Telit Wireless Solutions CE910 Series Installation manual

CE910 Series Hardware User
Guide
1vv0301010 Rev.11 –2015-10-27

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 2 of 75
APPLICABILITY TABLE
PRODUCT
CE910-DUAL
CE910-SC
CE910B-DUAL

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 3 of 75
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Notice
While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no
liability resulting from any inaccuracies or omissions in this document, or from use of the information
obtained herein. The information in this document has been carefully checked and is believed to be
entirely reliable. However, no responsibility is assumed for inaccuracies or omissions. Telit reserves
the right to make changes to any products described herein and reserves the right to revise this
document and to make changes from time to time in content hereof with no obligation to notify any
person of revisions or changes. Telit does not assume any liability arising out of the application or use
of any product, software, or circuit described herein; neither does it convey license under its patent
rights or the rights of others.
It is possible that this publication may contain references to, or information about Telit products
(machines and programs), programming, or services that are not announced in your country. Such
references or information must not be construed to mean that Telit intends to announce such Telit
products, programming, or services in your country.
Copyrights
This instruction manual and the Telit products described in this instruction manual may be, include or
describe copyrighted Telit material, such as computer programs stored in semiconductor memories or
other media. Laws in the Italy and other countries preserve for Telit and its licensors certain exclusive
rights for copyrighted material, including the exclusive right to copy, reproduce in any form,
distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted
material of Telit and its licensors contained herein or in the Telit products described in this instruction
manual may not be copied, reproduced, distributed, merged or modified in any manner without the
express written permission of Telit. Furthermore, the purchase of Telit products shall not be deemed
to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights,
patents or patent applications of Telit, as arises by operation of law in the sale of a product.
Computer Software Copyrights
The Telit and 3rd Party supplied Software (SW) products described in this instruction manual may
include copyrighted Telit and other 3rd Party supplied computer programs stored in semiconductor
memories or other media. Laws in the Italy and other countries preserve for Telit and other 3rd Party
supplied SW certain exclusive rights for copyrighted computer programs, including the exclusive
right to copy or reproduce in any form the copyrighted computer program. Accordingly, any
copyrighted Telit or other 3rd Party supplied SW computer programs contained in the Telit products
described in this instruction manual may not be copied (reverse engineered) or reproduced in any
manner without the express written permission of Telit or the 3rd Party SW supplier. Furthermore, the
purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents or patent applications of Telit or other 3rd Party
supplied SW, except for the normal non-exclusive, royalty free license to use that arises by operation
of law in the sale of a product.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 4 of 75
Usage and Disclosure Restrictions
License Agreements
The software described in this document is the property of Telit and its licensors. It is furnished by
express license agreement only and may be used only in accordance with the terms of such an
agreement.
Copyrighted Materials
Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by
law. No part of the software or documentation may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or by any means,
without prior written permission of Telit
High Risk Materials
Components, units, or third-party products used in the product described herein are NOT fault-tolerant
and are NOT designed, manufactured, or intended for use as on-line control equipment in the
following hazardous environments requiring fail-safe controls: the operation of Nuclear Facilities,
Aircraft Navigation or Aircraft Communication Systems, Air Traffic Control, Life Support, or
Weapons Systems (High Risk Activities"). Telit and its supplier(s) specifically disclaim any expressed
or implied warranty of fitness for such High Risk Activities.
Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service
names are the property of their respective owners.
Copyright © Telit Communications S.p.A.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 5 of 75
Contents
1. Introduction ...................................................... 8
1.1. Scope .......................................................... 8
1.2. Audience ....................................................... 8
1.3. Contact Information, Support ................................... 8
1.4. Document Organization .......................................... 9
1.5. Text Conventions .............................................. 10
1.6. Related Documents ............................................. 10
2. General Product Description ...................................... 11
2.1. Overview ...................................................... 11
2.2. Product Specifications ........................................ 12
2.3. RoHS Compliance ............................................... 12
3. CE910 Module Connections ......................................... 13
3.1. Pin-Out ....................................................... 13
3.1.1. LGA Pads Layout(CE910-DUAL & CE910B-DUAL) ....................... 18
3.1.2. LGA Pads Layout(CE910-SC) ....................................... 19
4. Hardware Commands ................................................ 20
4.1. Turning on the CE910 module ................................... 20
4.1.1. Initialization and Activation State ............................. 20
4.2. Turning off the CE910 module .................................. 24
4.2.1. Turning OFF by AT Command ....................................... 24
4.2.2. Turning OFF by tying low ON_OFF* ................................ 25
4.3. Summary of Turning ON and OFF the Module ...................... 26
4.4. Hardware Unconditional Shutdown ............................... 28
5. Power Supply ..................................................... 31
5.1. Power Supply Requirements ..................................... 31
5.2. Power Consumption ............................................. 32
5.3. General Design Rules .......................................... 33
5.3.1. Electrical Design Guidelines .................................... 33
5.3.2. + 5V Input Source Power Supply Design Guidelines ................ 33
5.3.3. +12V Input Source Power Supply Design Guidelines ................ 34
5.3.4. Battery Source Power Supply Design Guidelines ................... 35

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 6 of 75
5.3.5. Thermal Design Guidelines ....................................... 35
5.3.6. Power Supply PCB layout Guidelines .............................. 36
6. Antenna .......................................................... 38
6.1. CDMA Antenna Requirements ..................................... 38
6.2. CDMA antenna –PCB line Guidelines ............................ 39
6.3. CDMA Antenna installation Guidelines ............................ 39
7. USB Port ......................................................... 41
8. Serial Port ...................................................... 42
8.1. Modem Serial Port 1 ........................................... 43
8.2. Modem Serial Port 2 ........................................... 45
8.3. RS232 Level Translation ....................................... 46
9. Audio Section Overview ........................................... 47
9.1. Analog Audio Interface(AVI) ................................... 47
9.1.1. MIC Connection .................................................. 48
9.1.2. LIN-IN Connection ............................................... 49
9.1.3. EAR Connection .................................................. 50
9.2. Digital Voice Interface(DVI) .................................. 51
9.2.1. CODEC Example ................................................... 51
10. General Purpose I/O .............................................. 52
10.1. Logic Level Specification ................................... 53
10.2. Using a GPIO Pad as Input ................................... 53
10.3. Using a GPIO Pad as Output .................................. 54
10.4. Indication of Network Service Availability .................. 54
10.5. RTC Bypass Output ........................................... 55
10.6. VAUX/PWRMON Power Output .................................... 55
11. ADC section ...................................................... 57
11.1. Description ................................................. 57
11.2. Using ADC Converter ......................................... 57
12. Test Point ....................................................... 58
13. Mounting CE910 on the Application ................................ 59

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 7 of 75
13.1. General ..................................................... 59
13.2. Module Finishing & Dimensions ............................... 59
13.3. Recommended foot print for the application .................. 60
13.4. Stencil ..................................................... 61
13.5. PCB Pad Design .............................................. 61
13.6. Recommendations for PCB Pad Dimensions (mm) ................. 61
13.7. Solder Paste ................................................ 63
13.7.1. Solder Reflow .................................................. 63
14. Packing System ................................................... 65
14.1. Moisture Sensibility ........................................ 67
15. Application Design Guide ......................................... 68
15.1. Download and Debug Port ..................................... 68
16. Conformity Assessment Issues(Problèmes d'évaluation de conformité)69
17. Safety Recommendations ........................................... 73
18. Document History ................................................. 74

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 8 of 75
1. Introduction
1.1. Scope
The aim of this document is the description of typical hardware solutions useful for developing a
product with the Telit CE910 module.
1.2. Audience
This document is intended for Telit customers who are about to implement their applications using
our CE910 modules.
1.3. Contact Information, Support
For general contact, technical support, to report documentation errors and to order manuals, contact
Telit Technical Support Center (TTSC) at:
TS-[email protected]
TS-NORTHAMERI[email protected]
TS-LATINAMERI[email protected]
TS-[email protected]
Alternatively, use:
http://www.telit.com/en/products/technical-support-center/contact.php
For detailed information about where to buy the Telit modules or for recommendations on accessories
and components visit:
http://www.telit.com
To register for product news and announcements or for product questions contact Telit Technical
Support Center (TTSC).
Our aim is to make this guide as helpful as possible. Please keep us informed of comments and
suggestions for improvements.
Telit appreciates feedback from the users of our information.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 9 of 75
1.4. Document Organization
This document contains the following chapters:
Chapter 1: “Introduction”provides a scope for this document, target audience, contact and support
information, and text conventions.
Chapter 2: “General Product Description”gives an overview of the features of the product.
Chapter 3: “CE910 Module Connections”deals with the pin out configuration and layout.
Chapter 4: “Hardware Commands” How to operate the module via hardware.
Chapter 5: “Power supply” Power supply requirements and general design rules.
Chapter 6: “Antenna” The antenna connection and board layout design are the most important parts in
the full product design.
Chapter 7: “USB Port” The USB port on the Telit CE910 is the core of the interface between the
module and OEM hardware.
Chapter 8: “Serial ports” Refers to the serial ports of the Telit CE910.
Chapter 9: “Audio Section overview” Refers to the audio blocks of the Base Band Chip of the CE910
Telit Module.
Chapter 10: “General Purpose I/O” How the general purpose I/O pads can be configured.
Chapter 11: “ADC section”Deals with this one kind of converter.
Chapter 12: “Test Point”Deals with Test Point.
Chapter 13: “Mounting CE910 on the Application” Mechanical dimensions and
recommendations on how to mount the module on the user’s board.
Chapter 14: “Packing System”Deals with packing system.
Chapter 15: “Application Design Guide”Deals with the design of host system for download or
upgrade.
Chapter 16: “Conformity Assessment Issues” provides some fundamental hints about the conformity
assessment that the final application might need.
Chapter 17: “Safety Recommendation” provides some safety recommendations that must be followed
by the customer in the design of the application that makes use of the Telit CE910.
Chapter 18: “Document History”provides document revision history of the Telit CE910.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 10 of 75
1.5. Text Conventions
Danger –This information MUST be followed or catastrophic equipment failure or bodily injury
may occur.
Caution or Warning –Alerts the user to important points about integrating the module. If these
points are not followed, the module and end user equipment may fail or malfunction.
Tip or Information –Provides advice and suggestions that may be useful when integrating the
module.
All dates are in ISO 8601 format, i.e. YYYY-MM-DD.
1.6. Related Documents
CE910 Software User Guide, 1vv0301011
CE910 AT Commands Reference Guide, 80399ST10111A
Telit EVK2 User Guide, 1vv0300704

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 11 of 75
2. General Product Description
2.1. Overview
The aim of this document is the description of typical hardware solutions useful for developing a
product with the Telit CE910 module.
In this document all the basic functions of a mobile device will be taken into account; for each one of
them a proper hardware solution will be suggested and eventually the wrong solutions and common
errors to be avoided will be evidenced. Obviously this document cannot embrace all hardware
solutions and products that may be designed. Avoiding the discussed wrong solutions must be
considered as mandatory. While the suggested hardware configurations must not be considered
mandatory, the information given must be used as a guide and a starting point for properly developing
a product with the Telit CE910 module.
NOTE:
The integration of the CDMA 1xRTT module within a user application must be done according to the
design rules described in this manual.
The information presented in this document is believed to be accurate and reliable. However, no
responsibility is assumed by Telit Communication S.p.A. for its use, such as any infringement of
patents or other rights of third parties. No license is granted by implication or otherwise under any
patent rights of Telit Communication S.p.A. other than for circuitry embodied in Telit products. This
document is subject to change without notice.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 12 of 75
2.2. Product Specifications
CE910 Specifications
Air Interface
CDMA 1xRTT
Frequency Bands
CE910-DUAL : 800/1900MHz
CE910-SC : 800MHz
CE910B-DUAL : 800/1900MHz (BC0/BC10/BC1)
Data Service
CDMA 1xRTT: 153.6 Kbps (full-duplex)
Max. RF out power
CDMA BC0: Power class 3 (24.5dBm) for 1xRTT
CDMA BC1: Power class 2 (24.5dBm) for 1xRTT
CDMA BC10 : Power class 2 (24.5dBm) for 1xRTT
Typical conducted sensitivity
CDMA BC0: –108dBm
CDMA BC1: –107dBm
CDMA BC10: -108dBm
Device dimensions
28.2mm(L) x 28.2mm(W) x 2.05mm(T)
Weight
3.7g
Storage and Operating
Temperature Range
–40 ~ +85°C
Normal operating voltage
range
3.4 ~ 4.2V
IO voltage
1.8V
Interface
144 Land-Grid-Array interface
10 general I/O ports maximum including multi-
functional I/Os
State LED output
1 A/D converter
Full RS232 CMOS UART: baud rate up to 4Mbps
Reserved two wires CMOS UART for debugging
USB 2.0: baud rate up to 12Mbps
Antenna
Primary antenna, 800/1900MHz
Audio
Analog audio interface ( 1 EAR/MIC)
Message
SMS (MO/MT)
Approvals
CE910-DUAL & CE910B-DUAL:
Regulatory: FCC, IC
Carrier: Verizon, Sprint, Aeris
CE910-SC:
Regulatory: SRRC, CCC
2.3. RoHS Compliance
As a part of Telit’s corporate policy of environmental protection, the CE910 complies with the RoHS
(Restriction of Hazardous Substances) directive of the European Union (EU directive 2002/95/EG).

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 13 of 75
3. CE910 Module Connections
3.1. Pin-Out
Pin
Signal
I/O
Function
Type
USB FS 2.0 Communication Port
B15
USB_D+
I/O
USB differential Data(+)
C15
USB_D-
I/O
USB differential Data(-)
A13
VUSB
I
Power for the internal USB transceiver
5V
Asynchronous UART –Prog. / data +HW Flow Control
N15
C103/TXD
I
Serial data input from DTE
CMOS 1.8V
M15
C104/RXD
O
Serial data output to DTE
CMOS 1.8V
M14
C108/DTR
I
Input for (DTR) from DTE
CMOS 1.8V
L14
C105/RTS
I
Input for (RTS) from DTE
CMOS 1.8V
P15
C106/CTS
O
Output for (CTS) to DTE
CMOS 1.8V
N14
C109/DCD
O
Output for (DCD) to DTE
CMOS 1.8V
P14
C107/DSR
O
Output for (DSR) to DTE
CMOS 1.8V
R14
C125/RING
O
Output for (RI) to DTE
CMOS 1.8V
Asynchronous Auxiliary UART
D15
TX_AUX
O
Auxiliary UART (TX Data to DTE)
CMOS 1.8V
E15
RX_AUX
I
Auxiliary UART (RX Data from DTE)
CMOS 1.8V
RUIM Interface(*NOTE)
A3
RUIMVCC
-
Reserved but applicable only to RUIM variant :
Power supply for the RUIM
1.8/3V
A5
RUIMIO
I/O
Reserved but applicable only to RUIM variant :
RUIM Data I/O
1.8/3V
A6
RUIMCLK
O
Reserved but applicable only to RUIM variant :
RUIM Clock
1.8/3V
A7
RUIMRST
O
Reserved but applicable only to RUIM variant :
RUIM Reset
1.8/3V
Digital Voice interface
B9
DVI_WA0
I/O
Digital Voice interface (WA0)
1.8V
B6
DVI_RX
I
Digital Voice interface (RX)
1.8V
B7
DVI_TX
O
Digital Voice interface (TX)
1.8V
B8
DVI_CLK
I/O
Digital Voice interface (CLK)
1.8V
Analog Voice Interface
B2
EAR+
AO
Earphone signal output, phase +
B3
EAR-
AO
Earphone signal output, phase -
B4
MIC+
AI
Microphone input, phase +
B5
MIC-
AI
Microphone input, phase -
Digital IO
C8
GPIO_01
I/O
GPIO_01 / STAT LED
CMOS 1.8V
C9
GPIO_02
I/O
GPIO_02
CMOS 1.8V
C10
GPIO_03
I/O
GPIO_03
CMOS 1.8V

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 14 of 75
Pin
Signal
I/O
Function
Type
C11
GPIO_04
I/O
GPIO_04
CMOS 1.8V
B14
GPIO_05
I/O
GPIO_05
CMOS 1.8V
C12
GPIO_06
I/O
GPIO_06
CMOS 1.8V
C13
GPIO_07
I/O
GPIO_07
CMOS 1.8V
K15
GPIO_08
I/O
GPIO_08
CMOS 1.8V
L15
GPIO_09
I/O
GPIO_09
CMOS 1.8V
G15
GPIO_10
I/O
GPIO_10
CMOS 1.8V
ADC Section
B1
ADC_IN1
AI
Analog to Digital converter input
A/D
RF Section
K1
Antenna
I/O
CDMA Antenna (50Ohm)
RF
Miscellaneous Functions
R13
HW_SHUTDOWN*
I
Hardware Unconditional Shutdown
Pull up to VBATT
R12
ON_OFF*
I
Input Command for Power ON
CMOS 1.8V
C14
VRTC
I
RTC Power
Power
R11
VAUX/PWRMON
O
Supply Output for external accessories / Power
ON Monitor
1.8V
Test Point
C3
TP1
Test Point
TP
C4
TP2
Test Point
TP
C5
TP3
Test Point
TP
C6
TP4
Test Point
TP
C7
TP5
Test Point
TP
D3
TP6
Test Point
TP
E3
TP7
Test Point
TP
Power Supply
M1
VBATT
-
Main Power Supply (Baseband)
Power
M2
VBATT
-
Main Power Supply (Baseband)
Power
N1
VBATT_PA
-
Main Power Supply (Radio PA)
Power
N2
VBATT_PA
-
Main Power Supply (Radio PA)
Power
P1
VBATT_PA
-
Main Power Supply (Radio PA)
Power
P2
VBATT_PA
-
Main Power Supply (Radio PA)
Power
E1
GND
-
Ground
G1
GND
-
Ground
H1
GND
-
Ground
J1
GND
-
Ground
L1
GND
-
Ground
A2
GND
-
Ground
E2
GND
-
Ground
F2
GND
-
Ground
G2
GND
-
Ground
H2
GND
-
Ground
J2
GND
-
Ground
K2
GND
-
Ground
L2
GND
-
Ground
R2
GND
-
Ground

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 15 of 75
Pin
Signal
I/O
Function
Type
M3
GND
-
Ground
N3
GND
-
Ground
P3
GND
-
Ground
R3
GND
-
Ground
D4
GND
-
Ground
M4
GND
-
Ground
N4
GND
-
Ground
P4
GND
-
Ground
R4
GND
-
Ground
N5
GND
-
Ground
P5
GND
-
Ground
R5
GND
-
Ground
N6
GND
-
Ground
P6
GND
-
Ground
R6
GND
-
Ground
P8
GND
-
Ground
R8
GND
Ground
P9
GND
-
Ground
P10
GND
-
Ground
R10
GND
-
Ground
M12
GND
-
Ground
B13
GND
-
Ground
P13
GND
-
Ground
E14
GND
-
Ground
Reserved
C1
Reserved
-
Reserved
D1
Reserved
-
Reserved
F1
Reserved
-
Reserved
C2
Reserved
-
Reserved
D2
Reserved
-
Reserved
F3
Reserved
-
Reserved
G3
Reserved
-
Reserved
H3
Reserved
-
Reserved
J3
Reserved
-
Reserved
K3
Reserved
-
Reserved
L3
Reserved
-
Reserved
A4
Reserved
-
Reserved
N7
Reserved
-
Reserved
P7
Reserved
-
Reserved
R7
Reserved
-
Reserved
A8
Reserved
-
Reserved
N8
Reserved
-
Reserved
A9
Reserved
-
Reserved
N9
Reserved
-
Reserved
R9
Reserved
-
Reserved
A10
Reserved
-
Reserved

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 16 of 75
Pin
Signal
I/O
Function
Type
B10
Reserved
-
Reserved
N10
Reserved
-
Reserved
A11
Reserved
-
Reserved
B11
Reserved
-
Reserved
N11
Reserved
-
Reserved
P11
Reserved
-
Reserved
A12
Reserved
-
Reserved
B12
Reserved
-
Reserved
D12
Reserved
-
Reserved
N12
Reserved
-
Reserved
P12
Reserved
-
Reserved
D13
Reserved
-
Reserved
E13
Reserved
-
Reserved
F13
Reserved
-
Reserved
G13
Reserved
-
Reserved
H13
Reserved
-
Reserved
J13
Reserved
-
Reserved
K13
Reserved
-
Reserved
L13
Reserved
-
Reserved
M13
Reserved
-
Reserved
N13
Reserved
-
Reserved
A14
Reserved
-
Reserved
D14
Reserved
-
Reserved
F14
Reserved
-
Reserved
G14
Reserved
-
Reserved
H14
Reserved
-
Reserved
J14
Reserved
-
Reserved
K14
Reserved
-
Reserved
F15
Reserved
-
Reserved
H15
Reserved
-
Reserved
J15
Reserved
-
Reserved
*NOTE:
RUIM interface is reserved for Verizon/Sprint/Aeris variants and it is applicable only to RUIM
variant of CE910 (CE910-SC).
WARNING:
Reserved pins must not be connected.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 17 of 75
NOTE:
The following table is listing the main Pinout differences between the CE910 variants.
Product
BC0
BC10
BC1
Notes
CE910-DUAL
Yes
No
Yes
Reserved pads: A3, A5, A6, A7
CE910-SC
Yes
No
No
CE910B-DUAL
Yes
Yes
Yes
Reserved pads: A3, A5, A6, A7
NOTE:
If not used, almost all pins not in use must be left disconnected. The only exceptions are the following
pins:
PAD
Signal
Notes
M1,M2,N1,N2,P1,P2
VBATT&VBATT_PA
E1,G1,H1,J1,L1,A2,E2,F2,G2,H2
J2,K2,L2,R2,M3,N3,P3,R3,D4
M4,N4,P4,R4,N5,P5,R5,N6,P6
R6,P8,R8,P9,P10,R10,M12,B13
P13,E14
GND
R12
ON/OFF*
R13
HW_SHUTDOWN*
B15
USB_D+
If not used it should be connected to a Test point.
C15
USB_D-
If not used it should be connected to a Test point.
A13
VUSB
If not used it should be connected to a Test point.
N15
C103/TXD
If not used it should be connected to a Test point.
M15
C104/RXD
If not used it should be connected to a Test point.
L14
C105/RTS
If the flow control is not used it should be
connected to GND.
P15
C106/CTS
If not used it should be connected to a Test point.
D15
TX_AUX
If not used it should be connected to a Test point.
E15
RX_AUX
If not used it should be connected to a Test point.
K1
Main Antenna
C3,C4,C5,C6,C7,D3,E3
Test Point

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 18 of 75
3.1.1. LGA Pads Layout(CE910-DUAL & CE910B-DUAL)
Top View
NOTE:
The pin defined as RES must be considered RESERVED and not connected on any pin in the
application. The related area on the application has to be kept empty.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 19 of 75
3.1.2. LGA Pads Layout(CE910-SC)
Top View
NOTE:
The pin defined as RES must be considered RESERVED and not connected on any pin in the
application. The related area on the application has to be kept empty.

CE910 Family Hardware User Guide
1vv0301010 Rev.11 –2015-10-27
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.
Page 20 of 75
4. Hardware Commands
4.1. Turning on the CE910 module
To turn on the CE910, the pad ON_OFF* must be tied low for at least 1.5 second and then released.
The maximum current that can be drained from the ON_OFF* pad is 0.1 mA.
A simple circuit to power on the module is illustrated below:
4.1.1. Initialization and Activation State
Upon turning on CE910 module, the CE910 module is not active yet because the boot sequence of
CE910 is still executing internally. It takes about 10 seconds to complete the initialization of the
module internally.
For this reason, it would be useless to try to access CE910 during the Initialization state as below. The
CE910 module needs at least 10 seconds after the PWRMON goes High to become operational by
reaching the activation state.
