Muratec MFX-C2280 Installation guide

Muratec America, Inc. 3301 East Plano Parkway, Suite 100, Plano, Texas 75074
For more information on Muratec products or services,
call [phone] or visit our web site at www.muratec.com
MK3243
BUSINESS-CLASS DOCUMENT SOLUTIONS
MFX-C2280/C2880/C3680
PRINT
Feature Overview
MFX-C2280
MFX-C2880
MFX-C3680

table of contents
Carbon Copy Printing ............................................. 1
Blank Page Removal .............................................. 4
Changing the ICC Profile of the MFP (PostScript Driver Only) ............... 7
Printing on Tabs ................................................. 9
Inserting Tabs into a Print Job ..................................... 11
Bluetooth™ Printing — Mobile Printing ............................... 13
Web Connection Direct Print ....................................... 19
Print from a USB Thumb Drive ..................................... 23
Multi Page Tri-fold Creation — PCL Print Driver ........................ 27
Secure Print — PCL Print Driver .................................... 31
Retrieving a Secure Print at the bizhub MFP .......................... 34
Placing a Watermark on a Print Job ................................. 36
Booklet Creation from the PCL Print Driver — Booklet Legal FS-534 ....... 38
Banner Printing via Emperon Controller .............................. 41
Access the Eco-Indicator ......................................... 45
Saving a Custom Paper Size in the Print Driver ........................ 46
Setting Up Account Track at the MFP ............................... 48
Enabling Account Track via the Print Driver ........................... 50
Using Account Track from the Print Driver (From the PC) ................. 51
Setting Up User Authentication at the MFP (Restrict Public Access) ........ 52
Enabling User Authentication via the Print Driver ....................... 54
Using User Authentication from the Print Driver (from the PC) ............. 56

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
11
Carbon Copy Printing
APPLICATION
Your customer has electronic order forms that need to be printed on multiple
color pages.
Example: The Company gets a Yellow page, shipping and receiving gets
the Pink page,and customer would get the Blue Page. This feature will allow
for this onedocument to be printed on different colored papers as to simulate
carbon copy formthey currently purchase.
HOW
Pre-requisites
You will need an electronic order form (MS Word, excel or PDF) before beginning
this job shop. Preload yellow paper, pink paper and blue paper in paper trays.
1. Open the form
tobeprinted.
2. Select File Print.

2
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
2
3. Enter print driver through
Properties tab.
4. Select the Basic tab.
5. Select the paper tray
tobe used for the first
page of your document
example White Paper
(you cannot leave the
paper tray field on Auto).
6. Select Cover tab.
7. Select Carbon Copy.
NOTE: The tray you
selected first will be
grayed out.
8. Select the Output
Order as Tray.
9. Select the Tray(s) you
would like to use to print
the carbon copies from
(i.e. Tray 2, Tray 3).
10. Select OK.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
3
11. Select OK.
12. Select OK.
SELLING POINTS
• Widely used in all companies to facilitate document workflow to easily identify
each departments’ documents.
• Provides customer with an alternative to purchasing expensive pre-printed forms.
• Allows for Print On Demand Forms reproduction when forms are changed.
Eliminates the waste of unused forms.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
4
Blank Page Removal
APPLICATION
Your customer has electronic files that need to be printed. However, they have files
withblank pages in them. The Skip Blank Page function will allow them to send
theentire file and the file will be printed without printing the blank pages.
HOW
Pre-requisite
You will need an electronic file (MS Word or PDF) with blank pages before beginning
thisjob shop.
1. Open File with
blank pages.
2. Select File Print.

5
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
5
3. Enter print driver
through Properties tab.
4. Select the Layout tab.
5. Place check mark
inSkipBlank Pages.
6. Select OK.
7. Select OK.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
6
LEGAL
VERTICAL
MARKETS
Qualifying Questions:
• Do you receive electronic files via email, FTP site, and cloud
based server or on a CD that may contain blank pages?
• Did you know that our bizhub’s have a feature to eliminate
blankpages?
Useful Tips:
• Law firms receive a large amount of electronic files that have
blank pages and this would be a very useful feature to discuss
with the firm.
• Law firms consume a large amount of paper and many firms
areconcerned about the environment and are seeking green
initiatives.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
7
Changing the ICC Profile of the MFP (PostScript Driver Only)
An ICC profile is a file that describes how a particular device reproduces color.
ICCprofiles are created for three types of devices: a display device (monitor), an input
device (a scanner or digital camera), or an output device (a printer). So, in essence,
anICC profile is a “recipe” for optimum color based on how a device is manufactured.
TheICC profiles of Konica Minolta devices can be changed to affect their color output.
APPLICATION
A company prints a lot of Powerpoint presentations and is not happy with their color
quality. The bizhub PostScript print driver has several preloaded alternate ICC profiles
available to be applied to a print job to change the quality of the color output.
Open a multi-page color document and from the File menu, select Print.
1. Select a PCL Driver for the
bizhub and print a copy.
2. Select a PostScript driver
for the same device.
3. Select Quality tab.
4. Select Quality Adjustment.
5. Click the Detail
radiobutton.
6. Select the ICC Profile
tab, look in the drop
down and select the
sRGB profile. Click OK.
NOTE: The sRGB ICC
profile is designed
tooptimize the printing
ofMSOffice files.
Depending on the
document, thecolor change could bedramatic or subtle.

8
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
7. Click OK.
8. If necessary, select Print Range, Number of Copies, etc.
9. Click OK.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
9
Printing on Tabs
It is recommended that this be done on Punched, Single Reverse or Reverse Collated,
5Print On Tabs. Otherwise tabs will have to be manually reversed before printing.
The MFP will not punch holes in a print job when tabs are inserted so the entire job
must be punched with a separate device for insertion into a binder.
The MFP will only pull tabs from the Bypass Tray and pulls from the top, so the tabs
must be ordered with Tab 1 towards the front of the MFP, Tab 2 next from the front
ofthe MFP, Tab 3 next and so on.
AT THE DEVICE
1. From the Copy screen touch Paper Settings.
2. Select the Bypass Tray.
3. Touch Change Tray Setting.
4. Select Index Paper.
5. Touch Close.
6. Load Tab Paper in the Bypass Tray with the tabs facing Out.
Multiple Sets can be printed at one time.
FROM THE COMPUTER
1. Create a blank Word document with the number of pages equaling the number
of TABS to be printed (Example: 5 tabs equals 5 blank pages).
2. Click File and Print.
3. Click on Properties and go to the Basic tab on the print driver.
4. Select the Original Size as 8½ x 11 Tab.
A Confirm Settings Change dialog box will open asking to change settings
toPaper Type = Tab and Print type = 1 Sided. Click Yes.
5. Select the Cover Mode tab on the print driver and select Per Page Settings.
6. Click on Edit List and select a List. It can be renamed if desired. The settings
will stay in the print driver until changed or deleted.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
10
7. The Default Setting is 5 Tabs in a set. If other than 5 is required,
select Tab Paper Settings and select the number of tabs in the dropdown
menu. The driver will automatically position the tabs.
8. Select Add.
9. Assign the Page 1 to the first Tab.
10. Select Print Type as Print Insert.
11. Select the Paper Tray to be the Bypass Tray.
12. Click on Tab Paper and select Use.
13. In the Text On Tab area, type the name of the Tab.
14. To change the font, orientation or color of the text, select Tab Text Details.
15. Repeat steps 8 through 14 until finished.
16. Click OK 3 times to send the print job to the MFP.
LEGAL
VERTICAL
MARKETS
Type of Document Generated:
• Legal Briefs – A legal brief isa document used tosubmit anargument
toa court. Briefsare generally written by lawyers and are intended
topersuade the court to rule inyour favor on a particular issue.
• Pleadings – Pleading is a formal written statement filed with acourt
by parties in a civil action, which states what claims anddefenses are
at issue, pleadings establish the issues to be decided by the court.
Qualifying Questions:
• Are you buying Tabs to use for legal briefs or pleadings?
• Are you using a vendor to outsource the Tabs that your firm needs
for legal briefs andpleadings?
Useful Tips:
• MFPs that can print Tabs are a big win in the legal industry.
• Law firms that argue cases in court often times use Tabs for legal briefs
and pleadings.
• Legal briefs and pleadings contain supporting evidence for a case
suchas: police reports, medical records, affidavits (i.e. sworn testimony
of witnesses), expert reports and Tabs separate the evidence into sections.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
11
Inserting Tabs into a Print Job
It is recommended that this be done on Single Reverse or Reverse Collated, 5 Print
OnTabs. Otherwise tabs will have to be manually reversed before printing.
The MFP will not punch holes in a print job when tabs are inserted so the entire job
must be punched with a separate device for insertion into a binder.
The MFP will only pull tabs from the Bypass Tray and pulls from the top, so the tabs
must be ordered with Tab 1 towards the front of the MFP, Tab 2 next from the front
ofthe MFP, Tab 3 next and so on.
AT THE DEVICE
1. From the Copy screen touch Paper Settings.
2. Select the Bypass Tray.
3. Touch Change Tray Setting.
4. Select Index Paper.
5. Touch Close.
6. Load Tab Paper in the Bypass Tray with the tabs facing Out.
Multiple Sets can be printed at one time.
FROM THE COMPUTER
1. When Tabs will be inserted as part of a multipage print job.
2. Once document is ready to print, if it is required that the first tab come
before page 1 of the document, a blank page must be inserted at the front
of the document.
3. To create a 25 page test document, open Microsoft Word and type
=rand(101,20). Go to the very front of the document and insert a blank page.
4. Click File and Print.
5. Click on Properties. On My Tab or the Layout Tab select 1 Sided.
6. Select the Cover Mode tab on the print driver and select Per Page Settings.

12
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
7. Click on Edit List and select a List. It can be renamed if desired. The settings
will stay in the print driver until changed or deleted.
8. The Default Setting is 5 Tabs in a set. If other than 5 is required,
select Tab Paper Settings and select the number of tabs in the dropdown
menu. The driver will automatically position the tabs.
9. Select Add.
10. Assign the page 1 to the first Tab. This will place the Tab after page 1 (the blank
page) so that it is before the printed pages in the document. For the remaining
Tabs, the MFP will insert the Tab After the page number specified.
11. Select Print Type as Insert Blank Sheet.
12. A dialog box will open asking to confirm settings change. Click Yes. This will
change the Paper Tray to the Bypass Tray.
13. Click on Tab Paper and select Use.
14. In the Text on Tab area, type the name of the Tab to change the font,
orientation or color of the text, select Tab Text Details.
15. Repeat steps 5 through 9 until finished. Insert subsequent tabs after pages
5,12,16 and 20. (Tabs will be pages 2,6,13,17,21 in the document).
16. Click OK 3 times to send the print job to the MFP.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
13
Bluetooth™Printing —Mobile Printing
Pre-requisites
The MFP must be equipped with the optional Bluetooth printing capabilities
(EK-605required).
Prior to the customer setting up the MFP for Bluetooth printing, an authorized
KonicaMinolta Business Solutions Service technician must enable this function
inService Mode (Service Mode ,System 2 ,Bluetooth Setting ,Effective).
APPLICATION
Customers can download files from the internet on their mobile phone and print
thefiles directly from the MFP with Bluetooth technology.
INSTRUCTIONS
Once the Bluetooth function has been enabled in Service Mode, it needs
to be enabled via Administrator Mode.
1a. Press the Utility Icon key.
2a. Touch #3 Administrator
Settings.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
14
3a Enter Password
andtouchOK.
4a. Touch #9 System
Connection.
5a. Touch #5 Cellular
Phone/PDA Setting.
6a. Touch Allow.
7a. Touch OK.
8a. Touch Close 3 times
untilyou return to the
MainScreen.

15
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
15
Now that you’ve programmed the MFP to “allow” communication
with acell phone or PDA, we have to enable Bluetooth communication
via the Administrator Mode.
1b. Press the Utility Icon key.
2b. Touch #3 Administrator
Settings.
3b. Enter Password
and touch OK.

16
bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
4b. Touch #5 Network
Settings.
5b. Touch Forward (
33
)
Arrow toadvance
tosecond screen (3/3).
6b. Touch Bluetooth Setting.
7b. Touch Enable.
8b. Touch OK.
9b. Touch Close 3 times
until you return
to Main Screen.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
17
PRINTING VIA BLUETOOTH COMMUNICATION
1c. Press Box Icon.
2c. Touch System.
3c. Touch Mobile/PDA.
4c. Select Print List.
NOTE: Prior to printing,
you can check the
selected printer settings
(Color, Paper Size and
Duplex/Combine).
5c. Pair your cellular phone
or PDA with the MFP.
Your phone should auto-
discover the MFP.
NOTE: If you need to
access a file at a later
date, you can “Save
toUser Box” instead
ofprinting the file.
NOTE: Your phone/PDA must support Bluetooth printing not just Bluetooth
technology for a headset.
NOTE: You must be within 25 feet of the MFP for your device to discover
theMFP.
6c. Enter PIN Code into your phone/PDA.

bizhub C754 Series/C554 Series/C364 Series/754 Series
Print job shops
18
7c. Continue the print/send process to the MFP for your particular device.
NOTE: If you want to send multiple files leave the MFP set on the PIN Code
screen and do not exit out.
LEGAL
VERTICAL
MARKETS
Useful Tips:
• Attorneys can download documents from a popular site such
aswww.dropbox.com where documents are held or any other
internet site and print them on the MFP.
• Attorneys who have multiple offices that they travel to can benefit
from Bluetooth Printing.
