Mirror Installation Instructions
Honda Goldwing GL 1500, 1988-2000
THE safety accessory of the 21st Century.
™
P/N 210-0049-0 Rev E (10/5/07), BTV © 2003 Muth Mirror Systems, LLC.
®
INCLUDED ITEMS:
1 left and 1 right Signal®mirror and housing
1 left and 1 right wire harness
1 instruction manual
1 piece of heat shrink
2 black connectors
REQUIRED TOOLS:
Medium Philips screwdriver
Needle nose pliers
Electric drill
¼” drill bit
Masking tape
Multimeter
Sturdy gloves
Safety glasses or goggles
PROBLEMS OR QUESTIONS?
Technical Assistance is available by calling
Muth Mirror Systems Technicians at:
1-800-844-6616
Monday through Friday
Between 8:00 a.m. and 5:00 p.m. CST
Or through the Muth web site:
www.muthco.com
Please read instructions prior to installation.
ProfessionalInstallationRecommended:
Warrantydoesnotcoverdamagetothevehicleormirrorhousingduetoimproperinstallation.Muth
MirrorSystems,LLC(MMS)assumesnoresponsibilitywithregardtotheaccuracyofthisinformation.
MMSassumesnoliabilityorresponsibilityresultingfromimproperinstallation,eveninreliance
uponthisinformation.Properinstallationistheresponsibilityoftheinstaller.Itisyour
responsibilitytoverifyanycircuitbeforeinterfacingwithitusingadigitalmultimeter.
M
irror Housing Removal
Start on either the left or right side mirror. These
instructions start with the right side mirror. Pull
back the rubber boot covering the mirror mount.
1
2 3
Remove the accessory compartment cover. Remove
the four screws on all sides of the accessory
compartment. Remove the accessory compartment
from the motorcycle fairing and set it aside.
4
The motorcycle’s electrical wiring for turn
indicators is located forward of the accessory
compartment cavity and behind the front amber turn
indicator light. Disconnect the wire connected to
the turn indicator light.
5
There are three screws holding the mirror housing to the mirror mount. Remove the three screws. Set the mirror
housing aside.
M
irror Replacement
- 2 -
Remove the three screws holding the hinge to the
mirror housing. Remove the hinge and remove the
rubber boot surrounding the mirror housing.
1
Match the base of the hinge up to the new Signal®
mirror housing. Mark the place on the hinge where
the Signal®mirror wire will go through. Drill a ¼”
hole in the hinge.
2
Position the rubber boot over the Signal®mirror
housing.
3
Guide the Signal®mirror wire harness through the drilled hole in the hinge.
Mount the hinge on the Signal®mirror housing using the original three screws.
NOTE: Make sure the hinge is securely fastened AND properly aligned to
the housing or mirror vibration will occur! Do not over tighten or holes may
strip!
4 Shorter screw
Longer screws
Wiring and Wire Identification
Route wire from Signal®mirror harnessInstall plug and play harness. Male pins are already installed on harness from Signal®
mirror.
21 3
Route wire from Signal®mirror harness continued… Reinstall Signal®mirror onto motorcycle Reinstall Signal®mirror onto motorcycle continued…
54 6
6 16
- 3 -
Insert pins into female connector. NOTE: Insert pin from the black wire into hole #1. Put the pin from black with
red stripe into hole #2. Tuck wiring into fairing. Replace accessory
compartment cover, rubber boot, etc. Repeat steps for
the other Signal® mirror.
Plug mirror into motorcycle harness. Turn ignition on,
test the Signal® mirror for functionality.
7
8
9
Wiring and Wire Identification Continue
*
WARNING:
INCORRECT WIRING WIL
LCAUSE
SIGNAL
® MIRROR NOT TO FUNC
TION
*
