Multitech MultiModem iSMS SF100-G Service manual

MultiModem®iSMS
Intelligent SMS Server
Models: SF100-G
SF400-G
SF800-G
Administrator’s Guide

MultiModem® iSMS Administrator’s Guide 2
MultiModem® iSMS
Administrator’s Guide
Models: SF100, SF400, SF800
Part Number S000461D
Copyright © 2012
This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-Tech Systems, Inc.
All rights reserved.
Multi-Tech Systems, Inc. makes no representations or warranty with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to
notify any person or organization of such revisions or changes.
Revision Date Description
A 08/21/09 Initial release of SF400 and 800.
B 09/02/10 Release of 1.44 version.
C 01/30/2012 Removed references to product CD.
D 08/9/2012 Updated web interface.
Trademarks
MultiModem is a trademark of Multi-Tech Systems, Inc. The Multi-Tech logo is a registered trademark of Multi-Tech Systems, Inc.
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
Phone: [phone] or 800-328-9717
Fax: [phone]
Internet Address: http://www.multitech.com
Contacting Multi-Tech Support
Online Support Portal
support.multitech.com
In order to better serve our customers, manage support requests and shorten resolution times, we have created the online web portal
allowing you to submit questions regarding Multi-Tech products directly to our technical support team. Get answers to your most
complex questions, ranging from implementation, troubleshooting, product configuration, firmware upgrades and much more.
To create an account and submit a Support Case on the Portal, visit support.multitech.com
Knowledge Base and Support Services
www.multitech.com/en_US/SUPPORT
The Knowledge Base provides immediate answers to your questions and gives you access to support resolutions for all Multi-Tech
products. Visit our support area on the website for other support services.
Technical Support
Country By Email By Phone
Europe, Middle East, Africa: [email protected] (44) 118 959 7774
U.S., Canada, all others: [email protected] [phone] or [phone]
Warranty
Warranty and repair information for your product can be found at:
http://www.multitech.com/en_US/COMPANY/Policies/warranty/

3 MultiModem® iSMS Administrator’s Guide
Contents
Chapter 1 – Product Overview and Safety Information................................................................................... 7
Safety Warnings .....................................................................................................................................................7
Ethernet Port Caution ................................................................................................................................................ 7
Handling Precautions ................................................................................................................................................. 7
Packaging Contents ................................................................................................................................................7
MultiModem iSMS Documentation.........................................................................................................................8
User Guides................................................................................................................................................................ 8
AT Commands ............................................................................................................................................................ 8
Front and Back Panels.............................................................................................................................................8
Front Panel of model SF100....................................................................................................................................... 8
Front Panel of Models SF400 and SF800.................................................................................................................... 9
Installing a SIM Card for Model SF100 ....................................................................................................................... 9
Installing a SIM Card for Models SF400 and SF800.................................................................................................. 10
Modem Numbering.................................................................................................................................................. 11
Back Panels .............................................................................................................................................................. 11
Back Panel Connectors............................................................................................................................................. 11
Panel Mounting (SF100)........................................................................................................................................... 12
Rack or Wall Mounting (SF400/800) ........................................................................................................................ 13
Technical Specifications ........................................................................................................................................14
Chapter 2 – Setting up and using the iSMS ................................................................................................... 16
Setting Up Your MultiModem iSMS....................................................................................................................... 16
SF100 Cabling........................................................................................................................................................... 17
SF400/800 Cabling ................................................................................................................................................... 18
Establishing TCP/IP Communication......................................................................................................................19
Setting a Fixed IP Address ........................................................................................................................................ 19
Obtaining and Activating a Wireless Account ........................................................................................................22
Service Provider Fees ............................................................................................................................................... 22
Directly Communicating with the Cellular Modem.................................................................................................. 22
Signal Strength ......................................................................................................................................................... 23
Using AT Commands to Check Network Registration and Roaming Status ............................................................. 23
Chapter 3 – iSMS Basics and the Setup Wizard ............................................................................................. 24
Starting the iSMS.................................................................................................................................................. 24
Open a Web Browser ............................................................................................................................................... 24
Login......................................................................................................................................................................... 24

Contents
MultiModem® iSMS Administrator’s Guide 4
Web Interface Opens ............................................................................................................................................... 24
Navigating the Windows.......................................................................................................................................25
Menus ...................................................................................................................................................................... 25
Table of Menus and Sub-Menus .............................................................................................................................. 26
Saving System Configuration Changes ................................................................................................................... 27
Save & Restart Button under Menu Bar .................................................................................................................. 27
Using the Wizard Setup to Configure the MultiModem iSMS................................................................................. 28
Opening the Wizard Setup Window......................................................................................................................... 28
Saving System Settings............................................................................................................................................. 29
Chapter 4 – Using the MultiModem iSMS Web Interface.............................................................................. 30
Administration ..................................................................................................................................................... 30
Administration > System Setup................................................................................................................................ 30
Administration > SNTP Client................................................................................................................................... 32
Administration > Administrative Access .................................................................................................................. 34
Administration > Admin Access > Allowed Networks .............................................................................................. 35
Administration > Remote Syslog.............................................................................................................................. 35
Administration > Tools ............................................................................................................................................. 36
Administration > Factory Defaults ........................................................................................................................... 37
Network Setup .....................................................................................................................................................38
Network Setup > IP Settings..................................................................................................................................... 38
Network Setup > Cellular Modem............................................................................................................................ 39
Save & Restart.......................................................................................................................................................... 41
SMS Services ........................................................................................................................................................42
SMS Services > Address Book................................................................................................................................... 42
SMS Services > Groups............................................................................................................................................. 44
SMS Services > International Number ..................................................................................................................... 45
SMS Services > Users................................................................................................................................................ 45
SMS Services > SMS Settings.................................................................................................................................... 46
SMS Services > Send SMS......................................................................................................................................... 47
SMS Services > SMS API ........................................................................................................................................... 50
SMS Services > Load Balancing ................................................................................................................................ 53
SMS Services > Inbox................................................................................................................................................ 54
SMS Services > Outbox............................................................................................................................................. 55
Triggers ................................................................................................................................................................ 56
Triggers > Authentic List........................................................................................................................................... 56
Triggers > Broadcast Triggers................................................................................................................................... 56
Triggers > Action Triggers......................................................................................................................................... 58
Triggers > Pre-Configured SMS ................................................................................................................................ 60

Contents
5 MultiModem® iSMS Administrator’s Guide
Save & Restart.......................................................................................................................................................... 60
Utilities................................................................................................................................................................. 61
Utilities > Backup...................................................................................................................................................... 61
Utilities > Firmware Upgrade ................................................................................................................................... 62
Import & Export Address Book.............................................................................................................................. 63
Import & Export Address Book > Import.................................................................................................................. 63
Import & Export Address Book > Export .................................................................................................................. 65
Statistics & Logs.................................................................................................................................................... 66
Statistics & Logs > System Information.................................................................................................................... 66
Statistics & Logs > SMS Statistics ............................................................................................................................. 67
Statistics & Logs > Load Balancing Statistics ............................................................................................................ 68
Statistics & Logs > Log Traces................................................................................................................................... 69
Chapter 5 – Using the Non-Administrative User Interface ............................................................................ 70
Web Interface Available to Non-Administrative Users........................................................................................... 70
How Non-Administrative Users Login ...................................................................................................................... 70
Chapter 6 – SMS Examples........................................................................................................................... 72
Verifying the SIM Card is Installed and Activated ..................................................................................................72
Creating a Broadcast Message for Future Use........................................................................................................74
Appendix A – Application Programming Interface (API) ............................................................................... 75
Acronyms and Definitions........................................................................................................................................ 75
SMS API................................................................................................................................................................ 76
HTTP API................................................................................................................................................................... 76
TCP API ..................................................................................................................................................................... 92
Receive SMS API ...................................................................................................................................................96
Non Polling Mode Receive SMS API......................................................................................................................... 96
HTTP Receive API – Non-Polling Mode .................................................................................................................... 97
TCP Receive API – Non-Polling Mode..................................................................................................................... 101
Polling Mode Receive SMS API............................................................................................................................... 106
Receive API – Polling Mode.................................................................................................................................... 107
Appendix B – Table of Commonly Supported Subnet Addresses................................................................. 114
Appendix C – Antennas for the MultiModem iSMS .................................................................................... 118
RF Specifications................................................................................................................................................. 118
Antenna Specifications ....................................................................................................................................... 118
GSM/EGSM Antenna Requirements/Specifications............................................................................................... 118
Antennas Available from Multi-Tech Systems, Inc................................................................................................. 118
PTCRB Requirements Note..................................................................................................................................... 118
FCC Requirements Note......................................................................................................................................... 118
Appendix D – Waste Electrical and Electronic Equipment Directive (WEEE) ................................................ 119
Waste Electrical and Electronic Equipment (WEEE) Directive ............................................................................... 119

Contents
MultiModem® iSMS Administrator’s Guide 6
Appendix E – Time Zone Abbreviations ...................................................................................................... 120
Appendix F – End User License Agreement (EULA) ..................................................................................... 122
Appendix G – Regulatory Information........................................................................................................ 125
Restriction of the Use of Hazardous Substances (RoHS)....................................................................................... 125
Information on HS/TS Substances According to Chinese Standards...................................................................... 126
47 CFR Part 15 Regulation................................................................................................................................... 127
Index ......................................................................................................................................................... 128

7 MultiModem® iSMS Administrator’s Guide
Chapter 1 – Product Overview and
Safety Information
The Multi-Tech iSMS is an intelligent Short Message Services (SMS) server that gives businesses the ability to broadcast
and receive SMS text messages. The ready-to-use solution plugs into the Ethernet network and connects to the wireless
network through an integrated quad-band GSM modem. Now anyone on the network can broadcast messages, which
allows organizations to reach clients, subscribers, members and prospects in real-time through SMS.
Safety Warnings
Ethernet Port Caution
The Ethernet port is not designed to be connected to a Public Switched Telecommunication Network (PSTN).
Handling Precautions
All devices must be handled with certain precautions to avoid damage due to the accumulation of static charge. Although
input protection circuitry has been incorporated into the devices to minimize the effect of this static build up, proper
precautions should be taken to avoid exposure to electrostatic discharge during handling and mounting.
Before servicing any part of the MultiModem iSMS system, read the instructions and cautions in this section. This
information explains how to work safely when servicing product. Observe the following safety precautions when setting
up the equipment:
●Follow all cautions, warnings, and instructions.
●Ensure that the voltages and frequency rating of the power receptacle match the electrical rating label on the
equipment.
●Never push or attach objects of any kind through openings inside the equipment. Object may touch dangerous
voltage points or short components, resulting in fire or electric shock.
Caution: Maintain a separation distance of at least 20 cm (8 inches) between the transmitter’s antenna and the body of
the user or nearby persons. The modem is not designed for, nor intended to be, used in applications within 20 cm (8
inches) of the body of the user.
Packaging Contents
The following items are included in the package for the MultiModem iSMS product.
•One MultiModem iSMS
•For model SF100, a power supply (SF100) -or-
•For models SF400 and SF800, a power cord
•RJ-45 Ethernet cable
•Cellular antenna (not included with all models)
If any item is missing or damaged, contact Multi-Tech Systems, Inc.

Chapter 1 – Product Overview and Safety Information
MultiModem® iSMS Administrator’s Guide 8
MultiModem iSMS Documentation
User Guides
All product documentation is available on the Multi-Tech website: http://www.multitech.com/man.go
AT Commands
The AT commands used to configure this product are described in a reference guide. You can find this guide, “GPRS AT
Commands Reference Guide” on the Multi-Tech website. Document part numbers include: S000463 and S000293.
Front and Back Panels
Front Panel of model SF100
Front Panel LEDs of Model SF100
LED Description
Power Lights when power is being supplied to the MultiModem iSMS.
Status When functioning normally, the LED blinks. The LED is a solid light when the unit is booting up,
saving the configuration, restarting, or updating the firmware.
LAN
10/100
Lights when a successful connection to the 100BaseT LAN is established. Off when connected at
10BaseT.
LAN
LNK / ACT
Lights when the LAN port has a valid Ethernet connection.
Blinks when it is receiving or transmitting data.
Modem TD TRANSMIT DATA. This LED blinks when the modem is transmitting data to your wireless
carrier.
RD RECEIVE DATA. This LED blinks when the modem is receiving data from your wireless
carrier.
CD CARRIER DETECT. This LED lights when the modem detects a valid carrier signal from a
wireless carrier.
TR (DATA) TERMINAL READY. This LED lights when the modem is trying to establish a
wireless connection.
LS LINK STATUS. This LED flashes once every 3 seconds when network registration is
successful. This LED is on constant if the network registration is invalid, if a network signal
is not detected or if a SIM card is not installed in the modem.
Signal Indicates the wireless signal strength. See the Signal Strength section in this chapter.
SIM Location of the SIM card.

Chapter 1 – Product Overview and Safety Information
9 MultiModem® iSMS Administrator’s Guide
Front Panel of Models SF400 and SF800
Front Panel LEDs of Models SF400 and SF800
LED Description
Power Lights when power is being supplied to the MultiModem iSMS.
Status When functioning normally, the LED blinks. The LED is a solid light when the MultiModem iSMS is
booting up, saving the configuration, restarting, or updating the firmware.
Ethernet
100
Lights when a successful connection to the 100BaseT LAN is established. Off when connected at
10BaseT.
Ethernet
LNK
Lights when the LAN port has a valid Ethernet connection.
Blinks when it is receiving or transmitting data.
Modem nTD TRANSMIT DATA. This LED blinks when the modem is transmitting data to your wireless
carrier.
RD RECEIVE DATA. This LED blinks when the modem is receiving data from your wireless
carrier.
CD CARRIER DETECT. This LED lights when the modem detects a valid carrier signal from a
wireless carrier.
LS LINK STATUS. This LED flashes once every 3 seconds when network registration is
successful. This LED is on constant if the network registration is invalid, if a network signal
is not detected or if a SIM card is not installed in the modem.
Installing a SIM Card for Model SF100
A SIM (Subscriber Identity Module) card is required in order for the MultiModem iSMS to operate on a GPRS network. To
install the SIM card:
1. Remove power from the unit.
2. Use a small screwdriver to remove the screw closest to the outside edge of the MultiModem iSMS. Then swing the
SIM slot cover up and over to the left.
3. Insert the SIM card into the SIM card slot. The following graphic shows a partial front panel illustrating the correct
SIM card orientation.
4. Swing the cover back to its original placement and replace the screw.
5. Reattach the power supply.

Chapter 1 – Product Overview and Safety Information
MultiModem® iSMS Administrator’s Guide 10
Installing a SIM Card for Models SF400 and SF800
SIM (Subscriber Identity Module) cards are required for the MultiModem iSMS to operate on a GPRS network. This
section describes how to install the SIM card.
Before You Begin
Perform the procedure that follows—removal of chassis cover—only at an ESD workstation using an antistatic wrist strap.
If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it
to a metal ground screw (lug) next to power switch of MultiModem iSMS chassis.
1. Power off the unit and unplug the power cord.
2. Do not remove protective power supply cover. Harmful voltages may be exposed if cover is removed, and can lead to
electrical shock and or death.
Electrostatic discharge (ESD) is the release of stored static electricity that can damage electrical circuitry or components.
Static electricity is often stored in your body, and discharged when you contact an object of a different potential.
3. Use a small screwdriver to remove the six (6) screws on the back of the MultiModem iSMS. The figure that follows
uses red circles to indicate the location of these screws.
4. Lift the top cover from the back of the unit and then slide towards the front to remove.
5. Insert the SIM cards into the SIM card slots on the internal wireless modems. Each modem has a graphic line
depicting the correct SIM card orientation.
6. The figure that follows uses two red boxes to indicate the location of these receptacles. Note that the SF800 model is
used in the figure.
7. To re-attach the cover, tilt the cover up and align the “teeth” with the gaps between those on the bottom of the
chassis. The illustration uses red arrows to indicate the locations to align.
8. Rotate the cover down and push it toward the rear of the unit until it is flush.
9. Insert the six (6) screws back in to the unit and tighten.

Chapter 1 – Product Overview and Safety Information
11 MultiModem® iSMS Administrator’s Guide
Modem Numbering
In the Web interface, the modem tabs correspond to internal modems and use the numbering scheme shown in the
illustration that follows. The row of LEDs shows where the front of the unit is. Disable unpopulated modems as described
in Network Setup.
Back Panels
SF100
SF400/800
Back Panel Connectors
Connector Description
GSM Antenna
Connector (s):
1 for the SF100;
1 – 4 for the SF400;
1 – 8 for the SF800
SMA (female) antenna connector for a cellular antenna.
Note: One antenna must be attached for each internal modem in order for them to be
operational.
Ethernet
(LAN for the SF100)
The LAN (SF100) / Ethernet (SF400/800) port connects the MultiModem iSMS to your
Ethernet network-connected PC.
+9V to 32VDC [SF100 only] The SF100 power source can range from 9 volts to 32VDC.
Power Receptacle [SF400/800 only] Connection for standard power cord (provided).
COMMAND [SF400/800 only] A DE9 port for direct command access to the SF400/800.
Reset The Reset button resets the unit to factory settings, which includes deleting any existing
Address Book entries, SMS User account entries and any sent or received SMS history.
This Reset is the same as performing the MultiModem iSMS Factory Defaults option found
in the Administration menu. Press and hold the Reset button until the Status LED turns
off, and then release it. Do not press this button unless you want to restore all settings.

Chapter 1 – Product Overview and Safety Information
MultiModem® iSMS Administrator’s Guide 12
Panel Mounting (SF100)
You can mount the SF100 model using screws spaced according to the measurement shown in the illustration that
follows.
Note: Use either #6 or #8 pan head screws for all four mount locations.

Chapter 1 – Product Overview and Safety Information
13 MultiModem® iSMS Administrator’s Guide
Rack or Wall Mounting (SF400/800)
The MultiModem SF400/800 units can be rack (or wall) mounted with screws using the mounting brackets.
Rack Mounting
Ensure proper installation of the unit in a closed or multi-unit enclosure by following the recommended installation as
defined by the enclosure manufacturer. Do not place the unit directly on top of other equipment or place other
equipment directly on top of the unit. If installing the unit in a closed or multi-unit enclosure, ensure adequate airflow
within the rack so that the maximum recommended ambient temperature (50° C) is not exceeded. Ensure that the unit is
properly connected to earth ground by verifying that it is reliably grounded when mounted within a rack. If a power strip
is used, ensure that the power strip provides adequate grounding of the attached apparatus.
When mounting the equipment in the rack, make sure mechanical loading is even to avoid a hazardous condition. The
rack used must safely support the combined weight of all the equipment it supports.
Ensure that the mains supply circuit is capable of handling the load of the equipment. See the power label on the
equipment for load requirements.
Ensure that only properly qualified service personnel install this equipment. Only connect like circuits - connect SELV
(Secondary Extra Low Voltage) circuits to SELV circuits and TN (Telecommunications Network) circuits to TN circuits.
Note: The ambient temperature of the rack interior must not exceed 50° Celsius.
19-Inch Rack Enclosure Mounting Procedure
Two people may need to work together to attach the MultiModem iSMS to the rail of an EIA 19-inch rack. These people
must attach the brackets to the MultiModem iSMS chassis with the screws provided, as shown in the figure above, and
then secure unit to rack rails by the brackets.
Because equipment racks vary, screws for rack-rail mounting are not provided. Follow the instructions of the rack
manufacturer and use screws that fit.
1. Position the right rack-mounting bracket on the MultiModem iSMS using the two vertical mounting screw holes.
2. Secure the bracket to the MultiModem iSMS using the two screws provided.
3. Position the left rack-mounting bracket on the MultiModem iSMS using the two vertical mounting screw holes.
4. Secure the bracket to the MultiModem iSMS using the two screws provided.
5. Remove feet (4) from the MultiModem iSMS unit.
6. Mount the MultiModem iSMS in the rack enclosure per the rack manufacture’s mounting procedure.

Chapter 1 – Product Overview and Safety Information
MultiModem® iSMS Administrator’s Guide 14
Technical Specifications
Specifications SF100 SF400/800
Hardware Interfaces Network: 1 Ethernet 10/100BaseT Network: 1 Ethernet 10/100BaseT
Console: 1 serial RS-232
Wireless Modems 1 Quad Band GSM
850/900/1800/1900 MHz
4 or 8 Quad Band GSM
850/900/1800/1900 MHz
Dimensions 6.4” w x 1.2” h x 6” d
(16.3 cm x 3.0 cm x 15.2 cm)
17.4” w x 1.75” h x 8.5” d
(44.2 cm x 4.5 cm x 21.6 cm)
Weight 1.25 lbs.
(.56 kg)
SF400: 7.75 lbs. (3.52 kg)
SF800: 8.00 lbs. (3.64 kg)
Operating
Temperature
+32o to +120o F (0oto +50oC)
Note: UL listed @ +40oC (limited by power supply)
+32o to +120o F (0oto +50oC)
Humidity 20–90% non-condensing 20–90% non-condensing
Hardware
Connectors
SIM connector: Standard 3V
Antenna: RF 50 ohm SMA (female)
Network: RJ-45 (female)
SIM connector: Standard 3V
Antenna: RF 50 ohm SMA (female)
Network: RJ-45 (female)
Console: DE9 (female)
Power* External power supply
Input: 100-240Vac, 0.5A 50-60 Hz
Output: 9VDC, 1.7A
Power consumption
Maximum consumption is 0.95A at 9V
Input 9v Typical Maximum Peak
Current (A) 0.564 0.712 1.600
Watts 5.0 6.2
Input 20v Typical Maximum Peak
Current (A) 0.276 0.330 0.700
Watts 5.5 6.6
Input 32v Typical Maximum Peak
Current (A) 0.191 0.225 0.625
Watts 6.1 7.2
Power supply – (universal input)
Input: 100-240Vac, 1.8 – 1.0 A 50/60 Hz
SF400 / SF800:
Input 120Vac Typical Maximum
Current (Amps) 0.078/0.126 0.105/0.150
Watts 9.20/15.04 12.44/17.94
Input 220Vac Typical Maximum
Current (Amps) 0.068/0.124 0.085/0.140
Watts 14.96/27.30 18.73/30.84
Certifications and
Approvals
CE Mark; R&TTE
EMC compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
EN 301 511
RSS 132, 133, 102
CE Mark; R&TTE
EMC compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
EN 301 511
RSS 132, 133, 102

Chapter 1 – Product Overview and Safety Information
15 MultiModem® iSMS Administrator’s Guide
Specifications SF100 SF400/800
Safety:
cUL 60950-1; UL 60950-1;
IEC 60950-1; AS/NZS 60950
Network compliance:
PTCRB, GCF
Safety:
cUL 60950-1; UL 60950-1;
IEC 60950-1; AS/NZS 60950
Network compliance:
PTCRB, GCF
Warranty 2 years 2 years
* Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining
product load.

MultiModem® iSMS Administrator’s Guide 16
Chapter 2 – Setting up and using the
iSMS
Setting Up Your MultiModem iSMS
New MultiModem iSMS units are preconfigured with an IP address of 192.168.2.1 and a 24 bit subnet mask
(255.255.255.000).
Before connecting your new MultiModem iSMS to your network and powering it up, identify the existing IP network
numbering scheme of the target network. If the target network already implements a 192.168.2.xxx class C network, the
unit's host IP address of 192.168.2.1 may conflict with an existing computer or device on the network. Additionally,
advanced network configurations may block IP packets not of the current scheme. For example, if the current network
configuration is 10.1.x.x/16, any IP packets not of this subnet are blocked.
If either is the case, temporarily isolate a workstation and the new MultiModem iSMS from the target network. Connect
the Ethernet interface of the workstation directly to the Ethernet interface of the MultiModem iSMS. After configuring
the MultiModem iSMS with appropriate IP network parameters (IP address, subnet mask, default gateway and DNS), you
can connect the MultiModem iSMS to the target network.
Note: Be sure to perform a "Save to Flash" before powering off the unit, if you are physically moving the unit to a new
location.
The MultiModem iSMS LAN connection is a full duplex, auto negotiating 10/100 MHz, auto polarity sensing Ethernet
interface. You can use a traditional straight through RJ-45 Ethernet cable or a cross-over RJ-45 Ethernet cable when
connecting to an Ethernet port on a hub or switch or when connecting directly to the Ethernet interface of a workstation.
The LAN connection of the MultiModem iSMS does not support POE (Power over Ethernet) or 1GHz. These features may
need to be disabled on the equipment/port that the MultiModem iSMS is connected to.
You must cable and then configure your device:
●Basic cabling and TCP/IP directions are included in this chapter.
●Chapter 3 describes basic configurations.
●Chapter 4 describes advanced configurations.

Chapter 2 – Getting Started
17 MultiModem® iSMS Administrator’s Guide
SF100 Cabling
1. Plug one end of a RJ-45 cable into the LAN port on the MultiModem iSMS and the other end into your network or
workstation interface.
2. Attach the cellular antenna.
3. Connect the provided power supply cable to the 9 volt power port on the back of the MultiModem iSMS, and plug
the other end into an AC power outlet.
About 30 seconds after you apply power, the unit’s front panel Status and LAN LEDs report normally. For more
information about the LEDs, see Chapter 1.
Antenna Notes:
●Be sure to locate this appliance where there is wireless coverage.
●The antenna must be attached for the MultiModem iSMS to operate.
●Maintain a separation distance of at least 20 cm (8 inches) between the transmitter’s antennas and the body of the
user or nearby persons. The product is not designed for, nor intended to be, used in applications within 20 cm (8
inches) of the body of the user.

Chapter 2 – Getting Started
MultiModem® iSMS Administrator’s Guide 18
SF400/800 Cabling
1. Plug one end of a RJ-45 cable into the LAN port on the MultiModem iSMS and the other end into your network or
workstation interface.
2. Attach the cellular antennas.
3. Connect the provided power supply cable to the 9 volt power port on the back of the MultiModem iSMS, and plug
the other end into an AC power outlet. The unit’s front panel Status and LAN LEDs report normally approximately 30
seconds after power is applied. Refer to Chapter 1, Front Panel LEDs.
Antenna Notes:
●Be sure to locate this appliance where there is wireless coverage.
●The antenna must be attached in order for the MultiModem iSMS to be operational.
●Maintain a separation distance of at least 20 cm (8 inches) between the transmitter’s antennas and the body of the
user or nearby persons. The product is not designed for, nor intended to be, used in applications within 20 cm (8
inches) of the body of the user.

Chapter 2 – Getting Started
19 MultiModem® iSMS Administrator’s Guide
Establishing TCP/IP Communication
Use an IP enabled workstation with an Internet browser to setup and manage the MultiModem iSMS.
Your workstation needs to be configured with a 192.168.2.xIP address and subnet mask of 255.255.255.000, to be able to
communicate with a new (or factory defaulted) MultiModem iSMS (where xis not the number 0, 1, or 255, nor any other
host number that may already be in use by another computer or device on the 192.168.2.x subnet).
Note: When configuring your workstation with a 192.168.2.x IP address (either as an alias address or as the primary fixed
address) and when the workstation is not separated by a router or firewall from the MultiModem iSMS (that is, the units
are on the same local network), the workstation does not need to be configured with a default gateway address (default
route).
This section describes how to setup a Windows XP workstation so it can communicate with the MultiModem iSMS.
Setting a Fixed IP Address
1. Make the MultiModem iSMS connections.
2. From the Start menu, select Settings then Control Panel.
3. In the control panel, double-click Network Connections. The Network Connections window opens.
4. Right click the Local Area Connection icon and select Properties from the drop down list.

Chapter 2 – Getting Started
MultiModem® iSMS Administrator’s Guide 20
5. The Local Area Connection Properties dialog box opens.
6. Select Internet Protocol (TCP/IP).
7. Click Properties. The Internet Protocol (TCP/IP) Properties dialog box opens.
