics: View hardware information, operational information and network
settings.
Help: Enter connection manager software help.
Exit: Close the software.
3.2 Connecting to the Internet
With the help of MF668A USB Modem, you can access the Internet and browse
web pages while still be able to send and receive SMS.
Click the “Connect” button . The system will search for available networks
automatically. You can click “Cancel” button to cancel connection.
When connected, connection duration and data record will be shown in the
Internet information area. Then you can access the Internet and receive email
etc, through the network.
