Muonio UV-O User manual

INSTALLATION MANUAL
People spend 90% of their time indoors
but indoor air quality is 2-5 times worse
than outdoor air quality. Many diseases are
transmitted through poor indoor air quality
or unsterilized surface areas (viruses,
bacteria, moulds are all found indoors on
surfaces and in the air).
UVC treatment is an environmentally
friendly and chemical-free method of
sterilizing surfaces and air that does
not produce harmful byproducts during
sterilization.
MUONIO UV-O systems operate safely
on a timed or constant demand basis to
disinfect the air and all surfaces exposed
to the UV-O unit. The UV-O has a built in
motion sensor which will switch the unit
o if activated thus minimizing the risk of
injury.
The unit uses well established UVC
radiation which has been utilized
extensively in medical, food preparation
and other professions for more than 90
years to disinfect the air, surfaces and to
help mitigate the risk of contracting and
spreading an infection.
All bacteria and viruses tested to date
(including various coronaviruses) respond
to UVC disinfection.
MUONIO UV-O purication system is
particularly suitable for oce areas,
hospitality, hospitals, retail sector and
many more.
The UV-O disinfectant device is part of
a broader system range that combines
MUONIO UV-O
UVC Surface/Air Disinfectant Unit

Introduction
This manual gives a detailed understanding of how to mount, wire, set up,
and operate the Muonio UV-O device.
The Muonio UV-O can operate in combination with other MUONIO devices or
as a stand-alone unit.
For optimum system operating results, the device should be installed and
sized correctly.
ONLY use 0.5 mm2 to 1.5 mm2 wiring cable when connecting to the UVO.
Wiring external to the printed circuit board MUST be in accordance with current statutory wiring
regulations and any local regulations that apply.
The power supply must be 230 V~, 50/60 Hz, Single Phase. Attaching the Mounio UVO board to
more than one phase will cause irreparable damage.
To ensure single phase connection, we recommend that power be introduced only at the mains
input terminals and that all other power inputs be derived from suitable outputs on the board
itself.
Devices attached to the UV-O MUST be properly earthed in accordance with the manufacturer’s
specications. The method of connection to the mains electricity supply MUST facilitate the
complete electrical isolation of the entire installation.
A designated fused double pole isolation switch, with at least 3 mm (1/8”) contact separation in
both poles is required, to power the Muonio UV-O. The point of connection to the mains (Isolator)
should be readily accessible and, if possible, adjacent to the UV-O device.
This Operating Manual contains fundamental and essential advice to be followed
for the installation, operation and servicing of the Unit. It must be read without fail
before installation and use of the device by the tter, the operator and the specialist
personnel responsible for the device.
The addition of this symbol to a “Danger” or “Warning” safety label indicates that an
electrical hazard exists which will result in personal injury if the instructions are not
followed. Obey all safety messages that follow this symbol to avoid possible injury or
death.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
DANGER indicates a hazardous situation which, if not avoided, will result in death or
serious injury. IMPORTANT! Disregard will lead to permanent equipment damage!
When in operation the product will emit UV-C radiation. UV-C radiation is invisible to
humans and exposure to UVC radiation may cause serious damage to eyes and skin.
The bulb contain a small amount of mercury which can be poisonous at certain
concentrations. In case of actual or suspected damage to the bulb, immediately
ventilate and leave the room until it is ventilated;
INFORMATION indicates an explanation containing information that is useful to
know, a supplementary operating procedure, or other data. The Information symbol
is used to address practices not related to physical injury and to indicate where
WARNING INFORMATION
IMPORTANT

Introduction
UVC radiation has sanitizing properties and has many uses in commercial,
healthcare, and consumer settings. UVC has germicidal benets, depending
on the exposure dosage (based on strength, proximity and time). However,
there are serious risks to UVC exposure, so safety precautions are essential.
WARNING
The product as described herein contains components that emit UVC
light. Immediate or prolonged exposure to UVC light can result in
painful injury, such as eye injury, skin burns, premature skin aging or
skin cancer.
Do not use the product before carefully reading this manual. Always
keep this manual with the product and consult it regularly.
Avoid direct or indirect UVC lighting on eyes or skin for both humans
and animals. Avoid exposure to direct or reected UVC light.
Installation location should be selected to prevent exposure of
humans, animals and vulnerable components to the UVC light.
Place warning signs near all access panels or doors to a space
containing the Product.
INFORMATION FOR ENABLING UNIT:
Make sure the enable switch is not accessible to someone that could
potentially start the unit without being trained and/or approved to
operate the unit.

COMPLIANCE
This product must be installed by a fully qualied, competent person, registered with
a supervisory trade body. The installation must comply with the guidance, standards
and regulations applicable to the country or state where the product is being installed.
Failure to comply with the requirements of the relevant guidance, standards and
regulations could lead to injury, death or prosecution.
The UV-O is a UVC disinfection device that makes surrounding surfaces and air cleaner/healthier by signicantly
reducing the risk of surface and airborne infections.
When operated, it works towards eliminating Viruses, Bacteria & Fungi, Including SARS, Coronaviruses and mould,
by exposing the micro-organisms on surfaces and in the air to the UVC light.
The UVC light kills or inactivates any treated microbes by damaging their deoxyribonucleic acid (DNA).
The UV-O does not generate any harmful by-products such as ozone.
The UV-O is eective against all kinds of odours and harmful VOC - Volatile Organic Compounds.
The UV-O can operate by local switching or timed control.
Technical Information
MUONIO UVO
Terminals 0.5 mm2 To 1.5 mm2
Dimensions 107 X 100 X 1201mm
Mountable Bracket, Horizontal Or Vertical
Weigh 8 Kg
Fused Power Supply 230 Vac ~, 50 Hz, Single Phase
Power Supply 0.41 A
Fuse 5 Amp, Medium Burn
Wireless Frequency 2.4 Ghz With External Antenna (only for App controlled device)
Enclosure Rating Ip20
Hardware Version 1.0
Humidty/Temperature non condensing / 10 - 40 degC
Content In The Box
UV-O
Bracket
55 W Phillips UVC Lamp(s) (Not Installed)
User Manual
Ordering Information
UV-O 55 (1 X 55 W Phillips Uv-C Lamp)
UV-O 110 (2 X 55 W Phillips Uv-C Lamp)
Tested To Standard:
En 13098:2019 Measurement of Airborne Microorganisms and Microbial Compounds
TECHNICAL DATA
Technical Data
Do not operate the UV-O in the Presence of people or animals unless the correct
safety equipment / clothing is used.

LOCATING THE UNIT
This insTallaTion manual’sguidelines are for informaTion
only; They do noT provide compleTe assurance in individual
siTuaTions.
uvc has significanT germicidal benefiTs , depending on
exposure dose (based on sTrengTh, proximiTy and Time).
h owever , There are severe risks To uvc exposure , so safeTy
precauTions are essenTial.
correcTly sized uniTs should be selecTed for opTimum
disinfecTanT performances. The mounio seller or sales
agenTs are available To provide assisTance wiTh uniT selec-
Tion , locaTion decisions and oTher Technical suporT issues
if required.
These producTs musT be mounTed and insTalled correcTly.
The uniTs may operaTe as sTand alone devices or in combi-
naTion wiTh oTher muonio devices.
uvc radiaTion has saniTizing properTies and has many
uses in commercial, healThcare, and consumer seTTings.
This producT should noT be operaTed in The presence of
humans and animals.
The uniT is equipped wiTh amoTion sensor which will
prevenT The uniT from operaTing if acTivaTed.
The uniT musT noT be acTivaTed if The correcT insTallaTion
procedures have noT been followed.
insTall or locaTe This appliance only in compliance wiTh
The provided insTallaTion insTrucTions.
please read The warning and mounTing insTrucTions care-
fully before insTalling and mounTing The uniT.
ifThe mounTing and insTallaTion work is incorrecT, There
is ahigh risk of injury and damage To The uniT or oTher
objecTs.
ifThe equipmenT’sproTecTion is impaired, no righTs can
derive from The insTallaTion and procedures if The producT
is noT insTalled or used in compliance wiTh The manufac-
Turer’sinsTrucTions.
muonio recommends ThaT The producT insTallaTion is
by aprofessional insTaller, and The company cannoT be
held liable for any injury or damage caused by incorrecT
insTallaTion or assembly.
donoT use The producT before carefully reading This
manual.
always keep This manual wiTh The producT and consulT
iT regularly.
MUONIO UV-O producT conTains componenTs ThaT emiT
uvc lighT and poses no danger To healTh if operaTed
and insTalled correcTly according To These insTallaTion
insTrucTions.
failure To follow The warnings in This publicaTion and
any oTher safeTy guideline regarding The insTallaTion or
uses of uvc producTs could resulT in personal injury.
This uniT conTains high energy ulTravioleT c-band (uvc)
germicidal lamps, which can cause Temporary severe eye
and skin irriTaTion. never expose unproTecTed eyes or skin
To The uvc lighT.
immediaTe or prolonged exposure To uvc lighT can resulT
in painful injuries , such as eye injury , skin burns , premaTure
skin ageing or skin cancer.
iTis criTical To void exposure To direcT or sTrongly
reflecTed uvc lighT as iT can resulT in harmful uvc
radiaTion exposure.
donoT look direcTly or indirecTly aT The uvc lighT
when The power is on, for example, during The insTallaTion
or mainTenance acTiviTy.
The uniT should noT be adjusTed or repaired by anyone
excepT suiTably qualified service personnel.
iTis essenTial noT To bypass or Tamper wiTh The safeTy
inTerlocks.
donoT operaTe The uniT if iT is damaged.
iTis crucial ThaT The uniT is mounTed correcTly and ThaT
There is no damage To The screws or fixings.
Mounting the Unit on Hollow Walls:
ifThe uniT is To be insTalled on ahollow wall, such as
hollow bricks, wooden panels or plasTerboard, we recom-
mend conTacTing asuiTably qualified insTaller or consulT
The wall Type manufacTurer for aspecific recommendaTion
for The safesT resulTs.
place uvc warning signs near all access panels or doors
To aspace conTaining The producT.
Pre- Installation Information Eye & Skin Burn Hazard
Always isolate the AC mains supply before installing or work-
ing on any components that require 230 V~, 50 Hz supply.

General layout
GENERAL LAYOUT
551 551
MOUNTING BRACKET
UVC LAMPS
VISUAL / AUDIO
ALARM SIGNAL
EARTH CONNECTION
FIG 2

ULTRASONIC
MOTION
LUX / TIME /
SENSITIVITY
ADJUSTMENT

f asTenings are noT supplied because The opTions are Too
varied To ensure opTimal fixing sTrengTh.
please do noT insTall The uniT in locaTions where iT can be
deTrimenTally affecTed by accumulaTions of dirT, grease,
condensaTion, or oTher damaging subsTances.
donoT cover or obsTrucT The uv-o when operaTing.
ensure The appliance is earThed.
d o noT use This muonio uv-o in areas where excessive
dusT exisTs.
always disconnecT elecTrical mains supply
before working on The producT.
donoT insTall The uvc bulbs (delivered
in proTecTive packaging, inside The uniT)
unTil The uniT is securely fasTened in place,
wired and afTer all insTallaTions sTeps are
compleTe..
This producT should be mounTed safely To
solid wall or ceiling surfaces only.
solid brick or concreTe block walls musT
be drilled ( using a spiriT level as a guide
To ensure brackeT is level) and plugs wiTh
rawlplugs (noT supplied). The plug and
screw fasTenings musT be locaTed in The
solid parT of The wall, noT jusT in The
plasTer layer.
for panelled inTernal walls or ceilings, iT
is besT To locaTe in The sTudding, posiTion
The heaTer fixing brackeT accordingly.
Mounting The Unit on Walls or Ceilings
FIG 6
INSTALLATION
EXAMPLE
BRACKET FIXINGS
Choosing the correct fastening method to x the unit securely
to the selected wall or ceiling for the particular job is criti-
cally important to secure the public’s safety and protect the
FIG 3
FIG 5
FIG 4
551 551
Bracket Dimensions
WALL BRACKET
8 MM PLUGS
5 MM SCREWS
24 24
66
30
33
87
89

WALL BRACKET
Wall bracket supplied with the unit is intended to mount the unit in the horizontal or vertical position.
The bracket can support the UV-O unit being installed on the wall or ceiling.
SPACE REQUIREMENTS
24
24
66
8.00
30.00
33
551 551
INSTALLATION
Cable Entry Point 3 x M5 Screws
6 x Anchor Screws
2 Screws are required per bracket on
each arm to lock the unit in its optimal
Take note of the space requirements
on each side of the bracket for proper
FIG 7
FIG 8

INSTALLATION
Installation Procedure DIMENSIONS & CLEARANCES
FIG 9

CABLE
ENTRANCE
BRACKET
1197
1
00
6
0
1
UVC LAMPS
WARNING LED
ULTRASONIC MOTION
SENSOR WITH ADJUSTABLE
LUX, TIME & SENSITIVITY
ADJUSTER.
1. donoT use This uniT in areas during consTrucTion
or where excessive dusT/humidTy exisTs.
2. donoT mounT The uniT where The uvc lamps are
covered or obsTrucTed.
3. aTTach mounTing brackeT To ceiling or wall using
an appropriaTely sTrong fixing meThod To do The
job safely and properly.
5. The brackeT musT be mounTed securely using suiT-
able fasTeners Through aT leasT 4 of The 6 screw
holes before drilling The wire enTry hole.
6. ensure ThaT The uniT is secured To The mounTing
brackeT using four locking screws provided on each
side To fix iT aT The final selecTed angle posiTion.
7. use The mounTing brackeT To mark The mounTing
hole cenTres on The selecTed wall or ceiling,
allowing if necessary for The elecTric cables To
pass Through The cable enTry hole in The cenTre
of The brackeT.
8. wewould recommend screwed fasTenings wiTh
plugs for solid walls, direcTly To secure sTud parTi-
Tion ceiling Timber or if necessary To correcTly
sized Toggles Through drilled holes for drywall
or hollow concreTe block walls.
10. bring uniT up To mounTing brackeTs and lock inTo
posiTion wiTh four seTs of screws.
11. connecT The power supply To The uniT and check
if uniT sTarTs (wiThouT bulbs inserTed).
12. seTup The ulTrasonic moTion deTecTor (page 12)
11. inserT The uvc bulbs inTo The bulb holders and
genTly, buT firmly, roTaTe Them in Their sockeTs
unTil They lock inTo posiTion.
12. roTaTe uniT To required angle.
13. avoid direcT uvc eye and skin exposure during
iniTial TesTing / seTup, uvc proTecTive cloThing
and goggles musT be worn. ifThe angle of The
uv-o uniT musT be alTered afTer iniTial operaTion,
make sure To isolaTe The mains elecTrical power
beforehand.

TERMINAL IDENTIFICATION & DESCRIPTION
Safety Precautions/Warnings
To avoid the risk of electric shock, disconnect AC power before installation or maintenance.
FUSE
Double Pole Isolation
The uv-o device requires afused double pole isolaTed
elecTrical supply (230 ~ vac 1ph 50hz) exTernal To
The uniT, proTecTed by a5 amp fuse wiTh aconTacT
separaTion of aT leasT 3mm in boTh poles. The fused
power supply inpuT - l, n To The uniT should serve The
uv-o device only.
Control Module Connections
The conTrol board (pcb) in The muonio uv-o is
also used in oTher devices and some elemenTs are noT
required in This producT.
some conTrol board elemenTs are noT used:
• main swiTch - noT used in The uv-o uniT.
T he power supply To The uvc lamp ballasT is pre - wired
from The ballasT To The power board.
Power Supply
The cables To connecT The power supply and The
volTage free conTacTs are wired To connecTors ouTside
The uniT from The cable enTry poinT aT The Top of The
uniT. The power supply should be connecTed To n_in (
neuTral - blue) and l_in (live - brown). The e - (earTh
- green yellow) musT be connecTed To ground.
Volt free SWITCHING CONTROL
ifThe uv-o is To be operaTed by exTernal swiTching
equipmenT, Then an exTernal swiTch musT be insTalled
across The volT free Terminal connecTions. The uniT
will operaTe if The volT free Terminals make conTacT
Through The exTernal swiTch, for example aTimer or
co2sensor.
OPTIONAL SWITCH LIVE CONTROL
ifThe uniT is To be operaTed wiTh aswiTch conTrol
on The power supply Then The swiTch live and neuTral
feeds should connecT To The power supply inpuT. in
ThaT evenT iT will be necessary To connecT awire link
across The volT free inpuT Terminals for The uniT To
operaTe Through The swiTch live.
ULTRASONIC MOTION CONTROL WIRING
Pre-Wired
warning lighT
ballasT power supply
VOLT FREE
INPUT
VOLT FREE
INPUT
5 a. fuse medium burn
volT free swiTch *
power supply inpuT
donoT use
inThis model
EXTERNAL
SWITCH
OR
TIMER
N L
Earth Connection
donoT operaTe The uniT
wiThouT proper grounding
To earTh. see fig 2 for
earTh connecTion.
do noT connecT
volTage across The volT
free conTacTs or The
uniT will be damaged
link for
permanenT operaTion
Installation Wiring



ulTrasonic moTion
deTecTor
