MBN52832DK User Guide
Page 3 of 18
THE TABLE OF CONTENTS
1. INTRODUCTION.................................................................................................................................6
1.1 ACRONYMS ..........................................................................................................................................6
1.2 REFERENCES ........................................................................................................................................6
2. SETTING UP THE MBN52832DK FOR WINDOWS.......................................................................7
2.1 INTERFACE MODULE (IM)....................................................................................................................7
2.1.1 EVB power supply selection .......................................................................................................8
2.1.2 Application buttons......................................................................................................................9
2.1.3 IM-BM interface header pads......................................................................................................9
2.1.4 Programming and debug interface...............................................................................................9
2.1.5 UART interface .........................................................................................................................10
2.1.6 Power consumption measurement .............................................................................................10
2.2 BREAKAWAY MODULE (BM).............................................................................................................11
2.2.1 32KHz clock..............................................................................................................................11
2.2.2 2.4GHz antenna configuration...................................................................................................11
2.2.3 NFC antenna..............................................................................................................................12
2.2.4 Application LEDs......................................................................................................................12
2.2.5 Module IO header pads..............................................................................................................13
2.3 CONNECT AND TEST THE MBN52832DK...........................................................................................13
2.4 APPLICATION DEVELOPMENT .............................................................................................................15
2.4.1 MBN52832DK compatibility with nRF52 SDK .......................................................................15
2.4.2 Connect the MBN52832DK Evaluation Board .........................................................................16
2.4.3 Verifying USB Driver Installations...........................................................................................16
3. EVB SCHEMATIC.............................................................................................................................17
