Multitech TalkAnytime TA2410 User manual

TalkAnytime
Click-to-Talk Media Server
R
Cabling Guide
Digital Models: TA2410 &
TA3010

TalkAnytime®Cabling Guide
2 Multi-Tech Systems, Inc.
Cabling Guide
TalkAnytime®Click-to-Talk Media Servers
Digital Models (T1 and E1): TA2410 and TA3010
82100220L Rev. A
Copyright
This publication may not be reproduced, in whole or in part, without prior expressed
written permission from Multi-Tech Systems, Inc. All rights reserved.
Copyright © 2006 Multi-Tech Systems, Inc.
Multi-Tech Systems, Inc. makes no representations or warranty with respect to the
contents hereof and specifically disclaims any implied warranty of merchantability or
fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves
the right to revise this publication and to make changes from time to time in the
content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or
organization of such revisions or changes. Check Multi-Tech’s web site for current
versions of our product documentation.
Revision Date Description
A 11/29/06 Initial release.
Trademarks
Multi-Tech, TalkAnytime, and the Multi-Tech logo are registered trademarks of
Multi-Tech Systems, Inc. MultiVOIP is a trademark of Multi-Tech Systems, Inc. All
other brand and product names mentioned in this publication are trademarks or
registered trademarks of their respective companies.
Patents
This Product is covered by one or more of the following U.S. Patent Numbers:
6151333, 5757801, 5682386, 5.301.274; 5.309.562; 5.355.365; 5.355.653;
5.452.289; 5.453.986. Other Patents Pending.
GENERAL CONTACT TECHNICAL SUPPORT
Country By E-mail By Phone
France support@
multitech.fr (+33) 1-64
61 09 81
India support@
multitechindia.
com
(+91) 124-
2340780
Europe,
Asia,
Africa
support@
multitech.co.uk ([phone]
Multi-Tech
Systems, Inc.
2205 Woodale Drive
Mounds View,
Minnesota
55112, USA
[phone]
[phone]
Fax: [phone]
www.multitech.com
U.S.,
Canada,
All Others
support@
multitech.com (800) 972- 2439; (763)
717-5863

TalkAnytime®Cabling Guide
Multi-Tech Systems, Inc. 3
Introduction
This guide shows you how to make the cable connections to set up your
digital TalkAnytime®unit. See the TalkAnytime User Guide included on the
TalkAnytime CD for more information. The “Quick Start Instructions” chapter shows
how to get the TalkAnytime unit up and running with a basic configuration.
Safety Warnings
Lithium Battery Caution
A lithium battery on the voice/fax channel board provides backup power for the
timekeeping capability. The battery has an estimated life expectancy of ten
years.
When the battery starts to weaken, the date and time may be incorrect. If the
battery fails, the board must be sent back to Multi-Tech Systems for battery
replacement.
Warning: There is danger of explosion if the battery is incorrectly
replaced.
Ethernet Ports Caution
Caution: The Ethernet ports and command ports are not designed to
be connected to a Public Telecommunication network.
Safety Warnings Telecom
•Use this product only with UL- and CUL-listed computers (US).
•Never install phone wiring during a lightning storm.
•Never install a phone jack in a wet location unless the jack is specifically
designed for wet locations.
•Never touch uninsulated phone wires or terminals unless the phone line has
been disconnected at the network interface.
•Use caution when installing or modifying phone lines.
•Avoid using a phone during an electrical storm; there is a risk of electrical
shock from lightning.
•Do not use a phone in the vicinity of a gas leak.
•To reduce the risk of fire, use only 26 AWG or larger telephone line cord.
•This product must be disconnected from power source and telephone
network interface when servicing.
Safety Recommendations for Rack Instructions
•Ensure proper installation of the TalkAnytime unit in a closed or multi-unit
enclosure by following the recommended installation as defined by the
enclosure manufacturer. Do not place the TalkAnytime unit directly on top
of other equipment or place other equipment directly on top of the
TalkAnytime unit.

TalkAnytime®Cabling Guide
4 Multi-Tech Systems, Inc.
Safety Recommendations for Rack Instructions (cont’d)
•If installing the TalkAnytime unit in a closed or multi-unit enclosure, ensure
adequate airflow within the rack so that the maximum recommended
ambient temperature is not exceeded.
•Ensure that the TalkAnytime unit is properly connected to earth ground via a
grounded power cord. If a power strip is used, ensure that the power strip
provides adequate grounding of the attached apparatus.
•Ensure that the mains supply circuit is capable of handling the load of the
TalkAnytime unit. See the power label on the equipment for load
requirements.
•Maximum ambient temperature for the TalkAnytime unit is 60 degrees
Celsius (140°F) at 20-90%s non-condensing relative humidity.
•This equipment should only be installed by properly qualified service personnel.
•Only connect like circuits. In other words, connect SELV (Secondary Extra
Low Voltage) circuits to SELV circuits and TN (Telecommunications
Network) circuits to TN circuits.
•To reduce the risk of shock, all access doors should be closed during
normal operation of the equipment.

TalkAnytime®Cabling Guide
Multi-Tech Systems, Inc. 5
TA-2410/3010 Package Contents
•One TalkAnytime®TA2410 or TA3010 unit
•One power cord
•One command cable (RJ45-to-DB9 connectors)
•Two rack-mount brackets and four mounting screws
•One printed Cabling Guide
•One TalkAnytime CD containing software and user documentation.
Cabling
Guide
TalkAnytime R
TalkAnytimeR

TalkAnytime®Cabling Guide
6 Multi-Tech Systems, Inc.
Quick Hookup for TA2410 & TA3010

TalkAnytime®Cabling Guide
Multi-Tech Systems, Inc. 7
Earth Ground Connection & Power-Up
Product
Ground
Screw
Grounding connectors
must be secured
permanently to
product ground screw
and earth ground screw.
Earth Ground Screw:
Connected to
Permanent Earth Ground
of Building’s
Electrical System
Ground
Wire:
Size 18AWG
or thicker
TalkAnytime
Unit
GND
Ground Connection. Ensure that the unit is securely and permanently
connected to an earth ground (GND) with a ground wire of 18 gauge (18
AWG) or thicker. The ground wire needs to be installed between the
grounding screw on the TalkAnytime chassis and a permanent earth ground.
Whether the unit is used in a rack or on a desktop, you must verify that the
earth ground connection is permanent and reliable. In order for the ground
connection to be considered permanent, the grounding wire must connect to
the earth ground of the building's electrical wiring system and the ground
connection must use a screw terminal or other reliable means of fastening.
The ground connection must not be as easily disconnected as, for example, a
power cord.
Power-Up. The TalkAnytime unit’s fan is on whenever the power cord is
connected to a power source. Turn on power to the TalkAnytime circuitry by
placing the ON/OFF switch on the back panel to the ON position. Wait for
the Boot LED to go off before proceeding. This may take a few minutes.
TalkAnytime Configuration
When the cabling connections above have been made, go to the “Quick Start
Instructions” chapter of the User Guide (on your TalkAnytime CD) for detailed
instructions about configuration.

82100220L
