Mutable Instruments Kinks User manual

Installation
Kinks requires a
-12V / + 12V power supply
(2x5 pin connector).
The ribbon cable connector
must be aligned so that the
red stripe of the ribbon cable
(-12V) is on the same side of
the module’s power header as
the “Red stripe” marking on
the board. The module draws
25mA from both the +12V and
-12V supply rails.
Kinks happily accepts both
audio and CV signals.
Online manual and help
The full manual can be found
online at:
mutable-instruments.net/mod-
ules/kinks/manual
For help and discussions, head to:
mutable-instruments.net/forum
Kinks
Mingling and
mangling
Please refer to the online manual
for detailed information regarding
compliance with EMC directives

Rectifier and inverter
1. Signal input.
2. Inverted output.
3. Half-wave rectified output.
The negative half of the signal
is clipped to 0V.
4. Full-wave rectified output.
The negative half of the signal
is inverted.
Analog logic
1, 2. Signal inputs.
3. Analog OR (maximum,
peaks) output.
1 2
3 4
1 2
3 4
4. Analog AND (minimum,
troughs) output.
Try this with envelopes or
LFOs, or to create new wave-
shapes from VCO outputs.
Sample&hold and
white noise
1. Signal input, normalized to
the white noise generator.
2. Trigger input. Requires a
signal with sharp rising edges
(clock/gate/trigger generator,
square LFO or VCO).
3. Noise generator output.
4. Sample and hold output.
1 2
3 4
MAX
Input signals
MIN
