Mustang MTB/Cross User manual

ATTENTION!
Please read pages 13-18 before your first ride!
Please perform the functional check on pages 19-22 before every ride!
Please observe bike card!
Your MUSTANG bicycle and this translation of these original operating instructions comply with the
safety requirements laid down in the European standard EN 14766 mountain bike and EN 15194 are
referred to as pedelecs.
OPERATING INSTRUCTIONS
www.ridemustang.com
MTB / CROSS
PEDELEC / E-BIKE

BAUTEILBESCHREIBUNG
Federgabel:
I Gabelkopf
II Standrohr
III Tauchrohr
IV Ausfallende
Rahmen:
a Oberrohr
b Unterrohr
c Sitzrohr
d Kettenstrebe
1 Sattel
2 Sattelstütze
3 Sattelstützenklemme
4 Bremse hinten
5 Bremsscheibe
6 Umwerfer
7 Zahnkranz
8 Schaltwerk
9 Kette
10 Kettenblatt
A Motor
B Akku
C Display und
Bedieneinheit
11 Tretkurbel
12 Pedal
13 Vorbau
14 Lenker
15 Bremshebel
16 Schalthebel
17 Lenkungslager
18 Bremse vorne
19 Bremsscheibe
Laufrad:
20 Schnellspanner/
Steckachse
21 Speiche
22 Felge
23 Reifen
24 Nabe
e Sitzstrebe
f Steuerrohr
g Stoßdämpfer
COMPONENTS
Suspension fork:
I Fork crown
II Stanchion tube
III Lower leg
IV Drop-out
Frame:
a Top tube
b Down tube
c Seat tube
d Chainstay
1 Saddle
2 Seat post
3 Seat post clamp
4 Rear brake
5 Rotor
6 Front derailleur
7 Cassette sprockets
8 Rear derailleur
9 Chain
10 Chainring
AMotor
BRechargeable battery
CDisplay and
control element
11 Crankset
12 Pedal
13 Stem
14 Handlebar
15 Brake lever
16 Shifter
17 Headset
18 Front brake
19 Rotor
Wheel:
20 Quick-release/
thru axle
21 Spoke
22 Rim
23 Tyre
24 Hub
e Rear stay
f Head tube
g Rear Shock
DESCRIPTION DES COMPOSANTS
Fourche suspendue :
I Té de fourche
II Plongeur
III Fourreau
IV Patte de fi xation
Cadre :
a Tube supérieure
b Tube diagonale
c Tube de selle
d Base
1 Selle
2 Tige de selle
3 Collier de serrage
de selle
4 Frein arrière
5 Disque de frein
6 Dérailleur avant
7 Jeu de pignons
8 Dérailleur arrière
9 Chaîne
A Moteur
B Batterie
C Unité de commande
et visuel
10 Plateau
11 Manivelle
12 Pédale
13 Potence
14 Cintre
15 Levier de frein
16 Manette de vitesse
17 Jeu de direction
18 Frein avant
19 Disque de frein
Roue :
20 Attache rapide/
Axes traversants
21 Rayon
22 Jante
23 Pneumatique
24 Moyeu
e Hauban
f Tube de direction
g Amortisseur
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4, 5
7
8
9
10
11
12
c
III
IV
A
B
C
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4
5
7
8
9
10
11
12
c
III
IV
g

1
SOME NOTES ON THESE ORIGINAL
OPERATING INSTRUCTIONS
The illustration shows a typical mountain bike and an E-bike/pedelec –
this type corresponds to the MUSTANG bicycle or MUSTANG pedelec
that you have just purchased. Today’s bicycles and e-bikes/pedelecs
come in a great many types that are designed for specific uses and are
equipped accordingly.
In the present operating instructions bicycles with drive support and
described as EPACs in the European standard EN 15194 are referred to
as pedelecs. For a precise description of the different EPAC types see
the chapter “Intended Use”.
In these operating instructions the term “bicycle” will always be used
in general descriptions if this refers to mountain bikes and pedelecs. If
the warnings or information relate only to pedelecs then these will be
marked with a special symbol.
Pay particular attention to the following symbols:
gThis symbol indicates an imminent risk to your life or health
unless you comply with the corresponding handling in-
structions given or take preventive measures.
a This symbol warns you of incorrect actions that could result
in damage to property and the environment.
I This symbol provides you with information about how to
handle the product or refers to a passage in the operating
instructions that deserves your special attention.
The following symbols always appear if it is necessary to bring your
attention to special points concerning pedelecs. If you have purchased
a MUSTANG pedelec then you should pay special attention to this infor-
mation and these warnings. Please note as well in all cases the general
warning information given in these operating instructions.
e
f
g
h

23
H This symbol indicates an imminent risk to your life or health
unless you comply with the corresponding handling instruc-
tions given or take preventive measures when using your
MUSTANG pedelec. Please note as well in all cases the gen-
eral warning information given in these operating instruc-
tions.
S This symbol warns you of incorrect actions that could re-
sult in damage to property and the environment when using
your MUSTANG pedelec. Please note as well in all cases
the general warning information given in these operating
instructions.
u This symbol provides you with information about how to
handle the MUSTANG pedelec or refers to a passage in the
operating instructions that deserves your special attention.
Please note as well in all cases the general warning infor-
mation given in these operating instructions.
The described possible consequences will not be repeated in these op-
erating instructions every time one of the symbols appears.
This translation of the operating instructions is not intended to help you
assemble a MUSTANG bicycle from individual components, to repair it
or to make a partly assembled bicycle ready for use.
These operating instructions are not applicable to any other than
the displayed bicycle types.
These operating instructions correspond to the requirements of the
European standards EN 14766 for mountain bikes and EN 15194 for
Cycles– Electrically power assisted cycles– EPAC bicycles and the
Machinery Directive 2006/42/EU.
Comply also with the instructions of the parts manufacturers, which you
can find on the enclosed CD.
The present operating instructions are subject to European law. If your
MUSTANG bicycle is to be delivered to countries outside Europe, sup-
plementary information has to be provided by the bicycle manufacturer
as the case may be.
Technical details in the text and illustrations of these operating instruc-
tions are subject to change.
TABLE OF CONTENTS
SOME NOTES ON THESE ORIGINAL OPERATING INSTRUCTIONS 1
TABLE OF CONTENTS 3
GENERAL SAFETY NOTES 6
INTENDED USE 9
BEFORE YOUR FIRST RIDE 13
Additional information “Before Your First Ride” with your MUSTANG Pedelec .................................................. 17
BEFORE EVERY RIDE 19
Additional information “Before Every Ride” with your MUSTANG Pedelec .........................................................22
AFTER AN ACCIDENT 23
Additional information “After an Accident” with your MUSTANG Pedelec ..........................................................26
HOW TO USE QUICK-RELEASES AND THRU AXLES 27
Quick-releases .................................................................................................................................................. 27
How to Fasten Components Securely with a Quick-Release ....................................................................................... 28
Thru Axles .........................................................................................................................................................30
Notes on How to Mount Front Wheels........................................................................................................................... 30
Notes on How to Mount Rear Wheels ...........................................................................................................................32
ADJUSTING THE MUSTANG BICYCLE TO THE RIDER 33
Setting the Saddle Height ..................................................................................................................................34
Adjusting the Height of the Handlebars .............................................................................................................36
Adjustable Stems ..............................................................................................................................................37
Stems for Threadless Systems, the Aheadset® System .....................................................................................37
Adjusting the Tilt of the Handlebars, Bar Ends and Brake Levers ...................................................................... 39
Adjusting the Brake Lever Reach....................................................................................................................... 41
Correcting the Fore-To-Aft Position and Tilt of the Saddle ................................................................................42
Adjusting Saddle Position and Tilt ................................................................................................................................. 43
Patent clamping with one bolt or two parallel bolts ........................................................................................43
Clamping with two bolts in line .....................................................................................................................44
Single bolt system ...................................................................................................................................................... 45
Ritchey “Mast Topper” ..............................................................................................................................................46
Seat post Monorail ..................................................................................................................................................... 46
CARBON – IMPORTANT INFORMATION 47
MUSTANG DIRT, FREERIDE, DOWNHILL BIKES – SPECIAL FEATURES 49
Adjusting the saddle to the correct height .................................................................................................................... 50
BRAKE SYSTEM 51
General Information on Brakes .......................................................................................................................... 51
Rim Brakes........................................................................................................................................................ 53
V-Brakes ......................................................................................................................................................................... 53
Operation and Wear ................................................................................................................................................... 53
Functional Check ....................................................................................................................................................... 53
Synchronising and Readjusting ................................................................................................................................. 54
Disc Brakes .......................................................................................................................................................55
Operation and Wear ................................................................................................................................................... 55
Hydraulic Disc Brakes .................................................................................................................................................... 56
Functional Check ....................................................................................................................................................... 56
Wear and Maintenance .............................................................................................................................................56
Mechanical Disc Brakes ................................................................................................................................................ 57
Functional Check ....................................................................................................................................................... 57
Wear and Maintenance ............................................................................................................................................. 57
a
b
c
d

45
GEARS 58
Derailleur Gears ................................................................................................................................................58
Operation and Control .................................................................................................................................. 58
Checking and Readjusting ......................................................................................................................................... 60
Adjusting the Rear Derailleur .................................................................................................................................... 61
Adjusting the Limit Stops .......................................................................................................................................... 61
Adjusting the Front Derailleur .................................................................................................................................... 62
CHAIN – CARE AND WEAR 63
WHEELS AND TYRE EQUIPMENT 64
Tyres, Inner Tubes, Rim Tape, Inflation Pressure ...............................................................................................64
Valves................................................................................................................................................................65
Rim Trueness and Spoke Tension ......................................................................................................................67
TYRE PUNCTURE 68
Wheel Removal ................................................................................................................................................. 68
Clincher and Folding Tyres ................................................................................................................................ 69
Tyre Removal .................................................................................................................................................................. 69
Tyre Mounting ................................................................................................................................................................. 70
Tubeless/UST tyres ...........................................................................................................................................72
Tyre Removal .................................................................................................................................................................. 72
Repair .............................................................................................................................................................................. 72
Tyre Mounting ................................................................................................................................................................. 72
Tubular Tyres .....................................................................................................................................................73
Tyre Removal .................................................................................................................................................................. 73
Tyre Mounting ................................................................................................................................................................. 73
Wheel Mounting ................................................................................................................................................ 75
HEADSET 76
Checking and Readjusting ................................................................................................................................. 76
Threadless Headset – Aheadset® ....................................................................................................................77
SUSPENSION 78
Glossary ............................................................................................................................................................ 78
Suspension Forks ..............................................................................................................................................79
Adjusting the Spring Rate .............................................................................................................................................. 79
Damping and Lockout .................................................................................................................................................... 81
Maintenance ................................................................................................................................................................... 82
Rear Shock ........................................................................................................................................................ 83
What to Bear in Mind when Adjusting the Seating Position .................................................................................... 83
Adjusting the Spring Rate .............................................................................................................................................. 84
Adjusting the Damping Control ...................................................................................................................................... 86
Adjusting the Travel ........................................................................................................................................................ 87
Maintenance ................................................................................................................................................................... 87
PEDELECS 89
Useful Tips for Riding a MUSTANG Pedelec ....................................................................................................... 89
Riding with Drive Assistance ......................................................................................................................................... 89
Range – Useful Information for a Long Ride ................................................................................................................. 91
Riding Without Drive Assistance ................................................................................................................................... 92
Riding a MUSTANG Speed Pedelec – Special Features ..................................................................................... 93
Useful Information for Proper Handling of the Battery ....................................................................................... 95
LIGHTING SYSTEM 98
Battery-Powered Lighting .................................................................................................................................98
THINGS YOU NEED TO KNOW ABOUT BICYCLES AND CYCLING 99
Cycling Helmets and Glasses ............................................................................................................................99
Clothing ............................................................................................................................................................. 99
Pedals and Shoes ............................................................................................................................................ 100
Accessories ..................................................................................................................................................... 101
TRANSPORTING BAGGAGE 104
TAKING CHILDREN WITH YOU 105
Child-Carrier seats .......................................................................................................................................... 105
Child Trailers ................................................................................................................................................... 105
Children’s bicycle Towing Devices / ................................................................................................................ 106
Towing Systems ..............................................................................................................................................106
TRANSPORTING YOUR MUSTANG BICYCLE 107
By Car ............................................................................................................................................................. 107
By Public Transport ......................................................................................................................................... 108
Special points concerning transport of your MUSTANG pedelec...................................................................... 109
By Car ........................................................................................................................................................................... 109
By Train / By Public Transport ..................................................................................................................................... 110
By Plane ........................................................................................................................................................................ 110
GENERAL NOTES ON CARE AND SERVICING 111
Maintenance and Servicing ............................................................................................................................. 111
Cleaning and maintaining your MUSTANG bicycle or pedelec .......................................................................... 112
SERVICE AND MAINTENANCE SCHEDULE 114
RECOMMENDED TORQUE SETTINGS FOR COMPONENTS 116
Recommended Torque Settings for Disc Brakes.............................................................................................. 117
LEGAL REQUIREMENTS FOR RIDING ON PUBLIC ROADS 118
WARRANTY AND GUARANTEE 120
A Note on Wear ............................................................................................................................................... 121
WARRANTY / GUARANTEE FOR MUSTANG MODELS 122
DISTRIBUTOR - MUSTANG 123
SERVICE SCHEDULE (TO BE STAMPED) 124
BIKE CARD 130
HANDOVER REPORT 131
Edition 1, September 2012
© No part of this publication may be reprinted, translated, copied or transmitted in any form or by any means,
electronic, mechanical, by hand or otherwise for another business purpose without prior written permission of
Zedler – Institut für Fahrradtechnik und -Sicherheit GmbH.
© Text, concept, photos and graphic design
Zedler – Institut für Fahrradtechnik und -Sicherheit GmbH
www.zedler.de

67
GENERAL SAFETY NOTES
Dear Customer,
In purchasing this MUSTANG bicycle
(a-d) you have chosen a product
of high quality and technology. Each component of your new MUSTANG
bicycle has been designed, manufactured and assembled with great
care and expertise. Your MUSTANG bicycle dealer gave the bicycle its
final assembly and adjustment to guarantee proper operation and many
enjoyable riding experiences with complete peace of mind from the very
first metres.
These operating instructions contain a wealth of information on the
proper use of your MUSTANG bicycle, its maintenance and operation
as well as interesting information on bicycle design and engineering.
Please read these instructions thoroughly. We are sure that even if you
have been cycling all your life you will find useful and detailed infor-
mation. Bicycle and pedelec technology has developed at a very rapid
pace during recent years. Therefore, before setting off on your new
MUSTANG bicycle, be sure to read at least the chapter “Before Your
FIRST Ride” first.
To have as much fun as possible during cycling, be sure to carry out the
functional check described in chapter “Before EVERY Ride” before
setting off.
Even a manual as big as an encyclopaedia could not describe every
possible combination of bicycle models and components or parts on
the market. These operating instructions therefore focus on your newly
purchased MUSTANG bicycle and standard components and provide
useful information and warnings. In addition to this, your BionX system
operating instructions give important information and warnings on han-
dling your new MUSTANG pedelec.
When doing any adjusting or servicing, be aware that the detailed in-
structions and information provided in these operating instructions only
refer to this MUSTANG mountain bike or MUSTANG pedelec.
The information included here is not applicable to any other bicycle
type. As bicycles and pedelecs come in a wide variety of designs with
frequent model changes, the routines described may require comple-
mentary information. Comply also with the instructions of the parts
manufacturers, which you can find on the enclosed CD.
Be aware that these instructions may require further explanation, de-
pending on the experience and/or skills of the person doing the work.
For some jobs you may require additional (special) tools
(e) or sup-
plementary instructions
(f) . This manual cannot teach you the skills of
a bicycle mechanic.
Before you set off, let us point out a few things that are very important to
every cyclist: Never ride without a properly adjusted helmet and without
glasses
(g) and take care to always wear suitable, bright clothing. As
a minimum you should wear straight cut trousers and shoes fitting the
pedal system. Always ride carefully on public roads and observe the
traffic rules so as not to endanger yourself or others.
This manual cannot teach you how to ride. Please be aware that cycling
is a hazardous activity that requires the rider to stay in control of his or
her MUSTANG bicycle at all times.
Like any sport, cycling involves the risk of injury and damage. Keep this
in mind. When you decide to ride a bicycle or pedelec you need to ac-
cept the risk inherent to cycling. Please note that on a bicycle you have
no protection technique around you (e.g. bodywork, ABS, airbag) like
you have in a car. Therefore, always ride carefully and do respect the
other road users. Never ride under the influence of drugs, medication,
alcohol or when you are tired. Do not ride with a second person on your
MUSTANG bicycle and never ride without having both hands on the
handlebars
(h) .
a
b
c
d
e
f
g
h

89
Observe the legal regulations concerning off-road cycling (a) (also for
pedelecs). These regulations may differ in each country. Please respect
nature when riding off-road. Only use your pedelec on signposted, well
maintained trails and hard-surface roads.
Always bear in mind that you travel rapidly and quietly when you are
riding a MUSTANG pedelec
(b) . Do not startle pedestrians or other
cyclists. Always make others aware of your presence well ahead of
time and by ringing your bell or make use of the brakes so as to avoid
accidents. Familiarize yourself with your MUSTANG pedelec. You can
fi nd further information in the chapters “Useful Tips for Riding a
MUSTANG Pedelec“ and “Riding a MUSTANG Speed Pedelec –
Special Features”.
First of all, we would like to familiarize you with your MUSTANG bicycle
or pedelec. Please unfold the cover of this manual. A MUSTANG moun-
tain bike
(c) and a MUSTANG pedelec (d) are shown as examples in
which all the necessary components are described. Leave the page
unfolded as you read so that you can easily locate the components as
they are referred to in the text.
gFor your own safety, never do work on your pedelec unless
you feel absolutely sure about it. If you are in doubt or if you
have any questions, please contact your MUSTANG bicycle
dealer.
INTENDED USE
Keep in mind that every bicycle type is built for a specifi c intended use
(e-g) . Be sure to use your MUSTANG bicycle only according to its in-
tended use, as it may otherwise not withstand the stress and would fail
and cause an accident with unforeseeable consequences!
1. Cross bikes are equipped with 28”-wheels (inner diameter 622
mm) and intended for hard-surface roads. They are also suitable
for off-road cycling on gravel fi eld tracks, however, not for rough
terrain.
2. Cross-country, marathon and touring mountain bikes are also
suitable for off-road use, but not for extreme terrain, jumps, drops
and competitive use in the categories freeride, dual slalom, down-
hill-races, etc.
3. Enduro and all-mountain bikes are suitable for off-road use (Al-
pcross etc.); they are, however, not designed for dual, dirt, downhill
and freeride cycling etc.
4. Dirt/fourcross, urban and dual slalom bikes are intended for
hard use on secured terrain. There are different types which are
either equipped for trick and show cycling, for jumps and freestyle
in special obstacle courses or for races.
5. Downhill bikes are designed for high level downhill races.
6. Freeride bikes are suitable for jumps and drops in most challeng-
ing terrains and in bicycle parks.
gBe sure to use your bicycle only for its intended purpose,
as it may otherwise not withstand the stress and fail! Risk
of accident!
gFor your own safety, do not overestimate your cycling skills.
Please note that though looking easy the tricks of a profes-
sional are hazardous to your life and limb. Always protect
yourself with suitable clothing
(h) .
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4, 5
7
8
9
10
11
12
c
III
IV
A
B
C
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4
5
7
8
9
10
11
12
c
III
IV
g
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4, 5
7
8
9
10
11
12
c
III
IV
A
B
C
13
14
15
16
17
18
19
20
21
22
23
24
a
b
d
e
f
I
II
1
2
3
6
4
5
7
8
9
10
11
12
c
III
IV
g
a
b
c
d
e
f
g
h

10 11
7. Pedelecs (Pedal Electric Cycles) (a) or EPACs (Electrically Power
Assisted Cycles) are bicycles with an auxiliary motor that only
switches on when the pedals are moved by the rider. When you
stop pedalling, the motor switches off.
A driving licence is not required for riding a pedelec
(b) if the mo-
tor assistance switches off automatically at a speed of 25 kmh/15
mph. You do not need an operating licence and need not insure the
pedelec either. Please do not confuse your pedelec with a speed
pedelec (S-Pedelec) (see item 9).
All regulations that apply to bicycles, also apply to pedelecs, i.e.
they are allowed to or must use cycle paths without any restric-
tions. Wearing a helmet is recommended, but not compulsory.
Most pedelecs are designed for cycling exclusively on lanes and
roads with a smooth surface
(c) . Only use trails that are allowed for
bicycles. In general, typical pedelecs are not suitable for off-road
use. Using pedelecs off-road can result in crashes with unforesee-
able consequences.
If your pedelec does not look like a typical mountain bike (see the
cover), then please read the chapter “Before Your First Ride”.
U Please note that there are different types of pedelecs and
e-bikes which are subject to different overall legal condi-
tions. Check the class of your MUSTANG pedelec or e-bike
in the bicycle card. Keep the specific regulations for your
pedelec/e-bike class in mind when riding on public roads
and also through the countryside.
8. Pedelecs
(d+e) (Pedal Electric Cycles) as well as EPACs (Elec-
trically Power Assisted Cycles) with starting or pushing aid are
considered as motor vehicles with special authorization. Neverthe-
less, you do not need an operating licence and need not insure the
pedelec either. Wearing a cycle helmet is not compulsory either,
but highly recommended.
The starting or pushing aid provides assistance during pushing or
when doing a hill start, even without pedalling, up to a speed of 6
kmh / 3.7 mph.
These MUSTANG pedelecs are not required to be insured for riding
on public roads.
U If you were born after 1st April 1965 you will require a
moped driving licence (driving licence class M) or a driving
licence for motor vehicles according to the German Bicycle
Association (ZIV).
U The laws and regulations concerning pedelecs, speed
pedelecs and e-bikes are currently being revised. Read the
daily press to keep yourself informed about current legisla-
tive changes.
The other regulations do not differ from those relating to pedelecs
(see item 7.).
9. Speed pedelecs are bicycles with an auxiliary motor which pro-
vide assistance to the rider even beyond a speed of 25 kmh / 15
mph, as long as you continue pedalling. Without pedalling a speed
pedelec provides assistance to a maximum speed of 20 kmh/12
mph.
Speed pedelecs are regarded as motor vehicles, have an operat-
ing licence or EU type approval, and are therefore subject to strict
guidelines regarding the replacement of components or making
any conversions.
It is mandatory to wear a helmet
(f) in Germany and Switzerland.
If you are riding a speed pedelec you may not use cycle paths
within built-up areas in Germany. The only exception to this is in
cases where the cycle path or lane has been approved for use
by mopeds (this is marked by an additional sign). Outside built-up
areas it is permissible to ride a speed pedelec on cycle paths and
lanes
(g+h) .
These speed pedelecs are required to have an operating licence
and to be insured as motor vehicle when riding on public roads. If
you were born after 1st April 1965 you will require a moped license
(driving license class M) or a driving license for motor vehicles. You
can obtain a moped license if you are aged 15 or over. Enquire at
your driving license agency.
a
b
c
d
e
f
g
h

12 13
In Switzerland you may ride your speed pedelec on paths and
tracks where mopeds are not allowed if you ride without drive as-
sistance to maximum 20 km/h (12 mph), with drive assistance to
maximum 25 km/h (15 mph) or with the motor switched off com-
pletely.
Be sure to also read the chapter “Riding a MUSTANG Speed Pedelec
– Special Features”.
Most of the speed pedelecs
(a) are designed for cycling exclusively on
lanes and roads with a smooth surface. Only use trails that are allowed
for speed pedelecs / e-bikes. Typical speed pedelecs are generally not
suitable for off-road use. Using speed pedelecs off-road can result in
crashes with unforeseeable consequences.
I Comply also with the instructions of the parts manufactur-
ers, which you can find on the enclosed CD.
U For more information about the intended use of your
MUSTANG pedelec as well as the permitted overall weight
(rider, pedelec and baggage) see the BionX system operat-
ing instructions and the bicycle card
(b) and read the chap-
ter “Before Your First Ride”.
U For more information on approval for the use of trailers and
child-carrier seats on your MUSTANG pedelec please refer
to the BionX system operating instructions and the bicycle
card.
BEFORE YOUR FIRST RIDE
1. Your MUSTANG bicycle is designed for a maximum overall weight, including rider, baggage and MUSTANG bicycle
all together. The maximum overall weight is specified in the following table and in the bicycle card enclosed with
these operating instructions; if it is not, then contact your MUSTANG bicycle dealer.
Model name Frame Vehicle Rider’s Total Weight Child-carrier Trailer
weight weight weight guaranteed seat allowed allowed
MU Trackster HT Alloy 12-16 75 87-91 130 no no
130 131
BIKE CARD
(Hint to the dea ler: Please copy the bike card and the handover report
and keep one copy in your customer file. S end another copy to the
manufacturer.)
HANDOVER REPORT
Manufacturer
Model
Bike-ID
Frame no.
Rear shock - Manufacturer/Model
Suspension fork - Manufacturer/Model
- Serial no
Frame type
Frame size
Size of wheels and tyres
Colour
Special features
Permissible overall load
(bicycle, rider and baggage) __ __ kg
Pannier rack £ yes £ no
Permissible load ___ _ kg
Child carrier allowed £ yes £ no
Trailer allowed £ yes £ no
Permissible trailer load ____ kg
£ Lighting
£ Brakes rear and front
£ Suspension fork, rear shock (adjus ted to suit customer)
£ Wheels (trueness/sp oke tension/tyre pressure)
£ Handlebars/stem (p osition/bolts checked with
torque wrench)
£ Pedals (adjustment of release force, if neces sary)
£ Saddle/seat post (height a nd position of saddle
adjusted to suit customer, bolts checked with
torque wrench)
£ Gears (limit stops!)
£ Accessory fas tenings (check with torque wrench)
£ Other routines perfo rmed
£ Test ride
Dealer stamp
and signature
gBrake levers
Brakes assignment
Right lever
£ f ront wheel brake
£ rea r wheel brake
Left lever
£ f ront wheel brake
£ rea r wheel brake
£ Manual/operating instruction s
Additional instructions:
£ Brake system
£ Suspension seat post
£ Pedal system
£ Rear shock
£ Suspension fork
£ S eat post, stem
£ Gear system
£ S ystem operating instructions BionX
£ O thers
Dealer na me ____________________________
S treet ___________________________
Town ____________________________
The customer confirms with his signature that he has received the bicycle in proper order along with the accompany-
ing documents specified below and that he has bee n instructed on the proper use of the bicycle.
The above-described bicycle was delivered to the customer ready for use, i. e. after completion of assembly, inspec-
tion, and operational checks as described bel ow (additionally required routines in parentheses):
Delivery date, dealer stamp and signature
Customer name ____________________________
fi rst name _________________________
S treet ___________________________
Z IP code/town _____________________
Ph one ___________________________
F ax _____________________________
E- mail ___________________________
D elivery date and signature
Ph one ___________________________
F ax _____________________________
E- mail ___________________________
a
b
c
d

14 15
2. If you want to use your pedelec on public roads, it has to comply
with the respective legal requirements. These requirements may
vary in each country. The fittings of your bicycle are, therefore,
not necessarily complete. Ask your MUSTANG bicycle dealer con-
cerning the laws and regulations applicable in your country or in
the country you intend to use your MUSTANG bicycle. Have your
MUSTANG bicycle equipped accordingly before using it on public
roads.
iWe very strongly recommend you to take out private liability
insurance. Ensure that your insurance covers you for dam-
age caused while riding the bicycle or pedelec. Contact an
insurance company or broker.
3. Are you familiar with the brake system
(a) ? Have a look at the
bicycle card and check whether the brake lever
(b) of the front
brake is on the side you are used to (right or left). If it is not, ask
your MUSTANG bicycle dealer to switch the brake levers before you
set off for the first time.
Your new MUSTANG bicycle is equipped with modern brakes
(c)
which may be far more powerful than those that you were used to
before. Be sure to first practise using the brakes on a level, non-slip
surface off public roads!
You can find further information in the chapter “Brake System”
and in the instructions from the parts manufacturers, which you
can find on the enclosed CD.
4. Are you familiar with the type and functioning of the gears
(d) ? Ask
your MUSTANG bicycle dealer to explain you the gear system and
make yourself familiar with your new gears in an area free of traffic,
if necessary.
You can find further information in the chapter “Gears” and in the
instructions from the parts manufacturers, which you can find on
the enclosed CD.
5. Are both the saddle and handlebars properly adjusted? The sad-
dle should be set to a height from which you can just reach the
pedal in its lowest position with your heel
(e) . Check whether your
toes reach to the floor when you are sitting on the saddle. Your
MUSTANG bicycle dealer will be pleased to help you if you are not
happy with your seating position.
For more information see the chapter “Adjusting the MUSTANG
Bicycle to the Rider”.
6. If your MUSTANG bicycle is equipped with clipless or step-in ped-
als
(f) : Have you ever tried the shoes they go with? Do not set off
until you have practised engaging and disengaging the shoes from
the pedals when stationary. Ask your MUSTANG bicycle dealer to
explain the pedals to you.
You can find further information in the chapter “Pedals and
Shoes” and in the instructions from the parts manufacturers,
which you can find on the enclosed CD.
7. If you have bought a MUSTANG bicycle with suspension, you
should ask your MUSTANG bicycle dealer to adjust the suspen-
sion mechanism to your needs before delivery. Improperly adjusted
suspension components are liable to malfunction or damage. In
any case they will impair the performance of your bicycle as well as
your safety and pleasure whilst cycling.
You can find further information in the chapters “Suspension
Forks”
(g) and “Rear Shock” (h) and in the instructions from the
parts manufacturers, which you can find on the enclosed CD.
G Be aware that the distance you need to stop your bicycle
increases if you are riding with your hands on the bar ends.
The brake levers are not always within easy reach.
a
b
c
d
e
f
g
h
