MUTOH Rockhopper II Series User manual

Multi-Purpose Eco-Solvent Production Printer
Rockhopper II
Rev. 1.0 AP-75095
User's Guide
Read This Manual Before Using The
Equipment.
Rockhopper II

INSTALLATION
MANUAL
Multi-Purpose Eco-Solvent Production Printer
Rockhopper II
Installation Manual included in the
User's Guide

Rockhopper II - INSTALLATION MANUAL
2
TABLE OF CONTENTS
1Introduction･･････････････････････････････････････････････････ 3
1.1 Purpose of this manual･･･････････････････････････････････････････････3
1.2 Safety instruction････････････････････････････････････････････････････3
2Unpacking･･･････････････････････････････････････････････････ 4
2.1 Unpacking procedure ････････････････････････････････････････････････4
2.1.1 Unpacking packaging box of the main unit ･･･････････････････････････････････4
2.1.2 Unpacking stand packaging box ････････････････････････････････････････････5
2.2 Verification of packaged items ････････････････････････････････････････5
2.2.1 Packaging box of the main unit ･････････････････････････････････････････････5
2.2.2 Accessories box･･････････････････････････････････････････････････････････6
2.2.3 Stand packaging box･･････････････････････････････････････････････････････6
3Assembly ･･･････････････････････････････････････････････････ 7
3.1 Assembling the stand ････････････････････････････････････････････････7
3.2 Installing the stand ･･････････････････････････････････････････････････7
3.3 Installing accessories ････････････････････････････････････････････････8
3.3.1 Installing the scroller receiver･･･････････････････････････････････････････････8
3.3.2 Installing the waste fluid tank･･･････････････････････････････････････････････9
3.4 Removal of protective packaging material ･････････････････････････････11
3.5 Installation of optional product ･･･････････････････････････････････････12
4Installation ･････････････････････････････････････････････････ 13
4.1 Choosing a place for the printer ･･････････････････････････････････････13
4.1.1 Installation environment Requirements ･････････････････････････････････････13
4.1.2 Required space ･････････････････････････････････････････････････････････14
4.2 Installing the printer･････････････････････････････････････････････････15

Rockhopper II - INSTALLATION MANUAL
3
1 Introduction
1.1Purpose of this manual
This manual explains the unpacking, assembly and installation operation procedures of the
Multi-Purpose Eco-Solvent Production Printer (Rockhopper II) made by MUTOH EUROPE N.V..
This manual is prepared for unpacking, assembly and installation of this printer.
Before unpacking, assembly and installation of the printer, first understand the contents and
directions in this manual.
CAUTION

No part of this product or manual may be reproduced, copied, or transmitted in any form or by
any means,except for personal use, without the permission of MUTOH EUROPE N.V..

The product and the contents of this manual may be changed without prior notification.
 MUTOH EUROPE N.V..has made the besteffortstokeep thispublication free from error,
but if you find any uncertainties or misprints, please call us or call the shop where you bought
this product.
 MUTOH EUROPE N.V..shallnot be liable forany damages or troubles resulting from the
use of this products or this manual.
1.2Safety instruction
Safety terms in this manual are categorized into the following three types depending on the
degree of the risk (or the scale of accident).
Read the following explanations carefully, and follow the instructions in this manual.
Safety terms Details
WARNING
Must be followed carefully to avoid death or serious bodily injury.
CAUTION
Must be observed to avoid bodily injury (moderately or lightly) or damage to your
product.
NOTE
NOTE
Contains important information and useful tips on the operation of your product.

Rockhopper II - INSTALLATION MANUAL
4
2 Unpacking
The unpacking procedure and contents of the package are described below.
2.1Unpacking procedure
The unpacking procedure is described below.
The product is sent to the user with 2 packages, 1 for the main unit and the other for the
stand.
CAUTION

When unpacking this product, always work with 4 people or more.

When removing this product from the packaging box, always remove the vinyl plastic, and
hold on the side of the product. Holding the unit over the vinyl plastic wrapping can result in
slippage and dropping the unit, resulting in damage.
2.1.1Unpacking packaging box of the main unit
Unpack the package of the main unit according to the following procedure.
1. Move the packaging of the main unit to the location to unpack.
2. Remove the restraining bands.
3. Remove the top board, and take out the
packaging material (right upper side and
left upper side) and the scroller.
No. Name
1 Top board
2 Packaging material (right upper side)
3 Packaging material (left upper side)
4 Scroller
4. Remove the outer boards, and take out the
accessories box, and the packaging box of
the waste fluid tank.
No. Name
1 Outer board
2 Accessories box
3 Packaging box of the waste fluid tank
4
3
1
2
231

Rockhopper II - INSTALLATION MANUAL
5
2.1.2Unpacking stand packaging box
Unpack the package of the stand according to the following procedure.
1. Move the packaging of the stand to the location to unpack.
2. Open the package, and take out the foot,
stay, and the four packaging materials.
No. Name
1 Stay
2 Foot
3 Packaging material
2.2Verification of packaged items
After unpacking the packaging box, inspect to make sure that the unit is not damaged, and
that all necessary parts are present.
NOTE
NOTE
 The contents of the packages may be different depending on the market where they are used.
Contact the nearest MUTOH local dealer for details.
 If any part is missing or broken, contact either of the following:

The shop where you bought your MUTOH printer.

Nearest MUTOH local dealer.
2.2.1Packaging box of the main unit
No. Name Q’ty No. Name Q’ty
1 Main unit 1 set 3 Waste fluid tank 1 set
2 Scroller 1 4 Accessories box 1 set
3
1
3
2
12
3

Rockhopper II - INSTALLATION MANUAL
6
2.2.2Accessories box
No. Name Q’ty No. Name Q’ty
1 Scroller receiver (left side) 1 11 Cable clamp 3
2 Scroller receiver (right side) 1 12 Screw driver 1
3 Power cable 1 13
4 14 User's Guide 1
5 Tube clamp 2 15 Quick Start Manual 1
6 Foot switch 1 16 Network board Operation manual*1
7 Cleaning cloth for the cleaning wiper 1 set 17 Media Holder (left) 1
8 Hexagon socket head cap screw (M6 x 30) 8 18 Media Holder (right) 1
9 Hexagon socket head cap screw (M6x 16) 8 19 Installation sheets
10 Assembly tool (Hexagon wrench:
diagonal diameter 5mm)
1
2.2.3Stand packaging box
No. Name Q’ty No. Name Q’ty
1 Stay 1 set 2 Foot 2
1
3
2
45
67
89
10
11 12
13
14 16
15
17
18 19
12
2
* = included in User's Guide

Rockhopper II - INSTALLATION MANUAL
7
3 Assembly
The assembly of this product is described below.
CAUTION

When assembling this product, always work with 4 people or more.
3.1Assembling the stand
Assemble the stand according to the following procedure.
1. Place the stand upside down as shown in
the figure.
2. Install the foot to the stay according to the
following procedure.
a) Attach two feet on the bottom of the stay
as shown.
b) Attach the hexagon socket head cap
screws (M6 x 30: each 4) to each foot.
c) Using the assembly tool, tighten the
hexagon socket head cap screws to install
the feet.
No. Name
1 Stay
2 Foot
3 Hexagon socket head cap screw (M6 x 30)
3. Assembling the stand is completed.
3.2Installing the stand
Install the stand to the main unit according to the following procedure.
1. Place the stand with its feet on the floor.
2. With at least four persons, lift up the main
unit by holding it by the handles.
3. Place the main unit on the stand.
No. Name
1 Stand
2 Main unit
3 Handle
3
2
1
narrow wide
narrow
wide
1
2
3

Rockhopper II - INSTALLATION MANUAL
8
4. Attach the hexagon socket head cap screws
(M6 x 16: 8) to the stand.
5. Using the assembly tool, tighten the hexagon
socket head cap screws to install the stand.
No. Name
1 Hexagon socket head cap screw (M6 x 16)
2 Stand
3 Main unit
6. Installing the stand is completed.
3.3Installing accessories
Installing procedure of the accessories is described below.
The accessories include scroller receivers and a waste fluid tank.
NOTE
NOTE
 When installing the accessories, always work from the back of the main unit.
3.3.1Installing the scroller receiver
Install the scroller receiver according to the following procedure.
1. Remove the handles from the main unit
according to the following procedure.
a) Using the assembly tool, loosen the eight
hexagon socket head cap screws.
b) Remove the following parts:

Handles (2)

Hexagon socket head cap screws (M6 x 16: 8)
No. Name
1 Handle
2 Hexagon socket head cap screw (M6 x 16)
3 Main unit
1
2
3
1
1
2
3
1
