Muskoka sheridan User manual

sheridan
Español p. 14
Français p. 8
English p. 1
MEF2885BP
REV06-08
Save these instructions | Conserver ces instructions | Guarde estas instrucciones
ELECTRIC FIREPLACE FOYER ÉLECTRIQUE CHIMENEA ELÉCTRICA

2
ASSEMBLY TIPS
Before you begin, locate the instructions and hardware. Take out all the parts and compare them to the diagrams below. Be
sure you have all the parts and can identify them. Two people are required to assemble this product. Assembly time will take
approximately 30-60 minutes.
CARE AND MAINTENANCE
1. Dust your fireplace mantel regularly with a soft non-lint producing cloth or household dusting product.
2. You can clean your fireplace insert with a gentle non-abrasive household cleaner. Make sue to dry your fireplace
immediately with a soft cloth or towel.
PARTS
A 1 BASE ZZ.2885BP.01
B 1 LEFT SIDE PANEL ZZ.2885BP.02
C 1 RIGHT SIDE PANEL ZZ.2885BP.03
D 1 LEFT FRONT PANEL ZZ.2885BP.04
E 1 RIGHT FRONT PANEL ZZ.2885BP.05
F 1 UPPER FACING PANEL ZZ.2885BP.06
G 1 TOP ZZ.2885BP.07
